Nintendo Mv1-7.1 Manuel utilisateur
Mv1-7.1 installation manual
Installation guide
Required Items:
Recommended Tools:
1. MicroSD card containing atmospheric integration
package and genuine SanDisk card are recommended.
2. Mv1-7.1 cracking chipset
3. Nintendo switch V1 (Erista) / V2 (Mariko)
4. Tip soldering iron (340c) / solder
5. Y00 human screwdriver and #00 Philips cross
screwdriver
6. CPU heat dissipation paste
1. Liquid flux
2. Electronic magnifying glass or head mounted
magnifying glass
3. Alcohol (more than 91%)
4. Cotton swab / scissors
5. Kapton heat resistant tape / electrical tape
1
2
3
4
5
6
7
8
GENTLY BEND BACK THE CABLE
AND IT TO THE CHIP,CONNECT
THEN LAY IT FLAT AGAIN
IT SHOULD LINE UP
WITH THE PLUP.NAND
PRESS DOWN TO SECURE
THE CONNECTION
9
Assemble all removed parts again,
replace the cleaned heat dissipation
paste, and cut a little antimagnetic
wave so that the cable can pass through.
Cut off part of the metal
back plate, and use
heat-resistant adhesive
tape for insulation
protection. Finally,
the shell will not be tilted
after installation.
Install the NAND module
and fix it with adhesive tape.
