NEO ELIPSOLED 3100 MAX Manuel utilisateur

P. 1

- Neo Elipsoled MAX

USER MANUAL / MANUAL DE USUARIO

PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE

POR FAVOR LEA LAS INSTRUCCIÓNES ANTES DE USAR

ELIPSOLED

MAX

ELLIPSOIDAL LED LUMINAIRE

3100K COLOR TEMPERATURE

P. 2

Neo Elipsoled MAX -

1. OVERVIEW

English version

ELIPSOLED 3100 MAX

Ellipsoidal LED luminaire - 3100K color temperature

ELIPSOLED 3100 MAX is an ellipsoidal LED luminaire

and has a performance 50% greater than the MKII

version, which has an output similar to the classic

750W halogen xtures, with a 90Ra color reproduc-

tion. Thanks to its COB LED, Elipsoled 3100 MAX en-

ables a great energy saving and a very low heat gen-

eration, important attributes for both theater and

broadcasting. On the other hand, the luminaire has

a 16-bit dimmer with four dimming curves, strobe

effect and adjustable PWM, essential for a flicker

free operation in any given circumstances. Last but

not least, Elipsoled 3100 MAX has a wide variety of

lenses, including two zoom barrels, and is compati-

ble with the most popular lenses in the industry.

Source & Optics

• Light Source: 1 250W COB LED

• Color temperature: 3200K

• LEDs life: 50,000 hours

• Lens tubes: 5º,10º,19º,26º,36º,50º, 15-30º & 25-

50º

• Selectable refresh rate: 600Hz, 1200Hz, 2000Hz,

4000Hz & 25000Hz

Photometric data

• Luminous Flux:

• 19º: 10166 lm

• 26º: 11616 lm

• 36º: 9363 lm

• Color rendering: >90Ra

• Flux:

• 5º: 10581 Lux @ 32 . (10M)

• 10º: 4965 Lux @ 32 . (10M)

• 19º: 1724 Lux @ 32 . (10M)

• 26º: 1250 Lux @ 32 . (10M)

Eﬀects & Functions

• Dimmer: Full range 0-100% (16-bit)

• 4 dimming curves

• Strobe eect: 0-20 ashes per second

• Standard beam shutters

• Manual focus

• Flat and even light eld

• Compatible with industry standard lens tubes

• Adjustable PWM (Pulse Width Modulation) to

work icker free in any given situation

Control

• DMX channels: 1/2/3

• Operational modes: DMX, Static, Master/Slave

& On-board control

• RDM Function

Electrical

• Input voltage range: AC100–240V, 50-60Hz

• Power consumption: 250W

Physical

• LED display

• DMX connectors: 4 XLR connectors (XLR-3 In

and Out; XLR-5 In and Out)

• Power supply connectors: PowerCON® In/Out

• Cooling: Forced convection

• Dimensions: 720x380x340 mm. /

28.3x14.9x13.3 in.

• Weight: 9.6 Kg. / 21.1 Lbs.

P. 3

- Neo Elipsoled MAX

English version

IMPORTANT

• This product must be installed by a qualied

professional.

• All maintenance must be carried out by a quali-

ed electrician.

• A minumum distance of 0.5m must be maintained

between the equipment and a combustible sur-

face

• The product must always be operated in a well

ventilated area

• Do not stare directly into the LED light source.

• Always disconnect the power before carrying out

any maintenance.

• The earth must always be connected to the

ground.

• Ensure that all parts of the equipment are kept

clean and free of dust.

P. 4

Neo Elipsoled MAX -

English version

2. INSTALLATION

3. DISPLAY PANEL OPERATION

MOUNTING HANGING

POWE CONNECTIONS

The LED xture can be mounted un a hanging

position using the supporting bracket. The bracket

should be secured to the mounting truss or struc-

ture using a standard mounting clamp. Please note

that when hanging the unit a safety cable should

also be used.

• 220~240V: 7 units may be connected in series.

• 110~120V: 4 units may be connented in series.

DISPLAY OPERATION

• MENU return to the previus menu.

• ENTER enter the currently selected menu.

• UP scroll down through the current menu list or

decrease the value of the current function.

• DOWN scroll up through the current menu list

or increase the value of the current function.

QUICK-ACCESS KEYS

MENU By press and holding the MENU key when at

the main menu it is possible to directly access the

[DIM] function.

P. 5

- Neo Elipsoled MAX

English version

MENU MAP

P. 6

Neo Elipsoled MAX -

DIMMER DIMMING

DIMMING this menu allows the user to manually

control the intensity of the xture. Use UP or DOWN

keys to select required intensity.

RUN MODE

RUN MODE this menu allows the user to select the

operating mode of the xture.

English version

Select DMX for nomral DMX operation of SLAV for

slave operation

DMX ADDRESS

ADDRESS this menu allows the user to select the

start adress of the xture.

Use UP or DOWN keys to select required start

adress.

SPECIAL SETTINGS

P. 7

- Neo Elipsoled MAX

SETTING this menu allows the user to adjust key

operation settings for this xture. KEY select ON

for automatic lock-out. Password to re-enter the

display is UP + DOWN + UP + DOWN.

Select [DIM1], [DIM2], [DIM3] or [DIM4] for dierent

dimming speeds ([DIM4] is the slowest dimming

speed).

CURVE allows the user to adjust the shape of the

dmming curve. See the CURV chart to understand

more about actual dimming curves.

PERFORM this setting allows the user to select the

performance characteristics of the fixture.

LIVE mode is the default mode which balances the

requirements of output and noise.

STUDIO mode maintains extremely low noise at all

times and operates at a moderated power level.

POWER mode operates at high power for long peri-

ods of time without considerations for noise level.

SLOCK is use to lock settings menu. When SLCK

is set to ON the user must insert passcode (UP +

DOWN + UP + DOWN) in order to access the settings

English version

menu.

PERSONALITY this settings allows the user to select

DMX personality of the fixture. Refer to DMX per-

sonality charts for specific details.

DMX ERROR Choose SAVE in order to save the last

DMX data incase of DMX signal error. Choose BACK

in order to blackout in case of DMX signal error.

In order to reset custom modes to default values

select RESET.

MODE SETTING this function allows the user to se-

lect whether the fixture will send DMX data to other

fixtures during stand-alone operation. The MAST

setting allows data to be sent to other fixtures. The

SELF setting is default and will not send DMX data

to other fixtures.

PWM_RATE is PWM reflesh rate bottom, press UP/

DOWN to choose 600Hz, 1200Hz, 2000Hz, 4000Hz,

25000Hz.

NOTE with reflesh rate increase, gray rate dimmer

will be reduced (that´s means high reflesh rate, low

gray rate), when it´s 4000Hz, CV3 is invalid, when

it´s 25000Hz, CV1 CV2 CV3 are invalid, so please

lower PWM rate to increase gray rate in necessary.

CURV DIMMING

P. 8

Neo Elipsoled MAX -

4. USING A DMX512 CONTROLLER

CHANNEL ASSIGNMENT

NOTE this product have two DMX512 channel conguration: UNO, DOS, STD.P

CHANNEL VALUE FUNCTION

1 0 - 255 Dimmer

CHANNEL VALUE FUNCTION

1 0 - 255 Dimmer

2 0 - 255 Fine dimmer

CHANNEL VALUE FUNCTION

1 0 - 255 Dimmer

2 0 - 255 Fine dimmer

0 - 9 No strobe

10 - 99 Stobre (slow to fast)

100 - 109 No strobe

110 - 179 Lightning strobe (slow to fast)

180 - 189 No strobe

190 - 255 Random strobe (slow to fast)

UNO

DOS

STD.P

English version

P. 9

- Neo Elipsoled MAX

5. APPENDIX

PARTS DIAGRAM

NO ITEM

1Focus tube components (19° ED)

Focus tube components (26° ED)

Focus tube components (36° ED)

Focus tube components (50° ED)

2Handwring screw

3 Light tube components

4M10 hand shak

515 degree lens (19 in 1)

6LED board

7 Thermal switch holder

8Thermal switch

9Dirver board

10 Aerbody plastic handle

11 Display PCB

12 Fuse holder

13 PS socket (male)

14 PS socket (male)

15 Adaptor PCB

16 Fan

17 92 lens xed cover

18 92 convex 1

19 92 lens xed cover

20 Power supply

English version

P. 1 0

Neo Elipsoled MAX -

Versión Español

1. DESCRIPCIÓN

ELIPSOLED 3100 MAX

Luminaria LED elipsoidal - Temperatura color de

3100K

ELIPSOLED 3100 MAX es una luminaria LED elipsoi-

dal que tiene 1 LED COB de 250W, trabaja a 3100K y

tiene un rendimiento 50% mayor a la versión MKII,

la cual se equiparaba con los tradicionales equipos

halógenos de 750W, con una reproducción de color

de 90Ra. Gracias a su LED COB, Elipsoled 3100 MAX

posibilita un gran ahorro energético y una gene-

ración de calor muy baja, atributos importantes tanto

para teatro como para broadcasting. Por otra parte,

el equipo cuenta con dimmer de 16-bit con cuatro

curvas de dimmeo, efecto estrobo y frecuencia de

refresco seleccionable, que garantiza un funciona-

miento sin parpadeo. Por último, cabe destacar que

el Elipsoled 3100 MAX cuenta con una amplia varie-

dad de lentes, incluyendo dos zoom barrels, y que,

por otra parte, es compatible con los lentes más

populares de la industria.

Fuente & Ópticas

• Fuente de luz: 1 LED COB de 250W

• Temperatura color: 3200K

• Vida útil promedio: 50.000 horas

• Lentes: 5º,10º,19º,26º,36º,50º, 15-30º & 25-50º

• Frecuencia de refresco seleccionable: 600Hz,

1200Hz, 2000Hz, 4000Hz & 25000Hz

Datos fotométricos

Flujo lumínico:

19º: 10166 lm

26º: 11616 lm

36º: 9363 lm

Reproducción de color: >90Ra

Flux:

5º: 10581 Lux @ 10M

10º: 4965 Lux @ 10M

19º: 1724 Lux @ 10M

26º: 1250 Lux @ 10M

Efectos y funciones

• Dimmer: 0-100% (16-Bit)

• 4 curvas de dimmeo

• Efecto estrobo: 0-20 ashes por segundo

• Obturadores de haz estándar

• Foco manual

• Campo de luz plano y nivelado

• Compatible con los lentes estandar de la

industria

• PWM ajustable para trabajar sin parpadeo en

cualquier situación

Control

• Canales DMX: 1/2/3

• Modos de operación: DMX, Estático, Maestro/

Esclavo & control a bordo

• Función RDM

Eléctrico

• Rango de voltaje de entrada: AC100–240V,

50-60Hz

• Consumo de potencia: 250W

Físico

• Display LED

• Conectores DMX: 4 conectores XLR (XLR-3

entrada y salida; XLR-5 entrada y salida)

• Conectores de alimentación: PowerCON®

• Enfriamiento por convección forzada

• Dimensiones: 720x380x340 mm. /

28,3x14,9x13,3 Pulg.

• Peso: 9,6 Kg. / 21,1 Lbs.

Table des matières

Langues :

Autres manuels NEO Matériel de DJ

NEO

NEO ION 610B RGBW Manuel utilisateur

NEO

NEO PROTON IP Manuel utilisateur

NEO

NEO Proton 12 HEX USB Manuel utilisateur

NEO

NEO ELIPSOLED 5600 MAX Torch 4000 Manuel utilisateur

NEO

NEO ELIPSOLED LITE 50 Manuel utilisateur

NEO

NEO PROTON IP 7 QA Manuel utilisateur

NEO

NEO Proton 6 QUAD USB Manuel utilisateur

NEO

NEO BLINDER MKII Manuel utilisateur

NEO

NEO Ion 3715Z Manuel utilisateur

NEO

NEO ION 132 F Manuel utilisateur

NEO

NEO STORMER QUAD Manuel utilisateur

NEO

NEO PROTON IP QW ZOOM Manuel utilisateur

NEO

NEO ZOOM PANEL Manuel utilisateur

NEO

NEO FOLLOWER 15R Manuel utilisateur

NEO

NEO ION 715Z Manuel utilisateur

NEO

NEO ION 1915Z Manuel utilisateur

NEO

NEO Flex Par Manuel utilisateur

NEO

NEO NEO STRIP GOLD Manuel utilisateur

NEO

NEO ION 740Z Manuel utilisateur

NEO

NEO ION 280F Manuel utilisateur

NEO

NEO BOMBER Manuel utilisateur

NEO

NEO Ion 280 3-en-1 Manuel utilisateur

NEO

NEO Mini Panel Manuel utilisateur

NEO

NEO STEAM INFINITE 450 Manuel utilisateur

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
