First dive is a checkdive without the camera in the housing.

Check all buttons under water.

1. Preface

A camera in an underwater housing offers a lot of advantages to the profes-

sional and amateur underwater photographer:

 impeccable exposure due to the use of the most modern exposure

techniques of the camera;

 direct view on the subject, very short reaction time and swift image

processing;

 exact and swift focusing due to the autofocus objective;

 parallax faults no longer exist because one looks through the objective

(all settings are displayed on the LCD-screen);as the camera can also

be used on land, a second camera is not needed.

As housings and flashes have a long lifetime and are quite expensive, some

time should be invested in looking around to find the right equipment. Do-

ing this in cooperation with a professional salesman is probably the best

solution.

Different criteria determine the final choice of the camera:

 recording technique (viewfinder, controls, …);

 functionality and comfort (design of the housing, control switches and

their ergonomical position, …);

 price.

Also: some elements that determine ones choice when buying a safari

camera are not important at all when purchasing a camera for “underwater”

use. Cameras are always designed for “on land” use. Therefore HUGYFOT

always designs its housings from the divers’ ergonomical point of view and

translates this through the controls.

Hugyfot Housing for Nikon D200 5User manual

2. Techical information

1. Front shell - 2. Exposure lever - 3. Neoprene handstrap - 4. Main dial - 5. On/off switch -

6. Ball-and-socket joint for mounting flash arm - 7. External flash connections - 8. Zoom/fo-

cus control - 9. Ergonomic grip with ball-and-socket joint for mounting flash arm - 10. Port

11. Countersunk bolt - 12. Back shell - 13. Metering mode & Multi selector- 14. LCD moni-

tor - 15. Menu buttons - 16. White balance/ISO/Quality control - 17. Top screen - 18. Mode

button - 19. Metering button - 20. Main dial - 21. Auto focus lock.

131412

19 20

Hugyfot Housing for Nikon D200 6User manual

3. Hugyfot for Nikon D200

It is a trend in underwater photography to use a digital camera that can be

used by the amateur as well as by the professional.

Nothing is as simple as taking pictures with the automatic settings of the

Nikon D200. One can choose to take control himself and set each para meter

to his preference. The sensitive exposure lever is integrated in the front shell

which is a part of the patented Hugyfot-grip. This enables one-hand pho-

tography. With this sensitive lever the exposure lever of the ca mera can be

slightly squeezed so the camera is activated. All the settings then become

visible on the LCD-screen. One-hand photography, taking pictures during a

drift dive or point-shooting with the flash in the other hand are “child’s play”

thanks to the HUGYFOT design. Just as easy is the manipulation of the

zoom on the left side, the diaphragm and the shutter speed.

All parameters can be changed through the menu driven system, this can

be operated through the buttons on the back of the housing. The big LCD-

screen of the camera is entirely visible through the integrated window on

the back of the housing. Any flash can be connected through the standard

Nikonos contact.

The sensitive exposure lever is integrated in the

front shell which is a part of the patented

HUGYFOT-grip. This enables

one-hand photography.

The sensitive exposure lever is integrated in the

front shell which is a part of the patented

HUGYFOT-grip. This enables

one-hand photography.

The sensitive exposure lever is integrated in the

front shell which is a part of the patented

HUGYFOT-grip. This enables

one-hand photography.

Hugyfot Housing for Nikon D200 7User manual

4. Opening and closing the housing

The HUGYFOT Nikon D200 housing is opened and closed by means of 2 built-

in countersunk bolts.

This guarantees the safest way of closing. Only

with the right key you can open and close the

housing. A curious buddy cannot open the

housing by accident. Herewith we exclude the

unwanted opening of the housing. To seal the

housing, the socket screw key is inserted into

the countersunk bolt with the extended part and

then turned by the shorter part until the shells

are squeezed to one another. Further squeezing

the screws hasn’t got any sense and can only

damage the thread. At a depth of 6 meters the

hydrostatic pressure takes over and keeps all

the o-rings under pressure. Always check the

tension on the bolts before diving if the housing

wasn’t opened in between two dives.

First maintenance command:

The screws, and more specific the tread, must

be kept very clean at all times. The main o-ring

merely lies in the o-ring groove. It can be removed by blowing it out with com-

pressed air, by using a credit card or by rubbing two pieces of paper towards

each other against the o-ring so the o-ring pops out of his groove. Never use

a metal object or any other hard material: by doing this you can DAMAGE the

O-ring and the groove.

Second maintenance command:

Whenever the o-ring is dirty or misted up, it must be removed from its

groove (see first command) and cleaned up with soap (do not use corrosive

or chemical degreasers). Afterwards clean it with clear water.

O-rings have to be dried up with a clean cloth (do not squeeze) or by air.

Grease the O-rings (except the main red o-ring) by using HUGYFOT grease.

Pull the o-ring gently through your fingers without stretching it! O-ring

grooves, housing and shell edges have to be cleaned with a clean cloth.

To seal the housing, the sock-

et screw key is inserted into

the countersunk bolt with the

extended part.

Hugyfot Housing for Nikon D200 8User manual

5. Port with bayonet catch

The front port bayonet catch is a secure and fast method to connect the dif-

ferent ports to the HUGYFOT Nikon D200 housing.

The port has a mark which has to be positioned opposite to the mark at the left

of the housing when mounting and demounting the port. To actually close the

port it has to be turned clockwise until the mark on the port is opposite to the

mark on top of the housing. To demount the port it has to be turned counter

clockwise until the mark on the port is opposite to the mark on the left of the

housing.

When mounting the port, mind that it is held exactly in the middle of the

port mounting. Only then you can press the port so it slides nicely into the

port mounting. Check whether the port is closed properly before turning it

towards the marking on top of the housing. (secure position).

Third maintenance command:

The o-ring around the port can be removed from its groove by pressing it

with 2 fingers.

Port mounting, o-ring groove and bayonet catch have to be cleaned with a

wet cloth. Afterwards let everything dry.

Clean the inside of the portglas with water and soap. Never scrub it with a

cloth. Rinse it with fresh water and let it dry, or dry it with compressed air.

Grease the O-rings with HUGYFOT grease by gently pulling it through your

fingers without stretching it! Put it back into their grooves.

When mounting the port,

A and C must be opposite

to each other. Make sure

that the port is held ex-

actly in the middle of the

port mounting. Then turn

the port clockwise until B

and C are opposite to each

other.

Hugyfot Housing for Nikon D200 9User manual

6. Flash connections

Hugyfot housings can be equiped with Nikonos 5-pins or S-6 flash connec-

tions. These flash connections are plugged into a circuit board inside the

housing. An optional TTL-converter is also available.

The flash connection can be shut off by

using a small protection cap which can be

removed by turning it counter clockwise.

The cap has 2 o-rings which have to be

cleaned together with the thread. After-

wards, slightly grease o-ring and thread.

The flash plug also has to be serviced.

Slightly grease the o-rings and thread and

keep the flash contacts dry.

The multiple socket in the housing has

a small ridge. The projecting part of the

connection has a groove with the same

measurements as the ridge of the connec-

tion. Be sure that, whenever plugging the

connection into the socket, the groove and

the ridge fit well together. Only then the

connection is well positioned. Press the

plug gently into the contact. Then turn it

clockwise to tighten it. Whenever the flash

connection has to be removed from a wet

housing it always has to be positioned downwards. If not, the remaining

water can work its way into the flash connection. In that case, the water has

to be removed immediately by using an absorbing paper. Do not close the

flash connection when it is not entirely dry.

Fourth maintenance command:

Keep the inside of the plug dry and clean. The o-rings, the plug and the

thread need to be clean and slightly greased. DO NOT use the housing with

an open multiple socket: this can cause leakage and corrosion!

Be sure that, whenever plugging the

connection into the socket, the groove

and the ridge fit together well.

Hugyfot Housing for Nikon D200 10 User manual

Hugyfot Strobe Connections

The Hugyfot strobe connections are integrated in the leakage detector

circuit board. This circuit board runs on a single 3.6 Volt 1/2 AA Lithium

battery. The main parts of this system are described as below.

Standard setup .

External strobe connection(s) A is (are) connected to D and/or E on leakage detector. Hotshoe B is connected to

C on leakage detector. X is used for ﬁrmware upload.

Setup with TTL converter .

External strobe connection(s) A is (are joined and) connected to D on leakage detector. Connection E on leakage

detector is joined with connection F on TTL converter. Hotshoe B is connected to H on TTL converter. G is power

supply on TTL converter.

In case you run out of batteries, a backup system is provided. TTL control will no longer be available!

Backup for standard setup .

External strobe connection(s) A is (are) connected to J and/or K on backup circuit board. Hotshoe B is connected

to I on backup circuit board.

Backup for setup with TTL converter .

External strobe connection(s) A is (are joined and) connected to J or K on leakage detector. Hotshoe B is con-

nected to I on backup circuit board.

External strobe connection

Nikonos 5-pin or S6-pin

Internal camera hotshoe

Nikon or Canon

Hugyfot leakage warner with integrated

strobe connections Nikon or Canon

Battery holder for

3.6 V 1/2AA Lithium battery

+ -

TTL Converter Backup

A B

Autres manuels pour D200

Table des matières

Autres manuels Nikon Accessoires pour appareils photo

Nikon

Nikon SK-E900 - Flash Mounting Bracket Manuel utilisateur

Nikon

Nikon AF-S Fisheye NIKKOR 8-15mm f/3.5-4.5E ED Manuel utilisateur

Nikon

Nikon EN-EL7 Manuel utilisateur

Nikon

Nikon AF-S NIKKOR 24-70mm f/2.8 ED Manuel utilisateur

Nikon

Nikon Eclipse Ti Series Manuel utilisateur

Nikon

Nikon SK-E900 Manuel utilisateur

Nikon

Nikon EN-EL11 Manuel utilisateur

Nikon

Nikon Circular Polarizing Filter @... Manuel utilisateur

Nikon

Nikon EN-MH1 Manuel utilisateur

Nikon

Nikon AF-S DX NIKKOR 35mm f/1.8G Manuel utilisateur

Nikon

Nikon DS-2MBW Manuel utilisateur

Nikon

Nikon EN-EL 19 Manuel utilisateur

Nikon

Nikon 20mm 1/2.80 Manuel utilisateur

Nikon

Nikon WP-CP1 - Underwater Housing Manuel utilisateur

Nikon

Nikon AH-4 Manuel utilisateur

Nikon

Nikon NIKONOS Speedlight SB-102 Manuel utilisateur

Nikon

Nikon AF-S DX 55-200mm f/4-5.6G IF-ED VR II Manuel utilisateur

Nikon

Nikon SB-400 Manuel utilisateur

Nikon

Nikon FSB-6 Manuel utilisateur

Nikon

Nikon MC-EU1 Manuel utilisateur

Nikon

Nikon AF-S NIKKOR 500mm f/4E FL ED VR Manuel utilisateur

Nikon

Nikon AF-S DX NIKKOR 18-105mm f/3.5-5.6 ED VR Manuel utilisateur

Nikon

Nikon Slip-in Circular Polarizing Filters Manuel utilisateur

Nikon

Nikon f/3.5-5.6G ED VR Manuel utilisateur

Manuels Accessoires pour appareils photo populaires d'autres marques

Viltrox

Viltrox EF-NEX Instructions d'installation

Calumet

Calumet 7100 Series CK7114 Manuel utilisateur

Ropox

Ropox 4Single Series Manuel utilisateur

Cambo

Cambo Wide DS Digital Series Mode d'emploi

Samsung

Samsung SHG-120 Manuel utilisateur

Ryobi

Ryobi BPL-1820 Manuel d'utilisation

Aegis

Aegis ABL-36020P Manuel utilisateur

Pentax

Pentax Data Back Fc Manuel utilisateur

Fantasea

Fantasea EyeGrabber F Series Manuel utilisateur

Honeywell

Honeywell HDZ20HD Manuel utilisateur

EGO

EGO BA1400T Manuel utilisateur

Sima

Sima SRW-62 Manuel utilisateur

Shape

Shape A7SSMKIT Manuel utilisateur

Slide Kamera

Slide Kamera HST-2 Manuel utilisateur

Power works

Power works 2902613 Manuel utilisateur

SES

SES SE-2047-2 Manuel utilisateur

Olympus

Olympus PT-EP05L Manuel utilisateur

Starlite

Starlite OctoDome nxt Manuel utilisateur
