New Holland BigBaler PLUS Guide de l'utilisateur

BigBaler PLUS

Quick Operation Guide

Contents

General Overview……………………………………………………………………1

Drawbar Adjustment………………………………………………………………2

Pick Up setup………..……………………………………..........................3-4

Pre-Compression……………………………………………………………………5

Bale Formation………………………………………………………………………6

Operating Indicators………………………………………………………………7

Operating Tips……………………………………………………………………….8

Packer Cutter Machines…………..………………………………..………9-11

Rotor Cutter Machines……………..…………………………….……….12-15

Bale Compression….…………………………..…………………………...16-20

Hay Dogs Inspection……………………………………………………………..21

Driveline Protection……………………………………………………………..22

Timing Marks Check……………………………………………………………..23

Needle Protection Latch Check…………………………………………….24

Knotting System Operation………………….………………………….25-27

Twine Storage………………………..……...........................................28

Trouble shooting…..…………..……...........................................28-35

Notes……………………………………………………………………………….36-38

General Overview

1. Pick up

2. Feeding and pre-compression

3. Bale compression

4. Knotting

5. Bale dropping

123

Drawbar Adjustment

Adjustment of the drawbar hitch is critical to achieve optimal crop flow pattern

for the pickup

•A = ground to hitch height

•B = ground to output PTO tractor

•Adjust the position and tighten the bolts to 304—335 Nm

Note: the correct drawbar hitch height will depend on the model type and tyre

configuration. Refer to the Operators Manual, Section 4—Drawbar connection

and adjustment

The mounting position of the housing of the

mid-ship-bearing differs in functions of the

machine type and tires installed. There is 5

different positions- Please see operator

manual.

Pick Up Setup - Weight

Set the correct pick-up height and flotation.

The minimum tine to ground clearance is

25mm Avoid crop contamination with the

ground

Adjust flotation to give 30 –50kg of pick-up

down force.

The crop is continuously picked-up and fed

into the machine by the pick-up assembly. The

baffle plate on the side of the pick up reel

helps guide the material into the machine.

Four centering augers move the material from

the ends of the pick-up into the feeding

system.

Retract the cylinder and lower the pickup to

the ground.

Remove the special tool (1) from the cylinder

body (held in place by two wing-nuts) and

insert the tool horizontally into the shield

slots (7).

Raise the pickup and the special tool (1) will

hold the spring in the position you have

selected

Relocate the spring force setting collar (5) to

the position that best suites your machine

Lower the pickup until the special tool is free

Remove the special tool (1) from the shield

slots (7) and attach it back onto the cylinder

body using the two wing-nuts. 5

Pick Up Setup - Height

Gauge wheel adjustment

To position the gauge wheels proceed as follows:

•Put the machine on level ground and lower the pick-up.

•Turn the pickup reel manually until pick-up tines (1) of one bar are positioned in

their lowest position.

•Adjust the pickup gauge wheels (2) so

that the pickup tines (1) clear the

ground by a minimum of 30 mm

(1.18 in). In uneven or stony ground

conditions, adjust the gauge wheels

to provide 50 – 80 mm (2.0 – 3.1 in)

between the ground and the pickup

tines, depending on crop and field

conditions.

To adjust the height of the gauge

wheels, simply pull on the locking

pin (1) and select the required hole

for working height.

Pre-Compression

Set the stuffer lever 2—3 notches from the rear for silage and gradually

move the lever forward as the crop becomes drier

Note: The setting of the stuffer trip linkage determines the size of the

slice injected into the bale chamber and depends on crop conditions

Bale Formation

Number of Slices

Each slice wants to be 2 ½ - 3” in thickness

For a 5ft silage bale = 60 inches = 20 –24 slices per bale

For an 8ft straw bale = 96 inches = 32 –38 slices per bale

Main Screen

1. Information screen - This area displays the information of process and status of

the machine.

2. Menu bar - Displays a variety of buttons for operator selection. An arrow denotes

more lines are available above or below those shown.

3. Select implement key - Select the “Application Grid select” button to view and

choose from a grid of icons for all ISOBUS devices. If a camera is installed use this

button to switch to it.

4. Next implement key - Used to switch to the next ISOBUS device of which the

baler can be one.

5. VT screen - Select this button to view the active implement.

6. Home screen - Select this button and you will return to the home screen.

7. Job - Current active job.

8. Alarms/faults - Active alarms and/or faults.

9. The text at the bottom of the “ISOBUS” screen identifies the active application.

Screen Layout

Operating Indicators

Pre-charge Operating Indicators

•SmartFill™II system (drive direction indicators)

(1)

•No (colored) arrows shown: sufficient fill of the

precompression chamber, keep driving straight

over the center of the windrow.

•Green = suggestion of slight steering correction

•Light orange = recommend steering correction.

When staying too long in this zone, chance of

bale deformation.

•Dark orange = pay attention, strongly

recommend immediate steering correction

When staying too long in this zone, chance of

bale deformation

•Red = immediate steering correction needed,

chance of bale deformation and twine snap.

Capacity indicator (2)

•The capacity indication is the ratio between the

number of plunger strokes per stuffer stroke.
