Motorola RFS7000 Series Manuel utilisateur

Motorola RFS Series Wireless LAN Switches

WiNG CLI Reference Guide

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Symbol is

a registered trademark of Symbol Technologies, Inc. All other product or service names are the

property of their respective owners.

About This Guide

Introduction

This guide provides information about using the following Motorola switches and version

numbers:

• WS5100 3.1

• RFS6000 3.1

• RFS7000 1.1

This Motorola RF Switch CLI Reference Guide and contains the following sections:

•Who Should Use this Guide

•How to Use this Guide

•Conventions Used in this Guide

•Motorola Service Information

•Motorola, Inc. End-User License Agreement

Who Should Use this Guide

The Motorola RF Switch CLI Reference Guide is intended for administrators responsible

for implementing, configuring, and maintaining a WS5100, RFS6000 or RFS7000 model

switch using the switch’s command line interface (CLI). It also serves as a reference for

configuring/modifying system settings. The administrator should be familiar with wireless

technologies, networking concepts, Ethernet concepts, IP addressing and SNMP.

To avoid confusion amongst WS5100, RFS6000 and RFS7000 CLI users, generic examples

are used throughout this guide. These examples are relevant to each switch.

Motorola RF Switch CLI Reference Guide

viii

Example

RFSwitch>cluster-cli enable

RFSwitch>

The syntax, parameters and descriptions within this guide can also be used generically for

a WS5100, RFS6000 and RFS7000 model switch. However, some subtle differences do

exist amongst these baselines. These differences are strongly noted within the specific

commands impacted. When these differences are noted, the options available to each

switch baseline are described in detail.

How to Use this Guide

This guide will help you implement, configure, and administer the switch and associated

network elements. This guide is organized into the following sections:

Chapter Jump to this section if you want to...

Chapter 1, “Introduction” Review the overall feature-set of the switch, as well as

the many configuration options available.

Chapter 2, “Common

Commands”

Understand the commands common amongst many

contexts and instance contexts within the switch CLI.

Chapter 3, “User Exec

Commands”

Summarize the User Exec commands within the

switch CLI.

Chapter 4, “Privileged Exec

Commands”

Review the Priv Exec commands within the switch CLI.

Chapter 5, “Global

Configuration Commands”

Understand the Global Config commands within the

switch CLI.

Chapter 6, “Crypto-isakmp

Instance”

Review the crypto-isakmp commands within the

switch CLI.

Chapter 7, “Crypto-group

Instance”

Understand the crypto-group commands within the

switch CLI.

Chapter 8, “Crypto-peer

Instance”

Summarize the crypto-peer commands within the

switch CLI.

Chapter 9, “Crypto-ipsec

Instance”

Review the crypto-ipsec commands within the

switch CLI.

Chapter 10, “Crypto-map

Instance”

Understand the crypto-map commands within the

switch CLI.

Chapter 11, “Crypto-

trustpoint Instance”

Summarize the crypto trustpoint commands within

the switch CLI.

Chapter 12, “Interface

Instance”

Understand the config-if commands within the

switch CLI.

Chapter 13, “Spanning tree-

mst Instance”

Summarize the (config-mst) instance commands

within the switch CLI.

Chapter 14, “Extended ACL

Instance”

Review the config-ext-nacl commands within the

switch CLI.

Chapter 15, “Standard ACL

Instance”

Understand the config-std-nacl commands within

the switch CLI.

Chapter 16, “Extended MAC

ACL Instance”

Review the config-ext-macl commands within the

switch command line.

Chapter 17, “DHCP Server

Instance”

Understand the (config-dhcp pool) commands

within the switch command line.

Chapter 18, “DHCP Class

Instance”

Review the (config-dhcp-class) instance

commands within the switch CLI.

Chapter 19, “Radius Server

Instance”

Summarize the (config-radsrv) instance commands

within the switch CLI.

Chapter 20, “Wireless

Instance”

Understand the (config-wireless) instance

commands within the switch CLI.

Chapter 21, “SOLE Instance” Review the (config-sole) instance commands within

the switch CLI.

Chapter Jump to this section if you want to...

Motorola RF Switch CLI Reference Guide

Chapter 22, “ARPI Instance” Review the (config-arpi) instance commands within

the switch CLI

Chapter 23, “ESPI Instance” Review the (config-espi) instance commands within

the switch CLI

Chapter Jump to this section if you want to...

Conventions Used in this Guide

This section describes the following topics:

•Annotated Symbols

•Notational Conventions

Annotated Symbols

The following document conventions are used in this document:

NOTE: Indicates tips or special requirements.

CAUTION: Indicates conditions that can cause equipment damage or

data loss.

SWITCH NOTE: Indicates caveats unique to a WS5100,

RFS6000 or RFS7000 model switch.

WARNING! Indicates a condition or procedure that

could result in personal injury or equipment damage.

Motorola RF Switch CLI Reference Guide

xii

Notational Conventions

The following notational conventions are used in this document:

• Italics are used to highlight specific items in the general text, and to identify chapters

and sections in this and related documents.

• Bullets (•) indicate:

• action items

• lists of alternatives

• lists of required steps that are not necessarily sequential

• Sequential lists (those describing step-by-step procedures) appear as numbered lists.

Convention Example Token Description Valid Inputs

bold Bold text indicates commands

and keywords that you enter

literally

italics Italic text indicates arguments

for which you supply values.

() (on|off) Grouping (exactly one of a list of

tokens)

{} {key1|key2|key

Selective recursive (multiple

tokens allowed, but each can

only be used once)

key1 key3

[ ]

[key1|key2|key

Infinite recursive (multiple

tokens allowed, each can be

used multiple times)

key1 key1 key2 key3

key2 key3

. .<1-10> Simple infinite recursive 1 2 6

? [key1|?key2] Selective keyword in infinite

recursive (multiple tokens, but

you can pick one that’s only

allowed once)

key1 key1 key2

xiii

Motorola Service Information

Use the Motorola Support Center as the primary contact for any technical problem,

question, or support issue involving Motorola products. Motorola Support Center responds

to calls by email, telephone or fax within the time limits set forth in individual contractual

agreements:

Telephone (North America): 1-800-653-5350

Telephone (International): +1-631-738-6213

Fax: (631) 738-5410

Email: [email protected]

When contacting Motorola Support Center, please provide the following information:

• Serial number of the unit.

• Model number or product name.

• Software type and version number.

Customer Support Website

Comprehensive on-line support is available at http://www.symbol.com/support/ .

Registration is free and a variety of services can be linked through this Web portal.

Product Sales and Product Information

Motorola, Inc.

One Motorola Plaza

Holtsville, New York 11742-1300

Tel: 1-631-738-2400 or 1-800-722-6234

Fax: 1-631-738-5990

Motorola RF Switch CLI Reference Guide

xiv

General Information

For general information, contact Motorola at:

Telephone (North America): 1-800-722-6234

Telephone (International): +1-631-738-5200

Website: http://www.motorola.com
