Nibe AHPS Guide de l'utilisateur
IHB EN 1911-1
531217
INSTALLER MANUAL
Accumulator tank
AHP S/ AHPS S/ AHPH S
41 Important information
4Safety information
5General
72 Delivery and handling
7Transport
7Assembly
7Supplied components
8Removing the covers
93 Accumulator tank design
114 Pipe connections
11General
12System diagram
13Dimensions and pipe connections
15Installation alternative
175 Electrical installation
17Sensors
186 Commissioning and adjusting
18Filling and venting
197 Service
19Service actions
208 Technical data
20Diagram
21Dimensions and setting-out coordinates
23Technical specifications
23Energy labelling
24Item register
27Contact information
3Table of ContentsAHP S/ AHPS S/ AHPH S
Table of Contents
Safety information
This manual describes installation and service proced-
ures for implementation by specialists.
The manual must be left with the customer.
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given super-
vision or instruction concerning use of the
appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
Rights to make any design or technical
modifications are reserved.
©NIBE 2019.
SYMBOLS
NOTE
This symbol indicates danger to person or ma-
chine .
Caution
This symbol indicates important information
about what you should consider when installing
or servicing the installation.
TIP
This symbol indicates tips on how to facilitate
using the product.
MARKING
The CE mark is obligatory for most products sold in
the EU, regardless of where they are made.
CE
AHP S/ AHPS S/ AHPH SChapter 1 | Important information4
1 Important information
General
AHP S/ AHPS S/ AHPH S is designed and manufactured
according to good technical practice1in order to ensure
safe usage.
1Pressure Equipment Directive 2014/68/EU Article 4 point 3.
SERIAL NUMBER
The serial number can be found at the bottom right of
the front cover.
Caution
Always give the product's serial number when
reporting a fault.
RECOVERY
Leave the disposal of the packaging to the in-
staller who installed the product or to special
waste stations.
Do not dispose of used products with normal
household waste. It must be disposed of at a
special waste station or dealer who provides this type
of service.
Improper disposal of the product by the user results in
administrative penalties in accordance with current le-
gislation.
5Chapter 1 | Important informationAHP S/ AHPS S/ AHPH S
INSPECTION OF THE INSTALLATION
Current regulations require the heating installation to be inspected before it is commissioned. The inspection must
be carried out by a suitably qualified person.
DateSignatureNotesDescription
✔
Heat pump (page 16)
Shut off valves
Expansion vessel
Safety valve
Hot water (page 15)
Shut off valves
Mixing valve
Safety valve
Cold water (page 15)
Shut off valves
Non-return valve
Electricity (page 17)
Sensors
AHP S/ AHPS S/ AHPH SChapter 1 | Important information6
Transport
AHP S/ AHPS S/ AHPH S should be transported and
stored vertically in a dry place. However, the
AHP S/ AHPS S/ AHPH S may be carefully laid on its
back when being moved into a building.
R
0
R
0
Assembly
• The accumulator tank may only be installed vertically.
• The area where the AHP S/ AHPS S/ AHPH S is loc-
ated must be frost-proof and equipped with a floor
drain.
• Position AHP S/ AHPS S/ AHPH S on a firm base that
can take the weight, preferably on a concrete floor or
foundation. Use the accumulator tank's adjustable
feet to obtain a horizontal and stable set-up.
30 - 50 mm
30 - 50 mm
15 - 40 mm
20-55 mm
Supplied components
AHPS S300
2x straight connection Ø
22xG1
3x plug Ø 22
1x straight connection Ø
22xG¾
LOCATION
The kit of supplied items is placed on top of the product.
7Chapter 2 | Delivery and handlingAHP S/ AHPS S/ AHPH S
2 Delivery and handling
Removing the covers
FRONT COVER
UN
1. Disconnect the front cover at the top edge and pull
it straight out.
2. Lift the front cover upwards.
SIDE COVERS
UN
UN
UN
The side covers can be removed to facilitate the install-
ation.
1. Remove the screws from the upper and lower
edges.
2. Twist the cover slightly outward.
3. Move the hatch backwards and slightly to the side.
4. Pull the cover to one side.
5. Pull the hatch forwards.
AHP S/ AHPS S/ AHPH SChapter 2 | Delivery and handling8
AHPS300 AHPSS300
LEK
LEK
LEK
LEK
XL8 XL4 XL3 XL9 XL5
UA1
FR1
UA2
PF1
XL8 XL4 XL3 XL9
UA1
Sv PDB
UA2
Givarkabeldragning
Denna bild används för ?
PZ3
XL3XL4XL8 XL8XL13 XL14XL45 XL46 XL9XL45
UL
UA2
UA1
PZ1
XL19
UL
UA2
UA3
UA1
PZ1
XL19QM1
BT6
9Chapter 3 | Accumulator tank designAHP S/ AHPS S/ AHPH S
3 Accumulator tank design
AHPHS300
UA2
UA1
XL3XL4XL9XL46XL8PZ1
XL19
BT6
Pipe connections
Connection, cold waterXL3
Connection, hot waterXL4
Docking connection, supply line (from heat pump*)XL8
Docking connection, return line (to heat pump*)XL9
Connection, supply line (from solar heating system)XL13
Connection, return line (to solar heating system)XL14
Docking connection, return line high temperature
(to external heat source)
XL19
Docking connection, level 1XL45
Docking connection, level 2XL46
HVAC components
Drain valve, heating mediumQM1
Submerged tube for hot water sensor (BT7) (display)UA1
Submerged tube for hot water sensor (BT6) (control)UA2
Submerged tube for solar sensor (control)UA3
Electrical components
Hot water sensor (control)BT6
Miscellaneous
Rating platePZ1
Serial number platePZ3
Adjustable feetUL
*or another external heat source
Designations in component locations according to
standard IEC 81346-1 and 81346-2.
AHP S/ AHPS S/ AHPH SChapter 3 | Accumulator tank design10
