MP-Man MP-F72 Manuel utilisateur
MP-F72
Instruction manual
1
Table of Contents
Key Features
I. Position 3
II. Function Keys 3
III. LCD Windows 3
Operation
I. Installing the "DIGITAL AUDIO PLAYER" CD software 4
II. Getting Started 6
III. To Begin Listening 7
IV. Listening 7
1. MUSIC PLAYER 7
2. NAVIGATION 7
3. FM RADIO 7
4. VOICE RECORDER 7
V. Useful Features 12
VI. Safe Removal Procedure 13
VII. Additional Information 14
1. Installing Battery 14
2. Accessories 14
3. Precautions 15
4. Troubleshooting 16
5. Technical Specifications 17
6. Care and Maintenance 18
2
Key Features
lDigital Audio Player
-Supports MP3 and WMA.
-Supports WAV format (ADPCM Encoding)
lUSB interface for upload and download files (USB 1.1)
lFirmware Upgradeable
-Provides the latest updated features via free downloads from our
website and upgradeable to other digital music format if available.
llFull Graphic LCD for displaying information with blue backlight.
lFM Tuner function with memory function (Preset channel).
l6 Equalizing Patterns
lFM Tuner recording function.
lBuilt-in microphone for Voice Recording Function (High, Normal and
Low Quality selectable).
lProgrammable Music Playlist.
lLow battery level indicator.
lThe Digital Audio Player will power off automatically if the player is
idle for about 3 minutes.
lSupport for Win98SE (Installation of driver is required), Win ME, Win
2000 and Win XP.
3
Key Features
Part I Position
Part II Function Keys
4; Play / Pause button
< Stop button
+Increase volume / move up button.
-Decrease volume / move down button
9 Backward / Rewind button
: Forward / Next button
HOLD Hold button
NAVI Navigation / Enter button
MODE Mode button
n /EQ/
Record / Equalizer / Repeat button
AUTO Auto button (for FM Radio mode)
PRESET Preset button (for FM Radio mode)
MONO Mono button (for FM Radio mode)
Part III LCD Windows
USB So
cket
Earphone Jack
Control Keys
NAVI Button
4
Operation
Part I. Installing the "DIGITAL AUDIO PLAYER" CD software in
your computer
For Windows 98SE: The USB mass storage function will not be
activated without driver installation. To activate the USB mass storage
function, please use the installation CD-Rom to install the driver.
For Windows ME, Windows 2000 or Windows XP: Windows can
detect
Audio player without installing the CD software automatically after
connection with the USB port is established.
If you are connecting your player to your computer for the first time,
please follow these instructions: (For Windows 98SE)
1. Insert the Installation CD-ROM into the CD Drive. The Auto run
program will start to install the player driver automatically.
Hint: If the Install Shield Wizard does not start, please run the
Setup.exe under your CD-ROM Drive directory. Double click Setup.exe.
5
2. Follow the on screen instruction to install
the player driver.
Install the player driver under the preset directory.
Warning: DO NOT change the preset installation path. Otherwise, the
player driver cannot run properly.
3. Wheninstallationiscompleted,the new program will be added
to the folder of programs.
6
Part III. To begin listening
a. Insert the earphone plug into earphone jack of player and press
button.
b. Press MODE button once and MAIN MENU (MUSIC PLAYER,
NAVIGATION,FMRADIO, VOICERECORDER)will appear
on the LCD screen
c. You can press:or 9button to scroll different modes of "MUSIC
PLAYER" or "NAVIGATION" or "FM RADIO" or "VOICE
RECORDER",
and press NAVIbutton to confirm the selection.
Part IV. Listening
To listen to the MP3/WMA/ FM recording file or run the programmed list,
you maygo toMUSICPLAYERmode.
1. MUSIC PLAYER
2. a. Press MODE button to select the "MUSIC PLAYER" and press
NAVIbutton to confirm the selection
b. Press button to play or pause during playing music
c. Press button to stop
d. Press and hold button to turn off the player
e. Scroll up +to increase the volume and scroll down -to
decrease the volume
f. Press :to select the next track and 9to select the
previous track
g. Press and hold 9for fast rewind and press and hold :for
fast forward
h. Switch HOLD button to lock all buttons and all buttons will
not have function after locking
7
i. EQ button
Press and hold EQ button while playing music to display the
current EQ, the current [EQ] icon will change the background
color. Then press EQ button again to select the six EQ modes
[NORM, ROCK, UBASS, JAZZ, CLASS, POP ] icon. The program
will quit the EQ mode if no consecutive key pressed
j. Repeat Button
Press the /EQ/ button once to toggle different repeat mode
functions:
-Randomly play all files in the player and stop
-Randomly play all files in the player repeatedly
-Play a single file repeatedly
-Play all files in the player repeatedly
-Edit and play one section repeatedly. Press NAVIbutton
once to
start with point A and press NAVIbutton again to end with
point B.
-Play program list file and stop (only be activated upon
playlist is created)
-Play program list file repeatedly (only be activated upon
playlist is created)
k. Play the Playlist
Once the playlist is created (please refer to NAVIGATION mode
for
detail), press EQ button to select or icon. Then press
button and press button againtostartplaying the music
according to the programmed playlist
Remark:
甲、If the player stops during MUSIC PLAYER mode or VOICE
RECORDERmode,itwill automaticallyshutoff afterabout3
minutes.
8
2. NAVIGATION
You may search file, delete file and program the playlist in
"NAVIGATION"
mode.
a. Press MODE button to select the "NAVIGATION" and press NAVI
button
to confirm. Alternatively, you can simply press NAVIbutton to enter
the
function of "NAVIGATION" during "MUSIC PLAYER" mode
b. The LCD displays the music files in folders and files
c. Scroll up +to move up in the list and scroll down -to move down in
the list
d. Push :to enter a folder and 9to quit after selected the music file
Listen to the selected song/ file
Press button or NAVIbutton to play
CLEAR FILE / CLEAR LIST
Press button and a dialogue box [DELETE FILE / CLEAR LIST] icon
will show on the LCD screen. Scroll up+or scroll down-to toggle the
confirmation. Then another dialogue box [YES / NO] icon will appear.
Push
:or 9to select and pressNAVIbutton to confirm.
If [YES] icon is selected, LCD will display [File deleted] or [List deleted]
icon.
Remark:
-You cannot delete the file while music is playing
-[Operation Fail] icon: The file in the folder is protected so that you
cannot delete the file inside folder. These files can only be deleted
through the computer, not by the MP3 unit itself.
Program the Playlist
-Press EQ button once, a number will be displayed adjacent to the
song
name [01], [02], [03]...etc. Press EQbutton again to confirm, then
the
number will disappear and the song is stored in the playlist
-If more than one song is stored in the playlist, before pressingEQ
button to confirm, you can scroll up +or scroll down -to change
the playlist order number.
-Press MODE button to quit
Note: You cannot program the same music file on the Playlist more than
once.
9
3. FM RADIO
You may set the whole FM radio band, listen to the radio or record file of
FM radio program; please go to FM Radiomode.
a. Press MODE button to select the FM RADIO and press NAVI
button to
confirm.
b. Setting the FM band by auto scanning or manual present
Auto scanning the whole FM band
-If the [PRESET] icon is on, then press PRESET button to remove
it.
-Press and hold AUTO button to start auto scanning the whole FM
band.
[AUTO SCAN] icon and Channel number icons [C01], [C02] ~
[C10]... will be shown on LCD.
Each FM station detected will be stored in the 10-preset memory
(previously preset channel will be overwritten by new FM station
detected). Only the last 10 FM stations will remain in the memory.
