NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack 1

NEC Versa®LX, LXi, and NEC Versa Dock

Hard Disk Drive Cradle Pack

Congratulations on purchasing the NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive

Cradle Pack.

If you upgrade to a larger internal disk drive, you can



use the cradle pack to hold your original internal hard disk drive as a second drive in the

system’s VersaBay III after upgrading to a larger internal drive.



install a new hard disk drive into the cradle pack in the VersaBay III as a second hard

disk drive for the system.

Note

Before attempting to use a new hard disk drive, you must first define the fileformat for

the system (run fdisk) and format your new hard disk. For details, see the section, "Preparing

Your Hard Disk Drive" later in this document.

This document describes how to remove the system’s internal hard disk drive and install it into

the cradle pack as well as how to prepare a new hard disk drive using fdisk and format.

The cradle pack is designed to support the NEC Versa LX systems with

user-removable hard disk drives only. To be sure that you own a unit with a

user-replaceable hard disk drive, check the following.



Turn over your system. Note the label on the back of the unit, which contains the Doc

ID (model name), Model Number, and NEC Serial Number for the unit.



Look at the 14-alphanumeric characters in the model number. A unit with a user-

replaceable hard disk drive has the letter “A” in the next to last position of the model

number. An example of a model number for a unit with a user-replaceable hard disk

drive is VL210010-0000A0.

NEC Versa Hard Disk Drive Cradle Pack

Removing the Internal Hard Disk Drive

If you already upgraded the internal drive, this procedure is not necessary. This information is

also found in the documentation that came with your hard disk drive upgrade.

2NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack

The hard disk drive is located under the battery bay in your NEC Versa notebook computer. You

must remove the system’s main battery before removing the hard disk drive. Remove the hard

disk drive as follows.

1. Make sure the system is powered off and the AC adapter is disconnected.

2. Close the LCD and turn over the system.

3. Slide the battery release latch toward the back of the system and hold firmly.

A— Battery Release Latch

4. Continue to hold the battery release latch as you slide the battery out of the system.

Removing the battery

NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack 3

5. Remove the disk drive as follows:



Remove the screw that secures the hard disk drive.



Place your finger in the center notch of the hard drive lever and pull up the lever. Be

sure that both sides of the lever are raised.

Hard disk drive in the drive bay

A–Screw B–Hard Disk Drive Lever C–Hard Disk Drive



With the lever raised, place your fingers on the inside edge of the lever and on each

side of the center notch. Pull the drive toward the open side of the battery bay. Do not

apply pressure to the drive surface as you pull.

Use care when handling the hard disk drive. Hold it from the sides, do

not squeeze the drive by the top and bottom.

Disconnecting the drive



Once the drive is disconnected, use the lever to lift the drive out of the system. Once

removed, only handle the drive by its sides.

4NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack

Use care when handling the hard disk drive. Hold it from the sides, do

not squeeze the drive by the top and bottom. Do not push on the top and bottom of the drive.

To eliminate static discharge, touch a grounded metal object while handling the hard disk drive.

Lifting the drive out of the bay

Reverse the procedure to install your new hard disk drive in the system’s internal bay. Use

the screw you removed at the beginning of this procedure to secure your new hard disk

drive.

Installing the Drive in the Cradle Pack

Use the following steps to install the hard disk drive in the cradle pack.

1. Place the cradle pack as shown in the figure in step 2. The side with the screw that secures

the hard disk drive is facing up.

2. Remove the screw.

Removing the screw

A—Screw

NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack 5

3. Position the drive with the securing tab on the top. Keeping the lever raised, lower the hard

disk drive into the cradle pack. Align the drive connector with the cradle pack connector.

Lowering the drive into the cradle

A–Hard Disk Drive Lever B–Cradle Pack Connector

4. Slide the drive connector back into the cradle pack connector. Press down on both sides of

the lever to lock the drive into place. Secure the drive to the cradle with the screw.

Securing the drive

A—Hard Disk Drive Lever B—Screw

5. The cradle with the hard disk drive is ready to be inserted into the system’s VersaBay III

slot or into the NEC Versa Dock’s VersaBay III adapter bay.

6NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack

Using the NEC Versa and NEC Versa Dock

When booting the NEC Versa in the NEC Versa Dock, one of the following messages may

appear:



NVRAM bad checksum, NVRAM cleared not detected.



Resource conflict IDE hard disk not detected.



Resource conflict ATAI CD-ROM.

No action is required in response to this message. The message is cleared and the system boots

normally.

Preparing Your Hard Disk Drive

On a new hard drive, you must define your system’s file format (FAT32 for Windows 95 and

Windows 98; FAT 16 or NTFS format for Windows NT 4.0) and format the hard disk drive

before attempting to use it.

In addition, if you upgrade to a new larger hard disk drive as your primary hard disk, you need

to also load the operating system. This can be done in one of two ways as follows.



To load the operating system that originally shipped with your NEC Versa notebook

computer, use the Product Recovery CD to install the operating system. To use the

Product Recovery CD, see the section, “Using the Product Recovery CD,”in Chapter 7

of your NEC Versa user’s guide.



To load any other operating system, do so after running fdisk and format.

Follow the appropriate instructions provided here for the operating system installed on your

NEC Versa.

Note

fdisk and format must be accessed either from another hard disk or from a MS-DOS

boot diskette.

Windows 95 or Windows 98

Partition the drive as follows.

Note

Be sure to have an MS-DOS boot diskette priorto beginning these instructions. See the

Microsoft Windows documentation for details on creating this diskette.

1. Run the fdisk program.



If the new disk drive will be the primary drive for your system, you must run fdisk

from a MS-DOS boot diskette. Go to step 2.



If the new disk drive will not be used as your primary drive for your system, you can

run fdisk from the primary drive. In Windows, go to Start, Programs, and MS-DOS.

Go to step 3.

2. With the system power turned off, insert the MS-DOS boot diskette into the diskette drive,

then power on your NEC Versa notebook.

3. At the DOS prompt, type the command fdisk and press Enter.

A message appears, asking “Do you wish to enable large disk support?”

NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack 7

4. Type Yand press Enter.

The FDISK Options Menu appears.

5. Select option 5, “Change current fixed disk drive,”and press Enter.

The Change Current Fixed Disk Drive Menu appears.

6. Enter 1if the drive being partitioned is the primary hard drive or enter 2as the Fixed Disk

Drive Number if the VersaBay III hard drive is being partitioned. Press Enter.

The FDISK Options Menu appears.

7. Select option 4, “Display Partition Information,”and press Enter.

8. Verify that “Current fixed disk drive: 1 or 2”(depending on which drive to be partitioned)

appears under the Display Partition Information Menu.

9. Press Esc to continue.

10. Select option 1, “Create DOS Partition or Logical DOS drive,”and press Enter.

The Create DOS Partition or Logical DOS Drive screen appears.

11. Select option 1, “Create Primary DOS Partition,”and press Enter.

FDISK verifies the drive integrity. A message appears asking “Do you wish to use the

maximum available size for a Primary DOS Partition (Y/N)?”

12. Enter Yand press Enter to confirm that you want to use the maximum available partition

size.

FDISK verifies the drive integrity.

13. Press Esc to display the FDISK Options Menu.

14. Press Esc twice to exit to the DOS prompt.

15. Reboot the system.

Now that your drive has been partitioned, it must be formatted before use. If the drive is the

primary hard drive, boot with an MS-DOS boot diskette and format drive c (format c:). If

the drive is in the VersaBay III, follow steps 16 through 20.

16. Double click the My Computer icon to display its contents. Verify that drive D represents

your newly installed VersaBay III hard disk drive.

17. Right click the drive D icon and click Format.

18. Select Full, optionally enter a volume name in the Label field using up to11 characters, and

then click Start.

19. Verify the information given by the warning message and click OK to format the hard disk

drive.

The formatting process takes several minutes.

20. When the formatting process is complete, click Close, click OK, then click Close again.

A Windows Help screen displays giving you the option to run ScanDisk. When running

ScanDisk be sure to select drive D, the newly installed hard disk drive.

Note

Some disk compression and defragmentation programs may not work with a drive

formatted using FAT 32. Some older DOS applications and utilities may also be incompatible with

FAT 32.

8NEC Versa LX, LXi, and NEC Versa Dock Hard Disk Drive Cradle Pack

Windows NT 4.0

Windows NT®4.0 uses either the FAT 16 or NTFS format. FAT 16 can be partitioned using an

MS-DOS boot diskette with fdisk and format. NTFS must be partitioned and formatted using

Windows NT 4.0.

See the documentation supplied with your operating system for details on hard disk drive

formatting under Windows NT 4.0.

819-200611-001

12/99

'%&(#('
