Netvox R313W Manuel utilisateur

Model：R313W

Wireless Water Leak Sensor

R313W

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology and is issued in strict

confidential and shall not be disclosed to others parties in whole or in parts without written permission of NETVOX Technology.

The specifications are subjected to change without prior notice.

Table of Content

1. Introduction.............................................................................................................................................................2

2. Appearance..............................................................................................................................................................2

3. Main Features..........................................................................................................................................................3

4. Set up Instruction ....................................................................................................................................................3

5. Data Report .............................................................................................................................................................4

6. Installation...............................................................................................................................................................8

7. Important Maintenance Instruction.........................................................................................................................9

1. Introduction

Netvox water leak sensor R313W is a LoRaWAN device compatible with LoRaWAN protocol (ClassA). When the R313W sensor

detects a leak, it will send an alarm message to the gateway. When the sensor detects no leaks, it will send a message that shows

no leak to the gateway.

LoRa Wireless Technology:

LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other

communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.

Widely used in long-distance, low-data wireless communications. For example, automatic meter reading, building automation

equipment, wireless security systems, industrial monitoring. Main features include small size, low power consumption,

transmission distance, anti-interference ability and so on.

LoRaWAN:

LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and

gateways from different manufacturers.

2. Appearance

Indicator

Water Leak Sensor

Function Key

3. Main Features

Compatible with LoRaWAN

2 sections of 3V CR2450 button battery power supply

Detectable voltage and water leak status

Simple operation and setting

Protection level IP30

Compatible with LoRaWANTM Class A

Frequency hopping spread spectrum technology

Configuration parameters can be configured through third-party software platforms, data can be read and alarms can be set via

SMS text and email (optional)

Available third-party platform: Actility / ThingPark, TTN, MyDevices/Cayenne

Low power consumption and long battery life

4.Set up Instruction

On/Off

Power on Insert batteries. (users may need a screwdriver to open);

insert two sections of 3V CR2450 button batteries and close the battery cover.)

Turn on Press any function key till green and red indicator flashes once.

Turn off (Restore to factory setting) Press and hold both function keys for 5 seconds till green indicator flashes for 20 times.

Power off Remove Batteries.

Note:

1. Remove and insert the battery; the device memorizes previous on/off state by default.

2. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor

inductance and other energy storage components.

3. Press any function key and insert batteries at the same time; it will enter engineer testing

mode.

Network Joining

Never joined the network

Turn on the device to search the network.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Had joined the network

Turn on the device to search the previous network.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Fail to join the network

(when the device is on)

Suggest to check the device verification information on the gateway with your platform

server provider.

Function Key

Press and hold for 5 seconds

Restore to factory setting / Turn off

The green indicator flashes for 20 times: success

The green indicator remains off: fail

Press once The device is in the network: green indicator flashes once and sends a report

The device is not in the network: green indicator remains off

Sleeping Mode

The device is on and in the

network

Sleeping period: Min Interval.

When the reportchange exceeds setting value or the state changes: send a data report

according to Min Interval.

Low Voltage Warning

Low Voltage

2.4V

5. Data Report

When the device is turned on, it will immediately send a version package.

The transmission frequency of sending version package is once every 24 hours.

Data will be reported once per hour by default setting.

Default setting:

Maximum time: 3600s

Minimum time: 3600s

Battery: 0x01 (0.1V)

R313W sensor is triggered:

When the R313W status changes, it will send warning report.

No water leak:0

Water leak:1

Note:

The reported data is decoded by the Netvox LoRaWAN Application Command document and

http://www.netvox.com.cn:8888/page/index

Data report configuration and sending period are as following:

FPort：0x07

Bytes 1 1 Var (Fix =9 Bytes)

CmdID DeviceType NetvoxPayLoadData

CmdID– 1 byte

DeviceType– 1 byte – Device Type of Device

NetvoxPayLoadData– var bytes (Max=9bytes)

（1）Configure R313W device parameters:

MinTime = 1min、MaxTime = 1min、BatteryChange = 0.1v

Downlink：0106003C003C0100000000 003C(Hex) = 60(Dec)

Device returns：

8106000000000000000000（Configuration success）

8106010000000000000000（Configuration failed）

Min Interval

(Unit:second)

Max Interval

(Unit:second) Reportable Change Current Change≥

Reportable Change

Current Change＜

Reportable Change

Any number between

1~65535

Any number between

1~65535 Can not be 0. Report

per Min Interval

Report

per Max Interval

Description Device Cmd

Device

Type NetvoxPayLoadData

Config

ReportReq

R313W

0x01

0x06

MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

BatteryChange

(1byte Unit:0.1v)

Reserved

(4Bytes,Fixed

0x00)

Config

ReportRsp 0x81 Status

(0x00_success)

Reserved

(8Bytes,Fixed 0x00)

ReadConfig

ReportReq 0x02 Reserved

(9Bytes,Fixed 0x00)

ReadConfig

ReportRsp 0x82 MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

BatteryChange

(1byte Unit:0.1v)

Reserved

(4Bytes,Fixed

0x00)

（2）Read R313W device parameters:

Downlink：0206000000000000000000

Device returns：

8206003C003C0100000000（Current configuration）

Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V

Max Time Max Time

Sleeping (Min Time) Sleeping (Min Time)

1H 2H 3H

Note:

MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BatteryVoltageChange

value.

Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

Sleeping (MinTime) sleeping sleeping sleeping

0H 15th M 30th M 45th M 1H 2H

Wakes up and

collects data

2.8V

Does not report

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORT 2.8V

Wake up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

2.8V

Does not report

Wakes up and

collects data

2.8V

Does not report

Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

sleeping sleeping ...

0H 15th M 30th M 45th M 1H 1H 10th M 1H 25th M 1H 40th M 1H 55th M 2H 10th M

Notes:

1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect

data.

2) The data collected is compared with the last data reported. If the data change value is greater than the ReportableChange value,

the device reports according to MinTime interval. If the data variation is not greater than the last data reported, the device

reports according to MaxTime interval.

3)We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up

frequently and the battery will be drained soon.

4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle

of MinTime / MaxTime calculation is started.

Wakes up and

collects data

REPORTS

2.8V

Wakes up and

collects data

2.7V |2.7-2.8|=0.1

REPORTS 2.7V

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data 2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

REPORTS

2.7V

Wakes up and

collects data

2.8V

Does not report

Users push the button,

REPORTS 2.7V.

Recalculate MaxTime.

6. Installation

(1) This product does not have a waterproof function. After the screening is completed, please place it indoors.

(2) T

1. Remove the 3M glue on the back of the magnet body

and attach the body to the door frame (please do not stick

it on the rough door to avoid falling off after using the

device for a long time).

Note:

Wipe the door clean before installation to avoid dust

on the door and affect the adhesion of the device.

Do not install the device in a metal shielded box or

other electrical equipment around it to avoid affecting

the wireless transmission of the device.

2. Remove the 3M glue from the bottom of the sensor

probe and attach it to a flat ground position where it may

accumulate water leaks. As shown in the enlarged view

on the right.

The figure shows that the water immersion sensor (R313W) is

used in bathing rooms where there is a possibility of water

leakage in the pipeline.

It can also be applied to the following scenarios:

Data center and computer room

Document storage center

Basement leak monitoring

Water pipe leak detection

Bilge monitoring

The device is designed to detect water leaks and is not suitable

for detecting hazardous chemicals, solvents, oils, fuels, strong

acids or other corrosive liquids.

3.When the sensor probe detects a leak, the flood sensor

device will send an "alarm" message.

Remove the probe from the accumulated leak location;

dry the remaining water inside the sensor. The device is

back to a "normal" state, and send a "normal" status

message.

(2) The battery installation method is shown in the figure below (battery with "+" facing outward).

Note: To install the battery, use a screwdriver or similar tool to assist in opening the battery cover.

7. Important Maintenance Instruction

Kindly pay attention to the following in order to achieve the best maintenance of the product:

• Keep the device dry. Rain, moisture, or any liquid, might contain minerals and thus corrode electronic circuits. If the device gets

wet, please dry it completely.

• Do not use or store the device in dusty or dirty environment. It might damage its detachable parts and electronic components.

• Do not store the device under excessive heat condition. High temperature can shorten the life of electronic devices, destroy

batteries, and deform or melt some plastic parts.

• Do not store the device in places that are too cold. Otherwise, when the temperature rises to normal temperature, moisture will

form inside, which will destroy the board.

• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate

structures.

• Do not clean the device with strong chemicals, detergents or strong detergents.

• Do not apply the device with paint. Smudges might block in the device and affect the operation.

• Do not throw the battery into the fire, or the battery will explode. Damaged batteries may also explode.

All of the above applies to your device, battery and accessories. If any device is not working properly,

please take it to the nearest authorized service facility for repair.

Table des matières

Autres manuels netvox Capteur de sécurité

netvox

netvox ZB11D Manuel utilisateur

netvox

netvox R718WB Manuel utilisateur

netvox

netvox R718WAA Manuel utilisateur

netvox

netvox R311CB Manuel utilisateur

netvox

netvox R311W Manuel utilisateur

netvox

netvox Z801TXB Manuel utilisateur

netvox

netvox RA0708 Manuel utilisateur

netvox

netvox RA08D Series Manuel utilisateur

netvox

netvox R313CC Manuel utilisateur

netvox

netvox R718WB2 Manuel utilisateur

netvox

netvox ZB11C Manuel utilisateur

netvox

netvox RA08B Series Manuel utilisateur

netvox

netvox R718WB2 Manuel utilisateur

netvox

netvox S31501 Manuel utilisateur

netvox

netvox R313WA Manuel utilisateur

netvox

netvox R718WA2 Manuel utilisateur

netvox

netvox RA02C Manuel utilisateur

netvox

netvox R718WB2 Manuel utilisateur

netvox

netvox R311A Manuel utilisateur

netvox

netvox R718PA7 Manuel utilisateur

netvox

netvox R313A Manuel utilisateur

netvox

netvox R718B Manuel utilisateur

netvox

netvox R718WB Manuel utilisateur

netvox

netvox RA08D Series Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur

netvox R313W Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques
