NeoGate TG200 Manuel utilisateur
TG200
User Manual
Version 5.11.0.05
Yeastar Technology Co., Ltd
NeoGate User Manual
www.yeastar.com 2
Table of Contents
1. INTRODUCTION.............................................................................................................................4
1.1 Features.....................................................................................................................................4
1.2 Hardware Specification ........................................................................................................4
1.2.1 Exterior Appearance .....................................................................................................4
2. SYSTEM SET UP.............................................................................................................................7
2.1 SIM Card Placement .............................................................................................................7
2.2 Antenna Connection..............................................................................................................7
2.3 Ethernet Line Connection....................................................................................................7
2.4 Power Supply Connection ...................................................................................................7
3. NEOGATE CONFIGURATION .....................................................................................................9
3.1 Manager Login.........................................................................................................................9
3.2 GSM Settings.........................................................................................................................10
3.2.1 Module List .....................................................................................................................10
3.2.2 GSM Settings.................................................................................................................11
3.3 VoIP Settings.........................................................................................................................12
3.3.1 SIP Settings ...................................................................................................................12
3.3.2 IAX Settings...................................................................................................................15
3.3.3 Advanced Settings.......................................................................................................15
3.4 Route Settings ......................................................................................................................18
3.4.1 Outgoing Routes ..........................................................................................................18
3.4.2 Incoming Routes ..........................................................................................................20
3.4.3 Callback Settings .........................................................................................................22
3.4.4 Blacklist ...........................................................................................................................23
3.5 SMS ...........................................................................................................................................24
3.5.1 Send SMS .......................................................................................................................24
3.5.2 Sent SMS Logs..............................................................................................................25
3.5.3 Received SMS Logs .....................................................................................................25
3.6 Network Settings .................................................................................................................25
3.6.2 LAN Setting ....................................................................................................................25
3.6.2 Firewall ............................................................................................................................26
3.6.3 VLAN Settings ...............................................................................................................29
3.6.4 VPN Settings..................................................................................................................30
3.6.5 DDNS Settings ..............................................................................................................30
3.7 System Settings ...................................................................................................................31
3.7.1 Options ............................................................................................................................31
3.7.2 Password Settings .......................................................................................................32
3.7.3 Date and Time ..............................................................................................................32
3.7.4 Backup and Restore....................................................................................................33
3.7.5 Reset and Reboot ........................................................................................................33
3.7.6 Firmware Update..........................................................................................................34
NeoGate User Manual
www.yeastar.com 3
3.8 Reports ....................................................................................................................................35
3.8.1 Call Logs..........................................................................................................................35
3.8.2 System Info ...................................................................................................................35
4. APPLICATION ...............................................................................................................................37
NeoGate User Manual
www.yeastar.com 4
1. Introduction
NeoGate-GSM Gateway for Maximum Efficiency & Cost Savings
NeoGate is a device for connecting GSM Network to VoIP Network directly,
which can support two-way communication: GSM to VoIP or VoIP to GSM.
It is the best solution ever to connect IP-based telephone systems, soft switches,
and IP-PBXs to GSM network.
1.1 Features
●SIP proxy Registrar for IP phones included
●Incoming call routing
●Outgoing call routing
●SMS sending and receiving (WEB interface)
●Call Back
●LCR (Least Cost Routing)
●Top voice quality (EFR super sound)
●Simple web based configuration
●Easy to integrate
●Easy to install
1.2 Hardware Specification
1.2.1 Exterior Appearance
1) Back Side
NeoGate User Manual
www.yeastar.com 5
2) Front Side
Figure 1-1 NeoGate Front Panel Picture
NeoGate User Manual
www.yeastar.com 6
No.
Identifying
①Power
Green shining: Connected, correct function.
Green flashing: Device error.
No light: Disconnected, malfunction.
②RUN
Green Light：Indicates the server system is in working order
③Ready
Green Light：Indicates the system is ready.
④Port2
Red Light：stands for GSM port
LED –Red and Green (fast blink): GSM port is in talking.
⑤Port1
Red Light：stands for GSM port
LED –Red and Green (fast blink): GSM port is in talking.
NeoGate User Manual
www.yeastar.com 7
2. System set up
2.1 SIM Card Placement
Lift off the SIM card holder on the backside, insert the SIM card and replace
the holder, securing the latch.
Note1: Remember to set call forwarding, call barring, preferential
network(s), SMS centre and similar provider and SIM card services in your
mobile phone before inserting the SIM card in NeoGate.
Note2: Disconnect NeoGate from the power supply before inserting the SIM
cards.
2.2 Antenna Connection
NeoGate is equipped with two antenna connector for all the GSM modules.
The external antenna should always be installed vertically on a site with a
good wireless signal.
2.3 Ethernet Line Connection
NeoGate provides two 10/100M Ethernet ports with RJ45 interface and LED
indicator. Plug Ethernet line into NeoGate‟s Ethernet port, and then
connect the other end of the Ethernet line with a hub, switch, router, LAN or
WAN. Once connected, check the status of the LED indicator. A yellow LED
indicates the port is in 100M mode, if it‟s dark, the speed is 10M. Green LED
indicates the port is properly connected, if it‟s flickering, it means data
transmission.
2.4 Power Supply Connection
NeoGate utilizes the high-performance switch power, which supply the
enough voltage and electrical energy that required by NeoGate system.
AC Input: 100~240V
DC Output: 12V,1A
Please follow the steps below to connect the NeoGate unit to a power outlet:
1. Connect the small end of the power cable to the power input port on the
NeoGate User Manual
www.yeastar.com 8
NeoGate back panel, and plug the other end of the cable into a 100VAC
power outlet.
2. Check the Power LED on the front panel. A solid green LED indicates that
power is being supplied correctly.
NeoGate User Manual
www.yeastar.com 9
3. NeoGate Configuration
3.1 Manager Login
From your web browser, input the IP address of the NeoGate server.
If this is the first time you are configuring NeoGate, please use the default
settings below:
IP Address: http://192.168.5.150
Username: admin
Password: password
Figure 3-1
NeoGate User Manual
www.yeastar.com 10
3.2 GSM Settings
3.2.1 Module List
Figure 3-2
NeoGate Status Description:
Status
Idle: The port is idle.
Busy: The port is in use.
Error: The port has not inserted the SIM Card.
Signal
: No signal.
: Poor.
: Average.
: Good.
:Excellent.
