MSI MS-6507E Manuel utilisateur
i
Version 1.0
G52-MA00561
MS-6507E (v1.X) Micro ATX Mainboard
MSI
MICRO-STAR INTERNATIONAL
ii
Manual Rev: 1.0
Release Date: March 2002
FCC-BRadioFrequencyInterferenceStatement
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct
the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party respon-
sible for compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to
comply with the emission limits.
VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU
RESEAU.
Micro-StarInternational MS-6507E
Testedtocomply
withFCCStandard
ForHome orOffice Use
iii
Edition
March 2002
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR
INTERNATIONAL. We take every care in the preparation of this document,
but no guarantee is given as to the correctness of its contents. Our products
are under continual improvement and we reserve the right to make changes
without notice.
Trademarks
All trademarks are the properties of their respective owners.
Intel®and Pentium®are registered trademarks of Intel Corporation.
PS/2 and OS®/2 are registered trademarks of International Business Machines
Corporation.
Windows®95/98/2000/NT/XP are registered trademarks of Microsoft
Corporation.
Netware®is a registered trademark of Novell, Inc.
Award®is a registered trademark of Phoenix Technologies Ltd.
AMI®is a registered trademark of American Megatrends Inc.
Revision History
Revision Revision History Date
V1.0 First release March 2002
iv
1. Always read the safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Keep this equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. The openings on the enclosure are for air convection hence protects the
equipmentfrom overheating. DONOT COVERTHEOPENINGS.
6. Make sure the voltage of the power source and adjust properly 110/220V
before connecting the equipment to the power inlet.
7. Place the power cord such a way that people can not step on it. Do not
place anything over the power cord.
8. AlwaysUnplugthe PowerCord beforeinserting anyadd-on cardor module.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening that could damage or cause electri-
cal shock.
11. If any of the following situations arises, get the equipment checked by a
service personnel:
zThe power cord or plug is damaged
zLiquid has penetrated into the equipment
zThe equipment has been exposed to moisture
zThe equipment has not work well or you can not get it work according
to User’s Manual.
zThe equipment has dropped and damaged
zIf the equipment has obvious sign of breakage
12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT
MAYDAMAGETHEEQUIPMENT.
Safety Instructions
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
v
CONTENTS
Chapter1.GettingStarted ........................................................................ 1-1
Mainboard Specification ......................................................................1-2
Mainboard Layout ...............................................................................1-4
Quick Components Guide ....................................................................1-5
Key Features ........................................................................................1-6
MSI Special Features ...........................................................................1-7
PCAlert™ III .................................................................................1-7
Chapter2.HardwareSetup ....................................................................... 2-1
Central Processing Unit: CPU .............................................................. 2-2
CPU Installation Procedures ......................................................... 2-2
Installing the CPU Fan ..................................................................2-3
CPU Core Speed Derivation Procedure .........................................2-4
Memory................................................................................................2-5
Introduction to DDR SDRAM....................................................... 2-5
DDR Module Combination ............................................................ 2-6
Installing DDR Modules ............................................................... 2-6
Power Supply ....................................................................................... 2-7
ATX 20-Pin Power Connector .......................................................2-7
ATX 12V Power Connector: JPW1 ................................................2-7
BackPanel ............................................................................................2-8
Mouse Connector ......................................................................... 2-8
Keyboard Connector ..................................................................... 2-9
USB Connectors ............................................................................2-9
Serial Port Connector: COM A & COM B ................................... 2-10
Joystick/Midi Connectors ........................................................... 2-10
Audio Port Connectors ............................................................... 2-10
Parallel Port Connector ................................................................ 2-11
LANJack(RJ-45) ......................................................................... 2-12
vi
Connectors......................................................................................... 2-13
Floppy Disk Drive Connector: FDD1........................................... 2-13
Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-14
CD-InConnector:JCD1 ............................................................... 2-15
Aux Line-In Connector: JAUX1 .................................................. 2-15
Modem-In Connector: JPHN1 ..................................................... 2-15
Fan Power Connectors: C_FAN1/S_FAN1 .................................. 2-16
Chassis Intrusion Switch Connector: JCI1 .................................. 2-17
IrDA Infrared Module Header: JIR1 ............................................ 2-17
Wake On Ring Connector: JMDM1 ............................................. 2-18
Wake On LAN Connector: JWOL1.............................................. 2-18
SPDIF Connector: JSP1 ............................................................... 2-19
Front Panel Audio Connector: JAUD1 ........................................ 2-20
Modem Connector: MC1 ............................................................. 2-21
Front Panel Connectors: JFP1 & JFP2 ......................................... 2-22
Front USB Connector: JUSB1 or JUSB2 ...................................... 2-23
Jumpers .............................................................................................. 2-24
Clear CMOS Jumper:JBAT1 ........................................................ 2-24
Slots ................................................................................................... 2-25
AGP (Accelerated Graphics Port) Slot......................................... 2-25
PCI Slots ...................................................................................... 2-25
CNR(Communication NetworkRiser) ......................................... 2-25
PCI Interrupt Request Routing .................................................... 2-26
Chapter3.AWARD® BIOSSetup............................................................ 3-1
Entering Setup......................................................................................3-2
Control Keys ................................................................................. 3-2
Getting Help .................................................................................. 3-3
The Main Menu ................................................................................... 3-4
Standard CMOS Features .................................................................... 3-6
vii
Advanced BIOS Features .................................................................... 3-8
Advanced Chipset Features............................................................... 3-12
Integrated Peripherals ........................................................................ 3-14
Power Management Setup ................................................................. 3-18
PNP/PCI Configurations..................................................................... 3-22
PC Health Status ................................................................................ 3-24
Frequency/Voltage Control ................................................................ 3-25
LoadFail-Safe/OptimizedDefaults ..................................................... 3-27
Set Supervisor/User Password........................................................... 3-28
Glossary ....................................................................................................G-1
Getting Started
1-1
Chapter 1. Getting Started 1
Getting Started
Thank you for purchasing the MS-6507E v1.X Micro ATX mainboard.
The MS-6507E is based on Intel®Brookdale-E & ICH4 chipsets for optimal
system efficiency. Designed to fit the advanced Intel®Pentium®4 processors
in the 478 pin package, the MS-6507E delivers a high performance and profes-
sional desktop platform solution.
TOPICS
Mainboard Specification 1-2
Mainboard Layout 1-4
Quick Components Guide 1-5
Key Features 1-6
MSI Special Features 1-7
Chapter 1
1-2
CPU
Supports Intel®Pentium®4 processor in 478-pin package.
Supports 1.5GHz, 1.6GHz, 1.7GHz, 1.8GHz, 1.9GH z, 2GHz and up.
Chipset
Intel®Brookdale-E chipset
- Support 100MHz/133MHz system clock.
- Intel NetBurst micro-architecture supports 400MHz/533MHz system bus.
- 1.5V AGP interface with 4x data transfer and 4x fast write capability.
Intel®ICH4 chipset
- 2 channel Ultra ATA 100 bus Master IDE controller.
- PCI Master 2.2.
- I/O APIC.
- AC’97 2.2 interface.
- 3 UHCI Host controllers and 1 EHCI Host controller.
MainMemory
Supports four memory banks using two 184-pin DDR DIMM.
Supports up to 2GB PC2100/PC1600 DDR SDRAMs.
Supports 2.5v DDR SDRAM.
Slots
One AGP(Accelerated Graphics Port) slot.
- Support AGP2.0 including 1x/2x/4x AGP data transfer.
- AGP 1.5V support only. No support for 3.3V or Universal AGP connector.
Three PCI 2.2 32-bit Master PCI bus slots (support 3.3V/5V PCI bus interface).
One CNR (Communication Network Riser) slot.
On-BoardIDE
Support Ultra ATA 100/66/33, BMIDE and PIO operation modes.
2 channel ATA 100 IDE controller integrated.
Can connect up to four IDE devices.
On-Board Peripherals
External
- PS2 KBD + PS2 Mouse
- Parallel x 1 + Serial x 2 (COM A + COM B)
- USB 2.0 x 2 + Lan (RJ-45) x 1
Mainboard Specification
Getting Started
1-3
- Game port + Audio (Mic_in, Line_in, Line_out)
Internal
- Floppy port x 1, IDE x 2, ATX 12V Power Connector
- Front Panel (2 x 5 pin, Intel FPIO pin-define + 2 x 4 pin MSI pin-define)
- Front Audio (2 x 5 pin Intel FPIO pin-define)
- USB2.0 pin header x 2 sets (2 x 5 )
- Front IR, Chassis Intrusion, Onboard buzzer, JBAT1
- CPU Fan, System Fan, Audio (CD-in, Aux-in, Modem-in)
- S/PDIF output (1 x 3) with housing
- Modem Header for optional MSI proprietary modem MS6961
Audio
AC97 2.2 interface provided by ICH4
2 channel S/W audio codec
- AC'97 2.2 Compliant
- Meet PC2001 audio performance requirement
LAN(optional)
PCI local bus single-chip Fast Ethernet Controller, RealTek RTL8101L.
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10Mb/s and 100Mb/s auto-negotiation operation.
- Compliance with PCI v2.2.
- Compliance with PC99 and PC2001 standard.
- Supports Wake-On-LAN and remote wake-up.
- Supports ACPI power management.
Modem(optional with LAN)
MSI proprietary design.
BIOS
PnP (Plug & Play) BIOS to detect peripheral devices and expansion cards
automatically.
DMI (Desktop Management Interface) function to record motherboard
specification.
Provide WOL, chassis intrusion and SMBus for system management.
Dimension
Micro-ATX Form Factor (9.6" x 9.1").
Mounting
6 mounting holes.
Table des matières
Autres manuels MSI Carte mère
MSI
MSI Z370 TOMAHAWK Manuel utilisateur
MSI
MSI MS-9896 Manuel utilisateur
MSI
MSI ATX IR1 Manuel utilisateur
MSI
MSI 880GMA-E55 Series Manuel utilisateur
MSI
MSI Z97A GAMING 6 Series Manuel utilisateur
MSI
MSI B350 PC MATE Manuel utilisateur
MSI
MSI MPG B560I Manuel utilisateur
MSI
MSI 945PL Neo Series Manuel utilisateur
MSI
MSI MAG B460 TOMAHAWK Manuel utilisateur
MSI
MSI MS-6217 Series Manuel utilisateur
MSI
MSI MEG Z590I UNIFY Manuel utilisateur
MSI
MSI A88X-G41 PC Mate Manuel utilisateur
MSI
MSI MS-6390 Manuel utilisateur
MSI
MSI PRO-L J4205TI Manuel utilisateur
MSI
MSI MAG Z690 TOMAHAWK Manuel utilisateur
MSI
MSI z170a GAMING M9 ACK Manuel utilisateur
MSI
MSI MS-7520 ECLIPSE Series Manuel utilisateur
MSI
MSI Z77MA-S01 Series Manuel utilisateur
MSI
MSI 740GM-P21 Series Manuel utilisateur
MSI
MSI MS-6787 Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
