Mitsubishi Electric XD221U-G Manuel utilisateur

MULTIMEDIA DATA/VIDEO PROJECTORS

The XD221U-G’s high-volume 10W speaker

eliminates the need for an external speaker.

By using the “Audio Mix” feature and a wireless

microphone (not included), the presenter’s

voice is amplified loud and clear every time.

10W Speaker + Audio Mix Closed Caption (CC) Capable Additional Features

Advanced Features Make Teaching Easier Than Ever

Easy Maintenance and High Value Performance

Environmentally Friendly

In order to lessen our impact on natural resources,

Mitsubishi has engineered specific eco-friendly

features including:

With the touch of a button, the built-in closed

caption decoder transforms words into

subtitles that are then

projected onto the

screen; a convenient

function that

addresses the needs

of language students

and hearing-

impaired viewers.

Excellent Sound Projection

1. Built-in RJ-45 Port

All-in-one Web-based Management of Multiple Projectors

When connected to a dedicated LAN, you can view the status of multiple projectors in the same building.

Remote operation of power (on/off) switch, source inputs and other functions are all accessible.

2. Top-loading Lamp

Simple Lamp Replacement

The projection lamp is installed in the upper section of the chassis.

Whether sitting on a shelf or suspended from the ceiling, lamp replacement

is simple and easy, and there’s never any need to move the projector.

An overall low operating cost is achieved by utilizing DLP’s filter-free technology, a long estimated

lamp life of 4000 hours, and a low power standby mode of less than 1W. Maintenance frequency

and related costs are also reduced.

3. Low Operating Cost

Simple and Automatic Subtitles Designed for ease of use

THESE FLOWERS ARE SEEN

IN THE SPRING.

XD221U-G

Portable XGA

NEW

User-friendly, Viewer-friendly...

Teaching Doesn’t Get Much Easier

• Quick, Easy Menu

For improved ease of use, the tool bar has seven

basic main menu options and one custom menu.

Menu selection is so simple & easy, even

non-technical users can easily understand.

• Dual PC Input Terminals

Two computers can be connected simultaneously.

No need to unplug one PC to hook up another.

• Low Standby Power

When in Standby mode, the XD221U-G

consumes less than 1Watt of power

• Recycled Paper

The carton, and all paper materials

within are made from recycled paper

• Eco-friendly design

The paint-free cabinet design and use of lead-free

solder further minimizes impact on the environment

• BrilliantColorTM Technology

Clear, vivid images are reproduced from the

computer as well as full-motion videos.

The perfect projector for educational presentations

Projector

What’s

this?

What’s

this?

GREENER TECHNOLOGY

MOBILE XGA PROJECTOR

Screen size and Projection distance

As seen from the side

XD221U

Height

Projection Distance (L)

XD221U-G

0.55" 1-Chip DMD, DDP2230

1024 x 768 (Total 786,432 pixels) [4:3]

2300lm

2000 : 1

40" - 300"

1.76 - 2.15

Model

Display Technology

Resolution

Brightness

Contrast Ratio

Picture Size

Throw Ratio

f=19.9~23.9 mm, F=2.5-2.7Projection lens

7.9:-1Offset axis

Specifications

* Compliance with ISO21118-2005

** All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.

PC Compatibility Compressed: 1280 x 1024, Minimum: 640 x 480

Native: 1024 x 768, Sync on Green available

NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM / PAL-60

Component Video: 480i/p (525i/p), 576i/p (625i/p),

720p (750p), 1080i (1125i 60Hz), 1080i (1125i 50Hz)

Video Compatibility

160W (Shut-off Time 4000hr) with Low Mode,

180W (Shut-off Time 3000hr) with Standard Mode

Est. Lamp Life Rating

RGB: mini D-sub 15pin x 2

RCA x 1 + S-VIDEO x 1

Audio: Stereo mini jack (ø3.5mm) x 2 (One for PC, one for video)

RGB: mini D-sub 15pin x 1

Audio: Stereo mini jack (ø3.5mm) x 1 (variable)

Input Terminals

Output Terminals

Communication Terminal

Audio Speaker

Dimensions (W x H x D)

Weight

Power Requirements

Optional Lamp

Optional Accessories

Warranty

RS-232C: mini DIN 8pin x 1, LAN (RJ-45) x 1 (Projector control)

10W Mono

320 x 104 x 236 mm / 12.6 x 4.1 x 9.3 inch

7.0lbs / 3.2kg

AC 100-240V, 50/60Hz

Ceiling mount (PROJ-UCM-PRO2), Hard shell case (DKT1-ATAC)

VLT-XD221LP

3-Years of Parts/Labor, 3-Years of Express Replacement Assistance

(ERA),1-year or 500 hours lamp warranty (whichever comes first)

Screen

Diagonal Size Width (W)Max. Zoom Min. Zoom

Height (H)

inch

120

150

180

Distance from screen (L) Height projected

image (Hd)

inch

100

150

200

250

300

102

152

203

254

381

508

635

762

inch

120

160

200

240

122

163

203

305

406

508

610

122

152

229

305

381

457

inch

112

141

212

283

354

425

1.4

2.1

2.8

3.6

5.4

7.2

9.0

10.8

inch

103

137

172

259

345

432

1.7

2.6

3.5

4.4

6.6

8.8

11.0

inch

3.6

5.4

7.2

9.0

13.4

17.9

22.4

26.9

Screen size chart (4:3 aspect ratio)

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen

Diagonal Size Width (W)Max. Zoom Min. Zoom

Height (H)

inch

123

147

Distance from screen (L) Height projected

image (Hd)

inch

100

150

200

250

300

102

152

203

254

381

508

635

762

inch

131

174

218

261

133

177

221

332

443

553

664

100

125

187

249

311

374

inch

122

153

231

308

386

463

1.5

2.3

3.1

3.9

5.9

7.8

9.8

11.8

inch

112

149

187

282

376

471

1.9

2.8

3.8

4.8

7.2

9.6

12.0

inch

7.2

10.8

14.3

17.9

26.9

35.9

44.8

53.8

114

137

Screen size chart (16:9 aspect ratio)

The above numbers are approximate, and may be slightly different from the actual measurements.

320

236

116 116

34.5

45.4

113.9135.5

213

14.3

30.6

214

64.5

60.2

Top View Bottom View

Front View Side View

Unit:mm

Input and Output Terminals

Audio output

Audio input

S-Video/Video

Monitor output

PC/Component

Video input

Serial RS-232C

LAN (RJ-45)

Brilliant

ColorTM Color

Enhancer Gamma

Mode Cinema

Mode

10W

Speaker Dual VGA

Inputs

Audio

Mix Freeze

Function

Closed

Caption LAN

(RJ-45) Digital

Keystone Lamp

Mode

Instant

Shutdown

Ceiling

Mounted

Automatic

Power on Automatic

Power off

Auto

Distinguish

Source

Quick

Top

Lamp

Low

Standby

Power

2/09 - LITXD221U New publication, effective April 2009.

Specifications subject to change without notice.

MITSUBISHI DIGITAL ELECTRONICS

AMERICA, INC.

Presentation Products Division

Phone: 888.307.0349

www.mitsubishi-presentations.com

MITSUBISHI ELECTRIC SALES

CANADA, INC.

Display & Imaging Solutions Division

Phone: 905.475.7728

www.mitsubishielectric.ca

1 2 3 7654
