MSI MS-6764 Manuel utilisateur

KT2 Combo

Version 1.0

G52-M6764X1-K01

MS-6764 (v1.X) ATX Mainboard

Manual Rev: 1.0

Release Date: January 2003

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-StarInternational MS-6764

Testedtocomply

withFCCStandard

ForHomeorOfficeUse

iii

CopyrightNotice

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

AMD, Athlon™, Athlon™ XP, Thoroughbred™, and Duron™ are registered

trademarks of AMD Corporation.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Microsoft is a registered trademark of Microsoft Corporation. Windows®98/

2000/NT/XP are registered trademarks of Microsoft Corporation.

NVIDIA, the NVIDIA logo, DualNet, and nForce are registered trademarks or

trademarks of NVIDIA Corporation in the United States and/or other countries.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Kensington and MicroSaver are registered trademarks of the Kensington Tech-

nology Group.

PCMCIA and CardBus are registered trademarks of the Personal Computer

Memory Card International Association.

Revision History

Revision Revision History Date

V1.0 First release with VIA®KT266A January 2003

&VIA® VT8235

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipment from overheating. Do not cover the openings.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. Always UnplugthePower Cordbeforeinsertingany add-oncardormodule.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged.

zLiquid has penetrated into the equipment.

zThe equipment has been exposed to moisture.

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged.

zThe equipment has obvious sign of breakage.

12. Do not leave this equipment in an environment unconditioned, storage

temperatureabove600C(1400F),itmaydamagetheequipment.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

FCC-B Radio Frequency Interference Statement ...........................................ii

Revision History ........................................................................................... iii

Safety Instructions .......................................................................................iv

Chapter1.GettingStarted ........................................................................ 1-1

Mainboard Specifications .................................................................... 1-2

Mainboard Layout ...............................................................................1-4

MSI Special Features ...........................................................................1-5

FuzzyLogic™4 .............................................................................1-5

LiveBIOS™/LiveDriver™ ............................................................1-6

Live Monitor™ ..............................................................................1-7

D-Bracket(Optional) ..................................................................... 1-8

PCAlert™4 ................................................................................. 1-10

CPU Thermal Protection .............................................................. 1-12

Chapter2.HardwareSetup ....................................................................... 2-1

Quick Components Guide ....................................................................2-3

Central Processing Unit: CPU ..............................................................2-3

CPU Core Speed Derivation Procedure .........................................2-3

CPU Installation Procedures for Socket 462 ..................................2-4

Installing AMD Athlon CPU (Socket 462) Cooler Set ...................2-5

Memory................................................................................................2-6

Introduction to DDR SDRAM.......................................................2-6

DDR DIMM Module Combination ................................................2-7

Installing DDR Modules ...............................................................2-7

SDR DIMM Module Combination ................................................2-8

Installing SDR Modules ................................................................2-8

Power Supply .......................................................................................2-9

ATX 20-Pin Power Connector: JWR1 ............................................2-9

ATX 12V Power Connector: JPR1..................................................2-9

BackPanel .......................................................................................... 2-10

Mouse Connector ....................................................................... 2-10

Keyboard Connector ................................................................... 2-11

USB 2.0 Connectors .................................................................... 2-11

Serial Port Connectors: COM A & COM B.................................. 2-12

RJ-45LANJack (Optional) .......................................................... 2-12

Parallel Port Connector: LPT1...................................................... 2-13

Joystick/Midi Connectors ........................................................... 2-14

Audio Port Connectors ............................................................... 2-14

Connectors......................................................................................... 2-15

Floppy Disk Drive Connector: FDD1........................................... 2-15

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-16

Fan Power Connectors: CPUFAN1/SYSFAN1 ............................. 2-17

CD-In Connector: J10 .................................................................. 2-18

Chassis Intrusion Switch Connector: J3...................................... 2-18

Front Panel Connectors: JFP1 & JFP2 ......................................... 2-19

Front Panel Audio Connector: JAUD1 ........................................ 2-20

D-BracketConnector:JLED......................................................... 2-21

Front USB Connectors: JUSB2/JUSB3 ........................................ 2-22

Jumpers .............................................................................................. 2-24

Clear CMOSJumper: JBAT1 ........................................................ 2-24

FSB Clock Override Jumper: SW3 ............................................... 2-25

Slots ................................................................................................... 2-26

AGP (Accelerated Graphics Port) Slot......................................... 2-26

PCI (Peripheral Component Interconnect) Slots.......................... 2-26

PCI Interrupt Request Routing .................................................... 2-27

Chapter3.BIOS Setup.............................................................................. 3-1

Entering Setup......................................................................................3-2

Selecting the First Boot Device .....................................................3-2

vii

Control Keys ................................................................................. 3-3

Getting Help ..................................................................................3-3

The Main Menu ...................................................................................3-4

Standard CMOS Features ....................................................................3-6

Advanced BIOS Features ....................................................................3-8

Advanced Chipset Features............................................................... 3-12

Power Management Features............................................................. 3-17

PNP/PCI Configurations..................................................................... 3-21

Integrated Peripherals ........................................................................ 3-23

PC Health Status ................................................................................ 3-27

Frequency/Voltage Control ................................................................ 3-28

Set Supervisor/User Password........................................................... 3-30

Load Optimal/High Performance Defaults .......................................... 3-31

Appendix:Using4-or6-ChannelAudioFunction ...................................A-1

Installing the Audio driver ..................................................................A-2

Using 4-/6- Channel Audio Function ..................................................A-4

Testing the connected speakers........................................................A-14

PlayingKaraOK ................................................................................A-16

Troubleshooting ........................................................................................ T-1

Glossary ....................................................................................................G-1

1-1

Getting Started

Chapter 1. Getting

Started

Thank you for purchasing KT2 Combo (MS-6764 v1.

X) ATX mainboard. The KT2 Combo is based on VIA®KT266A

&VT8235 chipsets and provides six USB 2.0 ports for high-

speed data transmission. Designed to fit the advanced AMD®

Athlon™,Athlon™ XPor Duron™ processors, the KT2 Combo

delivers a high performance and professional desktop platform

solution.

Getting Started

1-2

MS-6764 ATX Mainboard

Mainboard Specifications

CPU

hSupports Socket A (Socket-462) for AMD®Athlon™/Athlon™ XP /Duron™

processors.

hSupports 600MHz up to 2600+ MHz processor and higher.

Chipset

hVIA®KT266A chipset (522 BGA)

- FSB @200/266MHz.

- AGP 4X and PCI advanced high performance memory controller.

hVIA®VT8235 chipset (376 BGA)

- High Bandwidth V-link Client controller

- Integrated Faster Ethernet LPC

- Integrated Hardware Sound Blaster/Direct Sound AC97 audio

- Ultra DMA 66/100/133 master mode PCI EIDE controller

- Integrated USB2.0 Host Controller

- ACPI

MainMemory

hSupport two 184-pin unbuffered PC2100/PC1600 DDR SDRAM or two 168-

pin unbuffered PC100/133 SDRAM

hSupports up to 2GB memory size

Slots

hOne AGP (Accelerated Graphics Port) slot

- AGP specification compliant

- Supports AGP 2.0 4x

hSix 32-bit Master PCI Bus slots

hSupports 3.3V/5V PCI bus Interface

On-Board IDE

hAn IDE controller on the VIA® VT8235 chipset provides IDE HDD/CD-

ROM with PIO, Bus Master and Ultra DMA 66/100/133 operation modes

hCan connect up to 4 IDE devices

On-Board Peripherals

hOn-Board Peripherals include:

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

2.88Mbytes

1-3

Getting Started

- 2 serial ports (COM A + COM B)

- 1 parallel port supports SPP/EPP/ECP mode

- 1 IrDA connector for SIR/ASKIR/HPSIR

- 1 audio/game port

- SPDIF output (1 x 3) with housing (Optional)

- 6 USB 2.0 ports (Rear * 2/ Front * 4)

Audio

hChip integrated (6-channel S/W audio)

- Direct Sound AC97 Audio

- 6-channel analog output

BIOS

hThe mainboard BIOS provides “Plug & Play” BIOS which detects the pe-

ripheral devices and expansion cards of the board automatically.

hThe mainboard provides a Desktop Management Interface (DMI) function

which records your mainboard specifications.

Dimension

hATX Form Factor: 30.4 cm (L) x 22 cm (W).

Mounting

h6 mounting holes.

Others

hSuspend to RAM/Disk (S3/S4).

hPC2001 compliant.

hVoltage independent adjustment in CPU, DDR, AGP.

hSupports DMI (Desktop Management Interface) through BIOS.

hSupports PCI 2.2.

hSuspends to RAM/Disk.

Table des matières

Autres manuels MSI Carte mère

MSI

MSI MPG X570S Carbon EK X Manuel utilisateur

MSI

MSI MS-7314 Manuel utilisateur

MSI

MSI B85-P33 Series Manuel utilisateur

MSI

MSI A88XM GAMING Manuel utilisateur

MSI

MSI Baby AT SI19 Manuel utilisateur

MSI

MSI P35D3 Platinum - Motherboard - ATX Manuel utilisateur

MSI

MSI G52-M6570XA-G22 Instructions d'utilisation

MSI

MSI MS-7759 (v1.x) Manuel utilisateur

MSI

MSI G41M-P33 series Manuel utilisateur

MSI

MSI 870S-C45 Series Manuel utilisateur

MSI

MSI A88X-G43 Series Manuel utilisateur

MSI

MSI 915GM Speedster MS-9625 Manuel utilisateur

MSI

MSI MPG Z490M GAMING EDGE WIFI Manuel utilisateur

MSI

MSI MAG B660 TOMAHAWK WIFI DDR4 Manuel utilisateur

MSI

MSI MAG B460M MORTAR WIFI Manuel utilisateur

MSI

MSI 694T Pro Manuel utilisateur

MSI

MSI G52-S9617X1 Manuel utilisateur

MSI

MSI 845PE-V2 Series Manuel utilisateur

MSI

MSI Z87-G43 Series Manuel utilisateur

MSI

MSI 945GCM5 Series Manuel utilisateur

MSI

MSI MEG Z590 ACE Manuel utilisateur

MSI

MSI Z170A KRAIT GAMING Manuel utilisateur

MSI

MSI K9A2 CF Manuel utilisateur

MSI

MSI P45 Neo Series Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
