Moxa Technologies DA-660A Series Manuel utilisateur

DA-660A Series Hardware User’s Manual

Version 2.1, June 2021

www.moxa.com/product

DA-660A Series Hardware User’s Manual

The software described in this manual is furnished under a license agreement and may be used only in accordance

with the terms of that agreement.

Trademarks

The MOXA logo is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a commitment on the part of

Moxa.

Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not

limited to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to

the products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility

for its use, or for any infringements on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes are periodically made to the

information herein to correct such errors, and these changes are incorporated into new editions of the publication.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas

Toll

-free: 1-888-669-2872

Tel:

+1-714-528-6777

Fax:

+1-714-528-6778

Moxa China (Shanghai office)

Toll

-free: 800-820-5036

Tel:

+86-21-5258-9955

Fax:

+86-21-5258-5505

Moxa Europe

Tel:

+49-89-3 70 03 99-0

Fax:

+49-89-3 70 03 99-99

Moxa Asia

-Pacific

Tel:

+886-2-8919-1230

Fax:

+886-2-8919-1231

Moxa India

Tel:

+91-80-4172-9088

Fax:

+91-80-4132-1045

Table of Contents

1. Introduction...................................................................................................................................... 1-1

Overview ...........................................................................................................................................1-2

Package Checklist ...............................................................................................................................1-2

Product Features ................................................................................................................................1-2

Hardware Specifications ......................................................................................................................1-3

2. Hardware Introduction ..................................................................................................................... 2-1

Appearance........................................................................................................................................2-2

DA-662A-8 Models ......................................................................................................................2-2

DA-662A-16 Models.....................................................................................................................2-2

Dimensions ........................................................................................................................................2-3

Hardware Block Diagram .....................................................................................................................2-3

DA-662A-8 Models ......................................................................................................................2-3

DA-662A-16 Models.....................................................................................................................2-4

LED Indicators....................................................................................................................................2-4

Reset Button ......................................................................................................................................2-4

LCD Screen........................................................................................................................................2-5

Push Buttons......................................................................................................................................2-5

Real-time Clock ..................................................................................................................................2-5

3. Hardware Connection Description ..................................................................................................... 3-1

Placement Options ..............................................................................................................................3-2

Rack Mounting ............................................................................................................................3-2

Connecting the Hardware ....................................................................................................................3-2

Wiring Requirements ...................................................................................................................3-2

Connecting the Power ..................................................................................................................3-2

Connecting to the Network ...........................................................................................................3-3

Connecting to a Serial Device .......................................................................................................3-3

Configurable Pull High/Low Resistors for the RS-485 Port .................................................................3-4

Connecting to the Console Port .....................................................................................................3-5

USB Host ...................................................................................................................................3-5

CompactFlash .............................................................................................................................3-5

1. Introduction

The DA-660A Series embedded computers come with 8 to 16 software selectable RS-232/422/485 serial

ports, making them suitable for a variety of industrial applications. Models with 4 10/100 Mbps Ethernet

ports are also available. The DA-660A also comes with CF and USB ports to make it easy to add additional

storage space. The computers are designed with a standard 19-inch, rugged 1U rackmount case, and are

embedded with a 100-240 VAC power input. This combination of features gives users a robust and reliable

ready-to-run solution for applications such as data acquisition and power substations.

The following topics are covered in this chapter:



Overview



Package Checklist



Product Features



Hardware Specifications

DA-660A Series HW UM Introduction

1-2

Overview

The DA-660A Series computers are RISC-based, ready-to-run embedded computers designed for industrial

data acquisition applications. The models have either 8 or 16 RS-232/422/485 serial ports, and 2 USB hosts

based on the Moxa Macro 500 MHz communication processor. The DA-660A has 4 Ethernet ports. The

casing is a standard 1U, 19-inch-wide rack-mounted rugged enclosure. The robust, rack-mountable design

provides the hardened protection needed for industrial environment applications and makes it easy for users

to install the DA-660A on a standard 19-inch rack. The DA-660A Series computers are ideal for applications

that require a distributed embedded technology, such as SCADA systems, plant floor automation, and power

electricity monitoring applications.

The DA-660A Series computers are suitable for IT control room applications, the critical assets used in the

control and automation system of industrial plant floors, and in electric power utility substations. The

computers can accept a wide range of power inputs (from 100 to 240V), which means that they can be

connected to AC power lines. Because of the no-hard-disk, fanless, and energy-efficient design, the

computers minimize heat generation, can operate around the clock, year in and year out, in heavy duty,

harsh industrial environments, delivering the kind of reliable computing power expected of a multifunctional

controller.

You can choose DA-660A Series models that come preinstalled with the open-standard Linux OS. The built-

in SDK makes program development easy by allowing you to follow the common programming procedures

used on a standard PC. The software you develop for your own applications can be stored in the onboard

Flash memory. The DA-660A Series embedded computers are ideal for creating control systems with

distributed architecture that are based on embedded technologies. Typical applications include SCADA

systems, plant floor automation, and power electricity monitoring.

Package Checklist

Before installing the DA-660A Series, verify that the package contains the following items:

•1 DA-660A Series embedded computer

•6 jumper caps

•19-inch Rackmount Kit with 2 L-shaped metal plates and 8 screws

•Ethernet Cable: RJ45-to-RJ45 cross-over cable, 100 cm

•CBL-RJ45M9-150: RJ45-to-DB9 male serial port cable, 150 cm

•CBL-RJ45F9-150: RJ45-to-DB9 female console port cable, 150 cm

•Quick installation guide

•Warranty card

NOTE: Notify your sales representative if any of the above items are missing or damaged.

Product Features

•Moxa Macro 500 MHz Processor

•On-board 128 MB RAM, 32 MB Flash ROM

•8 to 16 RS-232/422/485 serial ports

•4 10/100 Mbps Ethernet

•Standard 19-inch rack-mount installation, 1U height

•Wide range of power input voltages from 100 to 240VAC

•LCD screen and push buttons for Human-Machine Interface (HMI)

•Ready-to-run Linux platform

•Robust, fanless design

DA-660A Series HW UM Introduction

1-3

Hardware Specifications

NOTE

The latest specifications for Moxa’s products can be found at

https://www.moxa.com.

2. Hardware Introduction

The DA-660A Series hardware is compact, well-designed, and built for rugged industrial applications. LED

indicators help you monitor the performance and identify trouble spots. Multiple ports allow the connection

of different devices for wireless operation. With the reliable and stable hardware platform that is provided,

you can devote your attention to the development of your application. In this chapter, learn the basics

about the embedded computer hardware and its different parts.

The following topics are covered in this chapter:



Appearance

DA-662A-8 Models

DA-662A-16 Models



Dimensions



Hardware Block Diagram

DA-662A-8 Models

DA-662A-16 Models



LED Indicators



Reset Button



LCD Screen



Push Buttons



Real-time Clock

DA-660A Series HW UM Hardware Introduction

2-2

Appearance

DA-662A-8 Models

Front View

Rear View

DA-662A-16 Models

Front View

Rear View

DA-660A Series HW UM Hardware Introduction

2-3

Dimensions

Hardware Block Diagram

The following block diagrams show the layout of the internal components of the DA-660A Series.

DA-662A-8 Models

Unit = mm

DA-660A Series HW UM Hardware Introduction

2-4

DA-662A-16 Models

LED Indicators

LED indicators are located on the front panel of the DA-660A Series.

LED Name LED Color LED Function

Ready Red Power is On, and system is ready (after booting up)

LAN1, LAN2,

LAN3, LAN4

Orange 10 Mbps Ethernet connection

Green 100 Mbps Ethernet connection

P1-P16 (Rx) Orange Serial port is receiving RX data from the serial device

Off Serial port is not receiving RX data from the serial device

P1-P16 (Tx) Green Serial port is transmitting TX data to the serial device

Off Serial port is transmitting TX data to the serial device

Reset Button

Press the Reset button on the front panel continuously for at least 5 seconds to load the factory default

configuration. After the factory default configuration has been loaded, the system will reboot

automatically. The Ready LED will blink on and off for the first 5 seconds, and then maintain a steady glow

once the system has rebooted.

We recommend that you only use this function if the software is not working properly, and you want to load

factory default settings. To reset an embedded Linux system, always use the software reboot command

/>reboot to protect the integrity of data being transmitted or processed. The Reset button is not designed

to hard reboot the DA-660A Series.

ATTENTION

Pressing the Reset button will only load the configura

tion file. All files in the /etc directory will revert to

their factory defaults, and

all user data in the Flash ROM will be deleted.
