Introduction

Congratulations on your purchase of an advanced NAPCO EXPRESS XP-600 Security System. Meticulously developed

by a leading manufacturer of state-of-the-art security products, this system will provide you with unprecedented peace-of-mind &

incorporates some of the most sophisticated features available today. Above all, it has been designed an extra step, to provide

all those operating it with very easy, intuitive use. Please carefully review the information contained in this manual, so that you

and all potential users of the system familiarize yourselves with its operation, and can therefore take full advantage of EXPRESS’

many convenience features and amenities.

Your system consists of a control panel (a computer housed within a white metal panel enclosure), one or more EXPRESS

Decorator Keypads for controlling the system, and various security detection devices. These detection devices are divided

among separate areas known as “zones”, set up throughout your premises. Each zone number corresponds to a Zone light on

your Keypad’s gray display area.

When a zone’s red light is ON (or lit), it indicates that one or more detection device(s) assigned to that area are active or open.

For example, if Zone 1 is the front door, and it is open, the Zone 1 light will be on. If zone 2 is a motion detector, and there is

movement in that area, Zone light 2 will turn ON. Depending upon the actual layout your security professional has chosen to

properly protect your premises, each zone may function a little differently: The zone protecting your front door may be

programmed as an Exit/Entry zone to allow you time to enter the premises disarm the system , without inadvertently sounding

the alarm. Alternatively, a zone protecting a window could be designated as an “instant” zone, so that if it is entered or opened

while the system is on/armed, there will be an immediate alarm.

Your easy NAPCO EXPRESS Keypad puts super-simple system control at your fingertips. Most keypad commands

involve entering your four digit User Code. This includes Arming (or activating) and Disarming (or deactivating) the system.

Simply put, ARMED means the system is ON; DISARMED means the system is OFF. If the system is OFF and you want to turn

it ON, just enter your Code. To turn the system back OFF, enter your code again.

It’s easy, just always remember, in the

event of an alarm, entering your User Code will silence all Sirens.

Your keypad is your command and status center, it keeps

you informed visibly, using its zone and status lights (in the gray display area) and audibly, using its built-in keypad sounder. For

more information, please see Keypad Controls and Indicators on page 4.

Oi218a

page 2 Tuesday, September 16, 1997 08:28

1Bell / Battery Test

Test your bell or siren by pressing



followed by



.This

will cause the bell, or siren to sound for 2 seconds and also

initiate a test of the battery .

2Central Station Communication Test

(This test should only be performed on weekends or at a

time designated by your alarm company)

1. Notify Central Station of the impending test.

2. Secure all zones to light Ready Light on your keypad.

3. Enter your user code to Arm the system.

4. Violate your alarm by opening a window / door etc.

5. The siren or bell should sound and the system will send

the alarm signals to the Central Station

6. Enter you user code to silence the bell or sounder.

7. Call Central Station to insure that the alarm signals were

received properly.

Introduction

System Information

Central Station Phone Number: ____________________

Central Station Account Number: ____________________

For Service Call: ____________________

Entry Delay: ____________________

Exit Delay: ____________________

Alarm Time-out: ____________________

Important - Test Your System Weekly !

Table of Contents

Keypad Controls and Indicators ................................ 4

Arming your System (When Leaving) ....................... 5

Protecting Yourself While Home ............................... 6

Emergency Keys ....................................................... 7

Disarming the System ............................................... 8

Silencing an Alarm..................................................... 8

Resetting a Fire Alarm............................................... 8

Fire Protection .......................................................... 9

Special Functions .................................................... 11

System Troubles ....................................................... 12

Programming User Codes ......................................... 14

Glossary ................................................................... 15

Oi218a

page 3 Tuesday, September 16, 1997 08:28

$50('

5($'<

6<67(0

),5(

=21( 

=21( 

=21( 

=21( 

=21(



=21( 

ad Controls and Indicators

Read

ht will light when all zones are secure

and system is ready to be Armed.

AC Li

ht will light to indicate that AC Power

is present.

Fire Alarm Li

ht will flash and the Keypad

sounder will beep when system is in a Fire Alarm

Condition (See Silencing a fire Alarm, Page 8)

Zone Li

hts

(

1 through 6) will light to indicate

that the corresponding Zone is open, and will

flash to indicate a zone in alarm.

Armed Li

ht will light when system is Armed,

and will flash when system is in Alarm

Key - used to reset Fire Zone, clear miss-

entered codes, reset Alarm Memory, etc..

System Light will light and the Keypad sounder

will pulse to indicate that a system trouble is pre-

sent.(See System Troubles, Page12)

Key Press to display any present

System troubles. Only available when

System Light is lit.

(See System troubles, Page 12)

Emergency Keys Press

simultaneously to signal

an emergency condition.

Press )+)for Fire,

$+$for Auxiliary or

3+3for Police Emer-

gency. (Programmable)

Bypass Key Used to

bypass zones. Press

Bypass and the corre-

sponding zone number,

and then Arm system.

Key Used to enable

special functions and op-

tions. Press and then

the corresponding Spe-

cial Function number Op-

tion (See Special Func-

tions, Page 11)

Numerical Keys 1-9, 0. Used to enter

User Codes, Zone numbers, etc.

NAPCO

Oi218a

page 4 Tuesday, September 16, 1997 08:28

Arming Your System When Leaving

1Before armin

your system, make sure the Green Ready li

ht is ON. This indicates that all of your prot-

ective zones are secure. If any zones are open, the correspondin

Zone li

ht will be ON. Secure these

zones before proceedin

. If any zones cannot be secured, see Bypassin

Zones below.

2 Enter your user code. The Green Ready li

ht will

o out, the Red Armed li

ht will li

ht.

• If you make a mistake enterin

your code, press



and re-enter the code.

• If the FIRE light is on, the Fire zone has not been properly reset. Press



and enter the code.

(See Silencing a Fire Alarm, page 8)

3 Leave the premises through the Exit/Entry door. If the keypad gives a steady tone you have taken

too long. Enter your code again to disarm system and then re-enter code and leave.

Easy Arm

The Easy Arm feature allows the system to be armed by simply pressing



followed by



This will allow the easy arming of the system by someone who is not a regular system user.

Bypassing Zones

If an open zone cannot be immediately fixed it can be left unprotected, or

Bypassed

, while the rest of the

system is Armed. To Bypass a zone:

1Press



followed by the zone number to be Bypassed. The Bypassed Zone’s light will flash slowly.

2 Enter your user code. The Green Ready light will go out and the Red Armed light will light.

3 Leave the premises through the Exit/Entry door.

When the system is subsequently disarmed, all bypassed zones will be reset, ready to be armed again.

If it is necessary to bypass any inoperative zone(s), it is important to have the zone(s) repaired as soon as

possible. A bypassed zone does not provide any protection, compromising system security.

Arming Your System

FIRE

SYSTEM

READY

ZONE 3

ZONE 1

ZONE 2

ZONE 5

ZONE 6

ZONE 4

ARMED

Oi218a

page 5 Tuesday, September 16, 1997 08:28

Protecting Yourself While at Home

1 Before armin

your system, make sure the Green Ready li

ht is ON. This indicates that all of your

protective zones are secure. If any zones are open, the correspondin

Zone li

ht will be ON. Secure

those zones before proceedin

2 Enter your user code. The Green Ready li

ht will

o out, and the Red Armed li

ht will li

ht.

3Before your exit delay expires, press



to bypass any interior zones, deactivatin

devices such

as motion sensors, and allowin

free movement throu

hout the premises. The Zone li

ht of any

bypassed zones will flash slowly.

• Your system may have been pro

rammed for Automatic Interior Bypass , in which case it will reco

nize

that you have not left the premises and will automatically bypass any interior zones.

Instant Mode

Pressin



followed by



will cancel the Entry delay , activating the “Instant” mode. This is typically

done in the evening when all family members are home for the night. Instant Mode can be activated at any

time after the system has been armed. The Red Armed light will flash rapidly while in the Instant Mode.

Easy Exit (optional)

Your System may have been programmed to allow Easy Exit, which allows a user to exit the premises

with the system armed. By pressing



followed by



, the protection is removed from the Exit/ Entry

zone for 3 minutes. This will allow, for example, an early morning commuter to exit the house in the

morning, without having to disarm and rearm the system, waking the family.

Arming With a System Trouble Present (the 9System Light is Lit)

If the XP600 has a system trouble present, the

SYSTEM li

ht will be lit and the ke

pad sounder

pulsin

. If

ou cannot immediatel

clear the s

stem trouble, the s

stem can still be armed. Simpl

press



to view the trouble, press



ain to reset the trouble and then arm the s

stem.

For more information, refer to pa

e 12. Note: S

stem troubles should be repaired as soon as possible.

Armin

Your System

FIRE

SYSTEM

READY

ZONE 3

ZONE 1

ZONE 2

ZONE 5

ZONE 6

ZONE 4

ARMED

Oi218a

page 6 Tuesday, September 16, 1997 08:28

Emergency Buttons

The three sets of emergency buttons, if programmed, are always active whether the system is armed

or disarmed. Discuss these Buttons with your installer. The emergency signal will only be activated

when the two respective buttons are pressed at the same time.

Fire Alarm: Simultaneously press



to sound a fire alarm, and to alert the central

station of a fire emergency, if so programmed.

Auxiliary Alarm: Simultaneously press



to alert the central station of an auxiliary

emergency, if so programmed.

(The nature of this emergency alarm is to be determined by the installer)

Police Emergency: Simultaneously press



to sound a police emergency alarm, and to alert

the central station of a fire emergency, if so programmed.

Emergency Conditions





Fire

Emergency

Enabled?

Yes No



Auxiliary



Emergency

Enabled?

Yes No

Ambush Alarm

In the event that you are forced by an intruder to disarm your system, the ambush alarm can be

activated. Disarming the system with the Ambush Code will cause the system to disarm and

simultaneously send a silent ambush alarm signal to Central Station. If your system has the Ambush

feature enabled, the code assigned as the User 6 code will function as your Ambush Code.



Police



Emergency

Enabled?

Yes No

Ambush

Alarm

Enabled?

Yes No

Oi218a

page 7 Tuesday, September 16, 1997 08:28

Disarming Your System when Returning

1Enter your premises throu

h the Entry/Exit door. The keypad will sound a steady tone to remind you to

disarm the system before your Entry Delay time expires.

2 Enter your user code. The Red Armed li

ht will

o out, indicatin

that the system has been disarmed.

Note: If you make a mistake enterin

your code, press the



key and re-enter the code.

Alarm Indication

If the Red Armed li

ht is flashin

rapidly, an alarm occurred while you were away. Proceed with caution!

For your own protection, leave immediately and call authorities from a nei

hbor’s phone .

Silencing an Alarm

In the event that the system

oes into alarm due to a violated bur

lary zone, the bell or siren will sound and

the keypad sounder will also activate. To silence the system, enter your User code. The zone li

ht of the

zone which went into alarm will continue to flash until



is pressed to reset the alarm memory.

Silencing a Fire Alarm

In the event that the Fire alarm activates due to an violated smoke or fire detector, the bell or siren will

sound a distinct pulsatin

tone. The Red FIRE li

ht on the keypad will be flashin

, and the keypad sounder

will emit a pulsin

tone. If a Fire Alarm does occur:

1If a fire is in pro

ress, evacuate the premises immediately!Call the Fire Department from an outside phone.

2If there is no evidence of a fire, enter your User Code. The bell or siren will silence, and the FIRE li

ht on

the keypad will stop flashin

but will still be lit.

3Determine which device went into alarm. If you are protected by smoke detectors, the li

ht on the active

detector will be lit. Once it is determined which smoke detector is in alarm, press



to reset the fire zone.

4 If the Fire zone has reset properly, the FIRE li

ht on the keypad should

o out in approx. 30 seconds

If it does not

o out, press



ain in a few minutes. If the FIRE li

ht still does not

o out, call for

service.

Disarming Your System / Silencing an Alarm

FIRE

SYSTEM

READY

ZONE 3

ZONE 1

ZONE 2

ZONE 5

ZONE 6

ZONE 4

ARMED

Oi218a

page 8 Tuesday, September 16, 1997 08:28

Preparing a Fire Escape Plan

Even with the most advanced fire alarm system, adequate protection requires an escape plan.

To prepare your plan, draw floor plans of your building. (space is provided on the next page) Show two exits - a front or

back door and a window from each room. (Make sure each window works. You may need a special fire-escape ladder if

the window is high up.) Write down your outside meeting place.

Family Rehearsal

Rehearse each of the following activities:

1 Everyone in his room with the doors closed.

2 One person sounds the alarm.

3 Each person tests his door.

4 Pretend that the door is hot and use the alternate escape exit.

5 Everyone meets outdoors at the assigned spot.

Important! - Read Carefully

Discuss each of these escape procedures with all those who

use the building.

1 In a residence, sleep with the bedroom door closed.

2 When the fire alarm signals, escape quickly. Do not stop to pack.

3 Test the door. If it is hot, use your alternate route through the window.

If the door is cool, brace your shoulder against it and open it cautiously.

Be ready to slam the door if smoke or heat rushes in. Crawl through the

smoke, holding your breath. Close the doors again on leaving to help

prevent the fire from spreading.

4 Go to your specific outdoor meeting place so you can see that everyone is safe.

5 Call the Fire Department from a neighbor’s telephone.

Fire Protection

Would You Like More Safety Information?

For more information on home fire detection,

burn safety, and home fire safety, write to:

National Fire Protection Association,

Public Affairs Dept. 05A,

Batterymarch Plaza,

Quincy, MA 02269

Oi218a

page 9 Tuesday, September 16, 1997 08:28

Fire Protection

Floorplan

Draw a plan of your premises below.

Oi218a

page 10 Tuesday, September 16, 1997 08:28

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NAPCO Système de sécurité

NAPCO

NAPCO XP-400 Fiche technique

NAPCO

NAPCO MAGNUM ALERT-725 Manuel utilisateur

NAPCO

NAPCO XP-400 Express Series Manuel utilisateur

NAPCO

NAPCO F-TPG Manuel utilisateur

NAPCO

NAPCO FREEDOM - Manuel utilisateur

NAPCO

NAPCO EXPRESS XP-600 Manuel utilisateur

NAPCO

NAPCO NETLINK Manuel utilisateur

NAPCO

NAPCO Magnum Alert 1016e Manuel utilisateur

NAPCO

NAPCO MAGNUM ALERT-725 Manuel utilisateur

NAPCO

NAPCO EXPRESS XP-600 Manuel utilisateur

NAPCO

NAPCO STARLINK SL-1 FD-T Manuel utilisateur

NAPCO

NAPCO Gemini GEM-X255 Manuel utilisateur

NAPCO

NAPCO EXPRESS XP-600 Manuel utilisateur

NAPCO

NAPCO GEM-P400 Manuel utilisateur

NAPCO

NAPCO GEMINI-P400 Manuel utilisateur

NAPCO

NAPCO F-TPBR Manuel utilisateur

NAPCO

NAPCO Gemini GEM-X255 Manuel utilisateur

NAPCO

NAPCO FREEDOM64 Manuel utilisateur

NAPCO

NAPCO F64 CODED Manuel utilisateur

NAPCO

NAPCO MAGNUM ALERT 825 SYSTEM Manuel utilisateur

NAPCO

NAPCO FREEDOM - Manuel utilisateur

NAPCO

NAPCO Magnum Alert-700 Manuel utilisateur

NAPCO

NAPCO Magnum Alert-825HS Guide produit

NAPCO

NAPCO MVA-1000 Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
