NCR 7409-K332 Manuel
7409‐K332
FixedAngleMount
ImagingScanner
KitInstructions
IssueB
Revision Record
Issue Date Remarks
A Sept 2012 First Issue
B July 2013 Complete revision
1
Introduction
ThiskitprovidesanN5680ImagingScannerassemblyfortheNCRRealPOS25(7610)
andtheNCRREalPOS50(7611)terminals.Theassemblyinstallsonthefrontofthe
7409‐K035FixedAngleMount.
Components
31477
Screw, 6-32 x 0.312, PH, Ph
006-8616637
N5680 Imager
497-0476023
Imager Bracket
497-0472700
Nut, KEPS, 8-32
006-8611143
Scanner Filler Plate
497-0471591
Screw, 6-32 x 0.250, Phil, PH
006-8611016
2
Installation Procedures
1. Removethescrews(2)inthesidesoftheFixedAngleMount.
2. RestthebottomofthedisplayontheDisplaySupport.
Note: PlacetheDisplaySupportbehindtheextensiononthenDisplayHinge
Bracket.
32464
Screw
(One Each Side)
32465
Display Support
3
3. RemovetheBlankFaceplatefromtheFixedAngleMount(2screws).
4. InstalltheFaceplateandScannerAssemblyontheFixedAngleMount.
32468
Blank Face Plate Screws
32469
Face Plate and Scanner Assembly
4
5. ConnecttheUSBCabletotheterminalI/OPanel.
6. LowertheDisplaybacktotheoperatingpositionontheFixedAngleMountand
secureitwithscrews(2).
32470
USB Ports
32471
Screw
(One Each Side)
