National Electric EB-70ERC Instructions de montage
EB-70ERC
EB-70ERCD
Congratulations on choosing our appliance, which you will find is dependable and easy to use.
We recommend that you read this manual for best performance and to extend the life of your
appliance. Thank you.
Close-up View
A. Control Panel B. Knob for selecting the cooking features.
C. Knob for adjusting the cooking temperature. D. Electronic cooking programmer
E. Oven Light – When the light is on, it indicates that the oven is heating. It will turn off when the
temperature setting has been reached.
F. Glass oven door
A. Control Panel B. Knob for selecting the cooking features.
C. Knob for adjusting the cooking temperature. D. Electronic cooking programmer
E. Oven Light – When the light is on, it indicates that the oven is heating. It will turn off when the
temperature setting has been reached.
F. Glass oven door
1
How To Use YourAppliance
The＂Maxioven＂oven combines in a single appliance the advantages of traditional convection
ovens with those of modern forced air ventilation ovens. It is an extremely versatile appliance that
allows you to easily and safely choose between 9 different cooking modes. The selection of the
various functions can be obtained by putting the programmer to the manual position or setting a
beginning/end of cooking program (see specific chapter on page 5)and successively by turning the
selector (B) and thermostat (C) knobs on the control panel.
You can choose all the functions:
9 Functions
No Circle heating With Circle heating
8 Functions
No Circle heating With Circle heating
Oven light
When the selector knob is in any position other than the “0”position, the oven light comes on.
Attention: The first time you use the oven we recommend that you set the thermostat on the
highest setting and leave the oven on for about a half an hour with nothing in it. Then, open the
oven door an let the room air. The odour that is often detected during this initial use is due to the
evaporation of substances used to protect the oven during storage and until is installed.
Convection Mode
2
Set the thermostat knob (c) between 50℃and 250℃.
The outer heating elements at both the top and the bottom of the oven will come on. The heat is
distributed uniformly from top to the bottom. The convection mode is recommended for preparing
meat-based dishes featuring of liquids. It still remains the best cooking mode for dry pastries and
fruit in general. When cooking in convection mode, only use one dripping-pan or cooking rack at
a time, otherwise the heat distribution with be uneven. Select from among the various rack heights
based on the whether the dish needs more or less heat from the top or bottom.
Ventilated convection Mode
Set the thermostat knob (c) between 50℃and 250℃.
The outer heating elements at both the top and the bottom of the oven are activated, as well as the
fan. Based on the convection model, This combination of features increases the effectiveness of the
thermal radiation of the heating elements through forced air circulation of the air throughout the
oven. This helps prevents foods from burning on the surface, allowing the heat to penetrate into
the food.
Lower heating element
Set the thermostat knob (C) between 50℃and 250℃. By turning the knob to this position. The
oven light and lower heating element come on.
This position is recommended for finishing the cooking of food (in baking trays) which is already
superficially well-cooked but still soft inside.
Upper heating element
Set the thermostat knob (C) between 50℃and 250℃. By turning the knob to this position. The
oven light and upper heating element come on. This position is recommend for finishing off the
cooking of food (in baking trays) which is already inside well-cooked but still soft superficially.
Upper heating element grill
Set the thermostat knob (C) between 50℃and 250℃. The grill components and upper heating
element come on.
Grill
Important: do not set thermostat knob (C) to over 175℃. During grilling, keep the oven door
closed. Food is cooked in the grill by the downward thermal rays produced by an incandescent
electric heating element. The high, direct grill temperature immediately browns meat, thus
stopping juice dispersion and keeping meat more tender. The grill is particularly recommended for
cooking dishes requiring a high superficial temperature.
Ventilated Grill
Important: do not set thermostat knob (C) to over 175℃. During grilling, keep the oven door
closed. All grill components and fan work. In this setting, the central heating elements of the top
work. This combination of features compulsory in the air in the oven for the entire cycle of
increased non-direct heating elements heat radiation effect. This will allow the heat to penetrate
the internal food, and avoid food surface Charred.
3
Ventilated the central heating elements
Important: do not set thermostat knob (C) to over 175℃. During grilling, keep the oven door
closed. the central heating elements of the top are activated as well as the fan. This combination of
features increases the effectiveness of the thermal radiation of the heating elements through forced
air circulation of the air throughout the oven. This helps prevents foods from burning on the
surface, allowing the heat to penetrate into the food.
Maxigrill
Important: do not the thermostat knob (C) to over 175℃. During grilling, keep the oven door
closed. Both of the heating elements of the grill are activated. For more intensive grilling,select
this function.
Ventilated
Important: do not the thermostat knob (C) to over 175℃. During grilling, keep the oven door
closed. Both of the heating elements of the grill are activated, as well as the fan. This combination
of features increases the effectiveness of the thermal radiation of the heating elements through
forced air circulation of the air throughout the oven. This helps prevents foods from burning on
the surface, allowing the heat to penetrate into the food.
Ventilated Maxigrill
Important: do not the thermostat knob (C) to over 175℃. During grilling, keep the oven door
closed. Both of the heating elements of the grill are activated, as well as the fan and all grill
components. This combination of features increases the effectiveness of the thermal radiation of
the heating elements through forced air circulation of the air throughout the oven. This helps
prevents foods from burning on the surface, allowing the heat to penetrate into the food.
Gentle pastry oven
Set the thermostat knob (C) between 50℃and 250℃. The lower heating element and the fan
come on. This setting is ideal when cooking delicate foods, especially pastries that need to raise,
because the heat rising from the bottom facilitates leavening. Please note that with this feature it
takes a rather long time to reach higher temperatures in the oven. Therefore, if high temperatures
are needed, we recommend that you use the ＂Conventional＂setting.
Ventilation Mode
Set the thermostat knob (C) between 50℃and 250℃. The circular heating element and the fan
will come on. Since the heat remains constant and uniform throughout the oven, the air cooks and
browns food uniformly over its entire surface. With this mode, you can also cook various dishes at
the same time, as long as their respective cooking temperatures are the same. A maximum of 2
rack levels can be used at the same time. This cooking mode is ideal for au gratin dishes or those
which require an extended cooking time.
Moreover, the excellent heat distribution makes it possible to use lower temperatures when
cooking roasts. This results in less loss of juices, meat which is more tender and a decrease in the
loss of weigh for the roast. The ventilated mode is especially suited for cooking fish, which can be
4
prepared with the addition of a limited amount of condiments, thus maintaining their flavour and
appearance. The ventilated mode can also be used to thaw white or red meat, fish and bread by
setting the temperature to 80℃-100℃
To thaw
Select this function to thaw more delicate foods.In this mode you use only thecold air circulation.
The thermostat light (E)
This indicates that the oven is heating up. When the light goes out, the required temperature has
been reached. When the light alternately comes on and goes out, it means that the thermostat is
working properlyto maintain the oven temperature.
5
Operating instructions for Electronic Timer (3 keys)
Before using for the first time
Setting and changing the current time
The oven only operates when the time has been set.
When the appliance has been connected to
the electrical supply or when there has
been a power cut, the function indicator
Time flashes automatically.
1. To change the time that has already been
set, press the Selection button repeatedly,
until the function indicator Time flashes.
2. Set the current time using the or button
After approx. 5 seconds, the flashing stops
and the clock displays the time of day set.
The appliance is now ready to use.
The time can only be changed if neither of
the automatic functions (Cook time or
End time ) have been set.
3
STOP
STOP
STOP
STOP
3
Electronic Timer Setting (3 keys)
6
Countdown
To set a countdown, a signal sounds after the time has elapsed.
This function does not affect the operation of the oven.
Cook time
To set how long the oven is to be in use.
End time
To set when the oven is to switch off again.
Time
To set, change or check the time
(See also section “Before Using for the First Time”).
Clock Functions
Selector Button Button
Button
Time display Function IndicatorsFunction Indicators
STOP
STOP
7
How to use the clock functions
zWhen a function has been selected, the corresponding function indicator flashes for approx. 5 seconds. During
this time the desired times can be set using the or button.
zWhen the desired time has been set, the function indicator flashes for approx. another 5 seconds. After that the
function indicator is then lit. The set time begins to run.
zPress any of the buttons to stop the acoustic signal.
zThe desired oven function and temperature can be selected before or after the clock functions of Cook time
and End time are set.
zWhen the cooking time has ended, turn the oven function and temperature dial back to the OFF position.
STOP
3
Switching off the Time Display
By switching off the time display you can save energy.
Switching off the time display
Hold down any two buttons until the display becomes dark.
Switching on the time display
Hold down any button until the time reappears in the display.
The display can only be switched off if none of the clock functions Cook time End time
or Countdown are in use.
STOP
8
Countdown
1. Press Selection button repeatedly, until
the function indicator Countdown flashes.
2. Using the or button, set the required
Countdown (m ax. 2 hours 30 minutes).
After approx. 5 seconds, the display shows
the remaining time.
The function indicator Countdown will
light up.
When the time has elapsed, the function
indicator flashes and an acoustic signal
sounds for 2 minutes.
Press any button to switch off the signal.
STOP
STOP
STOP
STOP
STOP
9
