MC9090X-K/S Poster

BLACK

PANTONE 285

MC909X-K/S

http://www.symbol.com/mc9000

MC9090X-K/S Poster

Battery Removal

Scan Button

Cable Adapter Module Magnetic Stripe Reader

FEATURES

Back View

MC9094-SMC9090-K

SNAP-ON ACCESSORY INSTALLATION

CHARGING INSTRUCTIONS

Touch Screen

Microphone

Data

Slow Flash = Normal Charge= LED Indicator Location Solid Amber = Full Charge Fast Flash = Charging Error

DC Power Input

Data

DC Power Input

Four Slot Spare Battery Charger Single Slot Serial/USB Cradle Four Slot Cradles

Charge-Only Cradle and Ethernet Cradle

Indicator LED Bar

Scan Button

Power

Keypad

Strap

Exit Window

SIM Door

Headphone

Jack

Quick Start Guide

See User Guide for more information

Scan Button

Stylus

Speaker

Scan Button

Stylus

MC909X-K

MC909X-S

Speaker

Front View

MC909X-S Battery

MC909X-S Battery Adapter

MC909X-K

Battery

1. Connect cradle to power source.

2. Insert battery into mobile computer.

3. Insert mobile computer into cradle.

4. Charge the main battery until the amber charge indicator remains

lit (approximately 4 hours).

5. To fully charge the backup battery, keep a fully charged main

battery in the mobile computer for at least 15 hours.

Charging Instructions

POST IN WORK AREA

MC909X-K/S

MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are registered in the U.S. Patent

and Trademark Office. All other product or service names are the property of their respective owners.

012345

OPTIMUM IMAGING AND SCANNING POSITIONS

OPTIMUM BODY POSTURE

Recommended Usage Guide

http://www.symbol.com/mc9000

72-72220-02 Rev. A - October 2007

Taking breaks and

task rotation recommended

High Scanning

Use a ladder

Low Scanning

CORRECT

WRONG

Scanning/Imaging

WRONG

CORRECT

AVOID EXTREME

WRIST ANGLES

AVOID BENDING

AVOID REACHING

POST IN WORK AREAPOST IN WORK AREA

AVOID EXTREME WRIST ANGLESOPTIMUM UPRIGHT BODY POSTURE

Scan Button

Battery

Power

Scan Button

Indicator LED Bar

Stylus

Strap Strap

Speaker

SIM Door

Exit Window

Speaker

Exit Window

MC9094-K MC9090-S

Stylus

Alternate left

and right knees

Alternate left

and right hands
