Muratec MFX-1430 Manuel

MFX-1430/

MFX-2030

Product Demonstration Kit

MK3139

MFX-1430/MFX-2030

CONFIGURATIONS & OPTIONS

CONFIGURATIONS

The MFX-1430 comes in a standard version (1430) and as a duplex model MFX-1430D

(1430D). The MFX-2030 (2030), with standard duplex, comes in one configuration.

PAPER OPTIONS

PRINTING/

COMMUNICATIONS/

CONSUMABLES

OPTIONS

Printing Options

PCL500

PCL print

controller kit

Communication/Fax Options

AL500

DA7663

Second

fax modem

32 MB

memory

Telephone handset

2030THK

Page Counter

DA7664

Consumable Options

Toner cartridge

TS2030

Drum cartridge

DK2030

1. MFX-1430 – 550 sheets 2. Second paper cassette

(2030CAS) – 500 sheets

Total = 1,050 sheets

3. Paper cabinet (2030CAB)

2. Second paper cassette

(2030CAS) – 500 sheets

Total = 1,050 sheets

3. Paper cabinet (2030CAB)

2. Second paper cassette

(2030CAS) – 500 sheets

Total = 1,050 sheets

3. Paper cabinet (2030CAB)

MFX-1430

1. MFX-1430D – 550 sheets

1. MFX-2030 – 550 sheets

MFX-1430D:

MFX-2030:

MFX-1430 MFX-1430D MFX-2030

Standard

80-sheet ADF • • •

33.6 Kbps fax modem • • •

(1) 500-sheet cassette • • •

50-sheet bypass tray • • •

Network Printing & Color Scanning • • •

Local USB Printing & Color Scanning • • •

Duplex Print Kit • •

Optional

Paper Cabinet (2030CAB) • • •

500-Sheet Cassette (2030CAS) • • •

32 MB Memory Upgrade (DA7663) • • •

Telephone Handset (2030THK) • • •

Page Counter (DA7664) • • •

PCL Print Controller (PCL500) • • •

2nd Phone Line (AL500) • • •

OfficeBridge Expansion Kit (OB450) • • •

WHY MURATEC?

3,000 independent

office technology dealers

can’t be wrong.

They voted Muratec the top secondary product line

manufacturer in the industry. Why? Muratec focuses on

building highly reliable business-level “fax” machines

and award-winning multifunction units perfect for the

desktop or small workgroup. What’s more, other

manufacturers around the world put their own brand

name on Muratec machines.

For more information on Muratec and its products,

please log on to www.muratec.com

MFX-2830

Cannata Report

Fax Manufacturer of the Year

–

2005

Buyer’s Laboratory, Inc.

Muratec MFX-1700 –

2004 Pick of the Year

Muratec F-360 –

2002 Highly Recommended

Muratec F-320 –

2002 Highly Recommended

Muratec MFX-1200 –

2001 Recommended

Better Buys for Business

Muratec F-320 –

2002 Editor’s Choice

Muratec F-360 –

2002 Editor’s Choice

BERTL Digital Test Lab

OfficeBridge Pro –

BERTL’s Best Award –

Innovation of the Year 2005

Muratec MFX-2830 –

Recommended

Muratec MFX-1700 –

2003 BERTL’s Best

Awards: Best COHO/Satellite Office MFP

Muratec MFX-1700 –

Recommended

Business Technology

Association

2003 & 2004 Channel’s Choice Award –

Top Secondary Product Line Manufacturer

F-520

MFX-2030

WHAT IS NGP?

What is NGP?

NGP is an acronym for Network Gateway Platform, a design

on which Muratec has adopted its next generation of segment 1 and

fax products. This design has led to the development of MFP devices

with a built-in affinity for the network, meaning products seamlessly

integrate into and maximize the full potential of a corporate network environment.

What functions can I perform on NGP-enabled devices?

NGP-enabled devices are capable of:

■Color scan to network (direct SMB scanning)

■Color scan to FTP (direct or shortcut)

■Color scan to e-mail (direct or shortcut)

■Internet faxing (T.37 compliant, not T.38)

■Desktop faxing

■Traditional walk-up faxing (33.6 Kbps high-speed modem)

Without adding any additional hardware or software…

Simplistic operation

NGP-enabled products are the first segment 1 and fax-centric products to utilize a touchscreen, which

allows for intuitive user operation.

GENERAL FEATURES

80-sheet automatic document feeder

■Enables faxing, copying or scanning of large jobs without having to split into multiple sets

Intuitive touchscreen operation

■A first in this segment!

■Large, back-lit touchscreen is easy to operate and significantly reduces customers learning curve

■Program keys allow for one-touch initiation of complex fax and copy commands

■The function keys on the default screen can be customized, making commonly used functions accessible

Flexible paper capacity

■Standard 500-sheet front loading tray is accessible and user adjustable

■Optional second 500-sheet cassette allows for the simultaneous use of letter and legal-sized papers

Multipurpose bypass tray

■50-sheet bypass tray can be used for unique media such as letterhead, envelopes, labels or overhead

projector sheets

Easy network installation

■DHCP compliant (Non-DHCP environments may still enter the network settings manually)

■Print drivers can be installed via server or individual client

Duplex printing (MFX-1430D & MFX-2030)

■Reduce paper consumption and day-to-day operational costs by utilizing duplex print, copy and fax

reception capabilities

Expandable memory

■Standard 8-MB memory can be upgraded to 40-MB, creating sufficient memory storage for large

applications

■72-hour memory back-up ensures that business critical documents are not lost in the event of an

extended power outage

Energy Star compliant

■When the machine is left idle for a set period it will enter Energy Save Mode, which will reduce energy

consumption to minimum levels

EEaassyyCChhaannggeeSSMMtoner system

■Front loading high-yield consumables can be quickly changed without the need for a service call

Refined print engine

■14 and 20-ppm print engines provide superior quality and clarity

■Redesigned paper path reduces jam frequency

■Side-access jam removal system allows for quick and painless troubleshooting

Department Codes

■Track up to 100 codes for cost accounting purposes

■Extra level of security, only authorized users have access to certain machine functions

FAX FEATURES

33.6 Kbps fax modem

■Standard fax modem transmits documents at the highest regulated speeds

■JBIG compression reduces the transmission packet allowing for shorter connection times

■Up to 2 spp transmission time

300 entry address book

■Each location can house a fax number, e-mail address and group location

■Up to 30 locations can be manually entered per transmission

■330 number broadcast capabilities (fax and e-mail addresses can be mixed)

■OfficeBridge Expansion Kit allows customers to have both personal & shared address books

■OfficeBridge Expansion Kit can expand the address book to 2000 locations (w/ optional 512 MB

memory)

■Supports vCard import from Microsoft Outlook

LDAP search capabilities

■Quickly and easily locate contacts on a corporate server (Active Directory, OpenLDAP, etc.)

■Up to 5 LDAP servers can be registered

■Contacts located during an LDAP search can be added to the internal address book

Delayed transmission

■Send documents during off-peak hours to reduce machine congestion

Batch transmission

■Group several fax transmissions into one, reducing connection requirements and phone charges

Standard Internet fax functionality

■T.37 compliant – most common standard on the market

Transmission confirmation reports

■Ensures that business-critical documents reached their intended destination

Optional second 33.6 Kbps fax modem

■Allows the simultaneous sending and receiving of fax documents

ITU-I sub-address routing

■Send and receive fax documents into confidential mailboxes

SCAN FEATURES

Standard network scanning

■Surf corporate networks with ease, delivering documents directly into network folders

■High-quality 600 dpi scanning

■Create up to 20 folder shortcut keys for one-touch scan initiation (shared w/FTP shortcuts)

■Broadcast documents to an e-mail address and network folder (archive)

■Windows log-in security parameters

■Supports color scanning

Scan to e-mail

■Intuitive QWERTY keypad allows for customized e-mail transmissions

■File Formats include TIFF, PDF or JPEG

■File name, subject line and text message can be added to each transmission (SPAM prevention)

■Any document stored on the network may be attached to a transmission (simple network browse)

■Supports color scanning

Scan to FTP

■Upload documents to an FTP server for sharing or storage

■Create up to 20 FTP shortcuts for one-touch scan initiation (shared w/folder shortcuts)

■Supports color scanning

Standard local color scanning via USB

■TWAIN compliant

■High-resolution color scanner offers easy digital transfer of hardcopy photos, charts and various office

documents

PRINT FEATURES

Flexible OS support

■Windows 98SE, 2000, Me, NT 4.0, XP

■Windows Server 2003

Standard GDI-based network printing

■High-speed 10/100 BaseT Ethernet connection is the perfect solution for a small to mid-sized

workgroup

■Supports TCP/IP protocols

■RJ-45 network connection

Optional PCL support

■PCL 5e & 6

■Does not require a separate network drop, the standard NIC card can handle both GDI and PCL

commands

■Can be installed by the factory or installed as a field upgrade

Standard local GDI printing via USB

■High-speed USB 2.0 connection

Intuitive print drivers

■Seamless output from popular applications

■Server or client-based installation

■Choose watermarks, paper sources, options, etc.

Duplex print output (MFX-1430D & MFX-2030)

■Up to 5 page-per-minute duplex production

COPIER FEATURES

14 (MFX-1430) and 20 (MFX-2030) page-per-minute print engine

■Print engine produces letter-sized documents at 14 and 20 pages per minute

■600-dpi output insures high-quality digital imaging

Get the job going!

■10 second (MFX-2030) and 12 second (MFX-1430) first-copy-out-times

■23 second warm-up time

Duplex printing (MFX-1430D & MFX-2030)

■Reduce paper consumption and day-to-day operational costs by utilizing duplex print, copy and fax

reception capabilities

■Manual duplex scanning allows for 1:2, 2:2 or 2:1 output

QuadAccessTM technology

■Unique to Muratec, the MFX-1430 and MFX-2030 can simultaneously perform four tasks at once

allowing users to fax, copy and print at the same time without machine slowdown

Card Copy Mode

■Copy both sides of a driver's license, insurance card or other card-size object quickly and easily

■Does not require you to lower the platen cover prior to scanning

■Check-size documents (both personal and business size) may be copied in this mode

Digital copy features

■2-in-1 & 4-in-1 image combination

■Mixed original detection

■Digital zoom (25-400%) and image adjustment

■Electronic sorting

Programmable Macro Keys

■Conveniently program lengthy copy job processes into a single executable command

DEMONSTRATION

ORIGINALS

Apply the enclosed

Demonstration Originals

when conducting a

demo on the MFX-1430

and/or MFX-2030.

Autres manuels pour MFX-1430

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Muratec Imprimante tout-en-un

Muratec

Muratec MFX-1450 Manuel utilisateur

Muratec

Muratec MFX-1300 Manuel d'installation et d'exploitation

Muratec

Muratec MFX-C3400 Manuel utilisateur

Muratec

Muratec MFX-C2280 Manuel utilisateur

Muratec

Muratec MFX-C3035 Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE EXPANSION KIT (OB450) Manuel utilisateur

Muratec

Muratec MFX-1450 Manuel utilisateur

Muratec

Muratec MFX-2500 Manuel d'installation et d'exploitation

Muratec

Muratec MFX-2050 Manuel d'installation et d'exploitation

Muratec

Muratec MFX-2570 Manuel utilisateur

Muratec

Muratec F-525 Manuel utilisateur

Muratec

Muratec MFX-3090 Manuel utilisateur

Muratec

Muratec MFX-2550 Guide Manuel utilisateur

Muratec

Muratec MFX-C2828 Manuel utilisateur

Muratec

Muratec F-565 Manuel utilisateur

Muratec

Muratec MFX-3530 Manuel utilisateur

Muratec

Muratec MFX-1600 Manuel utilisateur

Muratec

Muratec MFX-1330 Manuel utilisateur

Muratec

Muratec MFX-1430 Manuel de l'opérateur

Muratec

Muratec MFX-2830 Manuel utilisateur

Muratec

Muratec MFX-C2500 Manuel utilisateur

Muratec

Muratec F-305 Manuel utilisateur

Muratec

Muratec F-68P Manuel utilisateur

Muratec

Muratec MFX-2590 Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur
