AP-7522 Access Point

INSTALLATION GUIDE

MN000879A01B.fm Page 1 Thursday, July 10, 2014 11:01 AM

2AP-7522 Access Point

MOTOROLA SOLUTIONS and the Stylized M Logo are registered in the US Patent & Trademark Office. © Motorola Solutions,

MN000879A01B.fm Page 2 Thursday, July 10, 2014 11:01 AM

Installation Guide 3

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.2 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.3 Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.4 AP-7522 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.4.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.5 AP-7522 Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.0 Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.1 Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.3 Access Point Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.4 Power Injector System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.5 Wall Mount Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.5.1 Wall Mount Procedure - New Installation . . . . . . . . . . . . . . . . . 12

2.5.2 Wall Mount Procedure - Existing Access Point Replacement . . 13

2.6 Suspended Ceiling T-Bar Mount Installation . . . . . . . . . . . . . . . . . . . 14

2.7 LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.0 Basic Access Point Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.0 AP-7522 Access Point Specifications . . . . . . . . . . . . . . . . . . . . . . . . 30

4.1 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.2 Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.3 Radio Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

5.0 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

5.1 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

5.2 Wireless Device Country Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . 32

5.2.1 Country Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

5.2.2 Frequency of Operation - FCC and IC . . . . . . . . . . . . . . . . . . . . . 33

5.3 Health and Safety Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . 34

5.3.1 Warnings for the use of Wireless Devices . . . . . . . . . . . . . . . . . 35

MN000879A01B.fm Page 3 Thursday, July 10, 2014 11:01 AM

4AP-7522 Access Point

5.3.2 Potentially Hazardous Atmospheres - Fixed Installations . . . . . . 35

5.3.3 Safety in Hospitals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

5.4 RF Exposure Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5.4.1 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5.4.2 International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5.4.3 EU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5.4.4 US and Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5.5 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

5.6 Radio Frequency Interference Requirements - FCC . . . . . . . . . . . . . . . 37

5.6.1 Radio Transmitters - Part 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

5.6.2 Radio Frequency Interference Requirements - Canada . . . . . . . . 37

5.7 CE Marking and European Economic Area (EEA) . . . . . . . . . . . . . . . . . 38

5.8 Statement of Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.9 Japan (VCCI) - Voluntary Control Council for Interference . . . . . . . . . 39

5.10 Korea Warning Statement for Class B ITE . . . . . . . . . . . . . . . . . . . . . 39

5.11 Other Countries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.12 Waste Electrical and Electronic Equipment (WEEE) . . . . . . . . . . . . . 41

5.13 Turkish WEEE Statement of Compliance . . . . . . . . . . . . . . . . . . . . . . 42

6.0 Motorola Solutions Support Center . . . . . . . . . . . . . . . . . . . . . . . . . . 43

7.0 AP-7522 Access Point China ROHS Compliance . . . . . . . . . . . . . . . 44

MN000879A01B.fm Page 4 Thursday, July 10, 2014 11:01 AM

Installation Guide 5

1 Introduction

The AP-7522 external antenna and internal antenna Access Point’s are mid-tier Access Point’s with a relatively

small footprint which supports functionality for dependable and efficient network performance.The AP-7522 is a

2x2:2 802.11ac Access Point utilizing one 2.4 GHz 802.11n radio and one 5 GHz 802.11ac radio. The Access Point

housing is Plenum-rated (UL2043).

The Access Point’s unique WiNG 5 software enables the Access Point to function as either a Standalone Access

Point, an Adaptive Access Point, or a Virtual Controller.

If new to Motorola Solutions Access Point technology, refer to the WiNG Access Point System Reference Guide to

familiarize yourself with Access Point technology and the feature set supported by the WiNG operating system.

The guide is available at https://portal.motorolasolutions.com/Support/US-EN/Wireless+Networks.

This document is written for the qualified network device installer.

1.1 Document Conventions

The following graphical alerts are used in this document to indicate notable situations:

NOTE Tips, hints, or special requirements that you should take note of.

CAUTION Care is required. Disregarding a caution can result in data loss or

equipment malfunction.

WARNING! Indicates a condition or procedure that could result in personal injury or

equipment damage.

MN000879A01B.fm Page 5 Thursday, July 10, 2014 11:01 AM

6AP-7522 Access Point

1.2 Warnings

• Read all installation instructions and site survey reports, and verify correct equipment installation before

connecting the AP-7522 Access Point.

• Remove jewelry and watches before installing this equipment.

• Verify any device connected to this unit is properly wired and grounded.

• Verify there is adequate ventilation around the device, and that ambient temperatures meet equipment

operation specifications.

1.3 Site Preparation

• Consult your site survey and network analysis reports to determine specific equipment placement, power

drops, and so on.

• Assign installation responsibility to the appropriate personnel.

• Identify and document where all installed components are located.

• Ensure adequate, dust-free ventilation to all installed equipment.

• Identify and prepare Ethernet and console port connections.

• Verify cable lengths are within the maximum allowable distances for optimal signal transmission.

1.4 AP-7522 Package Contents

An AP-7522 Access Point is available in external antenna (AP-7522) and internal antenna (AP-7522I)

configurations. An AP-7522 ships with the following:

• AP-7522 Access Point

• AP-7522 Installation Guide (This Guide)

• Wall mount screws and mounting bracket

1.4.1 Features

An AP-7522 Access Point supports the following feature set:

• Two RJ-45 connectors (GE1/POE and Console)

• Two LED indicators

• One 2.4 GHz 802.11n radio and one 5 GHz 802.11ac radio

• 2x2 MIMO, 2 spatial streams

The GE1/POE accepts 802.3at or 802.3af compliant power from an external source.

NOTE When operating in a Gigabit Ethernet environment, CAT-5e or CAT-6 cable

is recommended for Gigabit operation.

MN000879A01B.fm Page 6 Thursday, July 10, 2014 11:01 AM

Installation Guide 7

1.5 AP-7522 Antennas

An AP-7522 external antenna Access Point supports the following dual band antenna options:

An AP-7522 internal antenna Access Point supports the following dual band antenna:

Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi) Impdance (Ohms)

ML-2452-APA2-01 Dipole 3.17 4.6 50

ML-2452-HPA5-036 Dipole 3 5 50

ML-2452-APAG2A1-01 Dipole 2.7 1.7 50

ML-2452-PNA5-01R Panel 5.5 6 50

Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi) Impedance (Ohms)

BIRCH-INT-ANT Monopole 4.13 5.92 N/A

MN000879A01B.fm Page 7 Thursday, July 10, 2014 11:01 AM

8AP-7522 Access Point

2 Hardware Installation

2.1 Installation Instructions

An AP-7522 Access Point mounts either on a wall (with M 3.5 x 0.6 x 23 MM pan head screws and mounting

bracket- or equivalent) or on a suspended ceiling T-bar.

To prepare for the installation:

1. Match the part number on the purchase order with the part numbers in the packing list and on the case

of the Access Point.

2. Verify the contents of the box include the intended AP-7522 Access Point, and the included hardware

matches the package contents (see AP-7522 Package Contents on page 6).

3. Review site survey and network analysis reports to determine the location and mounting position for the

AP-7522 Access Point.

4. Connect a CAT-5 or better Ethernet cable to a compatible 802.3at or 802.3af power source and run the

cable to the installation site. Ensure there is sufficient slack on the cable to perform the installation

steps.

2.2 Precautions

Before installing an AP-7522 Access Point, verify the following:

• Your are using the correctly rated power solution for the AP-7522 (either the AP-PSBIAS-2P3-ATR power

injector or the PWRS-14000-54R external power supply)

• Motorola Solutions recommends you do not to install the AP-7522 in wet or dusty areas.

• Verify the environment has a continuous temperature range between -4° F to 104° F/-20° C to 40° C for

external antenna Access Points and 32° F to 104° F/0° C to 40° C for internal antenna Access Points.

Part Number Description

AP-7522-67040-US AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point external antenna US version

AP-7522-67040-WR AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point external antenna International version

AP-7522-67040-EU AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point external antenna EU version

AP-7522-67030-US AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point internal antenna US version

AP-7522-67030-WR AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point internal antenna International version

AP-7522-67030-EU AP-7522 dual radio 802.11ac 2x2:2 MIMO Access Point internal antenna EU version

NOTE When operating in a Gigabit Ethernet environment, CAT-5e or CAT-6 cable

is recommended for Gigabit operation.

MN000879A01B.fm Page 8 Thursday, July 10, 2014 11:01 AM

Installation Guide 9

2.3 Access Point Placement

For optimal performance, install the Access Point away from transformers, heavy-duty motors, fluorescent lights,

microwave ovens, refrigerators and other industrial equipment. Signal loss can occur when metal, concrete, walls

or floors block transmission. Install the Access Point in an open area or add Access Points as needed to improve

coverage.

Antenna coverage is analogous to lighting. Users might find an area lit from far away to be not bright enough. An

area lit sharply might minimize coverage and create dark areas. Uniform antenna placement in an area (like even

placement of a light bulb) provides even, efficient coverage.

Install the Access Point at an ideal height of 10 feet from the ground.

To maximize the Access Point’s radio coverage area, Motorola Solutions recommends conducting a site survey to

define and document radio interference obstacles before installing the Access Point.

2.4 Power Injector System

An AP-7522 Access Point can receive power via an Ethernet cable connected to the GE1/POE (LAN) port.

When users purchase a WLAN solution, they often need to place Access Points in obscure locations. In the past, a

dedicated power source was required for each Access Point in addition to the Ethernet infrastructure. This often

required an electrical contractor to install power drops at each Access Point location. The Power Injector merges

power and Ethernet into one cable, reducing the burden of installation and allowing optimal Access Point

placement in respect to the intended coverage area.

The AP-7522’s supported Power Injector (Part No. AP-PSBIAS-2P3-ATR) is a high power POE Injector delivering up

to 30 watts. The Access Point can only use a Power Injector when connecting the unit to the Access Point’s GE1/POE

port. The Power Injector is separately ordered and not shipped with an existing AP SKU.

CAUTION Using a non-compliant injector, or an injector supporting legacy modes

will not allow the AP-7522 to function at optimum performance levels.

CAUTION Do not plug the AP-PSBIAS-2P3-ATR Power Injector into the Access

Point’s Console port. Connecting the Power Injector into the console

port can damage the port and void the AP-7522’s product warranty.

MN000879A01B.fm Page 9 Thursday, July 10, 2014 11:01 AM

10 AP-7522 Access Point

The Motorola Access Point Power Supply (Part No. PWRS-14000-54R) is not included with the Access Point and is

orderable separately as an accessory. If the Access Point is provided both POE power and PWRS-14000-54R power

concurrently, the Access Point will source power from the PWRS-14000-54R supply only. Disconnecting the AC

power from the PWRS-14000-54R causes the Access Point to re-boot before sourcing power from the POE power

injector. If the AP is operating using injector supplied power, the AP will not automatically reboot if an AC adapter

is connected. The Access Point continues to operate with power supplied from the AC adapter without change to

the Access Point operating configuration. If using AC adapter supplied power and a change to the AP’s operating

configuration is warranted, the Access Point needs to be manually rebooted by the customer.

A separate Power Injector is required for each AP-7522 Access Point comprising the network.

CAUTION The Access Point supports any standards-based compliant power

source (including non-Motorola Solutions power sources). However,

using the wrong solution (including a POE system used on a legacy

Motorola Solutions Access Point) could either limit functionality or

severely damage the Access Point and void the product warranty.

MN000879A01B.fm Page 10 Thursday, July 10, 2014 11:01 AM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Motorola Point d'accès sans fil

Motorola

Motorola AP-51 Series Manuel d'installation et d'exploitation

Motorola

Motorola AP-51XX Manuel d'installation et d'exploitation

Motorola

Motorola MC-802 Manuel utilisateur

Motorola

Motorola AP6532 Manuel utilisateur

Motorola

Motorola Verizon VAP2500 Manuel utilisateur

Motorola

Motorola AP-6511 Manuel utilisateur

Motorola

Motorola AP 5131 - Wireless Access Point Mode d’emploi

Motorola

Motorola AP-7131N-FGR Manuel utilisateur

Motorola

Motorola TLN3221B Manuel utilisateur

Motorola

Motorola AP-6521E Manuel utilisateur

Motorola

Motorola VAP2500 Manuel utilisateur

Motorola

Motorola CB3000 - Client Bridge - Wireless Access... Manuel utilisateur

Motorola

Motorola WS2000 - Wireless Switch - Network Management... Manuel utilisateur

Motorola

Motorola AP-7131 Series Comment utiliser

Motorola

Motorola WA840G Mode d'emploi

Motorola

Motorola AP 6522M Manuel utilisateur

Motorola

Motorola AP-0622 Manuel utilisateur

Motorola

Motorola AP-7131 Series Manuel d'installation et d'exploitation

Motorola

Motorola WA840GV2 Manuel utilisateur

Motorola

Motorola WiNG 5.4.2 Manuel utilisateur

Motorola

Motorola AP-650 Series Manuel utilisateur

Motorola

Motorola PMP 320 Manuel

Motorola

Motorola PTP 600 Series Manuel utilisateur

Motorola

Motorola AP-7131N-FGR Manuel d'installation et d'exploitation

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
