NETGEAR D6200 Manuel utilisateur

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

December 2012

Support

Thank you for selecting NETGEAR products.

After installing your device, locate the serial number on the label

of your product and use it to register your product at

https://my.netgear.com.

You must register your product before you can use NETGEAR

telephone support. NETGEAR recommends registering your

product through the NETGEAR web site.

Phone (US only): 1-888-NETGEAR

Phone (Other Countries):

See http://support.netgear.com/general/contact/default.aspx.

NETGEAR recommends that you use only the official NETGEAR

support resources.

D6200 WiFi DSL Modem Router

Installation Guide

Package Contents

The box should contain the following items. If any items are

incorrect, missing, or damaged, contact your NETGEAR dealer.

Ethernet cable

Power adapter

D6200 Modem

Filter/splitter

Phone cable

Router

The filter or splitter

provided depends

on the region.

1. ADSL Internet 2. Computer

3. Power

4. Open browser

You can use this diagram to connect your modem router to ADSL or cable/fiber modem, or you can follow the

or cable/fiber

modem*

instructions in this booklet.

After power on, wait for

the WiFi LED to turn blue.

If the web page does not display,

close and reopen the browser to

http://routerlogin.net in the address

bar. Enter the user name admin

and the password password.

*Note: Connect to the telephone line for ADSL Internet or to the cable/fiber modem from the Gigabit Ethernet WAN port.

User Manual

You can get the user manual online at

http://downloadcenter.netgear.com or through a link in the product’s user

interface.

Compliance

For the complete EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

NETGEAR, the NETGEAR logo, and Connect with Innovation are

trademarks and/or registered trademarks of NETGEAR, Inc. and/or its

subsidiaries in the United States and/or other countries. Information is

Intended for indoor use only in all EU member states, EFTA states, and

Switzerland.

Contents

Before You Begin (DSL Connection). . . . . . . . . . . . . . . . . . . . . 2

Install Your Modem Router . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 4

1. Connect the router to your Internet service. . . . . . . . . . . 4

2. Power on your router.. . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. Connect a computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4. Open a web browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Preset Wireless Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Wireless Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . 8

Join the Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

WPS Method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Manual Method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Access the Router to Make Changes . . . . . . . . . . . . . . . . . . . . 10

NETGEAR genie App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

NETGEAR genie Mobile App . . . . . . . . . . . . . . . . . . . . . . 12

ReadySHARE Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

ReadySHARE Printer . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . 14

Control Center Configuration . . . . . . . . . . . . . . . . . . . . . . 16

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Before You Begin (DSL Connection)

If you are connecting to a DSL line, make sure that your DSL service

is active before you install the modem router. You need the

information listed here to install your DSL modem and connect to the

Internet. Locate it and have it on hand before you start the installation

procedure.

•DSL user name and password. These are included in the

welcome letter your DSL Internet service provider (ISP) sent you

when you signed up for your service. Record your DSL Internet

service account user name and password here:

User name:

Password:

•Your telephone number or DSL account number. If you do not

have voice service, you can use your DSL account number in

place of a phone number.

If you do not know or cannot locate your user name and

password, call your DSL Internet service provider.

Be specific when speaking with your DSL Internet service

provider. For example, you could say:

I need my DSL service user name and password. Can you help

me?

Note: If your provider says that they do not support NETGEAR

devices, tell them you need only your DSL user name and

password; you do not need support.

DSL Internet Service Provider Phone Number

AT&T DSL (not AT&T U-Verse) 877-722-3755

AT&T/BellSouth DSL (not AT&T U-Verse) 888-321-2375

CenturyLink 800-809-1410

Covad DSL 888-642-6823

EarthLink 888-829-8466

Qwest 800-247-7285

SureWest 888-639-1611

TDS DSL Support 866-571-6662

US Family 800-300-4256

Verizon 800-567-6789

Windstream 877-901-4692

Install Your Modem Router

Note: Keep your modem router in a vertical position.

1. Connect the router to your Internet service.

You can connect either directly to a DSL line or to a fiber/cable

modem.

To connect to a DSL line:

a. Install an ADSL microfilter between the phone line and the

phone.

b. Connect the ADSL port of the modem router to the ADSL

port of the microfilter

c. Use an ADSL microfilter for every phone line in the house if

your modem router and telephone connect to the same

phone line.

Plugs into the ADSL line

To connect to a cable/fiber modem:

Connect one end of the yellow Ethernet cable to the WAN port on

the router, and connect the other end to your cable/fiber modem.

2. Power on your router.

a. Connect the power adapter to the router, and plug the power

adapter into an outlet.

b. Wait until the WiFi LED turns solid blue.

3. Connect a computer.

You can use an Ethernet cable or connect wirelessly.

• Use an Ethernet cable (not provided) to connect your

computer to an Ethernet port on your router.

• Connect wirelessly by using the preset wireless security

settings on the label on the bottom of the router.

4. Open a web browser.

The NETGEAR genie installation wizard displays.

D6200

If you do not see the genie screen, close and reopen the browser,

and enter http://routerlogin.net in the address bar. See

Troubleshooting on page 17.

5. Click Next to allow the genie to help you. Follow the steps to set up

your Internet connection.

Note for DSL: If your DSL Internet service requires a user name

or password, you are prompted to enter this information. If you do

not have this information, contact your Internet service provider

(see Before You Begin (DSL Connection) on page 2).

Preset Wireless Security

This product has a unique WiFi network name (SSID) and network

key (password). The default SSID and password are uniquely

generated for every device, like a serial number, to protect and

maximize your wireless security. This information is on the label on

the bottom of the product.

The WiFi network name (SSID) and password are here.

NETGEAR recommends that you do not change the preset SSID and

password. If you do change the settings, the security SSID or

password on the bottom of the product no longer apply.

Note: Your network name (SSID) and password are case-sensitive.

Your network name, security method, and password need to be the

same for all the wireless devices that are connected to your router on

a network.

Wireless Network Settings

Record the default preset wireless settings that are printed on the

label in the spaces here for easy reference.

2.4 GHz WiFi network name (SSID):

2.4 GHz network key (password):

5 GHz WiFi network name (SSID):

5 GHz network key (password):

If you change the default settings, record them here for easy

reference, and then store this booklet in a safe place:

2.4 GHz WiFi network name (SSID):

2.4 GHz network key (password):

5 GHz WiFi network name (SSID):

5 GHz network key (Password):

To retrieve or update your wireless password, type

http://www.routerlogin.net in a web browser and log in using the

default user name (admin) and password (password).

Select Basic > Wireless Settings to locate your wireless passwords.
