Muratec MFX-1820 Manuel utilisateur

Please read this guide before operating this machine.

After you finish reading this guide, keep it handy for easy reference.

Plain-paper digital Fax/Copier/Printer/Scanner

Quick Start Guide

Printed in Japan

Part Number: DC2-90310-60

http://www.muratec-europe.de

Muratec Europe GmbH

Hanns-Martin-Schleyer-Strasse3,

D-47877, Willich, Germany

Manuals for the machine

Thank you for purchasing Muratec MFX-1820.

Printed manuals and manuals in PDF format are provided with the machine. The manuals in PDF format are

stored on the driver CD-ROM.

Printed manuals

Quick Start Guide

This is a summary of the machine’s basic functions and setup. Read this before

using the machine for the ﬁrst time or when you need to know about a function.

Safety Information

This contains instructions we would like you to follow in order to use the machine

safely.

Please read carefully before you use this machine.

PDF manuals

User’s Guide

This contains more detail about functions and setup.

Read it when you need more detailed information about settings and speciﬁcations.

Printer/Scanner Driver Guide

This describes how to install the drivers for the printer and scanner and settings for the

printer. Read this when you want to use the printer or scanner features of this machine.

Barcode/OCR Font Settings Manual

This manual provides descriptions for types of barcode, character code and samples of font

usage, etc. for models equipped with the Barcode/OCR font option.

How to view the PDF ﬁles

You must have either Adobe Reader or Adobe Acrobat Reader installed on your computer in order to view or

print PDF ﬁles. Adobe Reader is a free download from the following Web site. http://www.adobe.com/

Please read this guide before operating this machine.

After you finish reading this guide, keep it handy for easy reference.

Plain-paper digital Fax/Copier/Printer/Scanner

Quick Start Guide

Others

System Settings

Printer Functions

Scanner Functions

Fax Functions

Copy Functions

Getting Started

Preface

For Your Safety

Please observe the following to prevent electric shocks and injury to people or damage to property that

may occur through misuse of this machine.

Follow the safety precautions laid out in the separate

booklet “Safety Information”

Also read “Precautions,” page 7 in this book.

Maintain regularly

At least once a year check between the plug and inlet for dust and make sure the power cord is

undamaged.

If there is a malfunction

Do the following if you detect strange noises, smells, or smoke emitting from this machine.

1. Set the power switch to OFF.

2. Unplug the power plug from the outlet.

3. Contact your authorized Muratec dealer.

Warning symbols

In this manual, the following symbols are used with the items you should observe for safety operation and

with operational important information.

Describes warnings to protect yourself and others from serious or potentially fatal injury if you handle the

machine incorrectly. For safety operation, please follow instructions carefully.

Describes cautions to protect yourself and others from personal injury or damage to properties if you

handle the machine incorrectly. For safety operation, please follow instructions carefully.

IMPORTANT

Describes important conditions or restrictions you should carefully observe to avoid problems caused by

incorrect operations.

NOTE

Describes reference information and additional notes for operations.

Regulatory Information

CE declaration of conformity

This product complies in accordance with Council Decision 1999/5/EC for pan-European single termi-

nal connection to the public switched telephone network (PSTN).

ES 203 021-1, ES 203 021-2, ES 203 021-3

EG201 120, EG201 121

IEC 60950-1 / EN 60950-1

EN 55022, EN 55024

EN 61000-3-2, EN 61000-3-3

This product has DTMF (Dial Tone Multi Frequency) dialing only. In the event of problems or ques-

tions, you should contact your equipment supplier in the ﬁrst instance.

This product complies with the COMMISSION REGULATION(EC) No.1275/2008 implementing the

EuP Directive(2005/32/EC).

RoHS declaration of conformity

This product complies with the RoHS directive (2002/95/EC).

WEEE Directive

WEEE: Waste of Electrical and Electronic Equipment law.

This Equipment is marked with the European Directive 2002/96/EC recycling symbol. It indi-

cates that at the end of the equipments life you must dispose of it separately at an appropriate

collection point.

This equipment must not be disposed of in the normal domestic unsorted waste stream.

Batteries Directive

Batteries incorporated into this equipment are disposed in an environmentally friendly manner during the

treatment phase of the equipment. For replacement batteries, please contact your authorized Muratec dealer.

ENERGY STAR®

As an En E r g y St a r

partner, Muratec has determined that this product meets the En E r g y St a r

guidelines for energy efﬁciency.

What is an En E r g y St a r

program?

The international En E r g y St a r

program is the international program to promote energy efﬁcient consumer

products. This program aims the reduction of power consumption of ofﬁce equipments, of which power are often

turned ON for a long time, from the energy saving view that “efﬁciently use the energy when needed”.

It adopts the voluntary system a manufacturer can join by its independent decision.

Acoustic Noise

Machine Noise Regulation 3 GPSGV, the sound pressure level at the operator position according to EN ISO 7779

is equal to or less than 70dB(A).

Ozone Release

Locate the machine in a well ventilated room. A negligible amount of ozone is generated during normal opera-

tion of this machine. An unpleasant odor may, however, be created in poorly ventilated rooms during extensive

machine operations.

For a comfortable, healthy, and safe operating environment, it is recommended that the room be well ventilated.

Precautions

Installing the machine

Install in a well ventilated position.

This machine produces ozone during use. The amount of ozone produced is not enough to cause harm, but ensure

there is proper ventilation when using the machine in poorly ventilated rooms over long periods, or printing in

large amounts.

IMPORTANT

•Installthemachinetokeeptheventilatingholeofthemachineatleast10cmawayfromwallsorotherde-

vices.

•Toensureproperventilationandeasyoperation,secureanadequateinstallationspacearoundthemachine.

•Useyourmachinewithinthetemperaturerangeof10°Cto32°C,thehumidityrangeof20%to80%RH.

•Avoidinstallingorusingoutdoors.

Reverse Automatic Document Feeder (RADF)

886 mm

321 mm

925 mm

296 mm

100 mm

930 mm

1217 mm

100 mm

96 mm 91 mm

Automatic Document Feeder (ADF)

881 mm

321 mm

925 mm

296 mm

100 mm

100 mm100 mm

96 mm 91 mm

896 mm

100 mm

1183 mm

Platen cover

881 mm

321 mm

925 mm

296 mm

100 mm

100 mm100 mm

90°

1166 mm

100 mm

879 mm

96 mm 91 mm

Transporting the machine

•Beforetransportingthemachine,besuretocheckthatyoudisconnecttheplugfromtheoutletandremovethe

line cable. Use at least two people to move the machine.

•Whentransportingthemachine,removethetonercartridge.

•Whentransportingthemachine,supportthepartsshowninthegurebelow.Whenyouliftthemachine,be

sure to bend your knees sufﬁciently so as not to damage your back.

Handling of consumables

Never burn or dispose of the toner cartridge or developing unit in a ﬁre. This could cause any remaining toner to

ignite, resulting in a larger ﬁre and/or burns.

Toner cartridges should not be opened with force. Leaking toner should not be inhaled. Contact with skin should

also be avoided. Cartridges should be stored out of children reach. If your skin get in contact with toner clean it

under ﬂoating water and soap. In case of skin irritation please consult a doctor.

IMPORTANT

•Donotstorethetonercartridge,developingunit,drumunitorpaperinanyofthefollowingplaces:

  •Placesexposedtore

  •Placesexposedtodirectsunlight

  •Placessubjecttohightemperatureand/orhighhumidity

  •Placessubjecttorapidtemperaturechanges

  •Dustyareas

  •Insideacar,leftforalongtime

•Donotdirectlytouchthephotoreceptorsurfaceofthedrumunit,orexposeittodirectsunlight.Thiscould

cause defects in printing quality.

•Donotleavethedrumunit,developingunit,ortonercartridgesupsidedownoronanincline.Thiscouldcause

defects in printing quality.

•Donotdisassemblethedrumunit,developingunit,ortonercartridge.

•Protectthedrumunit,developingunit,andtonercartridgefromshocksandvibration.

•Donotremovethedrumunit,developingunit,andtonercartridgefromtheirpackaginguntilyouarereadyto

use them.

Daily maintenance

•Thefuserunitandareaarounditinsidethemachineareextremelyhotwhenoperating.Whenyouclearthe

paper jam or inspect inside, be careful not to touch around the fuser unit. It may cause burns.

•Whenclearingpaperjamsorreplacingthetonercartridge,becarefulnottogettonerpowderintoyoureyes

or mouth. If the toner gets in your eyes or mouth, immediately ﬂush with clean water and seek medical assis-

tance.

•Becarefulnottostainyourhandsorclotheswiththetoner.Ifyourhandsorclothesgetstained,washthem

immediately with cold water. The stains may become permanent if washed using warm water.

•Donotperformanyoperationsnotdescribedinthismanual.

Ventilation

•Pleaseusethismachineinaplacewithgoodventilation.

Using it for long periods in poor ventilation may harm your health. Please periodically ventilate the room.

•Donotblocktheheatdissipationventsofthemachine.Poorheatdissipationcanleadtoariseininternal

temperatures and cause malfunctions.

•Newmachinesareemittingsomegasesingeneral.Accordingtothispleasetakecareofaiructuationsinthe

room for the ﬁrst days. At high usage it is recommended to keep a distance to the working places.

Battery

A lithium battery and Ni-MH (Nickel Metal Hydride) batteries are installed inside machine as back up memory

batteries. (Refer to “Recycling,” below.)

Recycling

Old machines, batteries, empty toner cartridges, drum units and developing units will be return the local

Muratec partner and will be recycled. Machines for consumer usage can be recycled at local recycling stations

without any charge. Batteries should not be thrown in the usual waste.

For details, contact your authorized Muratec dealer.
