10/100 Mbps ETHERNET SWITCH

CORPORATE SERIES

Product Code: NP2240

The high-speed network switch your business needs

CHECK THESE GREAT FEATURES

sing intelligent networking technology, NetComm’s ProSwitch

pinpoints the exact recipient of a packet of data and delivers that

data directly to it, whereas an ordinary network hub simply

“sprays” the data to everyone, clogging up the system with

network traffic.

NetComm’s workgroup ProSwitch provides 24 high-speed

10/100Mbps Fast Ethernet ports capable of automatically

sensing the line speed and negotiating the operation mode with

any connected node.

The 24-port ProSwitch uses Store-&-Forward switching along

with back pressure flow control for half and full duplex modes,

thus preventing packet loss.

To further increase reliability and up-time, Netcomm has utilised the

latest in low power IC circuit design to reduce component count and

eliminate the need for an internal cooling fan – making ProSwitch the

quietest switch available.

Easy to install and use

NetComm’s self-powered ProSwitch is so smart it’s a pleasure to

install. And, once installed, you never need approach it again.

ProSwitch has been designed to be a full Plug & Play solution with

no drivers to install so installation is quick and simple.

Complies with IEEE802.3, IEEE802.3u, IEEE802.3x

Supports most popular Ether et protocols

I ter al power supply a d durable metal case

I tegrated address Look-Up E gi e, supports

8K absolute MAC addresses

24 high performa ce 10/100Mbps half/

full duplex auto-se si g switchi g ports

Wire speed receptio & tra smissio

Sta dard 19-i ch rack-mou t desig

Supports 2.5MB RAM for data bufferi g

Auto MDI/MDI-X for each port

10/100 Mbps ETHERNET SWITCH

CORPORATE SERIES

Standard IEEE 802.3 10BASE-T

IEEE 802.3u 100BASE-TX

Network Media Ethernet: TP Cat. 3,4,5, EIA/TIA-568

100-ohm screened twisted-pair (STP)a

Fast Ethernet: TP Cat. 5, EIA/TIA-568

100-ohm screened twisted-pair (STP)

Protocol CSMA/CD

Topology Star

Number o ports 24 x 10/100Mbps Auto-negotiation &

Auto-MDIX ports

Data trans er rate Ethernet: 10 Mbps (half duplex)

20 Mbps (full duplex)

Fast Ethernet: 100 Mbps (half duplex)

200 Mbps (full duplex)

Data RAM bu ers 2.5MBytes per device

Filtering address table 8K entries per device

Diagnostic LEDs Per Unit: Power

Per Port: 100 Mbps, Link/Activity

Collision/Full-duplex

Power 100-240 VAC, 50-60Hz

Power consumption 10 watts (max)

Dimensions 440 x 140 x 44 mm (W x H x D)

Temperature Operating: 0˚ to 50˚C

Storage: -10˚ to 70˚C

Humidity Operating: 10 to 90 RH

Storage: 5% to 90% RH

Emission FCC Class A, C-Tick,

CE mark Class A

VCCLA

TECHNICAL SPECIFICATIONS

• 24-port 10/100BASE Ethernet Switch with

RJ-45 connectors

• Support Auto-negotiation for speed and duplex modes

for each port

• Supports Auto-MDI/MDI-X for each port

• Wire speed reception and transmission

• Store-and-Forward switching method

• Integrated address Look- p Engine, supports 8K

absolute MAC addresses

• Supports 2.5Mbytes RAM for data buffering

• Front-panel diagnostic LEDs

• Broadcast storm protection

• IEEE 802.3x flow control for full-duplex

• Back pressure flow control for half-duplex

• Standard 19-inch rack-mount design

FEATURES

• ProSwitch 24-Port

• Quick Start Guide

• 240 volt AC power cord

• Self-adhesive rubber feet

• 19-inch rack mount kit

• Warranty Card

PACKAGE CONTENTS

1year warranty out of the box.

Extra 2years FREE with online

registration at www.netcomm.com.au

*Conditional upon registration online.

3 YEAR WARRANTY

Your Netcomm dealer: NetComm is Australia’s dynamic data communications and

networking solutions provider. For more in ormation on this and

other NetComm products, please visit www.netcomm.com.au

NetComm Ltd ABN 85 002 490 486

P Box 1200, Lane Cove NSW 2066 Australia.

PHONE (02) 9424 2070 • FAX (02) 9424 2010

www.netcomm.com.au • EMAIL [email protected]

Trademarks and registered trademarks are the property of NetComm Ltd or

their respective owners. Specifications are subject to change without

notice. Images shown may vary slightly from the product.
