NETGEAR GS116v2 Manuel utilisateur

Installation Guide

16-Port Gigabit Ethernet Unmanaged Switch

Model GS116v2

Package Contents

• Gigabit Ethernet switch

• Power adapter (varies by region)

• Installation guide

Note: You can wall mount the switch. A wall-mount kit is not included.

3. Check the LEDs

When you connect the power adapter to the switch and plug it into an electrical

outlet, the LEDs indicate the status.

LED Description

Power • On. The switch is receiving power.

• Off. The switch is not receiving power.

Port

(left and right)

• Both LEDs are solid green. 1000 Mbps link on this port.

• Left LED is solid green. 100 Mbps link on this port.

• Right LED is solid green. 10 Mbps link on this port.

• Blinking green. The port is sending or receiving trafc.

• Off. The switch does not detect a link on this port.

1. Register with the NETGEAR Insight app

Use the NETGEAR Insight App to register your switch, activate your warranty, and

access support.

1. On your iOS or Android mobile device, visit the app store, search for

NETGEAR Insight, and download the latest app.

2. Open the NETGEAR Insight app.

3. If you did not set up a NETGEAR account, tap Create NETGEAR Account

and follow the onscreen instructions.

4. Tap the menu in the upper-left corner to open it.

5. Tap REGISTER ANY NETGEAR DEVICE.

6. Enter the serial number located on the bottom of the switch, or use the

camera on your mobile device or tablet to scan the serial number bar code.

7. Tap Go.

8. Tap View Device to add the switch to a network.

The switch is registered and added to your account.

2. Connect the switch

Internet

Router

ReadyNAS

Sample connections

GS116v2

Desktop

Smart TV

Access point

Gaming console

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

NETGEAR INTERNATIONAL LTD

Floor 1, Building 3,

University Technology Centre

Curraheen Road, Cork,

T12EF21, Ireland

are trademarks of NETGEAR, Inc. Any non‑NETGEAR

trademarks are used for reference purposes only.

Support

Thank you for purchasing this NETGEAR product. You can visit

https://www.netgear.com/support/ to register your product, get help, access the

latest downloads and user manuals, and join our community. We recommend

that you use only ofcial NETGEAR support resources.

Si ce produit est vendu au Canada, vous pouvez accéder à ce document en

français canadien à https://www.netgear.com/support/download/.

(If this product is sold in Canada, you can access this document in Canadian

French at https://www.netgear.com/support/download/.)

For regulatory compliance information including the EU Declaration of

Conformity, visit https://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Do not use this device outdoors. If you connect cables or devices that are

outdoors to this device, see https://kb.netgear.com/000057103 for safety and

warranty information.

June 2019

Technical Specications

Specications Description

Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or

1000BASE-T

Network cable We recommend that you use Category 5e (Cat 5e)

cable or higher for Gigabit Ethernet connections.

Ports 16

Power adapter 12W max. and 12V@ 1A DC input

Power consumption 9.5W max

Weight 1.973 lb. (895 g)

Dimensions (W x D x H) 11.26 in. x 3.98 in. x 1.06 in

(286 mm x 101 mm x 27 mm)

Operating temperature 32 to 122° F (0 to 50° C)

Operating humidity 10% to 90% relative humidity, non-condensing
