Nikon SB-28 Manuel utilisateur

Photographic Accessories

Autofocus Speedlight

SB-28 • 28DX

www.nikon-image.com/eng/

The ultimate in

flash photography

■3D Multi-Sensor Balanced Fill-Flash with

Monitor Pre-flashes (with F5, F100, F90X, F80

or F70 and D-/G-type AF Nikkor)

■Multi-Sensor Balanced Fill-Flash with Monitor

Pre-flashes (with F5, F100, F90X, F80 or F70

and CPU lens* except D-/G-type AF Nikkor

and IX-Nikkor)

■Matrix Balanced Fill-Flash (with F4 series, F65,

F60 or PRONEA 600i and CPU lens**)

■Slow Sync (with F5, F100, F90X, F80, F70, F65,

F60, F55, PRONEA 600i, D1 series or D100)

■Red-Eye Reduction (with F100, F90X, F80, F70,

F65, PRONEA 600i, D1 series or D100)

■FP High-Speed Sync (with F5, F100, F90X,

D1 series or D100)

■AF-Assist Illuminator (with any Nikon AF SLR)

■Repeating Flash

■TTL/Manual flash output level compensation

■Built-in bounce card

■Automatic power zoom coverage from 24mm

to 85mm (with F5, F4 series, F100, F90X, F80,

F70, F65, PRONEA 600i, D1 series or D100

and CPU lens)

■Built-in wide flash adapter to cover 18mm

■Tilting/rotating flash head

■LCD panel with illumination

* CPU lenses refer to those AF Nikkor,

AI-P Nikkor or IX-Nikkor lenses

which feature a built-in microcomput-

er and CPU contacts.

** With F4 series, AI-S or AI Nikkor lenses

are also usable.

SB-28DX

Nikon Speedlight designed specially for the Nikon D1 series

In addition to offering all the features of Nikon’s SB-28 Speedlight, this flash unit enables

TTL flash control capability for the D1 series Nikon professional digital SLR. The SB-28DX

provides most of the same advanced flash control features as the SB-28 Speedlight, and is

compatible with current Nikon SLR cameras. The SB-28DX features 3D Multi-Sensor

Balanced Fill-Flash, designed specifically for the D1 series and D100. It also equips the D1

series with AA (Auto Aperture) Flash capability.

SB-28DX can not be used with F55.

SB-28

Nikon D1 with

the SB-28DX

Photographic Accessories

Autofocus Speedlight

SB-28 • 28DX / Specifications

Electronic construction: Automatic Insulated Gate Bipolar Transistor (IGBT)

and series circuitry

Flash exposure control: TTL automatic control with Nikon F5, F4 series,

F100, F90X, F80, F70, F65, F60, PRONEA 600i,

FM3A, D1 series or D100 (SB-28DX only); Non-TTL

automatic control; Manual control: full, 1/2, 1/4, 1/8,

1/16, 1/32 and 1/64 output

Guide number

(ISO 100, m/ft)

:36/118 (with zoom head set at 35mm)

Flash coverage: 85mm, 70mm, 50mm, 35mm, 28mm, 24mm;

20mm, 18mm (with built-in wide flash adapter)

Film speed range ISO 25 to 1000

in TTL auto flash mode:

Recycling time: Approx. 6.5 sec. (Manual at full)

Number of flashes: Approx. 150 (Manual at full)

AF-Assist Illuminator: Automatically fires LED beam toward subject when

performing autofocus with Nikon AF SLRs in low-

light conditions: cancelable

Power source: Four 1.5V LR6 (AA-type alkaline), 1.2V KR-AA (AA-

type NiCd) or 1.5V FR6 (AA-type lithium) batteries;

DC Unit SD-7*1*2; Battery Pack SD-8A*2

*1 SD-7 is not available in European countries.

*2 SD-7/8 cannot be used with the SB-28/SB-28DX sold

in European countries.

Dimensions (W ×H ×D): Approx. 69 ×128 ×90mm or 2.7 ×5.0 ×3.5 in.

(without mounting foot)

Weight (without batteries): Approx. 320g or 11.4 oz.

Other features: Ready-light, open-flash button, sync/multiple flash

terminal, LCD panel illumination

Specifications and designs are subject to change without

any notice or obligation on the part of the manufacturer.

Built-in bounce card

Built-in wide flash adapter

NIKON CORPORATION

FUJI BLDG., 2-3, MARUNOUCHI 3-CHOME, CHIYODA-KU, TOKYO 100-8331, JAPAN

www.nikon-image.com/eng/

April 2002

SB-28/28DX Specifications
