Controlling the projector using a personal computer

This projector can be controlled by connecting a personal computer with RS-232C terminal.

PC-controllable functions:

• Turning the power ON or OFF

• Changing input signals

• Inputting commands by pressing the buttons on the control panel and remote control

• Menu setting

Connection

RS-232C cable

D-SUB 9-pin

SERIAL

D-SUB 9-pin

To RS-232C

terminal

Important:

• Connect the computer with the projector on a one-to-one basis.

• Make sure that your computer and projector are turned off before connection.

• Boot up the computer rst, and then plug the power cord of the projector.

(If you do not follow this instruction, the Com port may not function.)

• Adapters may be necessary depending on the PC connected to this projector. Contact your dealer for details.

1. Interface

1.1 Pin assignment of SERIAL terminal (D-SUB 9-pin)

Pin No. Name I/O

1OPEN

2 RXD IN

3 TXD OUT

4OPEN

5GND

6OPEN

7OPEN

8OPEN

9OPEN

1.2 Communications format

PROTOCOL RS-232C

BAUD RATE 9600 [bps]

DATA LENGTH 8 [bits]

PARITY BIT NONE

STOP BIT 1 [bit]

FLOW CONTROL NONE

This projector uses RXD, TXD and GND lines for RS-232C control.

For RS-232C cable, the supplied cable (crossover cable) should be used.

2.Controlcommandconguration

The command consists of the address code, function code, data code, ACK/NAK, and end code. The length of the

command varies among the functions.

Address code Function code Data code ACK/NAK End code

ASCII ‘30h’ ‘30h’ Function Data ‘3Ah’ ‘4Eh’ ‘0Dh’

Character 00 Function Data :N

[Address code] Fixed to 00. (‘30h’ ‘30h’ in the ASCII code)

[Function code] Code unique to each control operation.

[Data code] Data (value) unique to each control operation (Not always indicated.)

[ACK/NAK] Code indicating the NAK return as described below

Fixed to :N (‘3Ah’ ‘3Eh’ in the ASCII code. Not added to ACK.)

[End code] Fixed to . (‘0Dh’ in the ASCII cade)

3. Control sequence

Computer Projecto

Sequence Note

1Send the command from the

personal computer to the projector.

The projector will send a return

command after it receives an end

code.

If the projector does not receive commands

normally, that is, if the projector is not connected

physically or unable to receive commands, it does

not send out a return command.

The projector sends out a return command within

one second at the latest.

When the received command cannot be executed,

NAK is returned (as described below).

The personal computer checks the

command and conrms if the sent

command has been received or not.

Use the check command to see

if the projector has executed the

command.

This projector sends various codes other than the

return code. When having a control sequence by

RS-232C, reject other codes from the personal

computer.

• NAK return

In the following cases, the projector returns the command with “:N” added.

(1) Though the command sent from the computer is received by the projector successfully, it cannot be

executed because the projector is in the operation prohibition state.

(2) The data length of the sent command is incorrect or the command is invalid.

• When a command is sent out during the following operations, it may not be executed.

(1) During signal switching

(2) In the process of the auto position

(3) After the power is turned on.

The projector receives no commands for about 20 seconds (or for 2 minutes at the longest if the lamp

does not light up promptly as the life is expiring). In this case, the projector returns the received command

with NAK added.

• The return command is sent out within 1 second at the latest.

• When sending commands successively, wait to receive the return command of the current command before

sending a next command.

• The projector may not receive a command when the splash screen is being displayed immediately after

turning on the power. Use command “00r10” to cancel the splash screen.

• While using the LAN terminals, the LAN functions take precedence.

• For the LAN terminals, the same commands as those for connecting with the TCP/IP (port number 63007) are

available. Note, however, that the response becomes slightly slower than when using the RS-232C terminals.

[Example 1] Turning ON the power. (Values enclosed in quotation marks are ASCII codes.):

Command sent from the PC Status code returned

from the projector Description

‘30’ ‘30’ ‘21’ ‘0D’

00!

Command for POWER ON

‘30’ ‘30’ ‘21’ ‘0D’

00!

Command receipt conrmation

(Command echo back)

[Example 2] Selecting VIDEO as the input signal during auto positioning (Values enclosed in quotation marks are

ASCII codes.):

Command sent from the PC Status code returned

from the projector Description

‘30’ ‘30’ ‘5F’ ‘76’ ‘31’

00_V1

(During auto positioning)

Command for selecting VIDEO as the

input signal is sent out.

‘30’ ‘30’ ‘5F’ ‘76’ ‘31’ ‘3A’ ‘4E’

00_v1:N

The command is received by the

projector but cannot be executed.

(NAK return)

• The owchart on the next page shows the recommended operating sequence for your reference to create a

program.

Projector error

Send out “00vER” to check error details.

Recover from error state.

0–3

To normal operation 4

Enter password.

Send out “00PASS****.”

Projector is functioning.

Use “00FNCOFF” to cancel the current function.

Sending “00vST”

Checking response to “00vST”

[Method of checking state of projector]

Sending out command

Awaiting response

from projector

Checking execution of

command (sending out

check command)

No response for

1 second or longer

END

NAK returned

Command is sent successfully.

Command execution fails.

Command is sent successfully.

Command is executed successfully.

Command sending fails.

No NAK returned

[RS-232C control flowchart]

START

Check the following.

•Check that the function code is

correct.

•Check that the data code is correct.

•Check that the projector is able to

issue the return command.

→Check the projectorʼs operation

using the 00vST command.

Note: In the following cases, NAK is

returned even when the

projector is in normal condition.

•

Immediately after the power is turned

on (about 20 seconds to 2 minutes)

•During input switching

•During auto positioning

•During password lock

Check the following.

•Check that the command begins

with “00”.

•The projector is not supplied with

AC power.

→Check that AC power cord is

connected.

→Turn on the power. (Turn on the

circuit breaker or main switch.)

•Not connected with the projector.

→Check that the RS-232C cable is

connected.

→Check the RS-232C cable for

electrical discontinuity.

[Compatibility with the former models]

To use the RS-232C commands designed for the former models of Mitsubishi projector, by inputting “00COMMAND0”,

the projector responds in the same way as the former models. (No NAK is returned.)

(For the recommended procedure to use the former command systems, see “Controlling the projector using a

personal computer” for FL7000U.)

ITEM Function Data

Character ASCII

Changing the RS-232C command system

COMMAND

43h 4Fh 4Dh 4Dh 41h 4Eh 44h 0 (Former command system), 1 (New command system)

4. Command list

4.1 Operation commands

The operation commands are used for the basic operation setting of this projector. They may not be executed

while the signals are changed. The operation commands have no data codes. (When the commands for input

select are sent while the splash screen is being displayed, the splash screen is only canceled.)

ITEM Function Note

Character

ASCII

POWER ON

21h

This command is invalid for 1 minute after the power is turned off.

POWER OFF

22h

This command is invalid for 1 minute after the power is turned on.

INPUT COMPUTER 1

_r1

5Fh 72h 31h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT COMPUTER 2

_r2

5Fh 72h 32h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT HDMI

_d1

5Fh 64h 31h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT DVI

_d2

5Fh 64h 32h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT VIDEO

_v1

5Fh 76h 31h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT S-VIDEO

_v2

5Fh 76h 32h

This command will not be executed in Stand-by mode or when the MUTE is executed.

[Example] When setting the input signal to COMPUTER 1. (Values enclosed in quotation marks are ASCII

codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘5F’ ‘72’ ‘31’ ‘0D’

00_r1

Command for setting the input signal

to COMPUTER 1

‘30’ ‘30’ ‘5F’ ‘72’ ‘31’ ‘0D’

00_r1

Command receipt conrmation

(Command echo back)

4.2 Reading command diagram

The projectors operating status, such as POWER-ON/OFF and the currently selected input terminal, etc. can be monitored.

ITEM Character ASCII

Function Data (Receive) Function Data (Receive)

POWER ON vP 1 76h 50h 31h

POWER OFF vP 0 76h 50h 30h

INPUT COMPUTER 1 vI r1 76h 49h 72h 31h

INPUT COMPUTER 2 vI r2 76h 49h 72h 32h

INPUT HDMI vI d1 76h 49h 64h 31h

INPUT DVI vI d2 76h 49h 64h 32h

INPUT VIDEO vI v1 76h 49h 76h 31h

INPUT S-VIDEO vI v2 76h 49h 76h 32h

POWER ON/OFF IMPOSSIBLE vPK 076h 50h 4Bh 30h

POWER ON/OFF POSSIBLE vPK 176h 50h 4Bh 31h

NO SIGNAL SUPPLIED vSM 0 76h 53h 4Dh 30h

SIGNAL SUPPLIED vSM 1 76h 53h 4Dh 31h

Use the following commands to obtain the values of the items in the INFORMATION menu.

ITEM Function Data (Receive)

Character

ASCII

LAMP TIME (LOW) vLE 76h 4Ch 45h hhhhmm

RESOLUTION vRESO 76h 52h 45h 53h 4Fh HHHHxVVVV

VERTICAL FREQUENCY

vVFREQ

76h 56h 46h 52h 45h 51h ***.**

HORIZONTAL FREQUENCY

vHFREQ

76h 48h 46h 52h 45h 51h ***.**

SYNC. TYPE

vSYNCT

76h 53h 59h 4Eh 43h 54h 0 (NO SIGNAL), 1 (Invalid), 3 (3wire),

4 (4wire), 5 (5wire), 6 (SCART)

“hhhh” and “mm” represent hours and minutes respectively.

“HHHH” and “VVVV” represent the horizontal and vertical resolutions respectively.

“***.**” represents the vertical frequency (in Hz) or the horizontal frequency (in kHz).

Use the following commands to obtain other information.

ITEM Function Data (Receive)

Character

ASCII

Model name vMDL

76h 4Dh 44h 4Ch

****************(within 16 characters)

Serial number vS/N

76h 53h 2Fh 4Eh

*******(within 7 characters)

Input source vSOUCE

76h 53h 4Fh 55h 43h 45h

r1 r2 v1 v2 d1 d2

ITEM Function Data (Receive)

Character

ASCII

Projector status vST 76h 53h 54h 0 (Stand-by mode),

(Within 1 minute after POWER-ON (warm-up mode)),

2 (POWER-ON mode (including state of warning)),

3 (Cooling mode),

(Abnormal state (including shutdown due to an error)),

5 (State of functioning (menu display, dialog display,

AV MUTE, FREEZE, etc.)),

6 (Awaiting password entry)

Error status vER 76h 45h 52h Reading out error data (3 digits, hexadecimal

numbers, total 9 bits)

(MSB) xb1, xb2... xb8, xb9, 0, 0, 0 (LSB)

xb1: Fan error

xb2:

Lamp error (The lamp goes out or does not light.)

xb3: Lamp warning 1 (The lamp life has expired.)

xb4: Lamp warning 2 (The lamp life is expiring.)

xb5: Temperature error

xb6: The temperature warning is being indicated.

xb7: Fixed to 0.

xb8: Fixed to 0.

xb9: States of other component abnormality

The PC sends the command without attaching the data code to it. On the other hand, the projector attaches to

the received command its current operating status as the data code and send it back to the PC.

[Example] When checking the currently selected input terminal (when the INPUT VIDEO is being selected).

(Values enclosed in quotation marks are ASCII codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘76’ ‘49’ ‘0D’

00vl

Command for checking the input

terminal

‘30’ ‘30’ ‘76’ ‘49’ ‘76’ ‘31’ ‘0D’

00vlv1

Check result (VIDEO)

4.3 Remote commands (Not executable in stand-by mode. When the remote commands are sent while the

splash screen is being displayed, the splash screen is only canceled.)

The remote commands allow the computer to control the projector in the same way as by the remote control.

(Some operations cannot be controlled.) The remote commands have no data codes.

Button’s name on remote Function

Character

ASCII

+/VOLUME r06 72h 30h 36h

-/VOLUME r07 72h 30h 37h

ZOOM/FOCUS r0f 72h 30h 66h

LENS SHIFT r47 72h 34h 37h

KEYSTONE r43 72h 34h 33h

AV MUTE ra6 72h 61h 36h

r53 72h 35h 33h

r2b 72h 32h 62h

←r4f 72h 34h 66h

→r59 72h 35h 39h

MENU r54 72h 35h 34h

ENTER r10 72h 31h 30h

AUTO POSITION r09 72h 30h 39h

FREEZE ra4 72h 61h 34h

ASPECT re2 72h 65h 32h

CE re7 72h 65h 37h

[Example] When displaying the MENU selection bar. (Values enclosed in quotation marks are ASCII codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘72’ ‘35’ ‘34’ ‘0D’

00r54

Command operating the same as the

MENU button

‘30’ ‘30’ ‘72’ ‘35’ ‘34’ ‘0D’

00r54

Command receipt conrmation

(Command echo back)

4.4 Direct commands (Not executable in stand-by mode. Possible only to read during muting.)

The direct commands are used to numerically adjust the volume and keystone.

When the computer sends the command without adding the setting value, the projector returns the received

command with the current setting value added as a data code.

ITEM Function Data

Character ASCII

VOLUME VL 56h 4Ch 00–31

KEYSTONE (vertical) KS 4Bh 53h ±35

KEYSTONE (horizontal) KSH 4Bh 53h 48h ±25

How to set the value

Use the character or ASCII code as shown below to set the value.

Character + - 0 1 2 3 4 5 6 7 8 9

ASCII ‘2Bh’ ‘2Dh’ ‘30h’ ‘31h’ ‘32h’ ‘33h’ ‘34h’ ‘35h’ ‘36h’ ‘37h’ ‘38h’ ‘39h’

[Example] When setting the volume to 15. (Values enclosed in quotation marks are ASCII codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘56’ ‘4C’ ‘31’ ‘35’ ‘0D’

00VL15

Command for setting the volume

‘30’ ‘30’ ‘56’ ‘4C’ ‘31’ ‘35’ ‘0D’

00VL15

Command receipt conrmation

(Command echo back)

4.5 Function commands (Not executable in stand-by mode. When the mute commands are sent while the splash

screen is being displayed, the splash screen is only canceled.)

The mute commands are used for the mute setting of this projector with the 0 (HEX: 30h) and 1 (HEX: 31h).

ITEM Function Data

Character ASCII

AV MUTE MUTE 4Dh 55h 54h 45h 0 (OFF), 1 (ON)

FREEZE FRZ 46h 52h 5Ah 0 (OFF), 1 (ON)

Function canceling FNCOFF 46h 4Eh 43h 4Fh 46h 46h

4.6 Menu setting commands (Not executable in stand-by mode. Possible only to read during muting.)

The menu setting commands are used for the menu setting of this projector. If the personal computer sends the

command without attaching the data code, the projector attaches to the received command its current setting

value as the data code and send it back to the PC.

ITEM Function Data

Character ASCII

COLOR ENHANCER CE 43h 45h 0 (AUTO), 1 (PRESENTATION), 2 (STANDARD),

3 (THEATER), 4 (sRGB), 5 (USER)

COLOR ENHANCER-

USER-GAMMA MODE

CEU1GS

43h 45h 55h 31h 47h 53h 0 (DYNAMIC), 1 (NATURAL), 2 (DETAIL)

COLOR ENHANCER-

USER-BrilliantColor™

CEU1B 43h 45h 55h 31h 42h 00–10

COLOR ENHANCER-

USER-RGB-COLOR

CEU1C 43h 45h 55h 31h 43h ±10

COLOR ENHANCER-

USER-RGB-TINT

CEU1T 43h 45h 55h 31h 54h ±10

CONTRAST PP 50h 50h ±30

BRIGHTNESS QQ 51h 51h ±30

COLOR TEMP. A 41h 1 (STANDARD), 2 (HIGH), 3 (LOW), 4 (USER)

COLOR TEMP.-USER-

CONTRAST

P 50h ±30 ±30 ±30 (R, G, B)

COLOR TEMP.-USER-

BRIGHTNESS

Q51h ±30 ±30 ±30 (R, G, B)

COLOR T 54h ±10

TINT S 53h ±10

SHARPNESS R 52h ±05

NOISE REDUCTION NR 4Eh 52h 0 (OFF), 1 (ON)

CTI CTI 43h 54h 49h 0 (OFF), 1 (ON)

INPUT LEVEL IPL 49h 50h 4Ch ±5,

For DVI and HDMI input: +0 (NORMAL), +1 (ENHANCED)

ITEM Function Data

Character ASCII

LAMP MODE LM 4Ch 4Dh 0 (STANDARD), 1 (LOW)

STANDBY MODE STBY 53h 54h 42h 59h 0 (STANDARD), 1 (LOW)

AUTO POWER ON APON 41h 50h 4Fh 4Eh 0 (OFF), 1 (ON)

AUTO POWER OFF APOF 41h 50h 4Fh 46h 00 (OFF), 05, 10, 15, 30, 60

SPLASH SCREEN SS 53h 53h 0 (OFF), 1 (ON)

BACK COLOR BB 42h 42h 0 (BLACK), 1 (BLUE)

AV MUTE MODE MM 4Dh 4Dh 0 (BLACK), 1 (IMAGE)

IMAGE REVERSE IR 49h 52h 0 (OFF), 1 (MIRROR), 2 (INVERT),

3 (MIRROR INVERT)

ZOOM/FOCUS LOCK FZL 46h 5Ah 4Ch 0 (OFF), 1 (ON)

LENS SHIFT LOCK LSL 4Ch 53h 4Ch 0 (OFF), 1 (ON)

LENS SHIFT RESET LSRST 4Ch 53h 52h 53h 54h

ASPECT SC 53h 43h 0 (NORMAL (FULL)), 1 (NORMAL (16:9)),

2 (NORMAL (4:3)), 3 (16:9), 4 (REAL), 5 (FULL)

ASPECT-16:9-MODE SCM 53h 43h 4Dh 0 (ALL SIGNAL), 1 (VIDEO ONLY)

PASSWORD FUNCTION

PSLOCK

50h 53h 4Ch 4Fh 43h

4Bh

0**** (UNLOCK), 1**** (DISPLAY INPUT),

2**** (MENU ACCESS), 3**** (SPLASH ID SCREEN)

**** is a 4 to 8-digit password comprised of any gures 1 to 4.

MENU POSITION MP 4Dh 50h 0 (Upper left), 1 (Lower right)

CINEMA MODE CINE 43h 49h 4Eh 45h 0 (VIDEO), 1 (AUTO), 2 (FILM)

VIDEO SIGNAL

(VIDEO only)

VS 56h 53h 0 (AUTO), 1 (NTSC), 2 (PAL), 3 (SECAM),

4 (4.43NTSC), 5 (PAL-M), 6 (PAL-N), 7 (PAL-60)

SET UP STU 53h 54h 55h 0 (AUTO), 1 (OFF), 2 (3.75%), 3 (7.5%)

SCART INPUT SRT 53h 52h 54h 0 (OFF), 1 (ON)

LANGUAGE LG 4Ch 47h 00 ( ), 01 (English), 02 (Español), 03 (Deutsch),

04 (Français), 05 (Italiano), 06 ( ), 07 ( ),

08 ( ), 09 (PORTUGUÊS), 11 (SVENSKA),

12 (POLSKI)

RESET ALL

RSTALL

52h 53h 54h 41h 4Ch 4Ch

MEMORY CALL MMC 4Dh 4Dh 43h 0 (AUTO), 1 (MEMORY1), 2 (MEMORY2)

HORIZ.POSITION HP 48h 50h + (increment), - (decrement)*1

VERT. POSITION VP 56h 50h + (increment), - (decrement)*1

FINE SYNC. FN 46h 4Eh 00–31

TRACKING TRK 54h 52h 4Bh + (increment), - (decrement)*1

COMPUTER INPUT CIN 43h 49h 4Eh 0 (RGB), 1 (YCBCR/YPBPR), 2 (AUTO)

OVER SCAN VOS 56h 4Fh 53h 00 (90%) – 10 (100%)

HOLD HLD 48h 4Ch 44h 0 (OFF), 1 (ON)

HOLD BEGIN HLB 48h 4Ch 42h 00–99

HOLD END HLE 48h 4Ch 45h 00–99

CLAMP POSITION CLP 43h 4Ch 50h 001–255

CLAMP WIDTH CLW 43h 4Ch 57h 01–63

VERT. SYNC VSC 56h 53h 43h 0 (AUTO), 1 (OFF)

LPF LPF 4Ch 50h 46h 0 (OFF), 1 (ON)

SHUTTER(U) SHU 53h 48h 55h 00–38

SHUTTER(L) SHL 53h 48h 4Ch 00–38

SHUTTER(LS) SHLS 53h 48h 4Ch 53h 00–63

SHUTTER(RS) SHRS 53h 48h 52h 53h 00–63

*1) Setting range differs depending on the input signals.

• Some commands are not executed depending on the input signal. The operational restrictions same as those

on the menu setting are applied. Refer to “Menu operation” in the User Manual for more details.

How to set the value

Use the character or ASCII code as shown below to set the value.

Character + - 0 1 2 3 4 5 6 7 8 9

ASCII ‘2Bh’ ‘2Dh’ ‘30h’ ‘31h’ ‘32h’ ‘33h’ ‘34h’ ‘35h’ ‘36h’ ‘37h’ ‘38h’ ‘39h’

[Example 1] When setting the AUTO POWER ON to ON. (Values enclosed in quotation marks are ASCII codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘41’ ‘50’ ‘4F’ ‘4E’ ‘31’ ‘0D’

00APON1

Command for setting the AUTO

POWER ON to ON

‘30’ ‘30’ ‘41’ ‘50’ ‘4F’ ‘4E’ ‘31’ ‘0D’

00APON1

Command receipt conrmation

(Command echo back)

[Example 2] When setting the CONTRAST R of the COLOR TEMP.-USER to +10, the CONTRAST G to 0, and the

CONTRAST B to -5. (Values enclosed in quotation marks are ASCII codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘50’ ‘2B’ ‘31’ ‘30’ ‘2B’ ‘30’ ‘30’ ‘2D’ ‘30’ ‘35’ ‘0D’

00P+10+00-05

Command for setting the

picture control

‘30’ ‘30’ ‘50’ ‘2B’ ‘31’ ‘30’ ‘2B’ ‘30’ ‘30’ ‘2D’ ‘30’ ‘35’ ‘0D’

00P+10+00-05

Command receipt conrmation

(Command echo back)

[Example 3] When checking the TINT setting (when the TINT is set to +10). (Values enclosed in quotation marks

are ASCII codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘53’ ‘0D’

00S

Command for checking the

TINT setting

‘30’ ‘30’ ‘53’ ‘2B’ ‘31’ ‘30’ ‘0D’

00S+10

Check result (+10)

[Example 4] When setting the GAMMA MODE of the COLOR ENHANCER-USER to DETAIL. (Values enclosed in

quotation marks are ASCII codes.):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘43’ ‘45’ ‘55’ ‘31’ ‘47’ ‘53’ ‘32’ ‘0D’

00CEU1GS2

Command for setting the

picture control

‘30’ ‘30’ ‘43’ ‘45’ ‘55’ ‘31’ ‘47’ ‘53’ ‘32’ ‘0D’

00CEU1GS2

Command receipt conrmation

(Command echo back)

4.7 Password lock commands

The password lock commands control the password lock. The password lock enabling or disabling command is

sent with a 4 to 8-digit password comprised of any gures 1 to 4 added to the end of the data code. When the

password lock is enabled or disabled successfully, the projector sends a return command comprising the data

code, password, and “1” at the end. When enabling or disabling the password lock fails, it sends a return com-

mand with “0” at the end. There is no reconrmation of the password. The password input command is for en-

abling projection of image when password lock has been set to DISPLAY INPUT. The password input command

is sent with a 4 to 8-digit password comprised of any gures 1 to 4 at the end.

ITEM Function Data

Character ASCII

Password lock enabling/

disabling

PSLOCK 50h 53h 4Ch 4Fh 43h 4Bh 0**** (Disabling), 1**** (DISPLAY INPUT),

2**** (MENU ACCESS), 3**** (SPLASH ID SCREEN)

Password input PASS 50h 41h 53h 53h ****

**** is a 4 to 8-digit password comprised of any gures 1 to 4.

[Example] When enabling the password lock of DISPLAY INPUT (in the case that the password is 123412):

Command sent from the PC, etc. Status code returned

from the projector Description

‘30’ ‘30’ ‘50’ ‘53’ ‘4C’ ‘4F’ ‘43’ ‘4B’ ‘31’ ‘31’ ‘32’ ‘33’ ‘34’ ‘31’ ‘32’ ‘0D’

00PSLOCK1123412

Command for enabling the

password lock of DISPLAY INPUT

‘30’ ‘30’ ‘50’ ‘53’ ‘4C’ ‘4F’ ‘43’ ‘4B’ ‘31’ ‘31’ ‘32’ ‘33’ ‘34’ ‘31’ ‘32’ ‘31’ ‘0D’

00PSLOCK11234121

Response informing that the

projector succeeded in enabling the

password lock of DISPLAY INPUT

Autres manuels pour WD3300U

Table des matières

Autres manuels Mitsubishi Projecteur

Mitsubishi

Mitsubishi EX200U Manuel utilisateur

Mitsubishi

Mitsubishi S250 Manuel utilisateur

Mitsubishi

Mitsubishi XD250U-ST Manuel utilisateur

Mitsubishi

Mitsubishi EX240U Manuel utilisateur

Mitsubishi

Mitsubishi ColorView SL1U Manuel utilisateur

Mitsubishi

Mitsubishi LVP-X200A Manuel utilisateur

Mitsubishi

Mitsubishi VS-50FD10U Manuel utilisateur

Mitsubishi

Mitsubishi LVP-X300U Manuel utilisateur

Mitsubishi

Mitsubishi SA51 Manuel utilisateur

Mitsubishi

Mitsubishi X300 Manuel utilisateur

Mitsubishi

Mitsubishi SD105U Manuel utilisateur

Mitsubishi

Mitsubishi DLP EX320U-ST Manuel utilisateur

Mitsubishi

Mitsubishi HC2000 Manuel utilisateur

Mitsubishi

Mitsubishi XD3500U Manuel utilisateur

Mitsubishi

Mitsubishi LVP-X30U Manuel utilisateur

Mitsubishi

Mitsubishi X250 Manuel utilisateur

Mitsubishi

Mitsubishi WD380U-EST Manuel d'utilisation et d'entretien

Mitsubishi

Mitsubishi HD8000 Manuel d'utilisation et d'entretien

Mitsubishi

Mitsubishi DLP XD1000U Manuel utilisateur

Mitsubishi

Mitsubishi SL4SU Manuel utilisateur

Mitsubishi

Mitsubishi ColorView S490U Manuel utilisateur

Mitsubishi

Mitsubishi XL5900U Manuel utilisateur

Mitsubishi

Mitsubishi VS-1281 Manuel utilisateur

Mitsubishi

Mitsubishi HD4000U Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
