Nilfisk-Advance Core 125 Mode d'emploi

Repair Manual ver. 1.0

Core 125

Core 130

Index

A. Saftey precautions 3

B. Technical data 4

C. Construction 5-6

D. Service / Repair 7-16

F. Operating supplies 19

E. Torque 17-18

G. Operation 20-23

H. Diagram 24-25

Safety precautions.

WARNING!

• High pressure jets can be dangerous. Never direct the water jet at persons

pets, live electrical equipment or the machine self.

• The operator and anyone in the immediate vicinity of the site of cleaning

should take action to protect themselves from being struck by debris dis-

lodged during operation. Wear goggles during operation.

• Never try to clean clothes or footwear on yourself or other persons.

• Do not let children or people who have not read the instruction manual

operate the machine.

• Never use the machine in an environment where there could be a danger of

explosion. If any doubt arises, please contact the local authorities.

• It is not allowed to clean asbestos- containing surfaces with high pressure.

• This high pressure washer must not be used at temperatures below 0°C.

• Never let any persons stay under the product when stored on the wall.

Technical Data.

Product segment:Consumer Core 125 Core 130

Specicaon bar Max 125 Max 130

Voltage V220-240 220-240

Frequency Hz 50-60 50-60

Power consumpon A5,8 6,5

Power absorbed KW 1,4 1,5

Water volume,HP l/min. 5,2 5,4

Pump pressure bar 85 95

Opening pressure bar 110-130 110-130

Retaining me min. 55

Oil contents ml 55 55

Oil type GB3141 N32/

ISO VG32

GB3141 N32/

ISO VG32

Max water inlet temperature C40 40

Max water inlet pressure bar 10 10

High pressure hose length m5m G1 So Hose

Ø10mm

6 m G1 So Hose

Ø10mm

Sucon height mMax 0.5 Max 0.5

Electric cable m55

Insulaon class FF

Tightness IPX5 IPX5

Construction.

Core 125—Core 130

Construction of cabinet parts.

Construction.

Core 125

Core 130

Construction of pump unit.

Service / Repair.

Dismounting of cabinet rear part on following variants: Core 125 Core 130

1. Tools: Screwdriver PH2 (fig.1)

2. Remove the water inlet coupling (fig. 2)

3. Remove the 2 screws to remove the wheels for easy disassembly (fig. 2)

4. Remove the 2 screws behind the wheels (fig.2)

5. Remove the remining 6 screws fixing the cabinet rear part (fig.2)

6. The cabinet rear part can be removed and there is now access to the motor pump unit

Fig. 1

Fig. 2

Service / Repair.

Fig. 1

Dismount / mounting of switch box cover and switch box Core 125.

1. Remove the 4 screws. (fig 1)

2. Remove the switch box cover. (fig 1)

3. Assembly: Ensure that the single cords are inside the box and are not squeezed during

assembly and that cable relief is mounted correctly in the slut in the switchbox.

4. Assembly: Ensure that the switch is correctly mounted the fixing sluts inside the switch

box. (fig 2)

Fig. 2

Service / Repair.

Fig. 1

Dismount / mounting of switch box cover and switch box Core 130 / Core 140.

1. Remove the 4 screws. (fig 1)

2. Remove the switch box cover. (fig 1)

3. Assembly: Ensure that the single cords are inside the box and are not squeezed during

assembly and that cable relief is mounted correctly in the slut in the switchbox.

4. Assembly: Ensure that the switch is correctly mounted the two fixing tap’s (fig 2)

5. Assembly: Turn knob axle counter clockwise, and align with knob in its right position

when mounting the front part including the knob.

Fig. 2

Fig. 3

Service / Repair.

Fig. 1

Dismounting / mounting of the start / stop valve Core 125 - Core 130.

Fig 1 is showing how the start / stop valve must be assembled.

There is no special tool available to dismount the seat of the start / stop valve

I will be possible to use a long 3 mm self cutting screw (eg. for wood) Fig.2

NOTE: the valve seat is no longer usable after dismounting

Fig. 2
