QUICK START GUIDE

NetCommWireless

NF8AC

VDSL / ADSL AC1600

WiFi Gigabit Modem Router

THANKS FOR PURCHASING

NETCOMM WIRELESS

This quick start guide is designed to get you up and running quickly with your new router. More

advanced set up instructions can be found in the user manual which can be downloaded from

from www.netcommwireless.com

SETTING UP YOUR ROUTER

1. Take the supplied power adapter and attach it to the Power socket on the rear of the

router. Connect the other end of the power adapter to a wall plug power source.

2. Connect the supplied RJ-11 telephone cable to the DSL port on the rear panel of the

router and then connect the other end of the cable to the telephone wall socket.

3. Press the Power button located on the left-side panel of the router so that it is ON. The

Power LED on the front panel of the router lights up green when the unit is correctly

powered on.

Connecting to the router using an Ethernet cable

4. Connect the yellow Ethernet cable provided to one of the yellow LAN ports on the

back of the NF8AC router.

5. Connect the other end of the yellow Ethernet cable to your computer.

CONNECTING THE ROUTER TO THE INTERNET

1. After establishing a connection to the router using the previous

steps, open your Web browser and type http://192.168.20.1 into the

address bar at the top of the web browser window and press Enter.

2. Enter admin into both the username and password elds and click

Login. The Device Info page is displayed.

3. Click the Basic Setup link on the left to congure your Internet

connection.

1

2

54

3

VDSL / ADSL AC1600 WiFi Gigabit Modem Router - NF8AC

Using ADSL

a. Select ADSL and click the Next button.

b. Select the WAN mode (PPPoE or PPPoA) and click the Next button.

c. In the User ID and Password elds, enter the Username and Password provided to you

by your Internet Service Provider. In most cases, the VPI should remain at 8 and the VCI

at 35. Do not change these values unless your Internet Service Provider has instructed

you to do so. Click the Finish button.

Using VDSL

a. Select VDSL and click the Next button.

QSG-00052 rev1

b. In the User ID and Password elds, enter the username and password assigned to you

by your Internet Service Provider (ISP).

c. Click the Finish button when you have entered the required details. The router connects

to the internet using the credentials you provided. This can take up to 2 minutes. When a

connection is made, the Internet LED on the front of the unit illuminates.

Using the WAN port

The blue WAN port on the back of your router can be use to connect to a Fibre broadband

connection, please refer to the Product User Guide for information on conguring this port.

CONNECTING YOUR WIRELESS DEVICES TO

THE ROUTER

The router comes shipped with the wireless function enabled so there is no conguration

necessary in order to use the wireless function.

1. Ensure WiFi is enabled on your device (e.g. computer/smartphone/gaming console).

2. Scan for wireless networks in your area and connect to the network name that matches

the Wireless network name found on the Wireless Security Card (included in the box).

3. When prompted for your wireless security settings, enter the Wireless security key listed

on your Wireless Security Card.

If you wish to disable the wireless function, change the default network name or password you

will need to change the settings on the wireless setup pages. You can nd instructions for

this in the user guide.

Wireless Security Card

Wireless Network Name (SSID) Wireless Security Key

11N - 11N -

11AC - 11AC -
