INSTALLER MANUAL

Indoor module

NIBE VVM 320 UK 1x230V

Quick guide

Navigation

Ok button (confirm/select)

Back button (back/undo/exit)

Control knob (move/increase/reduce)

A detailed explanation of the button functions can be found on page 39.

How to scroll through menus and make different settings is described on page 41.

Set the indoor climate

MY INSTALLATION

INDOOR CLIMATE HOT WATER

INFO

The mode for setting the indoor temperature is accessed by pressing the OK button twice, when in the start

mode in the main menu.

Increase hot water volume

1X INDOOR CLIMATE HOT WATER

MY INSTALLATION INFO

To temporarily increase the amount of hot water, first turn the control knob to mark menu 2 (water droplet)

and then press the OK button twice.

41 Important information

4Safety information

4Symbols

4Marking

5Serial number

5Recovery

5Country specific information

6Inspection of the installation

7Outdoor modules

82 Delivery and handling

8Transport

8Assembly

9Supplied components

10Removing the covers

123 Indoor module's design

13Component location, rear

13List of components

144 Pipe connections

14General pipe connections

18Dimensions and pipe connections

19Connecting air/water heat pump

19Connection during use without heat pump

19Heating medium side

19Cold and hot water

19Installation alternative

215 Electrical connections

21General

24Connections

27Settings

28Optional connections

31Connecting accessories

336 Commissioning and adjusting

33Preparations

33Filling and venting

34Start-up and inspection

36Setting the cooling/heating curve

37Setting hot water circulation

37Pool

38SG Ready

397 Control - Introduction

39Display unit

40Menu system

438 Control – Menus

43Menu 1 - INDOOR CLIMATE

44Menu 2 - HOT WATER

44Menu 3 - INFO

45Menu 4 - MY SYSTEM

46Menu 5 - SERVICE

569 Service

56Service actions

6010 Disturbances in comfort

60Info-menu

60Manage alarm

60Troubleshooting

62Electrical addition only

6311 Accessories

6512 Technical data

65Dimensions and setting-out coordinates

66Technical specifications

68Electrical circuit diagram

73Item register

79Contact information

3Table of ContentsNIBE VVM 320

Table of Contents

Safety information

This manual describes installation and service proced-

ures for implementation by specialists.

The manual must be left with the customer.

This appliance can be used by children

aged from 8 years and above and persons

with reduced physical, sensory or mental

capabilities or lack of experience and

knowledge if they have been given super-

vision or instruction concerning use of the

appliance in a safe way and understand

the hazards involved. Children shall not

play with the appliance. Cleaning and user

maintenance shall not be made by children

without supervision.

Rights to make any design or technical

modifications are reserved.

©NIBE 2020.

MinMaxSystem pres-

sure

0.05 MPa

(0.5 bar)

0.3 MPa

(3 bar)

Heating medium

0.01 MPa

(0.1 bar)

0.6 MPa

(6 bar)

Domestic water

Water may drip from the safety valve. A

factory-fitted overflow pipe goes from the

safety valve to an overflow cup. The overflow

pipe is visible, its mouth is open and is not

located close to electrical components. An

overflow pipe should be routed from the

overflow cup to a suitable drain. The entire

length of this overflow pipe is inclined to

prevent water pockets, and it must also be

frost-proof.

VVM 320 must be installed via an isolator

switch. The cable area has to be dimensioned

based on the fuse rating used.

Symbols

NOTE

This symbol indicates danger to person or ma-

chine .

Caution

This symbol indicates important information

about what you should consider when installing

or servicing the installation.

TIP

This symbol indicates tips on how to facilitate

using the product.

Marking

The CE mark is obligatory for most products sold

in the EU, regardless of where they are made.

Classification of enclosure of electro-technical

equipment.

IP21

Danger to person or machine.

Read the User Manual.

NIBE VVM 320Chapter 1 | Important information4

1 Important information

Serial number

The serial number can be found at the bottom right of

the front cover, in the info menu (menu 3.1) and on the

type plate (PZ1).

Serial number

Caution

You need the product's ((14 digit) serial number

for servicing and support.

Recovery

Leave the disposal of the packaging to the in-

staller who installed the product or to special

waste stations.

Do not dispose of used products with normal

household waste. It must be disposed of at a

special waste station or dealer who provides this type

of service.

Improper disposal of the product by the user results in

administrative penalties in accordance with current le-

gislation.

Country specific

information

UNITED KINGDOM

This installation is subject to building regulation approval,

notify the local Authority of intention to install.

Use only manufacturer’s recommended replacement

parts.

For more information see nibe.co.uk.

Benchmark places responsibilities on both manufactur-

ers and installers. The purpose is to ensure that custom-

ers are provided with the correct equipment for their

needs, that it is installed, commissioned and serviced

in accordance with the manufacturers instructions by

competent persons and that it meets the requirements

of the appropriate Building Regulations. The Benchmark

Checklist can be used to demonstrate compliance with

Building Regulations and should be provided to the

customer for future reference.

Installers are required to carry out the installation, com-

missioning and servicing work in accordance with the

Benchmark Code of practice which is available from the

Heating and Hotwater Industry Council who manage

and promote the Scheme. Visit centralheating.co.uk for

information.

Warranty and insurance information

Thank you for installing a new NIBE heat pump in your

home.

NIBE heat pumps are manufactured in Sweden to the

very highest standard so we are pleased to offer our

customers a comprehensive guarantee.

The product is guaranteed for 24 months for parts and

labour from the date of installation or 33 months from

the date of manufacture, whichever is the shorter.

The NIBE guarantee is based on the unit being installed

and commissioned by a NIBE accredited installer, ser-

viced every year and the Benchmark documents com-

pleted. Where this condition is not met, any chargeable

spare parts or components issued within the applicable

guarantee period still benefit from a 12 month warranty

from the date of issue by the manufacturer.

We recommend the installer completes and returns as

soon as possible, your guarantee registration card or

completes the guarantee form on the NIBE website

www.nibe.co.uk

5Chapter 1 | Important informationNIBE VVM 320

Inspection of the installation

Current regulations require the heating installation to be inspected before it is commissioned. The inspection must

be carried out by a suitably qualified person.

In addition, fill in the page for the installation data in the User Manual.

DateSigna-

ture

NotesDescription

✔

Heating medium, see section "System

diagram"

System flushed

System vented

Expansion vessel

Particle filter

Safety valve

Shut off valves

Boiler pressure

Connected according to outline dia-

gram

Hot water, see section "Cold and hot wa-

ter"

Shut off valves

Mixing valve

Safety valve

Pressure reduction valve

Tundish

Expansion vessel

Electricity, see section "Electrical connec-

tions"

Connected communication

Circuit fuses

Fuses, indoor module

Fuses property

Outside sensor

Room sensor

Current sensor

Safety breaker

Earth circuit-breaker

NIBE VVM 320Chapter 1 | Important information6

DateSigna-

ture

NotesDescription

✔

Setting of emergency mode thermo-

stat

Miscellaneous

Warranty

Benchmark checklist

Docked to

Outdoor modules

COMPATIBLE AIR/WATER HEAT PUMPS

NIBE SPLIT HBS 05

HBS 05-6

Part no. 067 578

AMS 10-6

Part no. 064 205

HBS 05-12

Part no. 067 480

AMS 10-8

Part no. 064 033

HBS 05-12

Part no. 067 480

AMS 10-12

Part no. 064 110

F2040

F2040-8

Part no. 064 109

F2040-6

Part no. 064 206

F2040-12

Part no. 064 092

F2120

F2120-12 1x230V

Part no. 064 136

F2120-8 1x230V

Part no. 064 134

7Chapter 1 | Important informationNIBE VVM 320

Transport

VVM 320 should be transported and stored vertically in

a dry place. However, the VVM 320 may be carefully

laid on its back when being moved into a building.

Assembly

• Place VVM 320 on a solid foundation indoors that can

take its weight. Use the product's adjustable feet to

obtain a horizontal and stable set-up.

The space where VVM 320 is located must be frost-

free.

30 - 50 mm

15 - 40 mm

20-55 mm

• Because water can emerge from the safety valve, the

area where VVM 320 is located must be provided with

floor drainage.

INSTALLATION AREA

Leave a free space of 800 mm in front of the product.

All service on VVM 320 can be carried out from the front.

800

10-25

NOTE

Leave 10 – 25 mm free space between

VVM 320 and the wall behind for routing cables

and pipes.

NIBE VVM 320Chapter 2 | Delivery and handling8

2 Delivery and handling

Supplied components

1 x Room sensor1 x Outdoor temperature

sensor

LEK

2 x Tundish (WM3)

LEK

1 x Valve connector (pres-

sure reduction valve

(QN17), expansion relief

valve (FL1) and non-return

valve (RM1))

LEK

1 x Connector with cable

LEK

1 x Armoured hose

(expansion vessel)

LEK

1 x Expansion vessel do-

mestic water (CM4) with

holder

(enclosed separately)

LEK

1 x Solenoid valve

LOCATION

The kit of supplied items is placed on top of the product.

9Chapter 2 | Delivery and handlingNIBE VVM 320

Removing the covers

Front cover

LEK

1. Remove the screws from the lower edge of the

front panel.

2. Lift the panel out at the bottom edge and up.

Side covers

The side covers can be removed to facilitate the install-

ation.

Caution

50 mm space required to remove the side

panels.

1. Remove the screws from the upper and lower

edges.

2. Twist the cover slightly outward.

3. Move the hatch backwards and slightly to the side.

4. Pull the cover to one side.

5. Pull the hatch forwards.

NIBE VVM 320Chapter 2 | Delivery and handling10

Autres manuels pour VVM 320

Table des matières

Autres manuels Nibe Chaudière

Nibe

Nibe ELK 42 Manuel utilisateur

Nibe

Nibe UKV 500 Manuel d'utilisation et d'entretien

Nibe

Nibe EKS 750 Manuel utilisateur

Nibe

Nibe PELLUX 100 Manuel utilisateur

Nibe

Nibe PUB2 160 Manuel d'utilisation et d'entretien

Nibe

Nibe Eminent Series Manuel d'utilisation et d'entretien

Nibe

Nibe PELLUX 100 Manuel utilisateur

Nibe

Nibe ES Series Manuel utilisateur

Nibe

Nibe VEDEX 1000 Manuel utilisateur

Nibe

Nibe VEDEX 4000 Manuel

Nibe

Nibe VVM 225 Manuel utilisateur

Nibe

Nibe VPAS 300 Series Manuel d'utilisation et d'entretien

Nibe

Nibe EKS 750 Manuel utilisateur

Nibe

Nibe EVC 13 Manuel utilisateur

Nibe

Nibe PELLUX 100/20 Manuel utilisateur

Nibe

Nibe EKS 500 NL Manuel d'utilisation et d'entretien

Nibe

Nibe VEDEX 3300 Manuel utilisateur

Nibe

Nibe NIBE GBM 10-15 Manuel d'utilisation et d'installation

Nibe

Nibe EVC 13 Manuel utilisateur

Nibe

Nibe VPB 500 Manuel d'utilisation et d'entretien

Nibe

Nibe PUB2 160 Manuel d'utilisation et d'entretien

Nibe

Nibe Eminent Exp Manuel d'utilisation et d'entretien

Nibe

Nibe VPB Manuel d'utilisation et d'entretien

Nibe

Nibe HK 15 Manuel d'utilisation et d'entretien

Manuels Chaudière populaires d'autres marques

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manuel utilisateur

Radijator

Radijator BIO max 23.1 Manuel utilisateur

Brunner

Brunner BSV 20 Manuel utilisateur

Buderus

Buderus Logamax GB062-24 KDE H V2 Manuel utilisateur

Potterton

Potterton 50e Fiche technique

UTICA BOILERS

UTICA BOILERS TriFire Manuel utilisateur

Joannes

Joannes LADY Series Manuel

ECR International

ECR International UB90-125 Manuel d'instructions

Froling

Froling FHG Turbo 3000 Manuel utilisateur

Froling

Froling P4 Pellet 8 - 105 Manuel utilisateur

U.S. Boiler Company

U.S. Boiler Company K2 Manuel utilisateur

Henrad

Henrad C95 FF Manuel utilisateur

NeOvo

NeOvo EcoNox EF 36 Manuel utilisateur

Potterton

Potterton PROMAX SL 12 Manuel utilisateur

Eco Hometec

Eco Hometec EC 25 COMPACT Manuel utilisateur

Viessmann

Viessmann VITODENS 200 Mode d’emploi

Baxi

Baxi Prime 1.24 Manuel utilisateur

REXNOVA

REXNOVA ISA 20 BITHERMAL Manuel utilisateur
