Hardware requirements
Update-Backup-Analysis FST-2XT FST-2XTs 9
3.2 CopyingtheFSTrmwareupdatetotheFST-2XT
►Save existing conguration:
»Save the conguration le internally
„4.1 Saving / loading the conguration internally on the FST“ on page 11.
If necessary, also:
»Save the conguration le on the USB stick.
„4.2 Saving the conguration on the USB stick, loading from the USB stick“ on page 11
►Use the controller fuse to switch the control system OFF and ON.
►Set the Auxiliary Mode switch of the FST-2XT to ON.
►Plug the USB stick with the rmware update into port X41 of the FST-2XT.
The message USBStick OK appears briey on the screen.
►In the menu of the FST controller, call up MAIN MENU/System/Update FST.
This menu item is only displayed if the USB stick is plugged in.
►Select option Upd. f. USBStick.
►Select YES to start the update.
After a few seconds, the FST-2XT update screen appears.
The update may take up to 4 minutes.
Following a successful update, the message UPDATE COMPLETE appears briey on the screen.
If the update could not be completed successfully:
e.g., if the FST controller restarts immediately after briey displaying the update screen:
►Use the controller fuse to switch the control system OFF and ON.
►Repeat update procedure.
The FST-2XT restarts following a successful update.
►Check the software version by pressing the SHIFT + ENTER buttons.
The following information appears:
--- FST information ---
HW Vers. :XXX-XXX
SW Vers. :V2.000 - XXXX
:tt/mm/jjjj
Boot Ver. :X.X.X.XX
DRV Vers. :XXXX
If the displayed SW version or the DRV version does not match the current software version:
repeat the update process.
►Press the ENTER button to exit the menu item again.
