Motorola BLUETOOTH WIRELESS HEADSET Manuel utilisateur

Macey Noyes Associates

January 2, 2002

UNIQUE MOTOROLA ACCESSORIES

MAC4256_UNIQUE_THOR_UserGd_Tri

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other

product or service names are the property of their respective owners. The Bluetooth trademarks

are owned by their proprietor and used by Motorola, Inc. under license. (C) Motorola, Inc. 2001.

MOTOROLA et le logo M stylisé sont enregistrés au United States Patent and Trademark Office.

Tous les autres noms de produits ou de services sont la propriété de leurs détenteurs respectifs.

Les marques de commerce BLUETOOTH sont la propriété de leur détenteur et sont utilisées sous

licence par Motorola, Inc. © Motorola, Inc. 2001.

MOTOROLA y el logo estilizado de la M están registrados en la Oficina de patentes y marcas

registradas de EE.UU. Todos los otros nombres de productos y servicios son propiedad de sus

respectivos dueños. Las marcas comerciales de Bluetooth corresponden a marcas registradas de

su propietario y son utilizadas por Motorola, Inc. bajo licencia. (C) Motorola, Inc. 2001.

9887570M01

Imported to Canada by

Motorola Canada Limited

Mississauga, Ontario L4Z 2H4

Importé au Canada par

Motorola Canada Limitée

Mississauga (Ontario) L4Z 2H4

Welcome

Welcome to Motorola’s“connected”world of Bluetooth™ personal area wireless

networking.

You can place a call directly from your BluetoothWireless Headset by using your

Bluetooth capable phone and your phone’s voice activation feature.The headset

provides handsfree convenience and freedom from cables and wires.Bluetooth

technology makes all connections quickly and

without any cables

All Motorola wireless products are designed and manufactured to meet Motorola’s

rigorous speciﬁcations and world-class quality standards.During development,our

testing team took the Motorola BluetoothWireless Headset through rigorous

durability tests including temperature,humidity,shock,dust, vibration,and drop

tests.

We are conﬁdent that you will ﬁnd your BluetoothWireless Headset to be a

convenient and secure way to make clear,crisp phone calls.Thank you for choosing a

Motorola Bluetooth product!

Welcome.fm Page 1 Monday, January 14, 2002 1:40 PM

Personal Communications Sector

600 North U.S.Highway 45

Libertyville,Illinois 60048

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States)

1-800-461-4575 (Canada)

www.motorola.com

MOTOROLA,the Stylized M Logo and all other trademarks indicated as such herein

are trademarks of Motorola,Inc. ® Reg.U.S.Pat.&Tm.Off.The BLUETOOTH

trademarks are owned by their proprietor and used by Motorola,Inc., under license.

TrueSync is a trademark of Starﬁsh,Inc.,a wholly owned subsidiary of Motorola,Inc.

All other product or service names are the property of their respective owners.

Manual number: 9887570M01-O

Welcome.fm Page 2 Monday, January 14, 2002 1:40 PM

Contents

Safety and General Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Introduction

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

What Is BluetoothWirelessTechnology? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

How Can I Use My BluetoothWireless Headset? . . . . . . . . . . . . . . . . . . . . . . . 7

What Is Included inThis Kit? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Headset Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using Your Headset

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

ChargingYour Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Wearing the Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

LinkingYour Headset and Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Controlling HeadsetVolume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Placing a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Ending a Call from the Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Transferring a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Disconnecting the Bluetooth Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

UsingYour Headset Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Resetting the Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Paired Link toTwo Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

BluetoothTOC.fm Page 3 Monday, January 14, 2002 1:41 PM

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ

THIS INFORMATION BEFORE USING YOUR PHONE.

Users are not permitted to make changes or modify the device in any way.Changes

or modiﬁcations not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.See 47 CFR Sec.15.21.

This device complies with part 15 of the FCC Rules.Operation is subject to the

following two conditions:(1)This device may not cause harmful interference,and (2)

this device must accept any interference received,including interference that may

cause undesired operation.See 47 CFR Sec. 15.19(3).

Electromagnetic Interference/Compatibility

Note:

Nearly every electronic device is susceptible to electromagnetic interference

(EMI) if inadequately shielded,designed, or otherwise conﬁgured for

electromagnetic compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility conﬂicts,turn off your

phone in any facility where posted notices instruct you to do so.Hospitals or health

care facilities may be using equipment that is sensitive to external RF energy.

Safety.fm Page 4 Monday, January 14, 2002 1:42 PM

Safety and General Information

Aircraft

When instructed to do so,turn off your phone when on board an aircraft.Any use of

a phone must be in accordance with applicable regulations per airline crew

instructions.

Medical Devices

Pacemakers

The Health Industry ManufacturersAssociation recommends that a minimum

separation of 6 inches (15 centimeters) be maintained between a handheld wireless

phone and a pacemaker.These recommendations are consistent with the

independent research by,and recommendations of,WirelessTechnology Research.

Persons with pacemakers should:

•ALWAYSkeepthephone and Bluetooth phone module more than sixinches (15

centimeters) from your pacemaker when the phone is turned ON.

•NOT carry the phone and Bluetooth phone module in the breast pocket.

• use the ear opposite the pacemaker to minimize the potential for interference.

• turn OFF the phone immediately if you have any reason to suspect that

interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids.In the event of

such interference,you may want to consult with your hearing aid manufacturer to

discuss alternatives.

Safety.fm Page 5 Monday, January 14, 2002 1:42 PM

Safety and General Information

Other Medical Devices

Ifyou use anyotherpersonal medical device,consultthe manufacturerofyour device

to determine if it is adequately shielded from RF energy.Your physician may be able

to assist you in obtaining this information.

FCC Notice to Users

This equipment has been tested and found to comply with the limits for a Class B

digital device,pursuant to part 15 of the FCC Rules.These limits are designed to

provide reasonable protection against harmful interference in a residential

installation.This equipment generates,uses and can radiate radio frequency energy

and,if not installed and used in accordance with the instructions,may cause harmful

interference to radio communications.However,there is no guarantee that

interference will not occur in a particular installation.If this equipment does cause

harmful interference to radio or television reception,which can be determined by

turning the equipment off and on,the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

•Connectthe equipment to an outlet on a circuit differentfrom that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Safety.fm Page 6 Monday, January 14, 2002 1:42 PM

Introduction

What Is Bluetooth Wireless Technology?

Bluetooth

wireless technology propels you into a new dimension in connectivity.

Bluetooth devices communicate without wires,using built-in radio transceivers that

operate on a globally available radio frequency to ensure worldwide compatibility.

Your BluetoothWireless Headset can communicate with other Bluetooth devices

within a range of approximately 10 meters (33 feet).

How Can I Use My Bluetooth Wireless Headset?

The BluetoothWireless Headset lets you connect with a Bluetooth device such as a

Motorola 270c wireless phone with attached Bluetooth module

• Use your phone hands-free.

• Handle incoming and outgoing calls with the headset multifunction control

button.

• Use voice activation to make calls.

Note:

Connecting your headset requires Bluetooth Headset Proﬁle Support.Consult

your User’s Guide for more information.

Intro.fm Page 7 Monday, January 14, 2002 1:42 PM

Introduction

What Is Included in This Kit?

This package includes the following:

• Bluetooth headset

• Motorola charger

• Headset pouch with built-in belt clip

• Lanyard option for carrying the headset

Intro.fm Page 8 Monday, January 14, 2002 1:42 PM

Introduction

Headset Features

1—Headset Indicator light

Provides visual cue about headset status.

2—Volume Control

Adjusts speaker (receive) volume up and down.

3—Microphone

Picks up your voice input.

4—Boom

Contains microphone and controls power (On/Off) status of headset.

5—Earhook

Attaches headset to ear.

6—Speaker

Plays the sound you receive on the call.

7—Charging Port

Receives the plug for your battery charger.

8—Lanyard Loop

Lets you attach a lanyard to the headset,so you can wear the

headset around your neck and always keep it near.

9—Multifunction Button

Controls several headset functions.

Headset On

(boom open)

Headset Off

(boom closed)

Intro.fm Page 9 Monday, January 14, 2002 1:42 PM
