MSI MS-6380LE Manuel utilisateur

MSI

Version 1.3

G52-MA00598

MS-6380E (v1.X) ATX Mainboard

KT3 Ultra2 Series

MICRO-STAR INTERNATIONAL

Manual Rev: 1.3

Release Date: June 2002

FCC-BRadioFrequencyInterferenceStatement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-StarInternational MS-6380E

Testedtocomply

withFCCStandard

ForHomeorOfficeUse

iii

Edition

June2002

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

AMD, Athlon and Duron are registered trademarks of AMD Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®98/2000/NT/ME/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision RevisionHistory Date

1.3 Modify chipset and USB June2002

connectors

Add JBT2

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipmentfromoverheating. DO NOT COVERTHEOPENINGS.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. AlwaysUnplug thePowerCordbefore inserting any add-on card ormodule.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged

zLiquid has penetrated into the equipment

zThe equipment has been exposed to moisture

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged

zIf the equipment has obvious sign of breakage

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT

MAYDAMAGETHEEQUIPMENT.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

Chapter1.GettingStarted ........................................................................ 1-1

Mainboard Specification ......................................................................1-2

Mainboard Layout ...............................................................................1-4

Quick Components Guide ....................................................................1-6

MSI Special Features ...........................................................................1-7

PCAlert™ III ................................................................................. 1-7

FuzzyLogic™4 .............................................................................1-8

LiveBIOS™/LiveDriver™ ............................................................1-9

D-Bracket™2(Optional) .............................................................. 1-10

S-Bracket(Optional) .................................................................... 1-12

MSIDVD (5.1Channel) ............................................................... 1-13

CPU Thermal Protection .............................................................. 1-15

Chapter2.HardwareSetup ....................................................................... 2-1

Central Processing Unit: CPU ..............................................................2-2

CPU Installation Procedures .........................................................2-2

CPU Core Speed Derivation Procedure .........................................2-4

CPU Clock Frequency Selection through BIOS.............................2-4

Memory................................................................................................2-5

Introduction to DDR SDRAM.......................................................2-5

DIMM Module Combination.........................................................2-6

Installing DDR Modules ...............................................................2-6

Power Supply .......................................................................................2-7

ATX 20-Pin Power Connector: JWR1 ............................................2-7

BackPanel ............................................................................................2-8

Mouse Connector ......................................................................... 2-8

Keyboard Connector .....................................................................2-9

USB Connectors ............................................................................2-9

Serial Port Connectors: COM A & COM B.................................. 2-10

Joystick/Midi Connector ............................................................. 2-10

Parallel Port Connector: LPT1...................................................... 2-11

Audio Port Connectors ............................................................... 2-12

Connectors......................................................................................... 2-13

Floppy Disk Drive Connector: FDD1........................................... 2-13

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-14

ATA133 RAID Connectors: IDE3 & IDE4 ................................... 2-15

Fan Power Connectors: CFAN1/SFAN1/PSFAN1/NBFAN1........ 2-16

Front Panel Connectors: JFP1 & JFP2 ......................................... 2-17

Front Panel Audio Connector: JAUD1 ........................................ 2-18

Front USB Connectors: JUSB2/3 ................................................. 2-19

CD-In Connector: JCD ................................................................. 2-21

Aux Line-In Connector: JAUX (optional).................................... 2-21

Modem-In Connector: JMDM (optional) .................................... 2-21

D-Bracket™Connector:JLED ..................................................... 2-22

S-Bracket Connector: JSP3 .......................................................... 2-23

IrDA Infrared Module Header: JIR1 ............................................ 2-24

Chassis Intrusion Switch Connector: J3...................................... 2-24

Wake On Ring Connector: JMDM1............................................. 2-25

Bluetooth Connector: JBT2 (optional) ........................................ 2-26

Jumpers .............................................................................................. 2-27

Clear CMOSJumper: JBAT1 ........................................................ 2-27

Slots ................................................................................................... 2-28

AGP (Accelerated Graphics Port) Slot......................................... 2-28

PCI Slots ...................................................................................... 2-28

CNR(CommunicationNetwork Riser) Slot .................................. 2-28

PCI Interrupt Request Routing .................................................... 2-29

Chapter3.BIOSSetup.............................................................................. 3-1

Entering Setup......................................................................................3-2

Selecting the First Boot Device .....................................................3-2

Control Keys ................................................................................. 3-3

vii

Getting Help ..................................................................................3-3

The Main Menu ...................................................................................3-4

Standard CMOS Features ....................................................................3-6

Advanced BIOS Features ....................................................................3-8

Advanced Chipset Features............................................................... 3-13

Power Management Features............................................................. 3-18

PNP/PCI Configurations..................................................................... 3-22

Integrated Peripherals ........................................................................ 3-24

PC Health Status ................................................................................ 3-27

Frequency/Voltage Control ................................................................ 3-28

Set Supervisor/User Password........................................................... 3-30

Load High Performance/BIOS Setup Defaults.................................... 3-31

Appendix.Using4-or6-ChannelAudioFunction ....................................A-1

Installing the Audio Driver .................................................................A-2

Installation for Windows 98SE/ME/2000/XP ................................A-2

Using 4- or 6-Channel Audio Function ...............................................A-4

Attaching Speakers ......................................................................A-4

Selecting 4- or 6-Channel Setting .................................................A-9

Testing the Connected Speakers.......................................................A-11

Testing Each Speaker: ................................................................A-11

PlayingKaraOK ................................................................................A-12

PlayingKaraOK: .........................................................................A-12

Glossary ....................................................................................................G-1

Getting Started

1-1

Chapter 1. Getting Started

Thank you for purchasing KT3 Ultra2 (MS-6380E v1.X) series

motherboard. The KT3 Ultra2 (MS-6380E v1.X) series ATX mainboard is a

high-performance computer mainboard based on VIA®Apollo KT333 &

VT8235 chipsets and designed for the AMD®Athlon™,Athlon™ XP or

Duron™ (PGA) processor for value business/personal desktop markets.

There are two models available for KT3 Ultra2 series mainboards.

They are KT3 Ultra2 and KT3 Ultra2-R. KT3 Ultra2 is the standard version

with common features most motherboards have. As for KT3 Ultra2-R, it

integrates ATA133 RAID on the board in addition to the standard features.

Getting Started

TOPICS

Mainboard Specification 1-2

Mainboard Layout 1-4

Quick Components Guide 1-5

MSI Special Features 1-6

Chapter 1

1-2

CPU

Supports Socket A (Socket-462) for AMD®Athlon™/Athlon™ XP /Duron™

processor

Supports 800MHz up to 1.8GHz (Athlon™ XP 2200+) processor

Chipset

VIA®KT333 chipset

- FSB @200/266 MHz

- AGP 4X and PCI Advanced high performance memory controller

VIA®VT8235 chipset

- Integrated Direct Sound AC97 audio

- Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller

- ACPI

- Integrated USB 2.0 controller

Clock Generator

100/133 MHz clocks are supported.

MainMemory

Supports six memory banks using three 184-pin DDR DIMMs

Supports a maximum memory size up to 3GB

Supports 2.5V DDR SDRAM DIMM

Slots

One AGP slot

- AGP (Accelerated Graphics Port) specification compliant

- Supports AGP 2.0 1x/2x/4x

Five 32-bit PCI bus slots (support 3.3v/5v PCI bus interface)

One CNR (Communication Network Riser) slot

On-BoardIDE

An IDE controller on the VT8235 chipset provides IDE HDD/CD-ROM with

PIO, Bus Master and Ultra DMA133/100/66/33 operation modes

Can connect up to four IDE devices

On-Board Peripherals

On-Board Peripherals include:

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

Mainboard Specification

Getting Started

1-3

2.88Mbytes

- 2 serial ports (COM A + COM B)

- 1 parallel port supports SPP/EPP/ECP mode

- 1 IrDA connector for SIR/ASKIR/HPSIR

- 1 audio/game port

- 1 D-Bracket™ pinheader

- 1 S-Bracket pinheader

Promise 20276 On-Board (KT3 Ultra2-R)

Supports ATA133 RAID 0 or 1

The two ATA133 RAID connectors support hard disk drives only

Note: Only two hard disk drives will adopt the RAID function.

USB Interface

Supports USB 2.0 and downward compatible with USB 1.1

Bluetooth

1 bluetooth connector for wireless connection (bluetooth module

optional)

Audio

Realtek ALC650 6-channel audio

- SPDIF out (through S-Bracket only)

BIOS

The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-

ripheral devices and expansion cards of the board automatically.

The mainboard provides a Desktop Management Interface (DMI) function

which records your mainboard specifications.

Dimension

ATX Form Factor: 30.4 cm (L) x 23.5 cm (W)

Mounting

6 mounting holes

Others

Modem (External/Internal) Ring Wake Up Function

PCI 2.2 LAN Wake Up Function

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels MSI Carte mère

MSI

MSI MSI-5149 Manuel utilisateur

MSI

MSI P6NGM series Manuel utilisateur

MSI

MSI 945G Neo2 Series Manuel utilisateur

MSI

MSI 848P NEO-V - Motherboard - ATX Manuel utilisateur

MSI

MSI B450M BAZOOKA V2 Manuel utilisateur

MSI

MSI MEG X570 GODLIKE Manuel utilisateur

MSI

MSI MEG X570S UNIFY-X MAX Manuel utilisateur

MSI

MSI G41M4 series Manuel utilisateur

MSI

MSI MAG B660M MORTAR WIFI DDR4 Manuel utilisateur

MSI

MSI MPower Z97 Manuel utilisateur

MSI

MSI MS-98D7 Manuel utilisateur

MSI

MSI B450M MORTAR MAX Manuel utilisateur

MSI

MSI Z97 GAMING 5 Manuel utilisateur

MSI

MSI K9A2 CF Manuel utilisateur

MSI

MSI MEG Z390 GODLIKE Manuel utilisateur

MSI

MSI Z68MA-G43 (G3) Series Manuel utilisateur

MSI

MSI H61M-P22 G3 Series Manuel utilisateur

MSI

MSI K7N2GM2-ILSR Manuel utilisateur

MSI

MSI G31M3-F - Motherboard - Micro ATX Manuel utilisateur

MSI

MSI X79A-GD65 (8D) Series Manuel utilisateur

MSI

MSI Z87-G43 Series Manuel utilisateur

MSI

MSI X299 RAIDER Manuel utilisateur

MSI

MSI MAG X570 TOMAHAWK WIFI Manuel utilisateur

MSI

MSI MS-7512 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
