NEC Nighthawk XT4100 Guide d'installation et d'utilisation

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100

V = Screen Height V = Screen Width (H) x 3/4

v 3.5

www.necvisualsystems.com Page 1 of 11

Contents

Product Description, Lens Specs, Notes and Formulas Page 1

Projection Distances and Screen Sizes

Desktop Setup Page 2

Ceiling Mount Installation Page 3

Lens Shift Adjustable Range

TL-1Z, TL-2Z and TL-4Z Lens Page 4

TL-08SF Lens Page 5

Cabinet Dimensions

Front, Bottom & Left Side Page 6

Back, Top & Right Side Page 7

Lens Dimensions Page 8

Ceiling Mount Dimensions Page 9

RS232 Control

Command Codes Page 10

Connection Page 11

Product Description

Type: 3 chip, 0.9" DLP Dimensions: 22.05"(W) x 12.13"(H) x 26.85"(D) w/o lens

Native Resolution: 1024 x 768 Weight: 94.8 lbs

Brightness: XT4100: 3500 ANSI Lumens Power Lens Shift/Power Zoom/Power Focus

XT5000/5100: 4500 ANSI Lumens

Lens Specification

TL-08SF Throw Ratio: 0.84:1 F/#: 3.0 Distortion (full offset): 1% max

Screen Sizes: 80” - 500" Lateral color error: 14 µm max

TL-1Z Throw Ratio: 1.5 - 2.5:1 F/#: 3.0 Distortion (full offset): 2% max

Screen Sizes: 80" - 500" Lateral color error: 14 µm max

TL-2Z Throw Ratio: 2.5 - 4.0:1 F/#: 3.0 Distortion (full offset): 2% max

Screen Sizes: 80" - 500" Lateral color error: 14 µm max

TL-4Z Throw Ratio: 4.0 - 7.0:1 F/#: 3.0 Distortion (full offset): 2% max

Screen Sizes: 80” - 500" Lateral color error: 14 µm max

Notes

• For screen not indicated in the tables, use formulas below.

• If the figures in the tables do not match the results of formulas, use the figures in the tables.

• The ceiling must be strong enough to support the projector and the installation must be in accordance with any local building

codes.

• Distances are in inches, for millimeters multiply by 25.4

• Distances may vary ± 5%.

Formulas

Throw Distance = Screen Width (H) x Lens Magnification H = Screen Width H = Screen Height (V) x 4/3

Screen Diagonal = Screen Height (V) x 5/3

Lens Throw Distance Formula

TL-08SF: H x 0.84

TL-1Z: (Wide) = H x 1.5 (Tele) = H x 2.5

TL-2Z: (Wide) = H x 2.5 (Tele) = H x 4.0

TL-4Z: (Wide) = H x 4.0 (Tele) = H x 7.0

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100 v 3.5

www.necvisualsystems.com Page 2 of 11

Projection Distance and Screen Size for No Offset Installation

The following shows the proper relative positions of the projector and screen.

Dimensions are in inches. For millimeters multiply by 25.4.

Desktop (no offset/optimum condition)

Throw Distance

Lens Offset from

Projector Ctr

2.87"

6.85"

Screen Ctr

Projection Distance

SF Fixed Lens Zoom Lens

TL-08SF TL-1Z TL-2Z TL-4Z

Diagonal Width (W) Height (V) 0.84:1 1.5 - 2.5 2.5 - 4.0 4.0 - 7.0

80" 64" 48" 53.8" 96" - 160" 160" - 256" 256" - 448"

100" 80" 60" 67.2" 120" - 200" 200" - 320" 320" - 560"

120" 96" 72" 80.6" 144" - 240" 240" - 384" 384" - 672"

150" 120" 90" 100.8" 180" - 300" 300" - 480" 480" - 840"

180" 144" 108" 121.0" 216" - 360" 360" - 576" 576" - 1008"

210" 168" 126" 141.1" 252" - 420" 420" - 672" 672" - 1176"

240" 192" 144" 161.3" 288" - 480" 480" - 768" 768" - 1344"

270" 216" 162" 181.4" 324" - 540" 540" - 864" 864" - 1512"

300" 240" 180" 201.6" 360" - 600" 600" - 960" 960" - 1680"

350" 280" 210" 235.2" 420" - 700" 700" - 1120" 1120" - 1960"

400" 320" 240" 268.8" 480" - 800" 800" - 1280" 1280" - 2240"

450" 360" 270" 302.4" 540" - 900 900" - 1440" 1440" - 2520"

500" 400" 300" 336.0" 600" - 1000" 1000" - 1600" 1600" - 2800"

Image Size (4:3)

Note: For screen sizes not indicated on the table, use formulas on Page 1

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100 v 3.5

www.necvisualsystems.com Page 3 of 11

Projection Distance and Screen Size for Ceiling Mount/With Offset

The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of

installation.

Dimensions are in inches. For millimeters multiply by 25.4.

Ceiling Mount/With Offset

X5.12"

Throw Distance

Lens Offset from

Ctr of Mount

2.87"

X = TL-08SF: 21.13"

TL-1Z: 17.36"

TL-2Z: 18.80"

TL-4Z: 19.01"

9.75"

Screen Ctr

Vertical Offset

Projection Distance

SF Fixed Lens Zoom Lens

TL-08SF TL-1Z TL-2Z TL-4Z

Diagonal Width (W) Height (V) 0.84:1 1.5 - 2.5 2.5 - 4.0 4.0 - 7.0

80" 64" 48" 53.8" 96" - 160" 160" - 256" 256" - 448"

100" 80" 60" 67.2" 120" - 200" 200" - 320" 320" - 560"

120" 96" 72" 80.6" 144" - 240" 240" - 384" 384" - 672"

150" 120" 90" 100.8" 180" - 300" 300" - 480" 480" - 840"

180" 144" 108" 121.0" 216" - 360" 360" - 576" 576" - 1008"

210" 168" 126" 141.1" 252" - 420" 420" - 672" 672" - 1176"

240" 192" 144" 161.3" 288" - 480" 480" - 768" 768" - 1344"

270" 216" 162" 181.4" 324" - 540" 540" - 864" 864" - 1512"

300" 240" 180" 201.6" 360" - 600" 600" - 960" 960" - 1680"

350" 280" 210" 235.2" 420" - 700" 700" - 1120" 1120" - 1960"

400" 320" 240" 268.8" 480" - 800" 800" - 1280" 1280" - 2240"

450" 360" 270" 302.4" 540" - 900 900" - 1440" 1440" - 2520"

500" 400" 300" 336.0" 600" - 1000" 1000" - 1600" 1600" - 2800"

Image Size (4:3)

Note: For screen sizes not indicated on the table, use formulas on Page 1

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100 v 3.5

www.necvisualsystems.com Page 4 of 11

Lens Shift Adjustable Range

Lens Shift Adjustable Range for Desktop and Ceiling Mount Application.

The diagram below shows the location of the image position in the lens. The lens can be shifted within the shaded area as shown

using the normal projection position as a starting point.

Maximum Possible Range for TL-1Z, TL-2Z and TL-4Z

Maximum Possible Range:

Up: 0.5V

Down: 0.32V (only if image is shifted right first)

Right: 0.3H

Left: 0.23H (only if image is shifted up first)

Normal Position

0.5V

Desktop/Front

Vertical

Max.

Note: There is a mechanical limitation to shift down without

first shifting right, and left without first shifting up. (Refer to

diagram)

H: width of projected image

V: height of projected image

Normal projection

position

0.23H 0.3H

0.5V

0.32V

Maximum Possible Range:

Up: 0.32V (only of image is shifted left first)

Down: 0.5V

Right: 0.23H (only if image is shifted down first)

Left: 0.3H

0.5V

Normal Position

Ceiling/Front

Vertical

Max.

Note: There is a mechanical limitation to shift up without first

shifting left, and right without first shifting down. (Refer to

diagram)

H: width of projected image

V: height of projected image

0.23H

0.3H

Normal projection

position

0.32V

0.5V

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100 v 3.5

www.necvisualsystems.com Page 5 of 11

Lens Shift Adjustable Range (Cont.)

Lens Shift Adjustable Range for Desktop and Ceiling Mount Application.

The diagram below shows the location of the image position in the lens. The lens can be shifted within the shaded area as shown

using the normal projection position as a starting point.

Fixed Lens TL-08SF

Maximum Possible Range:

Up: 0.15V

Down: 0.15V

Right: 0.08H

Left: 0.08H

Normal Position

Max. 0.15V

Desktop/Front

Vertical

Note: There is a mechanical limitation to shift down without

first shifting right, and left without first shifting up. (Refer to

diagram)

H: width of projected image

V: height of projected image

0.08H 0.08H

0.15V

Normal Projection

position

Note: To reduce the distortion of an image, it is recommended that the projector is horizontally positioned at a projection

angle of 0 degrees.

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100

12.83

6.85

12.444.92

1.971.97 4.33 10.08

1.18

12.13

26.85

18.11

5.55

18.11

8 - M5

For Mount

v 3.5

www.necvisualsystems.com Page 6 of 11

Cabinet Dimensions

The following drawings show the cabinet dimensions.

Dimensions are in inches. For millimeters multiply by 25.4.

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100

19.92

1.40 2.13

v 3.5

www.necvisualsystems.com Page 7 of 11

Cabinet Dimensions (continued)

The following drawings show the cabinet dimensions.

Dimensions are in inches. For millimeters multiply by 25.4.

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100

2.95

Ø5.91

4.39

Ø4.67

4.60

Ø4.72

6.72

Ø8.19

v 3.5

www.necvisualsystems.com Page 8 of 11

Lens Dimensions

The following drawings show the lenses mounted on the projector.

Dimensions are in inches. For millimeters multiply by 25.4.

TL-1Z 1.5-2.5:1 Zoom Lens

TL-2Z 2.5-4.0:1 Zoom Lens

TL-4Z 4.0-7.0:1 Zoom Lens

TL-08SF 0.84:1 Fixed Lens

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100 v 3.5

www.necvisualsystems.com Page 9 of 11

Optional Ceiling Mount Dimensions

The following drawings show the dimensions of the Optional Ceiling Mount (Order Code XT-CMKIT).

Dimensions are in inches. For millimeters multiply by 25.4.

1.09

0.50

0.312 (2x)

∅

1.77

14.44

4.50

2.87

4.12

±3°

19.25

12.00

2.31

3.81 4.50 4.50 2.00

5.12

2.87

4.504.50

4.50

1.56

16.62

15° (360° WITH PIPE) YAW, ±6° TILT

±3° ROLL

0.75

6.00

2.25

M6 (4X)

±6°

0.87

3.12

5.87

1.37

4.12

NEC Solutions (America), Inc.

Visual Systems

Installation Data for

Nighthawk XT4100/5000/5100 v 3.5

www.necvisualsystems.com Page 10 of 11

RS232 Control / Command Codes

Standalone operation HEX CODE

POWER ON: 02 00 00 00 00 02

POWER OFF: 02 01 00 00 00 03

Input 1 RGB 1: 02 03 00 00 02 01 01 09

Input 2 RGB 2: 02 03 00 00 02 01 02 0A

Input 3 RGB 3: 02 03 00 00 02 01 03 0B

Input 4 COMPONENT: 02 03 00 00 02 01 12 1A

Input 5 VIDEO 1: 02 03 00 00 02 01 06 0E

Input 6 VIDEO 2: 02 03 00 00 02 01 07 0F

Input 7 S-VIDEO 1: 02 03 00 00 02 01 0B 13

Input 8 S-VIDEO 2: 02 03 00 00 02 01 0C 14

Input 9 RGB DIGITAL: 02 03 00 00 02 01 1A 22

Input 0 SDI: 02 03 00 00 02 01 1B 23

PICTURE MUTE ON: 02 10 00 00 00 12

PICTURE MUTE OFF: 02 11 00 00 00 13

DISPLAY MUTE ON: 02 14 00 00 00 16

DISPLAY MUTE OFF: 02 15 00 00 00 17

LENS SHUTTER ON: 02 16 00 00 00 18

LENS SHUTTER OFF: 02 17 00 00 00 19

LAMP AUTO: 03 88 00 00 02 0B 00 98

HIGH-BRIGHT: 03 88 00 00 02 0B 01 99

VARIABLE: 03 88 00 00 02 0B 02 9A


BRIGHT 03 10 00 00 05 00 FF 00 Lower Upper CKS

Adustment Value from FFE1(min) to 001F(max).

CONTRAST 03 10 00 00 05 01 FF 00 Lower Upper CKS

Adustment Value from FFE1(min) to 001F(max).

COLOR 03 10 00 00 05 02 FF 00 Value 00 CKS

Adustment Value from 00(min) to 5F(max).

HUE 03 10 00 00 05 03 FF 00 Value 00 CKS

Adustment Value from 00(min) to 3C(max).

SHARPNESS 03 10 00 00 05 04 FF 00 Value 00 CKS

Adustment Value from 00(min) to 0F(max).

V-APERTURE 03 10 00 00 05 1D FF 00 Value 00 CKS

Adustment Value from 00(min) to 0F(max).

Lower : Lower byte of Value, Upper : Upper byte of Value

CKS : Check Sum

Lower eight bits digits of sum total of the first byte to the byte just before the last.

The unit address is not checked when the unit ID has become a general notification.

Please set "0" to the unit ID and set "00" to the unit address when you use the projector under the standalone mode.

Autres manuels pour Nighthawk XT4100

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NEC Projecteur

NEC

NEC LT10 - XGA DLP Projector Manuel utilisateur

NEC

NEC PH1202HL Manuel utilisateur

NEC

NEC U321H Manuel utilisateur

NEC

NEC MT 1020G /820G Manuel utilisateur

NEC

NEC VT650 Manuel utilisateur

NEC

NEC NP01LK Manuel utilisateur

NEC

NEC PE506UL Manuel utilisateur

NEC

NEC NP-PX800X Manuel utilisateur

NEC

NEC LT157 - XGA LCD Projector Instructions de montage

NEC

NEC GT5000 Series Manuel d'utilisation et d'entretien

NEC

NEC M260X Series Manuel utilisateur

NEC

NEC NP905 Series Manuel utilisateur

NEC

NEC VE281X Manuel utilisateur

NEC

NEC LT265 - INSTALLTION GUIDE Manuel utilisateur

NEC

NEC M350X Manuel utilisateur

NEC

NEC M260WS Manuel utilisateur

NEC

NEC VT670 Series Manuel utilisateur

NEC

NEC LT180 - LT 180 XGA DLP Projector Manuel utilisateur

NEC

NEC GT5000 - XGA LCD Projector Manuel d'utilisation et d'entretien

NEC

NEC VT46 Instructions de montage

NEC

NEC VT45 Guide d'installation et d'utilisation

NEC

NEC NP510 Series Manuel utilisateur

NEC

NEC NP61 Series Manuel utilisateur

NEC

NEC NP-V260 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
