MP-Man MP-FUB 31 Manuel utilisateur

TableofContents

Getting Started

Introduction 1

Key Features 1

Package Contents 2

Installing the Battery 2

Parts Description 3

Control Keys 3

LCD Screen 3

Downloading and Transferring Files

Install the digital audio player CD software 4 - 5

Safely remove your player from the computer 6

Transferring files 7

Operation

Listening to Music 8

Using the MAIN MENU 8 - 9

MUSIC 8

FM RADIO 9

VOICE REC 9

Customizing the Player

Using the SETTING MENU 10

REC RESOLUTION 10

CONTRAST 10

EQUALIZER 10

PLAY TIMER 10

REPEAT 11

LIGHT TIMER 11

LANGUAGE 11

AUTO SCAN 11

Additional Information

Precautions 12

Trouble Shooting 13

Technical Specifications 14

Care and Maintenance 15

Getting Started

INTRODUCTION

Your DAP is a device that stores and plays multi-format digital audio files including MP3, WMA

and WAV files. Download hours of music onto your PC and transfer them to your DAP digital

audio player. Use your DAP to record those quick reminder memos or even lengthy business

meetings or lectures. Record programs or songs directly from an FM radio station or just use it

to listen to your favorite FM station.

MPFUB 3X Series:

There are several versions of the FUB 3X Series of DigitalAudio Players. This Manual covers

the entire series, so please keep in mind some features may not apply to your particular model.

Please see the different features below for each model:

MPFUB32: No FM Tuner

MPFUB33: With FM Tuner

KEY FEATURES

 Multi-format player supports MP3, WMA and WAV files.

- MP3: (MPEG1 LAYER3) is an audio compression format that enables a WAV file to be

compressed to about 1/12 of its original size, while maintaining the original sound

quality.

- WMA: (Windows MediaAudio) is Microsoft's music file compression format that enables

WAV files to about 1/6 of its original size while maintaining the original sound quality.

- WAV: (ADPCM encoding) is the file format for voice or FM tuner recordings.

 USB data transfer: Use the supplied USB cable to move MP3, WMA and WAV files from

your computer to your unit.#

 Windows Plug & Play support for Windows ME, 2000 and XP.

 Windows 98 SE compatible: Install the driver with the enclosed CD-ROM so that your

computer will recognize the device.

 Built in FM tuner with auto scan and 10 station memory.

 FM tuner records FM radio programs and stores them as WAV files.

 Internal microphone for voice recording with adjustable quality level settings (select high,

normal or low quality levels).

 Upgradeable Firmware

- Update the latest features via free downloads from our website:

www.mpmaneurope.com

- Windows 98 SE operating systems may need to upgrade the Windows OS before

upgrading the firmware.

 Power equalizing allows you to set the frequency level according to 6 music categories:

Normal, Rock, Ultra Bass, Jazz, Classic and Pop.

 Full Graphic LCD for displaying information with blue-color backlight.

 Power saving feature automatically turns off when the player is idle for 3 minutes.

 Low battery level indicator.

PACKAGE CONTENTS

Check that you have the following accessories:

 Stereo Earphones

 USB Cable

 Installation CD-ROM with Windows 98SE Driver and User Manual

 Quick Start Guide

 One AAAAlkaline Battery

INSTALLING THE BATTERY

Press the button and then push the battery compartment door in the direction the button is

pointing. Insert the battery with the correct polarity as shown. Close the battery compartment

door.

- To avoid battery leakage or corrosion, remove the battery from the player if the player is not

to be used for a long time.

- Remove dead battery from the player immediately to avoid damaging the player.

- When corrosion occurs, wipe the battery compartment immediately with a dry cloth and

insert a new battery.

PARTS DESCRIPTION

1. Press to decrease the volume.

Press and hold the button down to decrease the volume rapidly.

2. Press and hold to access the SETTINGS menu.

Press to access the MAIN MENU.

3. Press to increase the volume.

Press and hold the button to increase the volume rapidly.

CONTROLS

Control Keys

There is a NAVI button that controls several key functions. Moving it up, down, right or left will

achieve the following actions.

1. Press to turn on the power.

Press to play or pause.

2. Press and hold to turn off the power.

Press to stop.

3. Press to select the previous file or track.

Press and hold the button to rewind.

4. Press to select the next file or track.

Press and hold the button to fast forward.

LCD SCREEN

INSTALL THE DIGITAL AUDIO PLAYER CD SOFTWARE

For Windows 98SE:

Windows 98SE will not recognize the player until you have installed the driver using the

included installation CD-ROM. Follow the instructions detailed in this section to activate the

USB mass storage function so you will be able to transfer files from your computer to your

player.

For Windows ME, Windows 2000 or Windows XP:

These version of Windows will automatically detect your player after connection with USB port

is established. In order to format the player, update or uninstall the software, you will need to

install the software on the included CD-ROM.

Procedure to Install Digital Audio Player Software

When connecting your player to your computer for the first time, please follow these

instructions:

1. Insert the Installation CD-ROM into the CD Drive. TheAuto-run program will start to install

the player driver automatically as shown.

NOTE: If the setup does not start, please run the setup.exe under your CD-ROM Drive

directory. Double click "setup" in the installation CD.

2. Follow the on screen instructions to install the software.

3. After succesfully installing the software, the “Digital Flash Player” program will appear in the

“Start” menu.

SAFELY REMOVE YOUR PLAYER FROM THE COMPUTER

NOTE : To avoid damage to your player or data loss, always follow the procedure listed below

before disconnecting the USB cable from your computer or disconnecting the player from the

USB cable.

Using your mouse, double click the "Safely Remove Hardware" icon on the task bar

From the "Safely Remove Hardware" window, select "USB Mass Storage Device" and click the

"Stop" button. The "Stop a Hardware Device" window will pop up as shown.

Click "OK" and when a "Safe to Remove Hardware" window is displayed you may remove the

player from the USB cable or remove the USB cable from the computer.

Remarks: If you do not see the "Safely Remove Hardware" icon on the task bar. Please go to

my computer, right click on "Removable Disk", double click "eject". The "Safely Remove

Hardware" window will pop up and follow the step on the above.

TRANSFERRING FILES

Push the USB button and then slide it to the left in order to expose the USB Plug. Then

connect the unit to your computer either directly or by using the supplied USB cable.

Press the II button to turn the player on. The following will be displayed in the LCD:

A "Removable Disk" window will appear in “My Computer”.

Locate the files you wish to copy from your computer to your player. Drag and drop MP3, WMA

or WAV files on your computer into the "Removable Disk" window. These files will now be

copied onto your player.

NOTE : When you are finished transferring files, please follow the Safely Remove Hardware

Procedure on the previous page before disconnecting your player.

Operation

LISTENING TO MUSIC

After you have transferred MP3, WMAor WAV files from your computer to your player, you can

start listening to music while you learn how to use all of the features.

With the battery installed, insert the earphones into the earphone jack of player.

Press the II button to turn the player on.

Use the control keys and the NAVI button to pause, play, stop, fast forward or reverse and

adjust the volume.

USING THE MAIN MENU

Press the mode button to access the MAIN MENU. The following menu will be displayed

on the LCD screen:

Using the NAVI button, press or until your desired selection is highlighted and

press the II button down to select.

MUSIC PLAYER

To listen to any of the files or songs stored in your player or run the program list, you can select

the MUSIC PLAYER mode.

Using the control buttons

- Press II button to play or pause playback.

- Press button to stop.

- Press and hold button to turn off the power.

- Scroll up +to increase the volume and scroll down -to decrease the volume.

- Push to select the next track. Push to select the previous track.

- Push and hold for fast rewind. Push and hold for fast forward.

- Slide hold button to the right to lock all buttons and slide hold to the left to unlock all

functions and return to normal playback.

FM RADIO

The unit has a built in FM tuner with auto scan and ten station memory. In addition to listening

to your favorite station, you can also record a song or program.

Press the mode button to access the MAIN MENU. The following menu will be displayed

on the LCD screen, highlight the icon as shown and press the II button to confirm.

Using the preset channels

- In order to use the preset function, you must first complete anAutoscan. Please see the

“Autoscan Setting” in the “Using the Setting Menu Section” for details.

- Press the preset or button to display the icon.

- Use the to select the next preset station and use the to select the previous

preset station.

Recording an FM radio station

- Press the II button to start recording.

- Press the button to stop recording.

- The recorded file can be played by returning to the Music Player mode.

VOICE RECORDER

Use your unit to record quick reminder memos or even lengthy business meetings or lectures.

Press the mode button to access the MAIN MENU. The following menu will be displayed in

the LCD screen, highlight the icon as shown and press the II button to confirm.

Recording a voice message

- Press the II button to start recording.

- Press the button to stop recording.

- The recorded file is saved as WAV format.

Playing the Recorded File

- Press the II button to play the recorded file.

- Press the button to stop.

- Push to select the previous recorded file.

- Push to select the next recorded file.

NOTE :

- The volume is not controlled during recording.

- You may select three different quality levels to record. Please see the Recording Resolution

in the Customizing Your Player section.
