NETkom MC55 Manuel utilisateur

Netkom MC55 Terminal

User Guide

Cinterionwireless modules by embedded

Safety information

Radio devices have limitations in the

vicinity of electronic devices:

Switch the Terminal off when you are in•

a hospital or near medical devices like

pacemakers or hearing aids. The Terminal

may interfere with the operation of

these devices.

Switch the Terminal off when ﬂying.•

Secure it so that it cannot be switched

on inadvertently.

Switch the Terminal off when you•

are near petrol stations, fuel depots,

chemical plants or blasting operations.

TheTerminal can disturb the operation of

technical equipment.

Interference can occur if the device is•

used near televisions, radios or PCs.

In order to avoid possible damage,•

we recommend that you only use the

speciﬁed accessories.These have been

tested and shown to work well with the

Terminal. However, the warranty does

not cover these accessories.

The warranty does not apply in the

event of improper use.

Contents

Safety information..............................................3

Contents................................................................4

Front view .................................................. 6

Rear view ................................................... 6

Overview...............................................................6

Product description............................................7

Highlights................................................... 8

Applications ............................................... 8

Highlights................................................... 9

SMS ........................................................... 9

Certiﬁcation................................................ 9

Features................................................................9

Data ......................................................... 10

Fax............................................................ 10

Supplementary services .......................... 10

External interfaces................................... 10

Accessories.............................................. 10

Package contents / scope of delivery.......11

Safety and installation information ..........11

Installation..........................................................11

Plug-in power supply unit ........................ 12

Interface description .......................................12

Antenna connector SMA ......................... 19

RS232 interface ....................................... 21

Switching on modem ............................... 24

Startup ................................................................24

Switching off ........................................... 25

Operating states / LED.....................................27

POWER DOWN ........................................ 28

Network search ....................................... 29

Contents

Standby Netkom MC55 terminal............. 29

DataTransfer Netkom MC55 ................... 29

terminal.................................................... 29

AT command control........................................30

SW update .........................................................30

Firmware.............................................................30

Maintenance tips..................................... 31

Certiﬁcation.............................................. 31

Certiﬁcation / maintenance............................31

Overview

Front view

Rear view

LED display Plug-in

power

SIM card

holder

RS232 interface

(9-pin D-Sub)

Antenna

connector

Product description

The Netkom MC55 terminal is a compact

GSM/GPRS modem for the transfer of

data, SMS and faxes in GSM networks.

The Netkom MC55 terminal supports

the GPRS standard and thus permits a

far higher data transmission rate up to 86

kbps. Packet-oriented data transmission

and a permanent online connection enable

rapid data access and transmission rates.

Industrial standard interfaces and an

integrated SIM card reader mean it can be

used rapidly, easily and universally as a tri-

band GSM/GPRS modem. Its performance

band width and the robust housing

make it easier to quickly implement new

applications in areas such as telemetry

and telematics.

The features, functions and interfaces of

the terminal Netkom MC55 are described

below.

The functionality of the terminal

corresponds to the features of the MC55i

module, to which a SIM card reader, an

RS232 interface and a greater supply

voltage range have been added.

All the external interfaces of the modem

are integrated permanently in the housing.

The plug-in connections are standardised

and suitable for use under vibration.

Product description

Quad-band GSM 850/900/1800/1900•

Data, SMS and fax•

Easy to integrate•

Industrial interfaces•

LED display•

Wide input voltage range•

Highly compact, light and powerful•

GPRS multi-slot class 12•

SIM application tool kit•

Highlights

Applications Fleet management•

Teleservice•

Security systems•

Telematics•

Telemetry•

Remote monitoring•

Remote meter reading•

Vending machines•

Mobile ofﬁce•

Features

Quad-band 850/900/1800/1900 MHz•

Output performance:•

Class 4 (2 W) for EGSM850-

Class 4 (2 W) for EGSM900-

Class 1 (1 W) for GSM1800-

Class 1 (1 W) for GSM1900-

Control via AT commands•

Input voltage range +8 V ... +30 V•

Dimensions: 53 x 76 x 30 mm•

Weight: approx. 115 g•

GPRS multi slot class 12•

Full PBCCH support•

Compliant to GSM phase 2/2+•

Mobile station class B•

SIM application tool kit•

Highlights

Certiﬁcation

SMS Point-to-point MT and MO•

SMS cell broadcast•

Text and PDU mode•

Transmission of SMS alternatively over•

CSD or GPRS

Features

CSD up to 14.4 kbps•

USSD•

Non-transparent mode•

V.110, RLP•

GPRS: max.86kbps (downlink)•

Coding scheme CS 1, 2, 3, 4•

Data

Fax Group 3, class 1•

Supplementary

services

Phone book•

Multiparty•

External interfaces Connector for plug-in power supply unit•

SIM card holder•

Antenna connector SMA•

RS232 interface (V.24/V.28 on the•

Sub-D socket)

Accessories Antenna GSM•

Power supply unit•

RS232 cable•
