MP-Man MP249 Manuel utilisateur

MP3 & Video Player

Instruction Manual

Please read this instruction carefully before the operation

For Model No.

MP249

- 1 -

1. Introduction

Congratulation for the purchasing of the EM831 Player. The high integration reduces the device weight and

the dimensions and the use is comfortable. The FLASH memory allows using the MP3 player in every

situation. The big display with TFT technology offers clear and sharp information and the USB 2.0 High

Speed interface make easier the data transfer operation from/to the computer. The EM831 MP3 Player has

built-in a Li-Polymer battery rechargeable by computer USB port. By the microphone inside it is possible to

record voice messages and play them directly with the device or by computer.

Before using this product, please read this manual and retain the instruction for future reference.

2. Description

Here below you will find a product descripti

3. Display

Here below you will find a display description

4. Use

1. Power ON /OFF

2. USB Connector

3. MICRO SD

4. Earphone connector

5. Memu

6. Next / Forward

7. Volume

8. Previous / Backward

9. Play [] / Pause []

1. Battery Life

2. Time

3. Repeat mode

4. A-B repeat

5. EQ Model

6. Album Cover

7. Current song location

8. File name

9. Artist

10. Album

11. Genre

12. Total Time

13. Current song

14. Total Number of songs

- 2 -

a) Power ON/OFF

The MP3 player has built-in a rechargeable battery. At the first use we suggest to recharge the battery for a

long period. To recharge the battery please connect the MP3 player to USB computer port or adapter.

Powering On:.

1. Turn on On/Off button to On position

2. Hold the PLAY [] button for 2 seconds to power on screen

Powering Off:

1. Hold the PLAY [] key for 4 seconds, and then you will see the power off screen

2. Then, turn the On/Off button to Off position.

3. Under the state of stop, the player may power off automatically if a sleep time is predefined in

System Menu

b) Recharge the Player

The player can be recharged by the provided USB cable by connecting to the PC or AC adapter During

charging, You should first turn on your PC, and then connect the player to the PC throught the USB cable.

The player should be fully charged in 3 to 4 hours.

5. Main Menu

After powering on the MP3 player, you can see the main menu with 10submenus (optional), which allow you

to select different functions and options.

By using the [] or [] buttons, you can select the desire option, and then press Play button to confirm the

selection.

The available options are:

- 3 -

Music:

Select this option to play song.

Video:

Select this option to play video.

Radio:

Select this option to use the FM radio.

Pocture:

Select this option to browse and see photos.

Ebook:

Select this option to read text.

Record:

Select this option to record voice messages by the microphone inside.

Browser:

Select this option to explore the Folder of the Flash memory

Camera:

Select this option to take pictures

Tools:

Select this option to use stopwatch, calculateor,PC camera

Setting:

Select this option to access at system setup.

a) Music Mode

The music player option allows playing songs. To activate this option please follow here below instruction:

1. Power ON the MP3 Player, Then press the[] button, The screen will display the main menu

2. By using [] or [] buttons, select MUSIC option then press PLAY [] button.

3. Choose the song and press PLAY []button to start playing.

i. Key Function at MUSIC Mode

During the song play it is possible to activate the following controls.

PLAY [ ►



Press the PLAY [



] to start to play a song. Press the play button again to

pause the song. To restart to play the song press play button again.

Hold the play button and mode button at the same time will eventually turn off

the player

REW & FFWD [][]

Press [



] or [



] to select the next or the previous song.

Press and Hold the [] or [] buttons to rewind or fast forward the song.

Volume (VOL+ and VOL-):

First long press [VOL] button to show the Volume Mark.Then press [



]buttom

to increase the volume and press [] button to decrease the volume.

ii. Music Submenu

By long pressing the MENU [M] button, you can find the following music submenus. Press[] or [] to

choose, and then press PLAY []key to confirm each submenus. Use the same technique to navigate

inside each of the submenus. Press [M] button to return previous menu till exit main menu

Status Submenu Options

- 4 -

While music is on

Play mode

Screen Mode

Add to my playlist

Add Tag

A-B Repeat

VariableSpeed playback

delete

Advanced

EQ setting

Information

Five play modes are listed including Sequence, Repeat One, Repeat All, shuffle and Intro.

Play mode:

With preset 8 equalizers including Normal, Rock, Pop, Classic, Soft, Jazz ,DBB and User EQ

EQ :

Two screen modes are listed including spectrum and Lyric.

Screen Mode:

The player can loop-playing a specified music interval of a song. While Playing Music, Press and hold

Mbutton for a few seconds, Then selec the”A-B repeat”option press PLAY []button to set repeat start

point A, and then press PLAY []button again to set repeat end point B. The player will then loop-play the

content between point A and B.

A-B repeat:

Delete specific song you want

Delete:

b) VIDEO Mode

The VIDEO mode allows to play movies . To activate this option please follow here below instruction:

1. Power ON the MP3 Player, Then press the[] button, The screen will display the main menu.

2. By using [] or [] buttons, select VIDEO mode option then press PLAY [] button.

3. Choose the video and press PLAY [] button to start playing.

i. Key Function at Video Mode

During the song play it is possible to activate the following controls.

PLAY [ ►]:

Press the PLAY [



] to start to play a movie. Press the play button again to

pause the movie. To restart to play the movie press play button again.

- 5 -

Hold the play button for longer time will eventually turn off the player

REW & FFWD [



][



]

Press [



]or[



] to select the previous or the next movie.

Press and Hold the []or[] buttons to rewind or fast forward the movie.

Volume (VOL+ and VOL-

First long press [VOL] button to show the Volume Mark.Then press

[]buttom to increase the volume and press [] button to decrease the

volume.

ii. Video Submenu

By long pressing the MENU [M] button while movie is on, you can find the following music submenus. Press

[]or[] to choose, and then press PLAY [] key to confirm each submenus. Use the same technique

to navigate inside each of the submenus, Press MENU [M] button to return previous menu till exit main

Status

Submenu options

While Video is on

Playback Mode

Scan Speed

Add Tag

Screen Size

Resume

Delete

Information

Playback Mode

Fou repeat modes are listed including Sequence, Repeat One, Repeat Alland Shuffle.

You can adjust the speed of rewind or fast forward the movie by using []or[]buttons.

Screen Speed

Three screen size are listed includeing full screen, original size and scale.

Screen Size

Delete specific video you want

Delete

.C) FM (FM Radio)

When the FM Radio mode is activated it is possible to hear radio programs.

This option allows us to enjoy FM radio programs. To use it, please follow here below instruction:

1. Power ON the MP3 Player, Then press the play[] button,the screen will display the main menu

2. By using []or[] buttons, select FM option then press play[]button to confirm.

3. The player will start broadcasting the last preset radio channel

4. Short press []or[] button, to choose the previous or the next preset channel.

- 6 -

5. Press [M button to return previous menu till exit main menu

I FM Submenu

By long pressing the MENU [M] button, you can find the following FM submenus. Press []or[] to choose,

and then press play[] key to confirm each submenus. Use the same technique to navigate inside each of

the submenus.

Here below you will find the FM radio option list.

Auto Search:

Select this option to start auto-searching for radio channels.

Save channel:

Select this option to save radio channels

Record Quality:

Select this option to choose the recording quality including High, Medium and Low

FM Record:

Select this option to FM Record

Channel list:

Select this option to see saving channels

Save path:

Select this option to set saving path

Tuner Region:

Select this option to choose the tuner region including CHN,USA,JAPAN and EUROPE

II Automatic Search

To scan automatically all the available channels, please follow here below instruction:

1. When the FM Mode is activated, Long press MENU [M] button to select AUTO option.

2. Press play[] button to start the automatic search. The MP3 Player will store maximum 20 radio

programs available.

3. It is muted while searching.

d) PHOTO (Photo Viewer)

The Photo option allows viewing photos. To activate this option please follow here below instruction:

1. Power ON the MP3 Player, Then press the play[] button ,The screen will display the main menu.

2. By using the []or[] buttons select PHOTO, and then press play[]button to enter the PHOTO

MENU.

3. Use []or[] buttons to choose the photo ，

4. Press play[] button to start showing the photo.

Status

Submenu Options

When playing photos（long press

[M]）

Delete

Rotate

Zoom

Delete specific picture you want

Delete

Can circumgyrate playing photos 90 degree,180 degree,270 degree(can not support photo in GIF)

Rotate

Zoom

- 7 -

Can blow up or reduce photo(can not support photo in GIF.

5. Press [M] to return previous menu till exit main menu

E）EBOOK

The EBOOK option allows reading EBOOK file. To activate this option please follow here below instruction:

1. Power ON the MP3 Player, Then press the play[] button ,The screen will display the main menu.

2. By using the []or[] buttons select TEXT, and then press play[] button to confirm.

Dir List

Press play[] button to enter into local folder and show all TXT files

Tag List

Press play[



] button to enter into and show all tag files

3. Use[]or[] buttons to choose the file

4. Press play[] button to start reading the file，short press play[] button to swich manual

playing mode and auto playing mode.

5. When manual playing,press[]or[] to cross or return to previous page

6. Reading TXT file,long press [M] to enter into sub-menu

Status

Submenu Options

When reading

TXT

Add Tag

Delete

Skip To

Choose Add Tag and press play[] button can add current reading file into tag

Add Tag

Delete specific TEXT you want

Delete

Choose Skip To and long press []or[]can skip to the file you want

Skip To

7．Press [M] button to return previous menu till exit main menu

f) Record (Voice messages recorder)

This option allows to record voice messages by using the microphone inside. To record voice message,

please follow here below instruction:

1. Power ON the MP3 Player, Then press the play[] button ,The screen will display the main menu.

2. By using []or[] buttons, select RECORD option then press play[] button.

Now format Press play[]button to enter, By using []or[] buttons

to chooseWAV or

MP3recording format,Press play[] button to confirm

Rec Quality

Press play[



]button to enter, By using [



]or[



] buttons to choose Low,medium

- 8 -

and high recording quality .Press play[



] button to confirm

Save Path

Press play[



]button to enter, By using [



]or[



] buttons to choose Internal

memory and Micro SD. Press play[] button to confirm.

3. When recording,you can press play[]button to stop or keep on recording,Long press [M] to save

recording file.

4. You can listen to your save file under the MUSIC submenu.

5. Press [M]button to return previous menu till exit main menu。

g) BROWSER

Under theBROWSER menu, you can locate all kinds of files including music, videos, recordings, photos,

and text files . And you can enjoy these files directly from here. To use it, please follow here below instruction:

1. Power ON the MP3 Player, Then press the play[] button ,The screen will display the main menu

2. By using []or[] buttons, select BROWSER option then press play[] button to confirm.

3. You will enter the folder menu, in which you can see all kinds of files.

4. You can choose files from the flash , press play[] button to confirm and enjoy these files.

5. Press [M] to return to the folder menu.

h) CAMERA

Under the CAMERA,menu,you can take pictures and take video,option , To activate this option please follow

here below instruction:

1. Power ON the MP3 Player, Then press the play[] button ,The screen will display the main menu.

2. By using the []or[] buttons to select CAMERA, and then press play[] button to enter the

CAMERA MENU. And press []button to enter the DV menu.

3. By using the play[]button to take pictures or take video.

Camera Submenu

By long pressing the MENU [M] button, you can find the following camera submenus. Press []or[] to

choose, and then press play[] key to confirm each submenus. Use the same technique to navigate

inside each of the submenus.

Here below you will find the camera option list.

White Balance:

Select this option to choose the white balance including Auto,Fine,Cloudy, Filament

Lamp,Fluoresecent Lamp

Brightness:

Select this option to choose the LCD brightness including -3,-2 ,-1,0,1,2,3

Exposure Mode:

Select this option to choose the exposure Mode including AUTO ,Indoor,Outdoor.

Special Effect:

Select this option to choose the Special Effect including Off,Black&white,Sepia,Negative.

Save Path:

Select this option tochoose the save path including Flash,MICRO SD Card.

Resolution:

Select this option to choose the resolution including 2048X1536,1600X1200,

1280X1024,1024X768.640X480.

Memory Free Space

Select this option to see Memory Free Space.

- 9 -

Self-timer:

Select this option to choose the self-timer including off,5S,10S,15S,20S.

Shutter Sound:

Select this option to choose the shutter sound including off,sound1,sound2,sound3.

Date Stamp:

Select this option to choose the date stamp including off, Date, Date&Time.

i) Setting

The SETTING option allows to access to MP3 Player setup system. To access at system setup please follow

here below instruction:

1. Power ON the MP3 player, button, Then press the play[] button ,The screen will display the main

menu.

2. By using the []or[] select SYSTEM option then press play[]button to enter the SYSTEM

MENU.

3. By using the []or[] select the system setup parameter and press play[] button.

The parameters available in the setup system are:

Power Saving

This option allows setting of the power off time and sleep time.

Display:

This option allows setting of the display parameters.

Date/

Time:

This option allows setting of the Date/Time parameters.

Language Select

This option can choose different languages

Sync media playlist

This option can generating playlist

Advanced:

This option allows setting of the information,Select Key tone ,Effect setting,User

Name and reset default setting parameters

J) Tools

To activate this option please follow here below instruction:

1.Power ON the MP3 Player, Then press the play[] button ,The screen will display the main menu.

2.By using the []or[] buttons select Tools, and then press play[]button to enter the Tools

MENU.

3.Use []or[]buttons to choose the Tools ，

4.Press play[] button to enter

Here below you will find the tools list.

Stopwatch:

Select this option to use stopwatch function

Calculator:

Select this option to use calculator function

Calendar: Select this option to use calendar function.

PC camera:

Select this option to use PC camera function.

Table des matières

Autres manuels MP-Man Lecteur MP3

MP-Man

MP-Man MP-F56 Manuel

MP-Man

MP-Man MP- F59 Manuel utilisateur

MP-Man

MP-Man MP-F60 Manuel utilisateur

MP-Man

MP-Man MP-F50 Manuel utilisateur

MP-Man

MP-Man BT 19 Manuel utilisateur

MP-Man

MP-Man MP-F90 Manuel utilisateur

MP-Man

MP-Man MP101 WOM Manuel utilisateur

MP-Man

MP-Man MP-FUB55 Manuel utilisateur

MP-Man

MP-Man MP3 WOM Manuel utilisateur

MP-Man

MP-Man MP-FOL7 Manuel utilisateur

MP-Man

MP-Man TS302 PAK Manuel utilisateur

MP-Man

MP-Man MP-F400 - annexe 1 Manuel utilisateur

MP-Man

MP-Man MP-FUB30 Manuel utilisateur

MP-Man

MP-Man SPORTY 2 Manuel utilisateur

MP-Man

MP-Man MIRROR2 Manuel utilisateur

MP-Man

MP-Man MPUB555 Manuel utilisateur

MP-Man

MP-Man Sporty 5 Manuel utilisateur

MP-Man

MP-Man MP-CS250 Manuel utilisateur

MP-Man

MP-Man MP135 Manuel utilisateur

MP-Man

MP-Man MP-FOL8 Manuel utilisateur

MP-Man

MP-Man MP-FUB 31 Manuel utilisateur

MP-Man

MP-Man MP-FUB26 - annexe 1 Manuel utilisateur

MP-Man

MP-Man MP-FUB34 Manuel utilisateur

MP-Man

MP-Man MP-FUB58 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur
