SERVICE STATION MANUAL

981078

V7 Classic

SERVICE STATION

MANUAL

V7 Classic

THE VALUE OF SERVICE

Only the mechanics of the official Moto Guzzi Service Network know this vehicle well, thanks to constant

technical professional development and Moto Guzzi specific training programmes, and have the tools

needed to carry out maintenance and repair operations correctly.

The reliability of the vehicle also depends on its mechanical conditions. Checking the vehicle before

setting off, carrying out routine maintenance and using only Moto Guzzi Original Spare parts is

fundamental!

For information about the nearest Official Dealer and/or Service Centre, consult the Yellow Pages or

search directly on the inset map in our Official Website:

www.motoguzzi.it

Only by purchasing Moto Guzzi Original Spare Parts will you get a product designed and tested during

the bike designing phase. Moto Guzzi Original Spare Parts are subject to systematic quality control

procedures so that their reliability and performance over time is guaranteed.

The descriptions and illustrations given in this publication are not binding; while the basic features as

described and illustrated in this manual remain unchanged, Moto Guzzi reserves the right, at any time

and without being required to update this publication beforehand, to make any changes to components,

parts or accessory supplies, which it deems necessary to improve the product or which are required for

manufacturing or commercial reasons.

Not all versions shown in this publication are available in all countries. The availability of individual

versions should be checked with the official Moto Guzzi sales network.

prohibited. Moto Guzzi - After sales service.

Moto Guzzi trademark is property of Piaggio & C. S.p.A.

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

SERVICE STATION MANUAL

V7 Classic

This manual provides the main information to carry out regular maintenance operations on your vehicle.

This manual is intended to Moto Guzzi Dealers and their qualified mechanics; several concepts have

been deliberately omitted as they are considered unnecessary. As it is not possible to include complete

mechanical notions in this manual, users should have basic mechanical knowledge or minimum

knowledge about the procedures involved when repairing scooters. Without this knowledge, repairing or

checking the vehicle may be inefficient or even dangerous. As the vehicle repair and check procedures

are not described in detail, be extremely cautious so as not to damage components or injure individuals.

In order to optimise customer satisfaction when using our vehicles, Moto Guzzi s.p.a. commits itself to

continually improve its products and the relative documentation. The main technical modifications and

changes in repair procedures are communicated to all Moto Guzzi Sales Outlets and its International

Subsidiaries. These changes will be introduced in the subsequent editions of the manual. In case of

need or further queries on repair and check procedures, consult Moto Guzzi CUSTOMER

DEPARTMENT, which will be prepared to provide any information on the subject and any further

communications on updates and technical changes related to the vehicle.

NOTE Provides key information to make the procedure easier to understand and carry out.

CAUTION Refers to specific procedures to carry out for preventing damages to the vehicle.

WARNING Refers to specific procedures to carry out to prevent injuries to the repairer.

Personal safety Failure to completely observe these instructions will result in serious risk of personal

injury.

Safeguarding the environment Sectionsmarkedwiththis symbol indicate the correct use of the vehicle

to prevent damaging the environment.

Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious

damage to the vehicle and sometimes even the invalidity of the guarantee.

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

INDEX OF TOPICS

CHARACTERISTICS CHAR

SPECIAL TOOLS S-TOOLS

MAINTENANCE MAIN

ELECTRICAL SYSTEM ELE SYS

ENGINE FROM VEHICLE ENG VE

POWER SUPPLY P SUPP

SUSPENSIONS SUSP

CHASSIS CHAS

BODYWORK BODYW

PRE-DELIVERY PRE DE

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

INDEX OF TOPICS

CHARACTERISTICS CHAR

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Rules

Safety rules

Carbon monoxide

If you need to keep the engine running in order to carry out any procedure, please ensure that you do

so in an open or very well ventilated area. Never let the engine run in an enclosed area. If you do work

in an enclosed area, make sure to use a smoke-extraction system.

CAUTION

EXHAUSTEMISSIONSCONTAINCARBONMONOXIDE,APOISONOUSGASWHICHCANCAUSE

LOSS OF CONSCIOUSNESS AND EVEN DEATH.

Fuel

CAUTION

FUEL USED TO POWER INTERNAL COMBUSTION ENGINES IS HIGHLY FLAMMABLE AND CAN

BECOME EXPLOSIVE UNDER SPECIFIC CONDITIONS. IT IS THEREFORE RECOMMENDED TO

CARRY OUT REFUELLING AND MAINTENANCE PROCEDURES IN A VENTILATED AREA WITH

THE ENGINE SHUT OFF. DO NOT SMOKE DURING REFUELLING AND NEAR FUEL VAPOURS,

AVOID ANY CONTACT WITH NAKED FLAMES, SPARKS OR OTHER SOURCES WHICH MAY

CAUSE THEM TO IGNITE OR EXPLODE.

DO NOT DISPOSE OF FUEL INTO THE ENVIRONMENT.

KEEP OUT OF THE REACH OF CHILDREN.

Hot components

The engine and the exhaust system components get very hot and remain in this condition for a certain

time interval after the engine has been shut off. Before handling these components, make sure that you

are wearing insulating gloves or wait until the engine and the exhaust system have cooled down.

Used engine oil and transmission oil

CAUTION

IT IS ADVISABLE TO WEAR LATEX GLOVES WHEN SERVICING THE VEHICLE.

ENGINE OR TRANSMISSION OIL MAY CAUSE SERIOUS INJURIES TO THE SKIN IF HANDLED

FOR PROLONGED PERIODS OF TIME AND ON A REGULAR BASIS.

WASH YOUR HANDS CAREFULLY AFTER HANDLING OIL.

HAND THE OIL OVER TO OR HAVE IT COLLECTED BY THE NEAREST USED OIL RECYCLING

COMPANY OR THE SUPPLIER.

DO NOT DISPOSE OF OIL INTO THE ENVIRONMENT

KEEP OUT OF THE REACH OF CHILDREN.

Brake and clutch fluid

V7 Classic Characteristics

CHAR - 7

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

BRAKE AND CLUTCH FLUIDS CAN DAMAGE THE PLASTIC OR RUBBER PAINTED SURFACES.

WHEN SERVICING THE BRAKING SYSTEM OR THE CLUTCH SYSTEM, PROTECT THESE COM-

PONENTS WITH A CLEAN CLOTH. ALWAYS WEAR PROTECTIVE GOGGLES WHEN SERVICING

THESE SYSTEMS. BRAKE AND CLUTCH FLUIDS ARE EXTREMELY HARMFUL FOR YOUR

EYES. IN THE EVENT OF ACCIDENTAL CONTACT WITH THE EYES, RINSE THEM IMMEDIATELY

WITH ABUNDANT COLD, CLEAN WATER AND SEEK MEDICAL ADVICE.

KEEP OUT OF THE REACH OF CHILDREN.

Battery electrolyte and hydrogen gas

CAUTION

BATTERY ELECTROLYTE IS TOXIC, CORROSIVE AND AS IT CONTAINS SULPHURIC ACID, IT

CAN CAUSE BURNS WHEN IN CONTACT WITH THE SKIN. WHEN HANDLING BATTERY ELEC-

TROLYTE, WEAR TIGHT-FITTING GLOVES AND PROTECTIVE APPAREL. IF THE ELECTRO-

LYTIC FLUID COMES INTO CONTACT WITH THE SKIN, RINSE WELL WITH ABUNDANT FRESH

WATER. IT IS PARTICULARLY IMPORTANT TO PROTECT YOUR EYES AS EVEN TINY

AMOUNTS OF BATTERY ACID MAY CAUSE BLINDNESS. IF THE FLUID GETS INTO CONTACT

WITH YOUR EYES, WASH WITH ABUNDANT WATER FOR FIFTEEN MINUTES AND CONSULT

AN EYE SPECIALIST IMMEDIATELY. IF THE FLUID IS ACCIDENTALLY SWALLOWED, DRINK

LARGE QUANTITIES OF WATER OR MILK, FOLLOWED BY MILK OF MAGNESIA OR VEGETA-

BLE OIL AND SEEK MEDICAL ADVICE IMMEDIATELY. THE BATTERY RELEASES EXPLOSIVE

GASES; KEEP IT AWAY FROM FLAMES, SPARKS, CIGARETTES OR ANY OTHER HEAT

SOURCE. ENSURE ADEQUATE VENTILATION WHEN SERVICING OR RECHARGING THE BAT-

TERY.

KEEP OUT OF THE REACH OF CHILDREN

BATTERY LIQUID IS CORROSIVE. DO NOT POUR OR SPILL IT, PARTICULARLY ON PLASTIC

COMPONENTS. ENSURE THAT THE ELECTROLYTIC ACID IS COMPATIBLE WITH THE BAT-

TERY TO BE ACTIVATED.

Maintenance rules

GENERAL PRECAUTIONS AND INFORMATION

When repairing, disassembling and reassembling the vehicle, strictly follow the recommendations re-

ported below.

BEFORE DISASSEMBLING COMPONENTS

•Before disassembling components, remove dirt, mud, dust and foreign bodies from the ve-

hicle. Use the special tools designed for this vehicle, as required.

COMPONENTS REMOVAL

•Do not loosen and/or tighten screws and nuts using pliers or other tools other than the

especially designed wrench.

•Mark positions on all connection joints (pipes, cables etc.) before separating them, and

identify them with distinctive symbols.

•Each component needs to be clearly marked in order to be identified during assembly.

•Clean and wash the dismantled components carefully using a low-flammability detergent.

Characteristics V7 Classic

CHAR - 8

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

•Keep coupled parts together since they have "adjusted" to each other due to normal wear

and tear.

•Some components must be used together or replaced altogether.

•Keep away from heat sources.

REASSEMBLING COMPONENTS

CAUTION

BEARINGS MUST BE ABLE TO ROTATE FREELY, WITHOUT JAMMING AND/OR NOISE, OTH-

ERWISE THEY NEED REPLACING.

•Only use ORIGINAL Moto Guzzi SPARE PARTS.

•Comply with lubricant and consumables usage guidelines.

•Lubricate parts (whenever possible) before reassembling them.

•When tightening nuts and screws, start from the ones with the largest section or from the

internal ones, moving diagonally. Tighten nuts and screws in successive steps before ap-

plying the tightening torque.

•Always replace self-locking nuts, washers, sealing rings, circlips, O-rings, split pins and

screws with new ones if their tread is damaged.

•When fitting bearings, make sure to lubricate them well.

•Check that each component is fitted correctly.

•After a repair or routine maintenance procedure, carry out pre-ride checks and test the ve-

hicle on private grounds or in an area with low traffic density.

•Clean all junction surfaces, oil guard rims and washers before refitting them. Smear a light

layer of lithium-based grease on the oil guard rims. Reassemble the oil guard and the bear-

ings with the brand or lot number facing outward (visible side).

ELECTRIC CONNECTORS

Electric connectors must be disconnected as described below as non-compliance with the procedure

so described causes irreparable damage to both the connector and the cable harness:

Press the relevant safety hooks, if any.

•Grip and disconnect the two connectors by pulling them in opposite directions.

•Ifthereare signs of dirt, rust, humidity, etc.,cleantheconnector internal parts carefully using

a pressurised air jet.

•Make sure that the cables are correctly linked to the connector internal terminal ends.

•Then insert the two connectors making sure that they couple correctly (if the relevant hooks

are provided, you will hear them "click" into place).

CAUTION

TO DISCONNECT THE TWO CONNECTORS, DO NOT PULL THE CABLES.

NOTE

THE TWO CONNECTORS CONNECT ONLY FROM ONE SIDE: CONNECT THEM THE RIGHT WAY

ROUND.

TIGHTENING TORQUE

CAUTION

V7 Classic Characteristics

CHAR - 9

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

DO NOT FORGET THAT THE TIGHTENING TORQUE OF ALL FASTENING ELEMENTS ON

WHEELS, BRAKES, WHEEL SPINDLES AND OTHER SUSPENSION COMPONENTS PLAY A KEY

ROLE IN ENSURING THE VEHICLE'S SAFETY AND MUST COMPLY WITH SPECIFIED VALUES.

CHECK THE TIGHTENING TORQUE OF FASTENING PARTS ON A REGULAR BASIS AND AL-

WAYS USE A TORQUE WRENCH TO REASSEMBLE THESE COMPONENTS. FAILURE TO COM-

PLY WITH THESE RECOMMENDATIONS MAY CAUSE ONE OF THESE COMPONENTS TO GET

LOOSE AND EVEN DETACHED, THUS BLOCKING A WHEEL, OR OTHERWISE COMPROMISE

VEHICLE HANDLING. THIS CAN LEAD TO FALLS, WITH THE RISK OF SERIOUS INJURY OR

DEATH.

Running-in

Engine run-in is essential to ensure engine long life and correct operation. Twisty roads and gradients

are ideal to run in engine, brakes and suspensions effectively. Vary your driving speed during run-in.

In this way, you allow for the work of components to be "loaded" and then "unloaded", thus cooling

engine parts.

CAUTION

THE CLUTCH MAY EMIT A SLIGHT BURNING SMELL WHEN FIRST USED. THIS PHENOMENON

SHOULD BE CONSIDERED NORMAL AND WILL DISAPPEAR AS SOON AS THE CLUTCH

PLATES GET ADAPTED.

ITISIMPORTANTTOSTRAIN ENGINE COMPONENTS DURINGRUN-IN,HOWEVER,MAKESURE

NOT TO OVERDO THIS.

CAUTION

ONLY AFTER THE SERVICE AT THE END OF THE RUN-IN PERIOD CAN THE BEST PERFORM-

ANCE OF YOUR VEHICLE BE OBTAINED.

Follow the guidelines detailed below:

•Do not twist the throttle grip abruptly and completely when the engine is working at a low

revs, either during or after run-in.

•During the first 100 km (62 miles) operate the brakes with caution, avoid rough and long

braking. That is to permit the adequate adjustment of the pad friction material to the brake

discs.

AFTER THE SPECIFIED MILEAGE, TAKE THE VEHICLE TO AN OFFICIAL Moto Guzzi DEALER

FOR THE CHECKS INDICATED IN THE "AFTER-RUN" TABLE IN THE SCHEDULED MAINTE-

NANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE VEHI-

CLE.

Vehicle identification

SERIAL NUMBER POSITION

These numbers are necessary for vehicle registration.

NOTE

ALTERING IDENTIFICATION NUMBERS CAN BE SERIOUSLY PUNISHED BY LAW, PARTICU-

LARLY MODIFYING THE CHASSIS NUMBER WILL IMMEDIATELY INVALIDATE THE WARRAN-

TY.

Characteristics V7 Classic

CHAR - 10

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Autres manuels pour V7 CLASSIC

Table des matières

Autres manuels MOTO GUZZI Moto

MOTO GUZZI

MOTO GUZZI Breva 1100 Manuel de la liste des pièces

MOTO GUZZI

MOTO GUZZI CALIFORNIA CLASSIC Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V7 CLASSIC Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Stelvio 4v-1200 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Stelvio 1200 8V Manuel utilisateur

MOTO GUZZI

MOTO GUZZI California EV V1100 Mode d’emploi

MOTO GUZZI

MOTO GUZZI V7 Racer Manuel utilisateur

MOTO GUZZI

MOTO GUZZI California 1100 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Breva 1100 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI GRISO Manuel d'instructions

MOTO GUZZI

MOTO GUZZI CALIFORNIA EV Manuel d'instructions

MOTO GUZZI

MOTO GUZZI 850 Le Mans III Manuel d'instructions

MOTO GUZZI

MOTO GUZZI V750 Ambassador Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Daytona RS Manuel d'instructions

MOTO GUZZI

MOTO GUZZI V11 SPORT MY 2003 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI Quota 1000 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V11 SPORT MY 2003 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Manuel d'instructions

MOTO GUZZI

MOTO GUZZI V7 Cafe Classic Mode d’emploi

MOTO GUZZI

MOTO GUZZI Stelvio 1200 NTX Mode d’emploi

MOTO GUZZI

MOTO GUZZI Griso 8V-1200 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI 1000S Manuel utilisateur

MOTO GUZZI

MOTO GUZZI 850-T5 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V1000 I-Convert Manuel utilisateur

Manuels Moto populaires d'autres marques

OHVALE

OHVALE GP-0 Manuel de la liste des pièces

Yamaha

Yamaha Star XV19CTSZ 2009 Manuel utilisateur

KTM

KTM 350 XCF-W USA Manuel utilisateur

HYOSUNG

HYOSUNG ST7 Manuel utilisateur

Husqvarna

Husqvarna FC 250 2016 Manuel utilisateur

Ducati

Ducati SCRAMBLER 800 Manuel d'instructions

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manuel utilisateur

Yamaha

Yamaha 2006 YZF-R1V Manuel utilisateur

KTM

KTM Freeride E-XC 2021 Manuel utilisateur

Fantic

Fantic Enduro 125 Manuel utilisateur

Ducati

Ducati Supersport 750 desmodue Manuel utilisateur

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manuel d'instructions

Yamaha

Yamaha XVS650A Manuel utilisateur

Yamaha

Yamaha YZF-R6T(C) Manuel

Ducati

Ducati 748 monoposto strada Manuel utilisateur

ATK

ATK 1988 250 Manuel utilisateur

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manuel utilisateur

Triumph

Triumph Thunderbird Manuel utilisateur
