Motorola RFS6000 - Wireless RF Switch Manuel utilisateur

Motorola RFS Series Wireless

LAN Switches

WiNG CLI Reference Guide

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Symbol is

a registered trademark of Symbol Technologies, Inc. All other product or service names are the prop-

erty of their respective owners.

About This Guide

This Motorola RF Switch CLI Reference Guide and contains the following sections:

•Who Should Use this Guide

•How to Use this Guide

•Conventions Used in this Guide

•Motorola Service Information

•Motorola, Inc. End-User License Agreement

Who Should Use this Guide

The Motorola RF Switch CLI Reference Guide is intended for administrators responsible

for implementing, configuring, and maintaining a RFS6000 or RFS7000 model switch using

the switch’s command line interface (CLI). It also serves as a reference for configuring/

modifying system settings. The administrator should be familiar with wireless

technologies, networking concepts, Ethernet concepts, IP addressing and SNMP.

To avoid confusion amongst RFS6000 and RFS7000 CLI users, generic examples are used

throughout this guide. These examples are relevant to each switch.

Example

RFSwitch>cluster-cli enable

RFSwitch>

Motorola RF Switch CLI Reference Guide

viii

The syntax, parameters and descriptions within this guide can also be used generically for

a RFS6000 and RFS7000 model switch. However, some subtle differences do exist

amongst these baselines. These differences are strongly noted within the specific

commands impacted. When these differences are noted, the options available to each

switch baseline are described in detail.

How to Use this Guide

This guide will help you implement, configure, and administer the switch and associated

network elements. This guide is organized into the following sections:

Chapter Jump to this section if you want to...

Chapter 1, “Introduction” Review the overall feature-set of the switch, as well as

the many configuration options available.

Chapter 2, “Common

Commands”

Understand the commands common amongst many

contexts and instance contexts within the switch CLI.

Chapter 3, “User Exec

Commands”

Summarize the User Exec commands within the

switch CLI.

Chapter 4, “Privileged Exec

Commands”

Review the Priv Exec commands within the switch CLI.

Chapter 5, “Global

Configuration Commands”

Understand the Global Config commands within the

switch CLI.

Chapter 6, “Crypto-isakmp

Instance”

Review the (crypto-isakmp) commands within the

switch CLI.

Chapter 7, “Crypto-group

Instance”

Understand the (crypto-group) commands within the

switch CLI.

Chapter 8, “Crypto-peer

Instance”

Summarize the (crypto-peer) commands within the

switch CLI.

Chapter 9, “Crypto-ipsec

Instance”

Review the (crypto-ipsec) commands within the

switch CLI.

Chapter 10, “Crypto-map

Instance”

Understand the (crypto-map) commands within the

switch CLI.

Chapter 11, “Crypto-

trustpoint Instance”

Summarize the (crypto trustpoint) commands

within the switch CLI.

Chapter 12, “Interface

Instance”

Understand the (config-if) commands within the

switch CLI.

Chapter 13, “Spanning tree-

mst Instance”

Summarize the (config-mst) instance commands

within the switch CLI.

Chapter 14, “Extended ACL

Instance”

Review the (config-ext-nacl) commands within the

switch CLI.

Chapter 15, “Standard ACL

Instance”

Understand the (config-std-nacl) commands within

the switch CLI.

Chapter 16, “Extended MAC

ACL Instance”

Review the (config-ext-macl) commands within the

switch command line.

Chapter 17, “DHCP Server

Instance”

Understand the (config-dhcp-pool) commands

within the switch command line.

Chapter 18, “DHCP Class

Instance”

Review the (config-dhcp-class) instance

commands within the switch CLI.

Chapter 19, “Radius Server

Instance”

Summarize the (config-radsrv) instance commands

within the switch CLI.

Chapter 20, “Wireless

Instance”

Understand the (config-wireless) instance

commands within the switch CLI.

Chapter 21, “RTLS Instance” Review the (config-rtls) instance commands within

the switch CLI.

Chapter 22, “ESPI Instance” Review the (config-rtls-espi) instance commands

within the switch CLI

Chapter 23, “RFID Instance” Review the (config-rtls-rfid) instance commands

within the switch CLI

Chapter Jump to this section if you want to...

Motorola RF Switch CLI Reference Guide

Chapter 24, “SOLE Instance” Review the (config-rtls-sole) instance commands

within the switch CLI

Chapter 25, “Smart RF

Instance”

Review the (config-wireless-smart-rf) instance

commands within the switch CLI

Chapter 26, “Role Instance” Review the (config-role) instance commands

within the switch CLI

Chapter Jump to this section if you want to...

Conventions Used in this Guide

This section describes the following topics:

•Annotated Symbols

•Notational Conventions

Annotated Symbols

The following document conventions are used in this document:

NOTE: Indicates tips or special requirements.

CAUTION: Indicates conditions that can cause equipment damage or

data loss.

SWITCH NOTE: Indicates caveats unique to a RFS6000 or

RFS7000 model switch.

WARNING! Indicates a condition or procedure that

could result in personal injury or equipment damage.

Motorola RF Switch CLI Reference Guide

xii

Notational Conventions

The following notational conventions are used in this document:

• Italics are used to highlight specific items in the general text, and to identify chapters

and sections in this and related documents.

• Bullets (•) indicate:

• action items

• lists of alternatives

• lists of required steps that are not necessarily sequential

• Sequential lists (those describing step-by-step procedures) appear as numbered lists.

Understanding Command Syntax

command / keyword The first word is always a command. Keywords are words that

must be entered as is. Commands and keywords are mandatory.

For example, the command,

RFSwitch>show wlan 1

is documented as

show wlan <idx>

where:

• show – The command

• wlan – The keyword

<variable> Variables are described with a short description enclosed within

a ‘<‘ and a ‘>’ pair.

For example, the command,

RFSwitch>show wlan 1

is documented as

show wlan <idx>

where:

• show – The command – Display information.

• wlan – The keyword – The wlan

• <idx> – The variable – WLAN Index value.

xiii

| The pipe symbol. This is used to separate the variables/keywords

in a list.

For example, the command

RFSwitch> show .....

is documented as

show [autoinstall|banner|ip|ldap|......]

where:

• set – The command

• [autoinstall|banner|ip|ldap|......] – Indicates the different commands

that can be combined with the show command. However, only one of

the above list can be used at a time.

show autoinstall ...

show banner ...

show ip ...

show ldap ...

[ ] Of the different keywords and variables listed inside a ‘[‘ & ‘]’

pair, only one can be used. Each choice in the list is separated

with a ‘|’ (pipe) symbol.

For example, the command

RFSwitch# clear ...

is documented as

clear [crypto|mobility|spanning-tree]

where:

• clear – The command

• [crypto|mobility|spanning-tree] – Indicates that three keywords are

available for this command and only one can be used at a time

Motorola RF Switch CLI Reference Guide

xiv

{ } Any command/keyword/variable or a combination of them inside

a ‘{‘ & ‘}’ pair is optional. All optional commands follow the same

conventions as listed above. However they are displayed itali-

cized.

For example, the command

RFSwitch> show autoinstall ....

is documented as

show autoinstall {status}

Here:

• show autostatus– The command. This command can also be used as

show autostatus

•{status} – The optional keyword status. The command can also be

extended as

show autoinstall status

Here the keyword status is optional.

<values> Values to be entered as shown in Blue.

For example, the command

RFSwitch>show wlan 1

is documented as

show wlan <idx>

This command’s parameter <idx> is described as under:

“<idx> – <idx> (1-256) is the Wlan Index.”
