Mitsubishi Electric WL6700LU Manuel

LCD Projector

WL6700U/WL6700LU

Controlling the projector using a personal computer

This projector can be controlled by connecting a personal computer with RS-232C terminal.

PC-controllable functions:

• Turning the power ON or OFF

• Changing input signals

• Inputting commands by pressing the buttons on the control panel and remote control

• Menu setting

Connection

RS-232C cable SERIAL

D-SUB 9-pin D-SUB 9-pin

To RS-232C

terminal

Important:

• Connect the computer with the projector on a one-to-one basis.

• Make sure that your computer and projector are turned off before connection.

• Boot up the computer ﬁrst, and then plug the power cord of the projector.

(If you do not follow this instruction, the Com port may not function.)

• Adapters may be necessary depending on the PC connected to this projector. Contact your dealer for details.

1. Interface

1.1 Pin assignment of SERIAL terminal (D-SUB 9-pin)

Pin No. Name I/O

1 OPEN

2 RXD IN

3 TXD OUT

4 OPEN

5 GND

6 OPEN

7 OPEN

8 OPEN

9 OPEN

1.2 Communications format

PROTOCOL RS-232C

BAUD RATE 9600 [bps]

DATA LENGTH 8 [bits]

PARITY BIT NONE

STOP BIT 1 [bit]

FLOW CONTROL NONE

This projector uses RXD, TXD and GND lines for RS-232C control.

For RS-232C cable, the reverse type cable should be used.

2. Control command diagram

The command consists of the address code, function code, data code, and end code. The length of the command

varies among the functions.

Address code Function code Data code End code

ASCII ‘30h’ 30h’ Function Data ‘0Dh’

Character 00 Function Data

[Address code] 00 (In ASCII code, ‘30h’ ‘30h’) ﬁxed.

[Function code] A code of each ﬁxed control move.

[Data code] A code of each ﬁxed control data (number) and not always indicated.

[End code] (In ASCII code, ‘0Dh’) ﬁxed.

3. Control sequence

Computer Projecto

Sequence Note

1Send the command from the

personal computer to the projector.

The projector will send a return

command after it receives an end

code.

If the projector does not receive commands

normally, that is, if the projector is not connected

physically or unable to receive commands, it does

not send out a return command.

The projector sends out a return command within

one second at the latest.

3The personal computer checks the

command and conﬁrms if the sent

command has been received or not.

Although the projector receives the commands, it

in some cases does not execute the commands.

Use the check command to see

if the projector has executed the

command.

This projector sends various codes other than the

return code. When having a control sequence by

RS-232C, reject other codes from the personal

computer.

• Although the projector sends out the return command, the command may not take effect in the following

cases.

(1) During signal switching

(2) In the process of the auto position

(3) After the power is turned on.

The projector receives no commands for about 20 seconds (or for 2 minutes at the longest if the lamp

does not light up promptly as the life is expiring.)

• When sending commands successively, wait to receive the return command of the current command before

sending a next command.

• The projector may not receive a command when the splash screen is being displayed immediately after turn-

ing on the power. Use command “00r10” to cancel the splash screen.

• While using the LAN terminals, the LAN functions take precedence.

• For the LAN terminals, the same commands as those for connecting with the TCP/IP (port number 63007) are

available. Note, however, that the response becomes slightly slower than when using the RS-232C terminals.

[Example] When turning the power ON. (Figures and symbols enclosed in quotation marks are ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘21’ ‘0D’

00!

Command for POWER ON

‘30’ ‘30’ ‘21’ ‘0D’

00!

Command receipt conﬁrmation

(Command echo back)

• The ﬂowchart on the next page shows the recommended operating sequence for your reference to create a

program.

Sending out command

Awaiting response

from projector

Awaiting response

from projector

Checking execution of

command (sending out

check command)

Sending command again

YesYes

Yes

10th trial

Less than

10 times

Projector error

Send out “00vER” to check error details.

Recover from error state.

0–3

To normal operation 4

Enter password.

Send out “00PASS****.”

Projector is functioning.

Use “00FNCOFF” to cancel the current function.

6 5

END

No response for

1 second or longer

No response for

1 second or longer

Sending command again

Number of trials

without response

Sending “00vST”

Checking response to “00vST”

[RS-232C control flowchart]

[Method of checking state of projector]

START

Check the following.

• The projector is not supplied with AC power.

→ Check that AC power cord is connected.

→ Turn on the power. (Turn on the circuit breaker or

main switch.)

• Not connected with the projector.

→ Check that the RS-232C cable is connected.

→ Check the RS-232C cable for electrical discontinuity.

• The projector is in the state of being unable to send out

a command.

→ Use command “00vST” to check if the projector

operates normally.

Note: In the following conditions, the projector

does not respond even if it operates

normally.

• Immediately after turning on the power

(for about 20 seconds to 2 minutes)

• During switching signals (about 10

seconds)

• In the process of the auto position

(about 10 seconds)

• During locking the password

4. Command list

4.1 Operation commands (Not executable in stand-by mode. When the commands for input select are sent

while the splash screen is being displayed, the splash screen is only canceled.)

The operation commands are used for the basic operation setting of this projector. They may not be executed

while the signals are changed. The operation commands have no data codes.

ITEM Function Note

Character

ASCII

POWER ON

21h

This command is invalid for 1 minute after the power is turned off.

POWER OFF

22h

This command is invalid for 1 minute after the power is turned on.

INPUT COMPUTER 1

_r1

5Fh 72h 31h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT COMPUTER 2

_r2

5Fh 72h 32h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT DVI

_d1

5Fh 64h 31h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT VIDEO

_v1

5Fh 76h 31h

This command will not be executed in Stand-by mode or when the MUTE is executed.

INPUT S-VIDEO

_v2

5Fh 76h 32h

This command will not be executed in Stand-by mode or when the MUTE is executed.

[Example] When setting the input signal to COMPUTER 1. (Figures and symbols enclosed in quotation marks

are ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘5F’ ‘72’ ‘31’ ‘0D’

00_r1

Command for setting the input signal

to COMPUTER 1

‘30’ ‘30’ ‘5F’ ‘72’ ‘31’ ‘0D’

00_r1

Command receipt conﬁrmation

(Command echo back)

4.2 Reading command diagram

The projectors operating status, such as POWER-ON/OFF and the currently selected input terminal, etc. can be

monitored.

ITEM Character ASCII

Function Data (Receive) Function Data (Receive)

POWER ON vP 1 76h 50h 31h

POWER OFF vP 0 76h 50h 30h

INPUT COMPUTER 1 vI r1 76h 49h 72h 31h

INPUT COMPUTER 2 vI r2 76h 49h 72h 32h

INPUT DVI vI d1 76h 49h 64h 31h

INPUT VIDEO vI v1 76h 49h 76h 31h

INPUT S-VIDEO vI v2 76h 49h 76h 32h

POWER ON/OFF IMPOSSIBLE vPK 0 76h 50h 4Bh 30h

POWER ON/OFF POSSIBLE vPK 1 76h 50h 4Bh 31h

NO SIGNAL SUPPLIED vSM 0 76h 53h 4Dh 30h

SIGNAL SUPPLIED vSM 1 76h 53h 4Dh 31h

Use the following commands to obtain the values of the items in the INFORMATION menu.

ITEM Function Data (Receive)

Character

ASCII

LAMP TIME (LOW) vLE 76h 4Ch 45h hhhhmm

RESOLUTION vRESO 76h 52h 45h 53h 4Fh HHHHxVVVV

VERTICAL FREQUENCY

vVFREQ

76h 56h 46h 52h 45h 51h ***.**

HORIZONTAL FREQUENCY

vHFREQ

76h 48h 46h 52h 45h 51h ***.**

SYNC. TYPE

vSYNCT

76h 53h 59h 4Eh 43h 54h 0 (NO SIGNAL), 3 (3wire), 4 (4wire),

5 (5wire), 6 (SCART)

“hhhh” and “mm” represent hours and minutes respectively.

“HHHH” and “VVVV” represent the horizontal and vertical resolutions respectively.

Use the following commands to obtain other information.

ITEM Function Data (Receive)

Character

ASCII

Model name vMDL

76h 4Dh 44h 4Ch

****************(within 16 characters)

Serial number vS/N

76h 53h 2Fh 4Eh

*******(within 7 characters)

Input source vSOUCE

76h 53h 4Fh 55h 43h 45h

r1 r2 d1 v1 v2

ITEM Function Data (Receive)

Character

ASCII

Projector status vST 76h 53h 54h 0 (Stand-by mode),

(Within 1 minute after POWER-ON (warm-up mode)),

2 (POWER-ON mode (including state of warning)),

3 (Cooling mode),

(Abnormal state (including shutdown due to an error)),

5 (State of functioning (menu display, dialog display,

MUTE, SPLIT, FREEZE)),

6 (Awaiting password entry)

Error status vER 76h 45h 52h Reading out error data (3 digits, hexadecimal

numbers, total 9 bits)

(MSB) xb1, xb2... xb8, xb9, 0, 0, 0 (LSB)

xb1: Fan error

xb2:

Lamp error (The lamp goes out or does not light.)

xb3: Lamp warning 1 (The lamp life has expired.)

xb4: Lamp warning 2 (The lamp life is expiring.)

xb5: Temperature error

xb6: The temperature warning is being indicated.

xb7: Lamp cover open error

xb8: Filter cover open error

xb9: States of other component abnormality

The PC sends the command without attaching the data code to it. On the other hand, the projector attaches to

the received command its current operating status as the data code and send it back to the PC.

[Example] When checking the currently selected input terminal (when the INPUT VIDEO is being selected).

(Figures and symbols enclosed in quotation marks are ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘76’ ‘49’ ‘0D’

00vl

Command for checking the input

terminal

‘30’ ‘30’ ‘76’ ‘49’ ‘76’ ‘31’ ‘0D’

00vlv1

Check result (VIDEO)

4.3 Remote commands (Not executable in stand-by mode. When the remote commands are sent while the

splash screen is being displayed, the splash screen is only canceled.)

Some remote control operations can be achieved by the remote command codes. The remote commands have

no data codes.

Button’s name on remote Function

Character

ASCII

+/VOLUME r06 72h 30h 36h

-/VOLUME r07 72h 30h 37h

ZOOM/FOCUS r0f 72h 30h 66h

LENS SHIFT r47 72h 34h 37h

KEYSTONE r43 72h 34h 33h

MAGNIFY r02 72h 30h 32h

SPLIT r04 72h 30h 34h

AV MUTE ra6 72h 61h 36h

r53 72h 35h 33h

r2b 72h 32h 62h

r4f 72h 34h 66h

r59 72h 35h 39h

MENU r54 72h 35h 34h

ENTER r10 72h 31h 30h

AUTO POSITION r09 72h 30h 39h

FREEZE ra4 72h 61h 34h

ASPECT re2 72h 65h 32h

CE re7 72h 65h 37h

[Example] When displaying the MENU selection bar. (Figures and symbols enclosed in quotation marks are

ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘72’ ‘35’ ‘34’ ‘0D’

00r54

Command operating the same as the

MENU button

‘30’ ‘30’ ‘72’ ‘35’ ‘34’ ‘0D’

00r54

Command receipt conﬁrmation

(Command echo back)

4.4 Direct commands (Not executable in stand-by mode. Possible only to read during muting.)

The direct commands are used for the keystone setting of this projector with the value.

ITEM Function Data

Character ASCII

VOLUME VL 56h 4Ch 00–31

KEYSTONE (vertical) KS 4Bh 53h ±35

KEYSTONE (horizontal) KSH 4Bh 53h 48h ±25

How to set the value

Use the character or ASCII code as shown below to set the value.

Character + - 0 1 2 3 4 5 6 7 8 9

ASCII ‘2Bh’ ‘2Dh’ ‘30h’ ‘31h’ ‘32h’ ‘33h’ ‘34h’ ‘35h’ ‘36h’ ‘37h’ ‘38h’ ‘39h’

[Example] When setting the volume to 15. (Figures and symbols enclosed in quotation marks are ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘56’ ‘4C’ ‘31’ ‘35’ ‘0D’

00VL15

Command for setting the volume

‘30’ ‘30’ ‘56’ ‘4C’ ‘31’ ‘35’ ‘0D’

00VL15

Command receipt conﬁrmation

(Command echo back)

4.5 Function commands (Not executable in stand-by mode. When the mute commands are sent while the splash

screen is being displayed, the splash screen is not muted but only canceled.)

The mute commands are used for the mute setting of this projector with the 0 (30h) and 1 (31h).

ITEM Function Data

Character ASCII

AV MUTE MUTE 4Dh 55h 54h 45h 0 (OFF), 1 (ON)

SPLIT SPLT 53h 50h 4Ch 54h 0 (OFF), 1 (ON)

MAGNIFY MGNFY 4Dh 47h 4Eh 46h 59h 0 (OFF), 1 (ON)

FREEZE FRZ 46h 52h 5Ah 0 (OFF), 1 (ON)

Function canceling FNCOFF 46h 4Eh 43h 4Fh 46h 46h

4.6 Menu setting commands (Not executable in stand-by mode. Possible only to read during muting.)

The menu setting commands are used for the menu setting of this projector. If the personal computer sends the

command without attaching the data code, the projector attaches to the received command its current setting

value as the data code and send it back to the PC.

ITEM Function Data

Character ASCII

COLOR ENHANCER CE 43h 45h 0 (AUTO), 1 (PRESENTATION), 2 (STANDARD),

3 (THEATER), 4 (sRGB), 5 (USER)

COLOR ENHANCER-

USER-GAMMA MODE

CEU1GS

43h 45h 55h 31h 47h 53h 0 (DYNAMIC), 1 (NATURAL), 2 (DETAIL)

COLOR ENHANCER-

USER-RGB-COLOR

CEU1C 43h 45h 55h 31h 43h ±10

COLOR ENHANCER-

USER-RGB-TINT

CEU1T 43h 45h 55h 31h 54h ±10

CONTRAST PP 50h 50h ±30

BRIGHTNESS QQ 51h 51h ±30

COLOR TEMP. A 41h 1 (STANDARD), 2 (HIGH), 3 (LOW), 4 (USER)

COLOR TEMP.-USER

(CONTRAST)

P 50h ±30 ±30 ±30 (R, G, B)

ITEM Function Data

Character ASCII

COLOR TEMP.-USER

(BRIGHTNESS)

Q 51h ±30 ±30 ±30 (R, G, B)

COLOR T 54h ±10

TINT S 53h ±10

SHARPNESS R 52h ±5

NOISE REDUCTION NR 4Eh 52h 0 (OFF), 1 (ON)

CTI CTI 43h 54h 49h 0 (OFF), 1 (ON)

INPUT LEVEL IPL 49h 50h 4Ch ±5,

For DVI input: +0 (NORMAL), +1 (ENHANCED)

LAMP MODE LM 4Ch 4Dh 0 (STANDARD), 1 (LOW)

AUTO POWER ON APON 41h 50h 4Fh 4Eh 0 (OFF), 1 (ON)

AUTO POWER OFF APOF 41h 50h 4Fh 46h 00 (OFF), 05, 10, 15, 30, 60

SPLASH SCREEN SS 53h 53h 0 (OFF), 1 (ON)

BACK COLOR BB 42h 42h 0 (BLACK), 1 (BLUE), 2 (IMAGE)

MUTE MODE MM 4Dh 4Dh 0 (BLACK), 1 (IMAGE)

IMAGE REVERSE IR 49h 52h 0 (OFF), 1 (MIRROR), 2 (INVERT),

3 (MIRROR INVERT)

ZOOM/FOCUS LOCK FZL 46h 5Ah 4Ch 0 (OFF), 1 (ON)

LENS SHIFT LOCK LSL 4Ch 53h 4Ch 0 (OFF), 1 (ON)

LENS SHIFT RESET LSRST 4Ch 53h 52h 53h 54h

ASPECT SC 53h 43h 0 (AUTO (FULL)), 1 (AUTO (16:10)), 2 (AUTO (16:9)),

3 (AUTO (4:3)), 4 (16:9), 5 (REAL), 6 (FULL)

PASSWORD FUNCTION

PSLOCK

50h 53h 4Ch 4Fh 43h

4Bh

0**** (UNLOCK), 1**** (DISPLAY INPUT),

2**** (MENU ACCESS), 3**** (SPLASH ID SCREEN)

**** is a 4 to 8-digit password comprised of any

ﬁgures 1 to 4.

MENU POSITION MP 4Dh 50h 0 (Upper left), 1 (Lower right)

CINEMA MODE CINE 43h 49h 4Eh 45h 0 (VIDEO), 1 (AUTO), 2 (FILM)

VIDEO SIGNAL

(VIDEO only)

VS 56h 53h 0 (AUTO), 1 (NTSC), 2 (PAL), 3 (SECAM),

4 (4.43NTSC), 5 (PAL-M), 6 (PAL-N), 7 (PAL-60)

SET UP STU 53h 54h 55h 0 (AUTO), 1 (OFF), 2 (3.75%), 3 (7.5%)

SCART INPUT SRT 53h 52h 54h 0 (OFF), 1 (ON)

LANGUAGE LG 4Ch 47h 00 ( ), 01 (English), 02 (Español), 03 (Deutsch),

04 (Français), 05 (Italiano), 06 ( ), 07 ( ),

08 ( ), 09 (PORTUGUÊS), 11 (SVENSKA),

12 (POLSKI)

RESET ALL

RSTALL

52h 53h 54h 41h 4Ch 4Ch

MEMORY CALL MMC 4Dh 4Dh 43h 0 (AUTO), 1 (MEMORY1), 2 (MEMORY2)

HORIZ.POSITION HP 48h 50h + (increment), - (decrement)*1

VERT. POSITION VP 56h 50h + (increment), - (decrement)*1

FINE SYNC. FN 46h 4Eh 00–31

TRACKING TRK 54h 52h 4Bh + (increment), - (decrement)*1

COMPUTER INPUT CIN 43h 49h 4Eh 0 (RGB), 1 (YCBCR/YPBPR), 2 (AUTO)

OVER SCAN VOS 56h 4Fh 53h 00 (90%) – 10 (100%)

HOLD HLD 48h 4Ch 44h 0 (OFF), 1 (ON)

HOLD BEGIN HLB 48h 4Ch 42h 00–99

HOLD END HLE 48h 4Ch 45h 00–99

CLAMP POSITION CLP 43h 4Ch 50h 001–255

CLAMP WIDTH CLW 43h 4Ch 57h 01–63

VERT. SYNC VSC 56h 53h 43h 0 (AUTO), 1 (OFF)

LPF LPF 4Ch 50h 46h 0 (OFF), 1 (ON)

SHUTTER(U) SHU 53h 48h 55h 00–20

SHUTTER(L) SHL 53h 48h 4Ch 00–20

SHUTTER(LS) SHLS 53h 48h 4Ch 53h 00–20

SHUTTER(RS) SHRS 53h 48h 52h 53h 00–20

*1) Setting range differs depending on the input signals.

• Some commands are not executed depending on the input signal. The operational restrictions same as those

on the menu setting are applied. Refer to “Menu operation” in the User Manual for more details.

How to set the value

Use the character or ASCII code as shown below to set the value.

Character + - 0 1 2 3 4 5 6 7 8 9

ASCII ‘2Bh’ ‘2Dh’ ‘30h’ ‘31h’ ‘32h’ ‘33h’ ‘34h’ ‘35h’ ‘36h’ ‘37h’ ‘38h’ ‘39h’

[Example 1] When setting the AUTO POWER ON to ON. (Figures and symbols enclosed in quotation marks are

ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘41’ ‘50’ ‘4F’ ‘4E’ ‘31’ ‘0D’

00APON1

Command for setting the AUTO

POWER ON to ON

‘30’ ‘30’ ‘41’ ‘50’ ‘4F’ ‘4E’ ‘31’ ‘0D’

00APON1

Command receipt conﬁrmation

(Command echo back)

[Example 2] When setting the CONTRAST R of the COLOR TEMP.-USER to +10, the CONTRAST G to 0, and the

CONTRAST B to -5. (Figures and symbols enclosed in quotation marks are ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘50’ ‘2B’ ‘31’ ‘30’ ‘2B’ ‘30’ ‘30’ ‘2D’ ‘30’ ‘35’ ‘0D’

00P+10+00-05

Command for setting the

picture control

‘30’ ‘30’ ‘50’ ‘2B’ ‘31’ ‘30’ ‘2B’ ‘30’ ‘30’ ‘2D’ ‘30’ ‘35’ ‘0D’

00P+10+00-05

Command receipt conﬁrmation

(Command echo back)

[Example 3] When checking the TINT setting (when the TINT is set to +10). (Figures and symbols enclosed in

quotation marks are ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘53’ ‘0D’

00S

Command for checking the

TINT setting

‘30’ ‘30’ ‘53’ ‘2B’ ‘31’ ‘30’ ‘0D’

00S+10

Check result (+10)

[Example 4] When setting the GAMMA MODE of the COLOR ENHANCER-USER to DETAIL. (Figures and sym-

bols enclosed in quotation marks are ASCII codes.):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘43’ ‘45’ ‘55’ ‘31’ ‘47’ ‘53’ ‘32’ ‘0D’

00CEU1GS2

Command for setting the

picture control

‘30’ ‘30’ ‘43’ ‘45’ ‘55’ ‘31’ ‘47’ ‘53’ ‘32’ ‘0D’

00CEU1GS2

Command receipt conﬁrmation

(Command echo back)

4.7 Password lock commands

The password lock commands control the password lock. The password lock enabling or disabling command is

sent with a 4 to 8-digit password comprised of any ﬁgures 1 to 4 added to the end of the data code. When the

password lock is enabled or disabled successfully, the projector sends a return command comprising the data

code, password, and “1” at the end. When enabling or disabling the password lock fails, it sends a return com-

mand with “0” at the end. There is no reconﬁrmation of the password. The password input command is for en-

abling projection of image when password lock has been set to DISPLAY INPUT. The password input command

is sent with a 4 to 8-digit password comprised of any ﬁgures 1 to 4 at the end.

ITEM Function Data

Character ASCII

Password lock enabling/

disabling

PSLOCK 50h 53h 4Ch 4Fh 43h 4Bh 0**** (Disabling), 1**** (DISPLAY INPUT),

2**** (MENU ACCESS), 3**** (SPLASH ID SCREEN)

Password input PASS 50h 41h 53h 53h ****

**** is a 4 to 8-digit password comprised of any ﬁgures 1 to 4.

[Example] When enabling the password lock of DISPLAY INPUT (in the case that the password is 123412):

Sending commands

from the PC, etc.

Status code

from the projector Description

‘30’ ‘30’ ‘50’ ‘53’ ‘4C’ ‘4F’ ‘43’ ‘4B’ ‘31’ ‘31’ ‘32’ ‘33’ ‘34’ ‘31’ ‘32’ ‘0D’

00PSLOCK1123412

Command for enabling the

password lock of DISPLAY INPUT

‘30’ ‘30’ ‘50’ ‘53’ ‘4C’ ‘4F’ ‘43’ ‘4B’ ‘31’ ‘31’ ‘32’ ‘33’ ‘34’ ‘31’ ‘32’ ‘31’ ‘0D’

00PSLOCK11234121

Response informing that the

projector succeeded in enabling the

password lock of DISPLAY INPUT

Autres manuels pour WL6700LU

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Mitsubishi Electric Projecteur

Mitsubishi Electric

Mitsubishi Electric HC6000 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric UD8900U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric TX20U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric DLP WD570U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric XD211U Manuel

Mitsubishi Electric

Mitsubishi Electric XD80 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric HC4900 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric XD400U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric UL7400U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric HC1500 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric WD510U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric XD520U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric HL650U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric DLP XD460U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric HC8000D Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric DLP HC900 Manuel du propriétaire

Mitsubishi Electric

Mitsubishi Electric DLP NW30U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric HC6500 Manuel d'utilisation et d'entretien

Mitsubishi Electric

Mitsubishi Electric WD2000U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric XD221U-G Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric WD500U-ST Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric XD206U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric WD390U-EST Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric HC3000U Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
