Monacor HDCAM-5090 Manuel utilisateur

HDCAM-5090

HIGH SPEED DOME CAMERA

USER’S MANUAL

Table of Contents

Precautions………………………………………………………………....2

Features……………………………………………………………………….3

Technical Data……………………………………………………………..9

Installation Guide…………………………………………………………10

Dome Settings…………………………………………………………..…17

Operation Instructions…………………………………………………20

1 Precaution

1. Please read this manual carefully before the installations and operations.

2. Transportation Security

No heavy stress, violent vibration or water splash are allowed during

transportation, storage. The unit should be transported in separated

packing. In shipments of distributor and delivery of maintenance, any

damages caused by integral packing are not covered by warranty.

3. Installation

Avoid heavy stress and violent vibration during installation. Don’t touch the

dome cover directly by hand. When connecting the power source, please

follow all electric safety standards and only use the power supply

designated for this device. Keep the video and control signal in a decent

distance from high voltage devices and cable. Don’t apply power to dome

before finishing the installation.

4. Internal Environment

Keep metal and inflammable material away from dome body to avoid fire

short circuit and damage. Please prevent all liquids material from entering

the dome. If this occurs, please shut down the power and pull out the

plug-in. Then please inform the technical personnel immediately.

5. Electrical Safety

The video image would be interfered when the dome is installed near

Television, radio transmitter, voltage changer and audio amplifier.

6. Camera Protection

Avoid shooting very bright objects directly into the camera’s CCD (such

As the sun or light fittings) and avoid fixating the camera lens on bright

static object for long time, as it will cause Irreparable damage to the

camera’s CCD.

7. Cleaning Method

Please don’t use abrasive and violent detergent to clean the dome. Please

choose dry fabric and neutral detergent. And please use lens paper to clean

the lens.

8. Internal removing, assembly, repair and operations should be only

performed by qualified service personnel.

9. Please use our production under the following environmental standards:

Environmental Temperature -35～60

Environmental Humidity

<95

％

Barometric Pressure

～

106KPa

Power Supply

DC12V/4A

2 Features

2.1 Main Features

• Stepless speed changes, auto zoom/speed matching

• Pan 0.01~360o/S, Tilt 0.01o~120o/S, Preset: 400o/S (high speed IR speed dome)

• Pan 0.5o~20o, Tilt 0.5o~20o, Preset: 20o/s (for Vari-speed IR dome)

• Auto object track with zoom in/out and motion detection (Auto Track Model)

• Timing actions for 7 days of programmable schedule

• Built-in Semi-conductor heater & digital temperature sensor

• PWM cooling fan vari-speed temperature control

• Reserved network interface and space for network module

• Pan Tilt accuracy +/- 0.1o, 220preset positions

• 8 cruising tracks, each cruising track has 32 presets

• 4 pattern tours,10 Mins memory, 500 programmable instructions

• Multi-Protocol through RS485 or coaxial cable.

• 8 auto scan with use-defined left and right boundaries and settable scan speed

• 8 Privacy Zones with defined English camera title

• Auto Compatible PELCO_P, PELCO_D compatible

• Guard Location: the dome will rotate back to preset position after a period of

vacant time

• Alarm triggering: the alarm can trigger preset, auto scan, cruising and pattern

tours functions

• Soft Address Function: the use can set up the dome address without uninstall

the dome

2.2 Integrated Super Speed PTZ Rotator

• Delicate stepping motor, stable, sensitive and accurate

• 360° Pan and 90° Tilt range (auto-flip) without blind area

• Stepless speed change, auto zoom/speed matching

• Near / far IR Light auto matches camera zoom in/out

2.3 Built-in High Definition Day/Night Camera

• Auto iris, auto back light compensation

• Auto/manual white balance

• Auto/manual brightness control

• Auto/manual focus

• Multiple compatible camera brands including Sony, Samsung, LG, CNB, Sanyo

etc.

2.4 All-weather Outdoor Design

• 6 Inch High die-cast alloy aluminum construction

• High Precision Mould with high heat conductivity

• Fully enclosed isolation design for heat sink

• Nanometer Dustproof, waterproof and fog-proof lens

• IP66 Waterproof

• 3000V lightning and surge current protection

2.5 Function Instructions

• Focus / PTZ Speed Auto Match

The pan/tilt rotation speed could be automatically adjusted according to the

focus in/out, which makes it much more practical for manual target tracking.

(Only for the auto tracking IR speed dome)

• Auto Flip

When the camera tilts downward and goes just beyond the vertical position, the

camera will rotate 180 degrees.

• Preset Position Set up and Call Up

In the Preset function the dome stores the current pan/tilt angle, zoom and

other position parameters in its memory. When necessary the dome recalls

these parameters and adjusts the camera to a particular position. The user can

store, recall and clear the presets easily and promptly by using the keyboard

controller. The dome can store up to 220 presets.

• Auto Scan

Users can set up the left and right boundaries by control keyboard. Then speed

dome can scan between this boundary. It supports up to 8 groups of scanning

paths.

• Cruising Track

The preset position can be programmed to be recalled in a set of sequences. This

sequence can be set to let the camera scan from one position to the next in a

cycle at a set speed. This feature is called the “auto cruise”. The cruise sequence

and dwell time of each preset can be set. It supports up to 8 cruising tracks, each

cruising track with 32 presets.

• Pattern Tour

Dome can memorize 600s running path or 500 programmable instructions.

When start pattern tour, speed dome will move automatically according

recorded action path. It supports 4 groups of pattern tours.

• Guard Location

The dome will automatically return to preset position if there is no operation in a

period of vacant time.

• Default Action

When you start up the dome camera or do not send commands over a long time,

the dome camera will return to its default functions which include the home

place, auto pan, auto cruise and pattern.

• Dome Address Setup

The dome supports up to 256 addresses and the dome will only response to the

instructions given to its own address. Please check the dip switch on the bottom

of the dome for address setup.

• Manual Object Tracking

The use can move the joystick up, down, left or right to track the appearing

object in the screen and use the joystick to zoom in and out with auto focus.

• Privacy Mask Protection

Set black mask areas to protect the privacy zones. The black privacy locations

can be set, and support up to 8 mask zones.

• Timing Running Function

Users can set speed dome operation task at total 8 timing areas during 7 days.

• Coordinates and Directions Display

User can define the dome’s direction of due north, which will help to show

up the exact moving directions on screen. And zone title is supported to

display when the dome moves to the specified zone.

• Auto Tracking (Only Auto Tack Model)

The dome will automatically fix and track the moving object according to the

user’s setup via OSD.

• Motion Detection

The dome will detect the changes in the defined video zone and trigger alarm.

It supports to 8 video Locations, each with 4 detection zones.

• PTZ and Lens Control

1) Zoom Control

Users can control zoom by keyboard to get near or far images.

2) Focus Control

The default setting is auto focus. The camera will auto focus based on the center

of the video display to get the clear image. In some special occasions, the user

could do the manual focus to get the desired image effect.

3) Auto Iris Control

Auto Iris is aiming to detect the environmental lights condition and adjust the iris

to get the stabilized brightness of the image.

4) Auto Back Light Compensation

In the highly bright background, auto back light compensation is aiming to

compensate the brightness of the dark object and adjust the background

brightness to get a clear image.

5) Auto/Manual White Balance

Auto/Manual WB adjust depending on the environment light changes.

6) Day and Night Switch (Only for Day/Nigh Camera)

Speed dome camera can auto switch according to the environmental

illumination changes.

7) OSD Setup (Only for camera with menu)

Call upon preset No.95 to enter into OSD menu setup interface. Press “Focus”

to choose menu items and press “Iris” to set menu contents.

3 Technical Specifications

Power Supply DC12V+10% 50W

Night IR Distance 120/150/180meters

Manual Speed

Pan 0.01o~360o, Tilt 0.01o~120o(high speed) /

Pan:0.5

~20

/S, Tilt:0.5

~20

/S (Vair-speed)

Preset Speed 400 o/S (high speed) / 20o/S (Vari-speed)

Pan Angle 360o continuous pan rotation

Tilt Angle 90o(Auto Flip)

Presets Positions 220

Preset Accuracy +/-0.1o

Auto Scan 8 auto scan tracks, user-defined left and right boundaries and scan speed

Auto Cruising

8 cruising tracks, each cruising tracks has 32 preset positions,

user-defined dwell time

Pattern Tour 4 groups, each one with 10 Mins memory, 500 programmable instructions

Guard Location The dome will rotate back to preset position after a period of vacant time.

IR LED On Mode Manual/Auto/Timing

Data

Communication

RS-485

Protocols Auto Compatible PELCO_P, PELCO_D
