User Guide for
Nokia Camera Flash PD-2
9232493
Issue 1
2
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION, declare under our sole responsibility that the
product PD-2 is in conformity with the provisions of the following Council
Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright© 2004 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the
contents in this document in any form without the prior written
permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia
Corporation. Other product and company names mentioned herein may
be trademarks or tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the
right to make changes and improvements to any of the products described
in this document without prior notice. Nokia reserves the right to revise
this document or withdraw it at any time without prior notice.
3
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS
OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT AS
REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE
THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR
NOTICE.
The availability of particular products may vary by region. Please check
with the Nokia dealer nearest to you.
9232493/Issue 1
EXPORT CONTROLS
This device may contain commodities, technology or software subject to
export laws and regulations from the US and other countries. Diversion
contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Contents
4
Contents
For Your Safety........................................................................................................5
1. Introduction.................................................................................................... 6
2. Getting started ............................................................................................... 7
Overview ...........................................................................................................7
Using Nokia Camera Flash............................................................................8
3. Troubleshooting ............................................................................................. 9
4. Battery information ....................................................................................11
Care and maintenance .......................................................................................13
Additional safety information .........................................................................15
Limited Warranty (U.S.)......................................................................................17
For Your Safety
5
For Your Safety
SWITCH ON SAFELY
Do not switch the device on when wireless phone
use is prohibited or when it may cause interference
or danger.
USE SENSIBLY
Use only in the normal position as explained in the
product documentation.
QUALIFIED SERVICE
Only qualified personnel may repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved batteries.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user
guide for detailed safety instructions. Do not
connect incompatible products.
Introduction
6
1. Introduction
Nokia Camera Flash enables you to take photos and video clips
in poor lighting conditions. Nokia Camera Flash can be
connected to compatible Nokia camera phones, such as the
Nokia 7610 phone. To check the compatibility of your Nokia
phone, contact your dealer or Nokia Customer Care.
Nokia Camera Flash includes a xenon flash tube and an LED
light. You can use the flash to take pictures of a subject up to 10
feet away. You can use the LED to record video clips of subjects
up to 1.5 feet away.
Do not use the flash at close range to people or animals.
Note: The flash is meant only for use in poor
lighting conditions or in the dark. If you use the
flash in normal indoor lighting or in daylight, some
of your photos may be overexposed.
Read this user guide carefully before using Nokia Camera Flash.
Read the user guide of your phone. Do not use this user guide in
place of the user guide for the phone, which provides additional
important safety and maintenance information.
Getting started
7
2. Getting started
■Overview
1. Pop-PortTM connector
2. Video LED light
3. Xenon flash tube
4. Battery door release button
5. Status LED indicator
To insert the battery, open the battery cover, put in the battery
(the required polarity is printed on the cover), and close the
cover. When the indicator light is red, the battery must be
replaced.
Getting started
8
■Using Nokia Camera Flash
1. Connect Nokia Camera Flash to the phone Pop-Port.
2. Wait for the flash to charge. The indicator light blinks green
while the flash charges. When the light stops blinking and
remains a steady green, the flash is ready for use.
3. Take a picture or record a video. For information about how
to take a picture or record a video, see the user guide for
the phone.
Note: Do not cover the flash while using it.
Troubleshooting
9
3. Troubleshooting
• Q: Why do I receive a message that the enhancement is not
supported when I connect Camera Flash to a compatible
phone?
A: Camera Flash must be correctly connected to your phone.
See the image below.
Troubleshooting
10
• Q: What does the LED indicate?
A: A blinking green LED indicates the flash is charging and
is not ready for use.
A steady green indicates the flash is charged and is ready
for use.
A blinking red indicates the charging of the flash stopped for
safety reasons, such as a humid environment.
A steady red indicates a low battery.
Note: The LED indicates only the readiness of the
flash for photos.
• Q: What is the optimal range for the flash?
A: The flash works for distances from 3 to 10 feet. The
optimal range depends on your phone model.
• Q: What is the optimal range for the video LED light?
A: The video LED light works for distances up to 1.5 feet.
The optimal range depends on your phone model.
