MSI MS-6533E Manuel utilisateur

Version 1.0

G52-MA00628

MS-6533E/G/EG (v1.X)

Micro ATX Mainboard

MSI

MICRO-STAR INTERNATIONAL

Manual Rev: 1.0

Release Date: July 2002

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-Star International MS-6533

Tested to comply

with FCC Standard

For Home or Office Use

iii

Edition

July 2002

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®98/2000/NT/XP are registered trademarks of Microsoft Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

1.0 First Release July 2002

Safety Instructions

1. Read the safety instructions carefully.

2. Save this User’s Guide for possible use later.

3. Keep this equipment away from humidity.

4. Lay this equipment on a stable and flat surface before setting it up.

5. The openings on the enclosure are used for air convection and to prevent

the equipment from overheating. Note: Do not cover the openings.

6. Make sure that the power voltage is within its safety range and has been

adjusted properly to the value of 110/220V before connecting the equip-

ment to the power inlet.

7. Place the power cord in a way that people are unlikely to step on it. Do not

place anything on the power cord.

8. Always unplug the power cord before inserting any add-on card or module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage the equipment

or cause an electrical shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zthe power cord or plug is damaged

zliquid has penetrated into the equipment

zthe equipment has been exposed to moisture

zthe equipment has not work well or you can not get it work according

to User’s Guide

zthe equipment was dropped and damaged

zthe equipment has obvious signs of breakage

12. Do not leave the equipment in an unconditioned environment with a stor-

age temperature of 600 C (1400F) or above, which may damage the

equipment.

CAUTION: To prevent explosion caused by improper battery

replacement, use the same or equivalent type of battery recommended

by the manufacturer only.

CONTENTS

Chapter 1. Getting Started ........................................................................ 1-1

Mainboard Specification ...................................................................... 1-2

Mainboard Layout ............................................................................... 1-5

Quick Components Guide .................................................................... 1-8

Chapter 2. Hardware Setup ....................................................................... 2-1

Central Processing Unit: CPU .............................................................. 2-2

CPU Installation Procedures ......................................................... 2-2

Installing the CPU Fan .................................................................. 2-3

CPU Core Speed Derivation Procedure ......................................... 2-4

Memory ................................................................................................ 2-5

Introduction to DDR SDRAM ....................................................... 2-5

DDR Module Combination ............................................................ 2-6

Installing DDR Modules ............................................................... 2-6

Power Supply ....................................................................................... 2-7

ATX 20-Pin Power Connector: CONN1 ......................................... 2-7

ATX 12V Power Connector: JPW1 ................................................ 2-7

Back Panel ............................................................................................ 2-8

Mouse Connector: JKBMS1 ......................................................... 2-8

Keyboard Connector: JKBMS1 ..................................................... 2-9

USB Connectors ............................................................................ 2-9

Serial Port Connectors: COM A & COM B / JCOM3 ................... 2-10

RJ-45 LAN Jack ........................................................................... 2-11

Joystick/Midi Connectors ........................................................... 2-11

Audio Port Connectors ............................................................... 2-11

Parallel Port Connector: LPT1 ...................................................... 2-12

Connectors ......................................................................................... 2-13

Floppy Disk Drive Connector: FDD1 ........................................... 2-13

Chassis Intrusion Switch Connector: J8 ...................................... 2-13

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-14

JCD1/JAUX1/JMD1 .................................................................... 2-15

CPUFA/SYSFA ............................................................................ 2-16

Front Panel Connectors: JFP1 & JFP2 ......................................... 2-17

Front Panel Audio Connector: JAUD .......................................... 2-18

Front USB Connectors: JUSB2 & JUSB3 ..................................... 2-19

IrDA Infrared Module Header: JIR .............................................. 2-20

LAN Active LED Jumper: JLAN .................................................. 2-20

IEEE 1394 Connectors: J1394_1 & J1394_2 .................................. 2-21

SPDIF Connector: JSP1 ............................................................... 2-22

Modem Connector: JMOD .......................................................... 2-23

Jumpers .............................................................................................. 2-25

Clear CMOS Jumper: JBAT1 ........................................................ 2-25

Slots ................................................................................................... 2-26

AGP (Accelerated Graphics Port) Slot ......................................... 2-26

PCI Slots ...................................................................................... 2-26

CNR (Communication Network Riser) ......................................... 2-26

PCI Interrupt Request Routing .................................................... 2-27

Chapter 3. AWARD BIOS Setup ............................................................... 3-1

Entering Setup ...................................................................................... 3-2

Control Keys ................................................................................. 3-2

Getting Help .................................................................................. 3-3

The Main Menu ................................................................................... 3-4

Standard CMOS Features .................................................................... 3-6

Advanced BIOS Features .................................................................... 3-8

Advanced Chipset Features ............................................................... 3-11

Integrated Peripherals ........................................................................ 3-13

Power Management Setup ................................................................. 3-19

vii

PNP/PCI Configurations ..................................................................... 3-24

PC Health Status ................................................................................ 3-26

Frequency/Voltage Control ................................................................ 3-27

Load Fail-Safe/Optimized Defaults ..................................................... 3-29

Set Supervisor/User Password ........................................................... 3-30

Appendix: Using 4- or 6-Channel Audio Function .................................... A-1

Installing the Audio Driver ................................................................. A-2

Using 4- or 6- Channel Audio Function .............................................. A-4

Selecting 4- or 6- Channel Setting ....................................................... A-6

Testing the Connected Speaker .......................................................... A-7

Playing KaraOK .................................................................................. A-8

Glossary .................................................................................................... G-1

Getting Started

1-1

Chapter 1. Getting Started

Thank you for purchasing the MS-6533E/G/EG series Micro ATX

mainboards. The MS-6533E/G/EG series are based on SiS645DX/SiS650GX/

SiS651 (co-layout) and SiS962L/SiS962 chipsets for optimal system efficiency.

Designed to fit the advanced Intel®Pentium®4 processors in the 478 pin

package, the MS-6533 E/G/EG series deliver a high performance and profes-

sional desktop platform solution.

Getting Started

TOPICS

Mainboard Specification 1-2

Mainboard Layout 1-5

Quick Components Guide 1-8

Chapter 1

1-2

CPU

Socket 478 for P4 processors (Willimate 478 and Northwood 478) with 400/

533 MHz (100/133MHz QDIR)

Core frequency from 1.7GHz to 2.53 GHz and up

Chipset

SiS®645DX/650GX/651 HMAC/IGUI HMAC /IGUI HMAC (702 pin BGA)

- High performance host interface 400/533 (645 DX and 651 only) MHz

- Support 64-bit high performance DDR333 (645 DX and 651 only) /

DDR266/DDR 200 and PC133/100 memory controller

- Support AGP 4X/2X interface with fast write transaction

- High throughput SiS HyperZip connect to SiS962L/962 HyperZip Media

I/O

- High performance 2D/3D and Video Accelerator (650GX and 651 only)

- Complete TV-out/Digital flat panel solution and MPEG-2/1 Video

decoder (651 only)

SiS®962L/962 HyperZip Media I/O (371BGA)

- High performance HyperZip connect to Sis series NB

- Integrated multi-threaded I/O link ensures concurrency of up/down stream

data transfer with 1.2GB/s bandwidth

- Integrated HyperZip connect to PCI bridge

- Dual IDE Master/Slave controller

- Integrated USB 2.0/1.1 host controller and Fast Ethernet MAC controller

- Integrated audio controller with AC97 interface

- Advanced power management and PC2001 compliance

- Integrated RTC and DMA interrupt and keyboard controller

- Integrated PCI to LPCC bridge

- Integrated IEEE 1394 Host controller (SiS962 only)

MainMemory

Supports four memory banks using two 184-pin unbuffered DDR DIMM.

Supports up to 2GB memory size.

Slots

One AGP (Accelerated Graphics Port) 2X/4X slot.

Three PCI 2.2 32-bit PCI bus slots (support 3.3V/5V PCI bus interface).

One CNR (Communication Network Riser) slot.

Mainboard Specification

Getting Started

1-3

On-BoardIDE

Dual IDE controllers integrated in Sis 962L/962.

Support P/O, Bus Master, Ultra DMA66/100/133 operation.

Can connect up to four IDE devices.

On-Board Peripherals

On-Board Peripherals include:

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

2.88Mbytes.

- 2 serial ports (COM A + COM B).

- 1 parallel port supports SPP/EPP/ECP mode.

- 6 USB ports (2.0/1.1) (Rear * 2/ Front * 4).

- 1 IrDA connector for SIR.

- 1 RJ-45 LAN jack (optional).

- 1 audio/game port.

- 1 VGA port (650GX and 651only).

- 2 IEEE 1394 ports (optional).

Audio

AC97 link controller integrated in SiS 962L/SiS 962.

2/6 channels software audio codec RealTek ALC201A/202A/ALC650.

- Compliance with AC97 v2.1 Spec.

- Meet PC2001 audio performance requirement.

LAN (optional)

PCI local bus single-chip Fast Ethernet Controller, RealTek RTL8101L.

- Integrated Fast Ethernet MAC and PHY in one chip.

- Supports 10Mb/s and 100Mb/s auto-negotiation operation.

- Compliance with PCI v2.2 and PC99 standard.

Supports Wake-On-LAN and remote wake-up.

Supports ACPI power management.

Modem(optional)

Supports MSI proprietary modem card MS-6961.

IEEE 1394 (SiS 962 only) (optional)

Compliant with IEEE 1394-1995 and 1394a-2000

Supports Serial Bus Data Rates of 100, 200 and 400 Mbits/s.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels MSI Carte mère

MSI

MSI MAG B650 TOMAHAWK WIFI Manuel utilisateur

MSI

MSI 865GM3 Series Manuel utilisateur

MSI

MSI X399 GAMING PRO CARBON AC Manuel utilisateur

MSI

MSI MS-98F5 Manuel utilisateur

MSI

MSI MS-6390 Manuel utilisateur

MSI

MSI 848P Neo2-V Series Manuel utilisateur

MSI

MSI MAG B550 TOMAHAWK Manuel utilisateur

MSI

MSI MS-6380 LE2 Manuel utilisateur

MSI

MSI MS-5148 Manuel utilisateur

MSI

MSI KT3 Ultra2-C MS-6593 Manuel utilisateur

MSI

MSI Wind Board 330 Manuel utilisateur

MSI

MSI Z270I GAMING PRO CARBON AC Manuel utilisateur

MSI

MSI H110M PRO-VD PLUS Manuel utilisateur

MSI

MSI MEG Z490 GODLIKE Manuel utilisateur

MSI

MSI MAG X570 TOMAHAWK WIFI Manuel utilisateur

MSI

MSI NF980-G65 series Manuel utilisateur

MSI

MSI MS-7021 Manuel utilisateur

MSI

MSI K7T TURBO2 - K7T Turbo 2 Motherboard Manuel utilisateur

MSI

MSI P45 NEO2-FR - Motherboard - ATX Manuel utilisateur

MSI

MSI H170A PC MATE Manuel utilisateur

MSI

MSI RS482M4-CSIP Manuel utilisateur

MSI

MSI B350M MORTAR ARCTIC Manuel utilisateur

MSI

MSI C236A WORKSTATION Manuel utilisateur

MSI

MSI X299M GAMING PRO CARBON AC Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
