NetComm NL1901ACV Manuel utilisateur

Enhanced Hybrid 4G LTE Gateway

NL1901ACV - QUICK START GUIDE

WELCOME

Thank you for choosing a NetComm NL1901ACV Enhanced Hybrid 4G LTE

Gateway. This guide will help you set up, connect and congure your device quickly

and easily.

TABLE OF

CONTENTS

PACKAGE CONTENTS 2

PRE-REQUISITES 4

SETTING UP YOUR GATEWAY

ADSL CONNECTIONS 4

VDSL CONNECTIONS 6

ETHERNET CONNECTIONS 8

LOGGING INTO THE WEB INTERFACE 10

CONFIGURING THE GATEWAY FOR USE 11

WITH AN INTERNET SERVICE

ADSL 12

VDSL 14

ETHERNET WAN 16

MOBILE NETWORK 20

CONNECTING WIRELESS DEVICES 21

CHANGING THE WIRELESS PASSWORD 22

CHANGING THE ADMINISTRATOR PASSWORD 24

1. 1 x NetComm NL1901ACV

Enhanced Hybrid 4G LTE Gateway

2. 2 x 4G/LTE antennas

3. 1 x RJ45 Ethernet cable

4. 1 x RJ11 Telephone cable

5. 1 x Power supply (12V/2A)

6. 1 x WiFi Security card

7. 1 x Warranty card

8. Quick Start Guide

PACKAGE

CONTENTS

PRE-REQUISITES

If you are using a voice service on the same line as the DSL

service, you will need a DSL line lter for each handset or back-

to-base home alarm system on the line. If you have a Naked

DSL service, line lters are not required. To use the 4G backup

feature, you will need an active SIM card in 2FF format.

1. Connect the supplied RJ11 cable to the “modem” port of your DSL line lter and then connect the other end to

the DSL port on the back of the NL1901ACV. Connect the DSL line lter (not included) to the wall socket and

then connect your handset to the “phone” port of the lter.

2. Connect the supplied RJ45 Ethernet cable from one of the yellow Ethernet ports (1-4) on the back of the

NL1901ACV to your computer.

3. If you intend to use a cellular connection as a backup, insert a SIM card (in 2FF format) in the direction shown

in the diagram on the next page, then attach the 4G/LTE antennas by turning them in a clockwise direction

on the antenna sockets, as shown in the diagram on the next page.

4. Connect the included power adapter to the Power jack of the NL1901ACV and then plug it into an available

wall socket. Press the ON/OFF button to power the router on. The Power light illuminates in red. When the

NL1901ACV has nished booting up, the Power light turns green.

SETTING UP YOUR

GATEWAY

ADSL Connections

= Optional Elements

1. Connect the supplied RJ11 cable to the “modem” port of your DSL line lter and then connect the other end to

the DSL port on the back of the NL1901ACV. Connect the DSL line lter (not included) to the wall socket.

2. Connect the supplied RJ45 Ethernet cable from one of the yellow Ethernet ports (1-4) on the back of the

NL1901ACV to your computer.

3. If you intend to use a cellular connection as a backup, insert a SIM card (in 2FF format) in the direction shown

in the diagram on the next page, then attach the 4G/LTE antennas by turning them in a clockwise direction

on the antenna sockets, as shown in the diagram on the next page.

4. Connect the included power adapter to the Power jack of the NL1901ACV and then plug it into an available

wall socket. Press the ON/OFF button to power the router on. The Power light illuminates in red. When the

NL1901ACV has nished booting up, the Power light turns green.

SETTING UP YOUR

GATEWAY

VDSL Connections

= Optional Elements

1. Connect a straight-through Ethernet cable to the blue WAN port on the back of the NL1901ACV and then

connect the other end to your upstream gateway device, e.g. an FTTP gateway or HFC cable modem.

2. Connect the supplied RJ45 Ethernet cable from one of the yellow Ethernet ports (1-4) on the back of the

NL1901ACV to your computer.

3. If you intend to use a cellular connection as a backup, insert a SIM card (in 2FF format) in the direction shown

in the diagram on the next page, then attach the 4G/LTE antennas by turning them in a clockwise direction

on the antenna sockets, as shown in the diagram on the next page.

4. Connect the included power adapter to the Power jack of the NL1901ACV and then plug it into an available

wall socket. Press the ON/OFF button to power the router on. The Power light illuminates in red. When the

NL1901ACV has nished booting up, the Power light turns green.

SETTING UP YOUR

GATEWAY

Ethernet Connections
