MOTO GUZZI V9 Roamer Mode d’emploi

SERVICE STATION MANUAL

2Q000193

V9 Roamer - V9 Bobber

SERVICE STATION

MANUAL

V9 Roamer - V9 Bobber

THE VALUE OF SERVICE

As a result of continuous updates and specific technical training programmes for Moto Guzzi products,

onlyMotoGuzziOfficialNetworkmechanicsknowthisvehiclefullyandhavethespecifictoolsnecessary

to carry out maintenance and repair operations correctly.

Thereliabilityofthevehiclealso dependsonitsmechanical conditions.Checkingthevehicle beforeriding

it, its regular maintenance and the use of original Moto Guzzi spare parts only are essential factors!

For information on the nearest Official Dealer and/or Service Centre consult our website:

www.motoguzzi.com

Only by requesting Moto Guzzi original spare parts can you be sure of purchasing products that were

developed and tested during the actual vehicle design stage. All Moto Guzzi original spare parts undergo

quality control procedures to guarantee reliability and durability.

Thedescriptionsandimagesinthispublicationaregivenforillustrativepurposesonlyandarenotbinding.

While the basic characteristics as described and illustrated in this booklet remain unchanged, Piaggio &

C.S.p.A. reserves theright, at anytime and withoutbeing required toupdate this publicationbeforehand,

to make any changes to components, parts or accessories, which it considers necessary to improve the

product or which are required for manufacturing or construction reasons.

Notallversions/modelsshowninthispublicationareavailableinallcountries.Theavailabilityofindividual

versions should be checked with the Official Moto Guzzi sales network.

The Moto Guzzi brand is owned by Piaggio & C. S.p.A.

in part is prohibited.

Piaggio & C. S.p.A. Viale Rinaldo Piaggio, 25 - 56025 PONTEDERA (PI), Italy

www.piaggio.com

SERVICE STATION MANUAL

V9 Roamer - V9 Bobber

This manual provides the main information to carry out regular maintenance operations on your vehicle.

This manual is intended to Moto Guzzi Dealers and their qualified mechanics; several concepts have

been deliberately omitted as they are considered unnecessary. As it is not possible to include complete

mechanical notions in this manual, users should have basic mechanical knowledge or minimum

knowledge about the procedures involved when repairing scooters. Without this knowledge, repairing or

checking the vehicle may be inefficient or even dangerous. As the vehicle repair and check procedures

are not described in detail, be extremely cautious so as not to damage components or injure individuals.

In order to optimise customer satisfaction when using our vehicles, Moto Guzzi commits itself to

continually improve its products and the relative documentation. The main technical modifications and

changes in repair procedures are communicated to all Moto Guzzi Sales Outlets and its International

Subsidiaries.These changes willbe introduced inthe subsequent editionsof the manual.In case ofneed

or further queries on repair and check procedures, consult Moto Guzzi CUSTOMER DEPARTMENT,

which will be prepared to provide any information on the subject and any further communications on

updates and technical changes related to the vehicle.

NOTE Provides key information to make the procedure easier to understand and carry out.

CAUTION Refers to specific procedures to carry out for preventing damages to the vehicle.

WARNING Refers to specific procedures to carry out to prevent injuries to the repairer.

Personal safety Failure to completely observe these instructions will result in serious risk of personal

injury.

Safeguarding the environment Sectionsmarked withthis symbol indicate the correctuse of the vehicle

to prevent damaging the environment.

Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious

damage to the vehicle and sometimes even the invalidity of the guarantee

INDEX OF TOPICS

CHARACTERISTICS CHAR

SPECIAL TOOLS S-TOOLS

MAINTENANCE MAIN

ELECTRICAL SYSTEM ELE SYS

ENGINE FROM VEHICLE ENG VE

ENGINE ENG

POWER SUPPLY P SUPP

SUSPENSIONS SUSP

CHASSIS CHAS

BRAKING SYSTEM BRAK SYS

BODYWORK BODYW

PRE-DELIVERY PRE DE

INDEX OF TOPICS

CHARACTERISTICS CHAR

Rules

Safety rules

Carbon monoxide

If you need to keep the engine running while working on the vehicle, please ensure that you do so in

an open or very well ventilated area. Never run the engine in an enclosed area. If you do work in an

enclosed area, make sure to use a fume extraction system.

CAUTION

EXHAUSTEMISSIONSCONTAINCARBONMONOXIDE, APOISONOUS GASWHICHCANCAUSE

LOSS OF CONSCIOUSNESS AND EVEN DEATH.

Fuel

CAUTION

THE FUEL USED TO POWER INTERNAL COMBUSTION ENGINES IS HIGHLY FLAMMABLE AND

MAY BE EXPLOSIVE UNDER CERTAIN CONDITIONS. IT IS THEREFORE RECOMMENDED TO

CARRY OUT REFUELLING AND MAINTENANCE PROCEDURES IN A VENTILATED AREA WITH

THE ENGINE SWITCHED OFF. DO NOT SMOKE DURING REFUELLING AND NEAR FUEL VA-

POURS, AVOIDING ANY CONTACT WITH NAKED FLAMES, SPARKS OR OTHER SOURCES

WHICH MAY CAUSE THEM TO IGNITE OR EXPLODE.

DO NOT DISPERSE FUEL IN THE ENVIRONMENT.

KEEP OUT OF THE REACH OF CHILDREN

Hot components

The engine and the exhaust system components become very hot and remain hot for some time after

the engine has been switched off. When handling these components, wear insulating gloves or wait

until the engine and the exhaust system have cooled down.

Used engine oil and transmission oil

CAUTION

IT IS ADVISABLE TO WEAR PROTECTIVE IMPERMEABLE GLOVES WHEN SERVICING THE VE-

HICLE.

THE ENGINE OR GEARBOX OIL MAY CAUSE SERIOUS INJURIES TO THE SKIN IF HANDLED

FOR PROLONGED PERIODS OF TIME AND ON A REGULAR BASIS.

WASH YOUR HANDS CAREFULLY AFTER HANDLING OIL.

HAND THE OIL OVER TO OR HAVE IT COLLECTED BY THE NEAREST USED OIL RECYCLING

COMPANY OR THE SUPPLIER.

DO NOT DISPOSE OF OIL IN THE ENVIRONMENT

KEEP OUT OF THE REACH OF CHILDREN

V9 Roamer - V9 Bobber Characteristics

CHAR - 7

Brake and clutch fluid

BRAKE AND CLUTCH FLUIDS CAN DAMAGE THE PLASTIC OR RUBBER PAINTED SURFACES.

WHEN SERVICING THE BRAKING SYSTEM OR THE CLUTCH SYSTEM, PROTECT THESE COM-

PONENTS WITH A CLEAN CLOTH. ALWAYS WEAR PROTECTIVE GOGGLES WHEN SERVICING

THESE SYSTEMS. BRAKE AND CLUTCH FLUIDS ARE EXTREMELY HARMFUL FOR YOUR

EYES. IN THE EVENT OF ACCIDENTAL CONTACT WITH THE EYES, RINSE THEM IMMEDIATELY

WITH ABUNDANT COLD, CLEAN WATER AND SEEK MEDICAL ADVICE.

KEEP OUT OF THE REACH OF CHILDREN

Battery electrolyte and hydrogen gas

CAUTION

THE BATTERY ELECTROLYTE IS TOXIC, CORROSIVE AND AS IT CONTAINS SULPHURIC ACID,

IT CAN CAUSE BURNS WHEN IN CONTACT WITH THE SKIN. WHEN HANDLING BATTERY

ELECTROLYTE, WEAR TIGHT-FITTING GLOVES AND PROTECTIVE APPAREL. IN THE EVENT

OF SKIN CONTACT WITH THE ELECTROLYTIC FLUID, RINSE WELL WITH PLENTY OF CLEAN

WATER. IT IS PARTICULARLY IMPORTANT TO PROTECT YOUR EYES BECAUSE EVEN TINY

AMOUNTSOF BATTERYACIDMAY CAUSEBLINDNESS. IF THEFLUID GETSINCONTACT WITH

YOUR EYES, WASH WITH ABUNDANT WATER FOR FIFTEEN MINUTES AND CONSULT AN EYE

SPECIALIST IMMEDIATELY. THE BATTERY RELEASES EXPLOSIVE GASES; KEEP IT AWAY

FROM FLAMES, SPARKS, CIGARETTES OR ANY OTHER HEAT SOURCES. ENSURE ADE-

QUATE VENTILATION WHEN SERVICING OR RECHARGING THE BATTERY.

KEEP OUT OF THE REACH OF CHILDREN

BATTERY LIQUID IS CORROSIVE. DO NOT POUR IT OR SPILL IT, PARTICULARLY ON PLASTIC

COMPONENTS. ENSURE THAT THE ELECTROLYTIC ACID IS COMPATIBLE WITH THE BAT-

TERY TO BE ACTIVATED.

Maintenance rules

GENERAL PRECAUTIONS AND INFORMATION

When repairing, dismantling and reassembling the vehicle follow the recommendations reported below

carefully.

BEFORE REMOVING COMPONENTS

•Beforedismantling components,remove dirt, mud, dust and foreign bodiesfrom thevehicle.

Use the special tools designed for this bike, as required.

COMPONENTS REMOVAL

•Donot loosenand/or tighten screws and nutsusing pliers or any othertools than the specific

wrench.

•Mark the positions on all connection joints (pipes, cables, etc.) before separating them, and

identify them with different distinctive symbols.

•Each component needs to be clearly marked to enable identification during reassembly.

•Clean and wash the dismantled components carefully using a low-flammability detergent.

•Keep mated parts together since they have "adjusted" to each other due to normal wear.

Characteristics V9 Roamer - V9 Bobber

CHAR - 8

•Some components must be used together or replaced altogether.

•Keep away from heat sources.

REASSEMBLY OF COMPONENTS

CAUTION

BEARINGS MUST BE ABLE TO ROTATE FREELY, WITHOUT JAMMING AND/OR NOISE: OTH-

ERWISE, THEY NEED TO BE REPLACED.

•Only use ORIGINAL Moto Guzzi SPARE PARTS.

•Comply with lubricant and consumables use guidelines.

•Lubricate parts (whenever possible) before reassembling them.

•When tightening nuts and screws, start from the ones with the largest section or from the

internal ones, moving diagonally. Tighten nuts and screws in successive steps before ap-

plying the tightening torque.

•Always replace self-locking nuts, washers, sealing rings, circlips, O-rings (OR), cotter pins

and screws with new ones if their tread is damaged.

•When assembling the bearings, make sure to lubricate them well.

•Check that each component is assembled correctly.

•After a repair or routine maintenance procedure, carry out pre-ride checks and test the ve-

hicle on private grounds or in an area with low traffic density.

•Clean all coupling surfaces, oil guard rims and gaskets before refitting them. Smear a light

layer of lithium-based grease on the oil guard rims. Reassemble oil guards and bearings

with the brand or lot number facing outward (visible side).

ELECTRIC CONNECTORS

Electric connectors must be disconnected as described below; failure to comply with this procedure

causes irreparable damage to both the connector and the wiring harness:

Press the relevant safety hooks, if any.

•Grip the two connectors and disconnect them by pulling them in opposite directions.

•If any signs of dirt, rust, moisture, etc. are noted, clean the inside of the connector carefully

with a jet of compressed air.

•Ensure that the cables are correctly fastened to the internal connector terminals.

•Then connect the two connectors, ensuring that they couple correctly (if fitted with clips, you

will hear them "click" into place).

CAUTION

TO DISCONNECT THE TWO CONNECTORS, DO NOT PULL THE CABLES.

NOTE

THE TWO CONNECTORS CONNECT ONLY FROM ONE SIDE: CONNECT THEM THE RIGHT WAY

ROUND.

TIGHTENING TORQUES

CAUTION

IF UNSCREWING A SELF-LOCKING NUT, IT MUST BE REPLACED WITH A NEW ONE.

CAUTION

DO NOT FORGET THAT THE TIGHTENING TORQUES OF ALL FASTENING ELEMENTS ON

WHEELS, BRAKES, WHEEL BOLTS AND ANY OTHER SUSPENSION COMPONENTS PLAY A

V9 Roamer - V9 Bobber Characteristics

CHAR - 9

KEY ROLE IN ENSURING VEHICLE SAFETY AND MUST COMPLY WITH SPECIFIED VALUES.

CHECK THE TIGHTENING TORQUES OF FASTENING PARTS ON A REGULAR BASIS AND AL-

WAYS USE A TORQUE WRENCH TO REASSEMBLE THESE COMPONENTS. FAILURE TO COM-

PLY WITH THESE RECOMMENDATIONS MAY CAUSE ONE OF THESE COMPONENTS TO GET

LOOSE AND EVEN DETACHED, THUS BLOCKING A WHEEL, OR OTHERWISE COMPROMISE

VEHICLE HANDLING. THIS CAN LEAD TO FALLS, WITH THE RISK OF SERIOUS INJURY OR

DEATH.

Running-in

Engine run-in is essential to ensure engine long life and correct operation. Twisty roads and gradients

are ideal to run in engine, brakes and suspensions effectively. Vary your riding speed during the run-

in. This ensures that components operate under both "loaded" and "unloaded" conditions, allowing the

engine components to cool.

CAUTION

THE CLUTCH MAY EMIT A SLIGHT BURNING SMELL WHEN FIRST USED. THIS PHENOMENON

SHOULD BE CONSIDERED NORMAL AND WILL DISAPPEAR AS SOON AS THE CLUTCH

PLATES GET ADAPTED.

ITIS IMPORTANTTO STRAINENGINECOMPONENTSDURINGRUN-IN, HOWEVER,MAKE SURE

NOT TO OVERDO THIS.

CAUTION

THE FULL PERFORMANCE OF THE VEHICLE IS ONLY AVAILABLE AFTER THE SERVICE AT

THE END OF THE RUNNING IN PERIOD.

Follow these guidelines:

•Do not twist the throttle grip abruptly and completely when the engine is working at a low

revs, either during or after run-in.

•During the first 100 Km (62 miles) use the brakes gently, avoiding sudden or prolonged

braking. That is to permit the adequate adjustment of the pad friction material to the brake

discs.

AFTER THE SPECIFIED MILEAGE, TAKE THE VEHICLE TO AN OFFICIAL Moto Guzzi DEALER

FOR THE CHECKS INDICATED IN THE "AFTER RUN-IN" TABLE IN THE SCHEDULED MAINTE-

NANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE VEHI-

CLE.

Vehicle identification

SERIAL NUMBER LOCATION

These numbers are necessary for vehicle registration.

NOTE

ALTERING IDENTIFICATION NUMBERS MAY BE SERIOUSLY PUNISHABLE BY LAW. IN PAR-

TICULAR, MODIFYING THE FRAME NUMBER IMMEDIATELY VOIDS THE WARRANTY.

Characteristics V9 Roamer - V9 Bobber

CHAR - 10

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels MOTO GUZZI Moto

MOTO GUZZI

MOTO GUZZI V750 Ambassador Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V 1000 G 5 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI CALIFORNIA STONE Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Breva 1100 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V750 Ambassador Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V1000 I-Convert Manuel d'instructions

MOTO GUZZI

MOTO GUZZI V1000 G5 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI Stelvio 4v-1200 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI stelvio 1200 NTX MY11 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Stelvio 1200 8V Mode d’emploi

MOTO GUZZI

MOTO GUZZI Stelvio 4V-1200 ABS Manuel utilisateur

MOTO GUZZI

MOTO GUZZI BREVA V1100 Manuel de la liste des pièces

MOTO GUZZI

MOTO GUZZI 850 Le Mans III Manuel d'instructions

MOTO GUZZI

MOTO GUZZI California Manuel utilisateur

MOTO GUZZI

MOTO GUZZI BREVA V750IE Manuel de la liste des pièces

MOTO GUZZI

MOTO GUZZI 1000 SP II Manuel d'instructions

MOTO GUZZI

MOTO GUZZI Nevada Classic 750 ie Manuel d'instructions

MOTO GUZZI

MOTO GUZZI V1000 G5 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI 2Q000297 Mode d’emploi

MOTO GUZZI

MOTO GUZZI V 50 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI California II Manuel d'instructions

MOTO GUZZI

MOTO GUZZI Griso 8V-1200 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Nevada Classic 750 ie 2004 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI NORGE 1200 Manuel utilisateur

Manuels Moto populaires d'autres marques

OHVALE

OHVALE GP-0 Manuel de la liste des pièces

Yamaha

Yamaha Star XV19CTSZ 2009 Manuel utilisateur

KTM

KTM 350 XCF-W USA Manuel utilisateur

HYOSUNG

HYOSUNG ST7 Manuel utilisateur

Husqvarna

Husqvarna FC 250 2016 Manuel utilisateur

Ducati

Ducati SCRAMBLER 800 Manuel d'instructions

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manuel utilisateur

Yamaha

Yamaha 2006 YZF-R1V Manuel utilisateur

KTM

KTM Freeride E-XC 2021 Manuel utilisateur

Fantic

Fantic Enduro 125 Manuel utilisateur

Ducati

Ducati Supersport 750 desmodue Manuel utilisateur

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manuel d'instructions

Yamaha

Yamaha XVS650A Manuel utilisateur

Yamaha

Yamaha YZF-R6T(C) Manuel

Ducati

Ducati 748 monoposto strada Manuel utilisateur

ATK

ATK 1988 250 Manuel utilisateur

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manuel utilisateur

Triumph

Triumph Thunderbird Manuel utilisateur
