Monster SuperStar Mode d’emploi
Manual and Warranty ·Manuel et Garantie ·Handbuch und Garantieschein ·Manual y Garantía
LIT_MAN_SuperStar_WW_g1jl.indd 1 2/7/14 10:38 AM
1
2
3
4
7
6
5
SuperStar™Features and Controls
Please Note:
SuperStar™oers audio feedback when you use the controls. When you hear
the sound the unit is performing the function you’ve initiated.
Functions that include audio feedback include:
• Power On
• Power O
• Bluetooth®pairing available
• Bluetooth pairing completed
• Incoming phone call
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 2 2/7/14 10:38 AM
1Bluetooth Sync Indicator
Blinks blue when ready to pair. Solid blue when paired. Bluetooth LED
is o when the device is not paired.
2Built-In Microphone for Speakerphone Use
For use when SuperStar™is connected to your smartphone or tablet.
3Bluetooth Control
Hold for about 3 seconds to initiate pairing mode.
4Volume Up
Press and hold to increase volume.
5Volume Down
Press and hold to decrease volume.
Note:
When playing music, SuperStar™is initially set at maximum audio level.
We recommend that you control the volume from you music source device.
(Music player, smartphone, computer).
When in phone mode, use the volume controls on your SuperStar™to
control the volume of your call.
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 3 2/7/14 10:38 AM
When you reach the maximum volume using the controls on your
SuperStar™, the Power Indicator LED will rapidly ash red. Likewise, when
you reach the minimum volume using the controls on your SuperStar™,
the Power Indicator LED will rapidly ash red.
6Power
Press and hold for about 3 seconds to turn the power On/O.
Note:
Auto o mode: The unit will automatically power o after 60 minutes
if no charging cable is attached. The unit will stay on if you’re playing music
or using the phone.
7Power Indicator
Solid Red = ON
Fast Flash = LOW BATTERY
Slow Flash = CHARGING. TURNS SOLID RED WHEN FULLY CHARGED
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 4 2/7/14 10:38 AM
8
910
83.5mm Audio Line In
Standard audio in for use without Bluetooth.
9Passive Radiator
10 USB Port
Micro USB port for charging SuperStar™and playing music from USB
equipped playback devices. (Cable Included)
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 5 2/7/14 10:38 AM
Note:
There is a slight tilt designed into the way the unit stands and the listening angle
is important for maximum audio performance. If you use SuperStar™laying at
it will still function normally but we recommend using the unit upright for best
audio enjoyment.
In the Box
• SuperStar™ Speaker System
• Carrying Case
• USB Charging/Audio Cable
Compatibility
Wireless
Devices with Bluetooth 2.0 wireless technology or above (See General
Specications for proles), such as Bluetooth wireless technology equipped
computers, and most Bluetooth wireless technology equipped smartphones
and MP3 players.
Wired
Devices with a standard 3.5 mm headphone output port via 3.5 mm minijack
cable (not included).
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 6 2/7/14 10:38 AM
Safety
Do not leave the product exposed to a heat source or high temperatures.
Do not remove or attempt to remove the non-user-replaceable battery. When
disposing of the product, take it to a waste electronics service.
The apparatus shall not be exposed to dripping or splashing and that no objects
lled with liquids, such as vases, shall be placed on the apparatus.
Batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, re, or the like.
Caution: Danger of explosion if battery is incorrectly replaced. Batteries must
be recycled or disposed of properly.
Information to consumers in application of EU WEEE Directive 96/2002
This product is subject to European Union regulations that promote the
re-use and recycling of used electrical and electronic equipment. This
product required the extraction and use of natural resources and may contain
hazardous substances. The symbol above, on the product or on its packaging,
indicates that this product must not be disposed of with your other household
waste. Instead, it is your responsibility to dispose of your waste equipment
by handing it over to a designated collection point for the recycling of waste
electrical and electronic equipment. The separate collection and recycling of
your waste equipment at the time of disposal will help to conserve natural
resources and ensure that it is recycled in a manner that protects human health
and the environment. For more information about where you can drop o
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 7 2/7/14 10:38 AM
your waste equipment for recycling, please contact your local city oce, your
household waste disposal service, or the store from which you purchased
the product. For more information about Monster products, please visit us at:
www.MonsterProducts.com.
This device complies with Part 15 of FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including interference
that may cause undesired operation. Changes or modication not expressly
approved by the party responsible for Compliance could void the user’s
authority to operate the equipment. Connecting of peripherals requires the use
of grounded shielded signal cables. The socket-outlet shall be installed near the
equipment and shall be easily accessible. Note: This equipment has been tested
and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 8 2/7/14 10:38 AM
FCC ID:RJE191011-00
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s (or your) authority to operate the equipment.
Avoid storage in extreme heat or cold. Avoid exposure to liquids, temperature
extremes and high humidity. The product’s working temperature range is
0–45°C (32–113°F).
Industry Canada
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. Under Industry
Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 9 2/7/14 10:38 AM
Operation
Power
SuperStar™ comes with a lithium-ion battery. For best results, fully charge
SuperStar™ before use. (recommended output of charging device is 2A)
To charge, plug the micro USB cable into SuperStar™ and plug the standard
USB connector into your power source. (Wall adapter. Laptop. Desktop.
External battery etc.) While charging the red power LED will blink. When
charging is complete, the light will be solid red.
Audio Connection
There are three ways to connect to audio sources.
• Bluetooth
• USB Cable
• Direct AUX In 3.5mm
Bluetooth Connection
To use Bluetooth for your audio connection rst pair SuperStar™with your
audio source. (Music Player. Smartphone. Laptop. Or other Bluetooth equipped
device that can act as a source of music)
First press and hold the Bluetooth button for three seconds or until you hear
the tone. The blue Sync LED will come on and blink. This means SuperStar™is
in pairing mode. Make sure Bluetooth is enabled on your audio source and in a
ENGLISH
LIT_MAN_SuperStar_WW_g1jl.indd 10 2/7/14 10:38 AM
