NETkom ES75 Manuel utilisateur

Netkom ES75Terminal

User Guide

www.nwm.pl

Cinterion

wireless modules by embedded

www.nwm.pl

Safety information

Radio devices have limitations in the

vicinity of electronic devices:

Switch the Terminal off when you are in•

a hospital or near medical devices like

pacemakers or hearing aids.TheTerminal

may interfere with the operation of

these devices.

Switch the Terminal off when ﬂying.•

Secure it so that it cannot be switched

on inadvertently.

Switch the Terminal off when you•

are near petrol stations, fuel depots,

chemical plants or blasting operations.

TheTerminal can disturb the operation of

technical equipment.

Interference can occur if the device is•

used near televisions, radios or PCs.

In order to avoid possible damage,•

we recommend that you only use the

speciﬁed accessories.These have been

tested and shown to work well with the

Terminal. However, the warranty does

not cover these accessories.

The warranty does not apply in the

event of improper use.

www.nwm.pl

Contents

Safety information..............................................3

Contents................................................................4

Front view .................................................. 6

Rear view ................................................... 6

Overview...............................................................6

Product description............................................7

Highlights................................................... 8

Applications ............................................... 8

Highlights................................................... 9

Certiﬁcation................................................ 9

SMS ........................................................... 9

Features................................................................9

Data ......................................................... 10

Fax............................................................ 10

Supplementary services .......................... 10

External interfaces................................... 10

Accessories.............................................. 10

Package contents / scope of delivery.......11

Safety and installation information ..........11

Installation..........................................................11

Plug-in power supply unit ........................ 12

Interface description .......................................12

Antenna connector SMA ......................... 19

RS232 interface ....................................... 21

Mini USB interface................................... 24

Switching on modem ............................... 25

Startup ................................................................25

Switching off ........................................... 26

Operating states / LED.....................................28

POWER DOWN ........................................ 29

www.nwm.pl

Contents

Network search ....................................... 30

Standby Netkom ES75 terminal .............. 30

DataTransfer Netkom ES75 terminal ...... 30

AT command control........................................31

Maintenance tips..................................... 32

Certiﬁcation.............................................. 32

Certiﬁcation / maintenance............................32

Contact................................................................34

Headquarters..............................................34

Distributors..................................................34

www.nwm.pl

Overview

Front view

Rear view

RS232 interface

(9-pin D-Sub)

Antenna

connector miniUSB

connector

LED display Plug-in

power

SIM card

holder

www.nwm.pl

Product description

The Netkom ES75 terminal is a compact

GSM/GPRS/EDGE modem for the transfer

of data, SMS and faxes in GSM networks.

The Netkom ES75 terminal supports the

EDGE standard and thus permits a far

higher data transmission rate up to 236.8

kbps. Packet-oriented data transmission

and a permanent online connection enable

rapid data access and transmission rates.

Industrial standard interfaces and an

integrated SIM card reader mean it can

be used rapidly, easily and universally

as a quad band GSM/GPRS modem.

Its performance band width and the

robust housing make it easier to quickly

implement new applications in areas such

as telemetry and telematics.

The features, functions and interfaces of

the modem Netkom ES75 are described

below.

The functionality of the modem

corresponds to the features of the MC75

module, to which a SIM card reader, an

RS232 interface, an mini USB interface

and a greater supply voltage range have

been added.

All the external interfaces of the modem

are integrated permanently in the housing.

The plug-in connections are standardised

and suitable for use under vibration.

www.nwm.pl

Product description

Quad-band GSM 850/900/1800/1900•

Data, SMS and fax•

R&TTE approval, GCF approval•

Easy to integrate•

Industrial interfaces•

LED display•

Wide input voltage range•

Highly compact, light and powerful•

GPRS multi-slot class 12•

EGPRS multi-slot class 12•

SIM application tool kit•

Highlights

Applications Fleet management•

Teleservice•

Security systems•

Telematics•

Telemetry•

Remote monitoring•

Remote meter reading•

Vending machines•

Mobile ofﬁce•

www.nwm.pl

Features

Quad-band 850/900/1800/1900 MHz•

Output performance:•

Class 4 (2 W) for EGSM850-

Class 4 (2 W) for EGSM900-

Class 1 (1 W) for GSM1800-

Class 1 (1 W) for GSM1900-

Class E2 for EGSM850 8-PSK-

Class E2 for EGSM900 8-PSK-

Class E2 for EGSM1800 8-PSK-

Class E2 for EGSM1900 8-PSK-

Control via AT commands•

Input voltage range +8 V ... +30 V•

Dimensions: 53 x 76 x 30 mm•

Weight: approx. 110 g•

GPRS multi slot class 12•

Full PBCCH support•

EGPRS multi slot class 12•

Mobile station class B•

SIM application tool kit•

RLS Monitor (Jamming Detection)•

Highlights

Certiﬁcation R&TTE approval•

GCF approval•

SMS Point-to-point MT and MO•

SMS cell broadcast•

Text and PDU mode•

Transmission of SMS alternatively over•

CSD or GPRS

www.nwm.pl

Features

CSD up to 14.4 kbps•

USSD•

Non-transparent mode•

V.110, RLP•

GPRS: max. 86kbps (downlink)•

EDGE: max. 236.8 kbps (downlink)•

Coding scheme CS 1, 2, 3, 4•

PPP-stack•

Data

Fax Group 3, class 1•

Supplementary

services

Phone book•

Multiparty•

External interfaces Connector for plug-in power supply unit•

SIM card holder•

Antenna connector SMA•

RS232 interface (V.24/V.28 on the•

Sub-D socket)

Mini USB 2.0 interface•

Accessories Antenna GSM•

Power supply units•

RS232 cables•

USB cables•
