MySmartBlinds AUTOMATION KIT Manuel utilisateur
User’s Manual
TM
mysmartblinds.com/installation
AUTOMATION KIT
QUICK START
1. Download the MySmart-
Blinds app to your smart
device from the App Store
or Google Play.
2. Visit www.mysmartblinds.
com/installation or
www.youtube.com/c/
mysmartblinds to access
installation and trouble-
shooting videos.
Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., reg-
istered in the U.S. and other countries. App Store is a service mark of Apple Inc.
Android, Google Play and the Google Play logo are trademarks of Google Inc.
TABLE OF CONTENTS
SAFETY INFORMATION 6
ABOUT MYSMARTBLINDS 9
BLINDS IDENTIFIER 10
PARTS IDENTIFIER 12
ROD RETENTION TYPES 13
INSTALLATION 14
USING THE APP 28
TROUBLESHOOTING 37
LIMITED WARRANTY 40
6 7
SAFETY INFORMATION
Do not use the MySmartBlinds automation kit for any-
thing other than its intended use. Any usage of any part
of this kit outside of its intended purpose is not covered
by the warranty.
CAUTION
Existing blinds may have sharp edges. Use gloves to
prevent cuts or abrasions when removing and reinstall-
ing blinds.
CAUTION
Read all warnings and instructions prior to installing
the MySmartBlinds automation kit. Failure to follow
these instructions may result in property damage or
serious personal injury.
WARNING
FCC STATEMENT:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Warning: Changes or modications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the equip-
ment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio
To prevent cable damage or abrasion, do not expose
cables to edges of sheet metal or other sharp objects.
CAUTION
Route cables away from sharp edges and moving parts.
CAUTION
8
ABOUT MYSMARTBLINDS
MySmartBlinds is a retrot blinds-automation kit that
uses Bluetooth technology to control tilting in your
existing blinds.
MySmartBlinds ts inside 2-inch horizontal
blinds* and is compatible with Apple devices running
iOS 7 or later (iPhone 4s or newer, iPad 3rd generation
or newer, iPod touch 5th generation or newer, and
Apple Watch) and Android devices with Bluetooth L.E.
support operating OS 4.3 or later.
Visit mysmartblinds.com/installation for a PDF
version of this manual.
*Compatible with 2-inch blinds between 20” and 72” wide with a mini-
mum space of 5” between barrels, or 9” between barrels if the headrail
has only two barrels (see Figures 1 and 2 on page 35). Not compatible
with cordless lift blinds.
9
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following mea-
sures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV
technician for help.
RF WARNING STATEMENT:
The device has been evaluated to meet general RF
exposure requirement. The device can be used in por-
table exposure condition without restriction.
10 11
BLINDS IDENTIFIER
Slats
Tilt rod
Barrel
Tilt mechanism
Headrail
12 13
ROD RETENTION TYPES
Version A: Rod pin
Version B: End brackets
Version C: Crimps
PARTS IDENTIFIER
Motor box (A)
Manual switch C-clip (C)
Battery pack (E)
Rod adapters (F) Cable clips (G) 4x Rubber tubing (H)
Manual switch (D)
Motor box bracket (B)
14 15
INSTALLATION
1 Removing Existing Blinds
1. Pull your blind’s cord to
raise the slats.
2. Carefully remove any
valances or trim placed
over your blinds (Fig. 1.1).
3. If your blinds use a tilt
wand, remove the wand
by sliding it out from the
hook, and set aside (Fig.
1.2).
4. Unclip the brackets at the
ends of the headrail (Fig.
1.3), and pull the headrail
out from the brackets.
5. To remove the tilt rod and
tilt mechanism, identify
the type of retention Fig. 1.3
Fig. 1.2
Fig. 1.1
device on your rod,
according to the images
on page 10:
Version A—Rod pin:
Remove the pin from the
rod (Fig. 1.4), and slide the
rod out of the headrail (or, if
your headrail is exception-
ally long, slide the rod as far
as is necessary to install the
MySmartBlinds hardware)
(Fig. 1.5). Bend the headrail
slightly away from the tilt
mechanism, and remove
the mechanism from the
headrail (Fig. 1.6).
Version B—End brackets:
Remove the brackets from
the ends of the headrail,
and slide out the tilt rod
(Fig. 1.5). Bend the headrail
slightly away from the tilt
mechanism, and remove
the mechanism from the
headrail (Fig. 1.6).
Fig. 1.4
Fig. 1.5
Fig. 1.6
16 17
Version C—Crimps:
Bend the headrail gently
away from the tilt mecha-
nism, and remove the tilt
mechanism, sliding it off the
end of the tilt rod (Fig. 1.7).
Slide the tilt rod out from the
barrels, removing it from the
headrail (Fig. 1.5).
6. If your blinds use strings
to tilt the slats, you may
need to remove the tassels
on the ends of the strings
in order to remove the tilt
mechanism. Untie the knot
inside of the tassels, slide
the tassels off of the string,
and set the tassels aside.
Fig. 1.7
2 Installing MySmartBlinds Hardware
1. Remove the manual switch C-clip (C) from the
bottom of the manual switch (D) by pressing
down on the clip’s center and sliding it out.
Remove the adhesive
lm from the manual
switch, and insert the
manual switch through
the hole previously occu-
pied by the tilt mech-
anism, making sure
the switch is properly
oriented (Fig. 2.1).
2. Pull the hook down
through the hole so
that the switch lies flat
against the bottom
surface of the headrail
(Fig. 2.2), and press
the exposed adhesive
against the front of the
headrail.
3. Lay the blind on its side, and position the C-clip
(C) beneath the manual switch (D). Press down on
Fig. 2.2
Fig. 2.1
18 19
the center of the C-clip
to flatten it, and slide the
clip underneath the man-
ual switch until the clip
locks in place (Fig. 2.3).
NOTE
HARDWARE PLACEMENT: For the following instal-
lation instructions, refer to Figures 2.4 and 2.5
to determine the best hardware placement and
installation method for your set of blinds. Spread
out the hardware as much as your headrail will
allow in order to avoid kinking the cables.
Fig. 2.4
Fig. 2.5
Fig. 2.3
4. Lay the battery pack (E)
inside the headrail so that
the cable is on the top
left side (Fig. 2.6). If your
headrail has more than
two barrels, place the bat-
tery two bays away from
the manual switch (D).
5. Connect the battery pack
(E) cable to the white
connector on the motor
box’s (A) right side (Fig
2.7).
6. Connect the manual
switch (D) cable to the
gray connector on the
motor box’s left side (Fig.
2.8).
Fig. 2.6
Fig. 2.7
Fig. 2.8
