UC-7112-LX Plus/UC-7112/UC-7110

Hardware User’s Manual

Edition 7.0, February 2017

www.moxa.com/product

UC-7112-LX Plus/UC-7112/UC-7110

Hardware User’s Manual

The software described in this manual is furnished under a license agreement and may be used only in accordance with

the terms of that agreement.

Trademarks

The MOXA logo is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a commitment on the part of

Moxa.

Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited

to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the

products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for

its use, or for any infringements on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes are periodically made to the

information herein to correct such errors, and these changes are incorporated into new editions of the publication.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas

Toll

-free: 1-888-669-2872

Tel:

+1-714-528-6777

Fax:

+1-714-528-6778

Moxa China (Shanghai office)

Toll

-free: 800-820-5036

Tel:

+86-21-5258-9955

Fax:

+86-21-5258-5505

Moxa Europe

Tel:

+49-89-3 70 03 99-0

Fax:

+49-89-3 70 03 99-99

Moxa Asia

-Pacific

Tel:

+886-2-8919-1230

Fax:

+886-2-8919-1231

Moxa India

Tel:

+91-80-4172-9088

Fax:

+91-80-4132-1045

Table of Contents

1. Introduction...................................................................................................................................... 1-1

Overview...........................................................................................................................................1-2

Package Checklist...............................................................................................................................1-2

Product Features ................................................................................................................................1-3

Product Specifications .........................................................................................................................1-3

Hardware Specifications...............................................................................................................1-3

Hardware Block Diagram .....................................................................................................................1-5

2. Hardware Introduction ..................................................................................................................... 2-1

Appearance........................................................................................................................................2-2

Dimensions........................................................................................................................................2-2

Panel Views .......................................................................................................................................2-3

LED Indicators....................................................................................................................................2-3

Internal SD Socket..............................................................................................................................2-4

Additional Functions............................................................................................................................2-4

Reset Button...............................................................................................................................2-4

Real Time Clock ..........................................................................................................................2-4

3. Hardware Connection Description..................................................................................................... 3-1

Wiring Requirements...........................................................................................................................3-2

Connecting the Power ..................................................................................................................3-2

Grounding the UC-71xx Embedded Computers................................................................................3-2

Connecting Data Transmission Cables ...................................................................................................3-3

Connecting to the Network ...........................................................................................................3-3

Connecting to a Serial Device .......................................................................................................3-3

Serial Console Port ......................................................................................................................3-4

Installing a Secure Digital (SD) Memory Card.........................................................................................3-4

1. Introduction

The Moxa UC-7110/7112 series of embedded computers are RISC-based, box-type computers that feature

dual 10/100 Mbps Ethernet ports, two RS-232/422/485 serial ports, and an ARM9 processor. The computers

come with Linux pre-installed. In addition, the UC-7112 Plus and UC-7112 have an internal SD socket for

storage expansion to offer high performance communication with unlimited storage in a super-compact,

palm-size box. The UC-7110/7112 series of embedded computers are the right solution for embedded

applications that call for a small computer, but that can store large amounts of memory and provide good

computing performance.

The following topics are covered in this chapter:



Overview



Package Checklist



Product Features



Product Specifications

Hardware Specifications



Hardware Block Diagram

UC-7112-LX Plus/UC-7112/UC-7110 Hardware Introduction

1-2

Overview

The UC-7110/7112 series of RISC-based communication platforms are ideal for embedded applications. All

three computers in the series (UC-7110, UC-7112, and UC-7112 Plus) come with 2 RS-232/422/485 serial

ports and dual 10/100 Mbps Ethernet LAN ports to provide users with a versatile communication platform.

The UC-7110/7112 series computers use the Moxa ART ARM9 192 MHz RISC CPU. Unlike the x86 CPU, which

uses a CISC design, the ARM9’s RISC design architecture and modern semiconductor technology provide these

computers with a powerful computing engine and communication functions, but without generating too much

heat. The built-in NOR Flash ROM (8 MB for UC-7110/7112, 16 MB for UC-7112 Plus) and SDRAM (16 MB for

UC-7110/7112, 32 MB for UC-7112 Plus) give you plenty of storage capacity, and the SD socket provides

greater flexibility for running various applications. The dual LAN ports built into the ARM9 allow the UC-71xx

computers to be used as communication platforms for basic data acquisition and protocol conversion

applications, and the two RS-232/422/485 serial ports allow you to connect a variety of serial devices.

The UC-7110 and UC-7112 come with the µClinux operating system pre-installed, and the UC-7112 Plus comes

with the Linux operating system with MMU support pre-installed. Software written for desktop PCs is easily

ported to the UC-71xx computers with a GNU cross complier, so that you will not need to spend time modifying

existing software code. The operating system, device drivers, and your own software can all be stored in the

computers’ Flash memory.

Package Checklist

The UC-7110/7112 series currently includes four models:

Standard Operating Temperature Models (-10 to 60°C)

UC-7110-LX

Ready-to-run embedded RISC computing platform with 2 Serial Ports, dual eEthernet, μClinux OS.

UC-7112-LX

Ready-to-run embedded RISC computing platform with 2 Serial Ports, dual eEthernet, SD slot, μClinux OS.

UC-7112-LX Plus

Ready-to-run embedded RISC computing platform with 2 Serial Ports, dual eEthernet, SD slot, Linux OS.

Wide Operating Temperature Model (-40 to 75°C)

UC-7110-T-LX

Ready-to-run embedded RISC computing platform with 2 Serial Ports, dual eEthernet, μClinux OS, Wide

Temperature.

Each model is shipped with the following items:

•1 UC-7110 or UC-7112 or UC-7112 Plus

•Quick installation guide (printed)

•Document & software CD

•Ethernet Cable: RJ45 to RJ45 cross-over cable, 100 cm

•CBL-4PINDB9F-100: 4-pin header to DB9 female console port cable, 100 cm

•Universal Power Adaptor

•Warranty card

Optional Accessories

•35 mm DIN-Rail Mounting Kit (DK-35A)

NOTE: Please notify your sales representative if any of the above items are missing or damaged.

UC-7112-LX Plus/UC-7112/UC-7110 Hardware Introduction

1-3

Product Features

The UC-7110/7112 series computers have the following features:

•Moxa ART ARM9 32-bit 192 MHz processor

•16 or 32 MB RAM (about 12 MB of user programmable space)

•8 or 16 MB Flash ROM (about 4 MB of user programmable space)

•Dual 10/100 Mbps Ethernet for network redundancy

•2 software-selectable RS-232/422/485 ports

•Serial port speed from 50 bps to 921.6 Kbps (non-standard baudrates supported)

•SD socket for storage expansion (UC-7112 and UC-7112 Plus only)

•Built-in RTC, Buzzer, WDT

•Built-in Linux Kernel 2.6 platform

•-40 to 75°C wide operating temperature model available (UC-7110 only)

•DIN-Rail or wall mountable

•Robust fanless design

Product Specifications

Hardware Specifications

Computer

CPU:

MOXA ART ARM9 32-bit RISC CPU, 192 MHz

OS (pre

-installed): μClinux or Linux

DRAM:

-7110/7112: 16 MB

-7112 Plus: 32 MB onboard

Flash:

-7110/7112: 8 MB onboard

-7112 Plus: 16 MB onboard

Storage

Storage Expansion:

SD slot (UC-7112/UC-7112 Plus only)

Ethernet Interface

LAN:

Auto-sensing 10/100 Mbps (RJ45) 2 ports

Magnetic Isolation Protection:

1.5 KV built-in

Serial Interface

Serial Standards:

RS-232/422/485 software-selectable (DB9 male) 2 ports

ESD Protection:

15 KV ESD for all signals

Console Port:

RS-232 (TxD, RxD, GND): 3-wire pin-header

Serial Communication Parameters

Data Bits:

5, 6, 7, 8

Stop Bits:

1, 1.5, 2

Parity:

None, Even, Odd, Space, Mark

Flow Control:

RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for RS-485

Baudrate:

50 bps to 921.6 Kbps (supports non-standard baudrates; see user's manual for details)

Serial Signals

-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND

-422: TxD+, TxD-, RxD+, RxD-, GND

-485-4w: TxD+, TxD-, RxD+, RxD-, GND

-485-2w: Data+, Data-, GND

UC-7112-LX Plus/UC-7112/UC-7110 Hardware Introduction

1-4

LEDs

System:

Ready

LAN:

LED located on the RJ45 connector: 10M/Link x 2, 100M/Link x 2

Serial:

TxD x 2, RxD x 2

Physical Characteristics

Housing:

Aluminum (1 mm)

Weight:

190 g

Dimensions:

77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in)

Mounting:

DIN-Rail, wall

Environmental Limits

Operating Temperature:

Standard Models:

-10 to 60°C (14 to 140°F)

Wide Temp. Models:

-40 to 75°C (-40 to 167°F)

Storage Temperature:

Standard Models:

-20 to 80°C (-4 to 176°F)

Wide Temp. Models:

-40 to 85°C (-40 to 185°F)

Ambient Relative Humidit

y: 5 to 95% (non-condensing)

Anti

-Vibration: 1 g @ IEC-68-2-6, sine wave (resonance search), 5-500 Hz, 1 Oct/min, 1 cycle,

13 min 17 sec

per axis (UC

-7110 only)

Power Requirements

Input Voltage:

12 to 48 VDC

Power Consumption:

4.5 W

• 170 mA @ 24 VDC

• 340 mA @ 12 VDC

Standards and Certifications

Safety:

UC-7110/7112: UL 60950-1, CSA C22.2 No. 60950-1-03, EN 60950-1

EMC:

EN 55032 Class A, EN 61000-3-2 Class A, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class A

Green Product:

RoHS, CRoHS, WEEE

Reliability

Alert Tools:

Built-in buzzer and RTC (real-time clock)

Automatic Reboot Trigger:

Built-in WDT (watchdog timer)

MTBF (mean time between failures):

• UC

-7110: 149,414 hrs

• UC

-7112: 148,980 hrs

Warranty

Warranty Period:

5 years

Note:

The Hardware Specifications apply to the embedded computer unit itself, but not to accessories. In

particular, the wide temperature specification does not apply to accessories such as the power adaptor and

cables.

UC-7112-LX Plus/UC-7112/UC-7110 Hardware Introduction

1-5

Hardware Block Diagram

UC-7110/7112-LX

UC-7112-LX Plus

2. Hardware Introduction

The UC-7110, UC-7112, and UC-7112 Plus are compact, rugged embedded computers designed for industrial

applications. The LED indicators on the computers’ outer casing help you monitor their performance, and assist

in identifying trouble spots. The hardware platform is both reliable and stable, and is an ideal solution for

adapting to custom applications. In this chapter, we cover the basic hardware of the UC-71xx series embedded

computers.

The following topics are covered in this chapter:



Appearance



Dimensions



Panel Views



LED Indicators



Internal SD Socket



Additional Functions

Reset Button

Real Time Clock

UC-7112-LX Plus/UC-7112/UC-7110 Hardware Hardware Introduction

2-2

Appearance

The front view of the UC-7112 is shown in the following figure. The UC-7110 and UC-7112 Plus look the same,

except that the UC-7110 does not have an internal SD slot.

Dimensions

The dimensions of the UC-7110, UC-7112, and UC-7112 Plus are exactly the same.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Moxa Technologies Ordinateur de bureau

Moxa Technologies

Moxa Technologies V2616 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MC-5157-AC/DC Manuel utilisateur

Moxa Technologies

Moxa Technologies V2403C Series Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-8112-ME-T-LX Instructions d'utilisation

Moxa Technologies

Moxa Technologies MC-1100 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MPC-2121 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies V2416A-C7 Manuel utilisateur

Moxa Technologies

Moxa Technologies ThinkCore DA-660-8-CE Manuel utilisateur

Moxa Technologies

Moxa Technologies MPC-2240 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-8100-ME-T Series Instructions d'utilisation

Moxa Technologies

Moxa Technologies V2406 Manuel utilisateur

Moxa Technologies

Moxa Technologies V2616A Series Instructions d'utilisation

Moxa Technologies

Moxa Technologies MC-7400 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies THINKCORE W311 Instructions d'utilisation

Moxa Technologies

Moxa Technologies V2403 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-7410-LX Plus Manuel utilisateur

Moxa Technologies

Moxa Technologies DA-681 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ThinkCore V481 Instructions d'utilisation

Moxa Technologies

Moxa Technologies UC-8100 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-8410A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies DA-682A-DPP Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MC-1112 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MC-5150-DC-CP Series Manuel utilisateur

Moxa Technologies

Moxa Technologies THINKCORE W315 Instructions d'utilisation

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
