INSTRUCTION MANUAL
Model: MRMPO12T & MRMPO12W
Read these instructions carefully before
using this appliance for the rst time.
STORE THESE INSTRUCTIONS CAREFULLY
MultiOven
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au
2
Model: MRMPO12T MRMPO12W
Colour: Titanium White
Rated Voltage: 220-240V~50-60Hz
Rated Power: 2000W
Maximum Temperature: 230°C
Maximum Oven Capacity: 12L
External Dimensions (L x W x H): 427 x 367 x 249mm
Net Weight: 7kg
PARTS AND ACCESSORIES
SPECIFICATIONS
Temperature Control
Handle
Timer DialFunction Dial
Grill Rack
Baking Pan
Door Handle
Glass Door
Lid
3
WARNING
To reduce the risk of fire, electric shock, injury to persons or
damage to property, follow basic precautions including the
following:
• If the power cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
• Keep the appliance and its cord out of reach of children.
• WARNING: Misuse of appliance could cause personal injury.
• This appliance is not intended to be operated by means of an
external timer or a separate remote-control system.
• The appliance is not to be used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction.
• Children being supervised are not to play with the appliance.
• In the absence of supervision, the cleaning and maintenance
work should not be done by a child.
• Use of accessories not recommended or sold by the original
manufacturer may cause risks of fire, electric shock or
personal injury.
• This appliance must be used in accordance with the
instructions and must not be used for other purposes.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: HOT SURFACE
PLEASE BE AWARE OF HOT SURFACES
HANDLE WITH CARE
4
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
Location
• Do not use outdoors or near water, for indoor use only.
• Always use the appliance on a secure, dry level surface.
Power cord
• The power cord should reach from the socket to the base unit
without straining the connections.
• Do not let the cord hang over the edge of the table or counter
and keep it away from any hot surfaces.
• Do not let the cord run across an open space e.g. between a
low socket and table.
• This appliance has been incorporated with a grounded plug.
Please ensure the wall outlet is well earthed.
Personal safety
• The door and outer surface may get hot when the appliance is
operating. Use handle or knobs only.
• WARNING: To protect against fire, electric shock and personal
injury, do not immerse cord, plugs, or appliance in water or
other liquid.
• WARNING: Extreme caution must be used when moving
the appliance when containing hot food, water, or other hot
liquids.
5
• Unplug from the wall socket when not in use, before putting on
or taking off attachments, and before cleaning.
• Do not operate any appliance with a damaged cord or plug, or
after an appliance has malfunctioned, or has been dropped or
damaged in any way.
Other safety considerations
• Do not use any of the appliance parts in a microwave or on
any cooking/heated surfaces.
• Do not place on or near a hot gas or electric burner, or in a
heated oven.
• Do not leave the machine unattended.
• Never insert oversized food or flammable material such as
paper, cardboard or plastic into the appliance.
• Care should be taken when disposing of hot oil/grease after
cooking.
Treating scalds
• Run cold water over the affected area immediately. Do not
stop to remove clothing, seek medical help quickly.
Electrical requirements
• Check that the voltage on the rating plate of your appliance
corresponds with your house electricity supply which must be
A.C.
• WARNING: This appliance must be earthed.
• WARNING: This appliance is NOT to be used with extension
leads and/or power boards.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
6
CONTROL PANEL
Function Dial Timer Dial
Temperature Control Lever
BEFORE FIRST USE
Before using this product for the first time, please:
• Wash the Grill Rack and Baking Pan in warm soapy water and
dry before use.
• Before placing the Baking Pan onto the base heating element,
make sure there is no water between the pan base and the
base heating plate.
• Ensure any accessory placed in the appliance is fitted
correctly.
• Hold the door handle and lift up the top lid, which can be
opened to an angle of 85°-90°.
7
BEFORE FIRST USE
• Hold the door handle of the glass door and pull down and the
glass door can be opened to an angle of 90°-95°.
• Insert the Baking Pan into the oven cavity and ensure it is
stable on the base heating element.
• Place the Grill rack onto the Baking Pan.
• NOTE: The appliance is not designed for steaming food, so
please do not over fill the baking pan with water and steam
food on the grill rack, this could cause burning or an electric
shock.
• NOTE: The Grill Rack is not be used directly on the heating
element. It can only be used on the Baking Pan.
8
COOKING TEMPERATURES
OPERATING INSTRUCTIONS
• After connecting the power and turning the unit on, a short
beep will be heard and the timer dial indicator will illuminate
for 2 seconds, and then the power indicator will illuminate
solidly.
• Turn the Function Dial to the desired cooking setting. Dual
Heat for all round cooking, baking, roasting and panini’s &
pizza’s. Base Heat for frying, searing, grilling or BBQ and
Upper Grill for toasting, reheating or giving foods a lovely
crispy finish.
• Select the desired temperature with the Temperature Control.
The adjustable temperature ranges between 40°C and 230°C.
One beep can be heard after every temperature selection.
After reaching the selected temperature or 5 minutes after
the heating time is reached, three beeps can be heard and
preheating is completed.
• If you want to use the timer, turn the dial clockwise to select
the corresponing time in 5 minute increments. Turn the dial
anti-clockwise to reduce the timer. The appliance will turn off
automatically after the time expires.
• The unit can be turned off manually by sliding the Temperature
Control to OFF or automatically when the timer has been used
and the time expires.
• WARNING: During heating, the main body, Baking Pan and
Grill Rack will become very hot, so please handle carefully to
prevent being burnt.
• NOTE: When heating for the first time expect a small amount
of smoke. This is normal and should stop within 15 minutes.
For the first use, it is recommended to operate in a well
ventilated room.
• NOTE: Keep at least 30mm between the top of the food and
the upper grill element.
• NOTE: The Grill Rack is not to be used directly on the base
heating element. It can only be used on the Baking Pan. Do
NOT put food directly on the heating element, only the Baking
Pan or Grill Rack.
9
COOKING TEMPERATURES
OPERATING INSTRUCTIONS
DUAL HEAT FUNCTION
Baking, roasting and cooking panini’s & pizza’s can be done with
the Dual Heat function.
• Open the top lid or pull down the glass door by following the
instructions on pg 6 & 7. Put the food on the Grill Rack and
then close the top lid or glass door.
• NOTE: The Grill Rack is not be used directly on the heating
element. It can only be used on the Baking Pan.
• Turn the Function Dial to DUAL HEAT and then select the
desired temperature on the Temperature Control and select the
desired time with the Timer Dial. The MultiPot with Oven will
begin to operate.
• NOTE: During operation, you can turn the Function Dial,
Temperature Control or Timer Dial to different settings.
• NOTE: During normal operation of the appliance, if the
Function Dial is adjusted to an incorrect position, the
appliance will stop working. During this time, the Timer
indicator will keep flashing until the user turns the Function
Dial to the correct position.
• The selected time will begin to countdown and the indicator of
the selected time flashes. When the countdown is complete,
five beeps will be heard and the function is completed. The
power indicator will illuminate.
• NOTE: Continuous use of the Dual Heat function may leave
a residue of cooking oils and fats in the oven cavity. It is
recommended to turn the unit off and allow it to cool before
cleaning the cavity carefully.
• NOTE: When cooking foods containing high moisture content,
a little excess water may expel from the unit. This is due to the
sealing of the inner cavity and has no bearing on the safety of
the product.
10
COOKING TEMPERATURES
OPERATING INSTRUCTIONS
BASE HEAT FUNCTION
To cook kebabs or vegetables, it is recommended to use the
Base Heat function using the Grill Rack on top of the Baking Pan.
To fry, sear or grill meat, it is recommended to use the Base Heat
function using the Baking Pan.
• Open the top lid and apply some cooking oil to the Baking Pan
and then put the food on the Baking Pan. You can cook using
this function with the lid open or closed.
• Turn the Function Dial to BASE HEAT and then select the
desired temperature on the Temperature Control and select the
desired time with the Timer Dial. The MultiPot with Oven will
begin to operate.
• NOTE: During operation, you can turn the Function Dial,
Temperature Control or Timer Dial to different settings.
• NOTE: During normal operation of the appliance, if the
Function Dial is adjusted to an incorrect position, the
appliance will stop working. During this time, the Timer
indicator will keep flashing until the user turns the Function
Dial to the correct position.
• The selected time will begin to countdown and the indicator of
the selected time flashes. When the countdown is complete,
five beeps will be heard and the function is completed. The
power indicator will illuminate.
• NOTE: When selecting the BASE HEAT function, do NOT add
any more than 50ml of water to the Baking Pan, this could
cause a short circuit and other hazards caused by steam
entering the top lid assembly.
• NOTE: The Grill Rack is not to be used directly on the base
heating element. It can only be used on the Baking Pan. Do
NOT put food directly on the heating element, only the Baking
Pan or Grill Rack.
