OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

Content

Purpose and Function..............................................................................................................................4
Technical specifications..........................................................................................................................5
Design...........................................................................................................................................................6
Installation...................................................................................................................................................7
Setting the tracker.....................................................................................................................................8
1 Connecting to the Configurator......................................................................................................8
2 Setting using commands...............................................................................................................10
3 Setting the connection to the server...........................................................................................11
4 Setting data transmission..............................................................................................................11
5. Setting route (track) drawing ....................................................................................................12
5.1 Selecting presets of route drawing quality........................................................................12
5.2 Expert setting of tracking parameters. ...............................................................................13
6 Setting the fixation (freezing) of coordinates during the parking.......................................15
6.1 Coordinates fixation by the ignition ....................................................................................15
6.2 Coordinates fixation by speed ..............................................................................................15
7 Operation mode................................................................................................................................15
7.1 “Tracker” operation mode......................................................................................................16
7.2 “Beacon” operation mode......................................................................................................16
Connection of additional equipment..................................................................................................16
Description of commands.....................................................................................................................18
Upgrading tracker software..................................................................................................................20
1 Updating the tracker software via the configurator................................................................20
2 Updating the tracker software via the configurator using the firmware file ....................20
3 Updating the tracker software via GPRS...................................................................................21
Handling and transport regulations....................................................................................................21
Warranty obligations............................................................................................................................21
Marking and packaging .......................................................................................................................22
Disposal...................................................................................................................................................22
Scope of supply.....................................................................................................................................22
Acceptance certificate .........................................................................................................................23
Appendix A. Description of the field bits«STATUS» .........................................................................24
Appendix B. Description of transmitted parameters in Wialon ..................................25



OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

This Operation manual relates to the tracker ADM007 (hereinafter referred as tracker) and

describes the procedure of its installation and connection as well as its function and settings.

The Operation manual is designed for professionals who have familiarized themselves with

the rules of repair and installation works execution in vehicles and who have special professional

knowledge in electronic and electric equipment used on various transport means.

The tracker proper work can be guaranteed if it is installed and set by qualified professionals.

To use the tracker properly it is necessary to familiarize with the monitoring system work principles

in general and to understand the function of all its components. For this reason, it is strictly

recommended to get basic knowledge on GLONASS and GPS global navigation satellite systems

functioning, GSM network, issues related to data transmission by means of short message service

(SMS), GPRS and Internet.

OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

1 Purpose and Function

The tracker is intended for installation on a vehicle as an additional device that records the location

of the vehicle, its speed, and travel direction. View of the tracker is shown in Figure 1.

Additionally, the voltage level at the analog input is recorded. All events and conditions fixed by the

tracker are stored in its non-volatile memory.

The accumulated data is transmitted through the GSM 850/900/1800/1900 cellular network

operator using packet data transmission technology GPRS to a dedicated server with a static IP

address or domain name from which it can be received via the Internet for further analysis and

processing in a monitoring center.

The tracker can be configured in any convenient way: locally (via Bluetooth, using the

Configurator program) or remotely (by sending commands via SMS or GPRS).

To ensure data security, when the external power is turned off and the GSM network is lost, the

tracker has got a non-volatile memory. Data transmission is possible only if there is a GSM

850/900/1800/1900 cellular network supporting a packet data service (GPRS).

Figure 1 - View of the tracker (the wires are not shown)

The vehicle travel route is described in the form of separate points in time. The route point is

saved when at least one event occurs, such as:

−travel direction changes by an angle which is greater than the pre-set one;

−the straight-ahead travel is performed at a distance, which is longer than the pre-set one;

−the pre-set acceleration limit is broken;

−the time for putting the point while traveling (parking) is expired;

−device status change (see the Appendix A);

−an event occurs on analogue input.

In this way, route points can be saved with the time interval from one second to several

minutes allowing for a quality routing, recording any changes without a surfeit of information saved

in the “black box” and increase in GPRS traffic.

OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

The tracker with the GLONASS/GPS module ensures time and navigation parameters

measuring based on GLONASS and/or GPS satellites. After being connected to the power supply,

the tracker starts receiving data from satellites, locating itself, identifying speed, time, measuring

voltage in inputs and connecting to the server. After being connected to the server, the tracker

transmits thereto the data packets with the pre-set frequency or when an event occurs. If for any

reason the connection to the server fails, all the information will be saved in the tracker non-volatile

memory and transmitted as soon as the connection is restored. If there is no signal from GLONASS

and/or GPS satellites and there is GPRS connection the time is synchronized via NTP protocol with

one of the available public servers. The points will be recorded without data about location.

Data transmitted by the tracker:

⎯GMT date and time;

⎯coordinates (latitude, longitude, altitude);

⎯speed, acceleration and travel direction;

⎯number of satellites when fixing a navigation problem;

⎯precision loss factor in a horizontal plane;

⎯voltage values on analogue input;

⎯data about events occurred;

⎯device status

2 Technical specifications

⎯GLONASS/GPS receiver:

chipset: МТ3333 (MediaTek);

frequency ranges: GLONASS –L1 (СT-code), GPS - L1 (С/Аcode);

sensitivity in cold start/tracking, dBm: -149 dBm/-161dBm;

number of tracking/picking-up channels: 33/99;

positioning precision, 95% of time, not worse: 3 m

⎯Connection standard:

GSM 850/900/1800/1900, GPRS Multi-slot Class 12

⎯GSM transmitter power: 2 W

⎯Number of SIM-cards: 1 or 1 SIM-chip (optional, upon request)

⎯Number of analogue inputs: 1

- Analogue input features:

voltage measurement range: 0..58,8 V

OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

discreteness (sensitivity): 57,4 mV

input resistance: 200 kOhm

⎯Number of route records saved: at least 49 000

⎯PC connection interface: Bluetooth

⎯Operation temperature: -40..+85°С.

⎯Power voltage: +8..+45 V of unregulated direct current

⎯Current consumption (at the supply voltage 12 V):

maximum: 200 mА

average: 30 mА

⎯Dimensions: 45x25x12mm

⎯Weight: not more than 30 g.

3 Design

Functionally, the tracker consists of a microcontroller, non-volatile memory, a combined

GLONASS/GPS-, GSM-, Bluetooth module, analog input.

The GLONASS / GPS unit of the combined module is designed to receive signals from the

GLONASS / GPS satellites and determine the geographical coordinates of the receiver antenna

(latitude, longitude and altitude), as well as the exact time (GMT), speed and direction of travel.

GSM / GPRS unit of the combined module performs the following functions:

-establishment and maintenance of outgoing TCP / IP connection (data reception and transmission

in GPRS mode);

-receiving and sending SMS messages.

For information transmission, the GSM / GPRS unit of the combined module establishes and

maintains connection to the server, periodically transmitting information packets. The period of data

transfer to the server during the parking and during the movement of the vehicle is different and can

be changed by user.

Bluetooth unit of the combined module provides connection to the PC, as well as wireless

information exchange between the tracker and the configurator program ADM Configurator.

OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

To display the operating status, the tracker has 2 LED indicators: green and blue.

The green LED indicates the status of the GLONASS / GPS unit of the combined module:

-flashes three times - the GLONASS / GPS unit is on, but there is no data from it;

-flashes twice - data from the GLONASS / GPS unit received, but the coordinates are invalid;

-flashes once - the GLONASS / GPS unit has determined the time and the actual coordinates.

The blue LED indicates the status of the GSM / GPRS unit of the combined module:

- flashes three times - the GSM / GPRS unit is disabled for re-initialization;

- flashes twice - the GSM / GPRS unit is on, but there is no connection to the server;

- flashes once - the tracker has established connection to the server and successfully transmits

information packets;

- constantly shines, briefly turning off - SIM card is not available.

Three wires are put out of the tracker: red –plus of the tracker power, black - minus, yellow -

analog input. The color marking of the tracker wires is shown in Figure 2.

Figure 2 –Color marking of the tracker wires

4 Installation

The internal GLONASS/GPS and GSM antennas are used in the tracker, which allow for its

installation almost in any place of the vehicle. However, it is not recommended to install it in the

places where the received signals will be attenuated by the vehicle metallic housing, since this can

affect the tracker work quality. For a proper function of the receiver GLONASS/GPS, put the tracker

so that its sticker is directed upwards.

OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

Insert the SIM card into the holder with a deactivated PIN code request, activated data

transmission service via GPRS, SMS and sufficient balance for these services

Supply the power to the wires according to the layout in Figure 3: for the red wire - plus of the

vehicle network, for the black - minus of the vehicle network (housing, GND). When connecting the

plus of the vehicle network to the tracker, install a 2A fusible as close as possible to the point of

connection to the vehicle network, which is especially important when connecting directly to the

battery clamp.

Figure 3 –Standard connection layout of the tracker

If there is valid satellite data and an established connection to the server, the tracker will

determine the time, coordinates and transmitinformation packets to the server, which will be marked

by a single flashing of the green and blue LEDs.

It is highly recommended to conduct a preliminary test of the tracker's performance in the

laboratory, using a power supply instead of the vehicle network, providing an output voltage of 8 to

45 VDC and a current of at least 1A.

5 Setting the tracker

5.1 Connecting to the Configurator

To connect the ADM007 tracker to a personal computer using Bluetooth wireless technology, you

should do the following:

1) Bring the Bluetooth adapter of the PC to the working state;

2) Start the ADM Configurator program version not older than 2.2 (available for download at

http://neomatica.com);

3) Turn the Configurator to the Bluetooth radio connection mode. To do this, you need to select

OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

the way to connect the device by clicking on the Bluetooth icon in the upper left corner of the

Configurator, as shown in Figure 4;

Figure 4 - ADM Configurator: choosing how to connect the device

4) to supply power to the tracker ADM007;

5) if there are several active trackers ADM007 within the reach of the Bluetooth adapter of the

personal computer, select the "Select device" flag and enter the last 4 digits of IMEI in

accordance with Figure 5. If there is only one active tracker ADM007 within the reach of the

Bluetooth adapter of the personal computer, you may remove the "Select device" flag. In this

case, a random tracker will be connected from all detected;

Figure 5 - ADM Configurator in device connection standby mode

6) after a few seconds the connection between the tracker and the ADMConfigurator program

will be installed and the settings window will be displayed;

7) after the device is set or, if connection of other tracker is required, click "disable device" in

the upper right corner of the ADMConfigurator program. The configurator will go into a

standby mode, as shown in Figure 6.

OOO Neomatica. Terminal ADM007 GLONASS / GPS. Rev.1.3 dated 13.09.2019

Figure 6 - ADM Configurator: the "disable device" button

5.2 Setting using commands

The tracker is managed by commands sent via SMS, GPRS or Bluetooth. The syntax is the

same for any way of sending.

General rules for writing and sending commands:

⎯only Latin characters and punctuation may be used in commands;

⎯character case does not matter;

⎯commands transmission syntax is the same for SMS, GPRS and Bluetooth.

⎯All commands syntax: «CMD X1,…,X3», where CMD is a command, X1..X3 are commands

parameters.

⎯Commands are separated by a SPACE. Parameters are separated by commas, except for

the DN0 command which parameters are separated by a colon.

After receiving a command, the tracker executes it and sends a feedback message.

If the command parameters extend beyond the acceptable range, the tracker changes them to

the nearest acceptable values. If it is not possible to change parameters or parameters are not

enough, the tracker will answer with an error message. A command without parameters returns the

current settings.

•Sending commands using ADM Configurator program

To configure the tracker via Bluetooth, you should use the "ADM Configurator" program. If a

password different from “0” was set in the tracker then the Configurator will ask to enter the

password.

•Sending commands using SMS messages

To manage the tracker using SMS, it is necessary to send the SMS command "ADD ME 0" to

the number of the SIM card installed in the tracker, where 0 (zero) is the default password (if the

password has been changed, you should enter it instead of 0). The phone number from which this

command was sent will be authorized in the tracker. An authorization is done only once, afterwards

the tracker saves the telephone number in a non- volatile memory within its whole service life. The

Table des matières

Autres manuels Neomatica GPS

Neomatica

Neomatica ADM50 Manuel utilisateur

Neomatica

Neomatica ADM500 Manuel utilisateur

Neomatica

Neomatica ADM333 Manuel utilisateur

Neomatica

Neomatica ADM333 BLE Manuel utilisateur

Neomatica

Neomatica ADM700 3G Manuel utilisateur

Neomatica

Neomatica ADM100 Manuel utilisateur

Neomatica

Neomatica ADM333 BLE Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Garmin

Garmin SOUNDER 125 Manuel utilisateur

Garmin

Garmin DEZL 580 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Garmin

Garmin ECHOMAP PLUS Manuel utilisateur

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Garmin

Garmin 15 H Series Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

Garmin

Garmin DEZL OTR500 Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur
